Smeg ALFA31XE Instructions For Installation And Use Manual

Smeg ALFA31XE Instructions For Installation And Use Manual

Smeg oven instructions for installation and use
Hide thumbs

Advertisement

Quick Links

Download this manual
1.
2.
INSTALLATION OF THE OVEN_____________________________ 21
3.
DESCRIPTION OF CONTROLS ____________________________ 23
4.
USE OF THE OVEN ______________________________________ 24
5.
CLEANING AND MAINTENANCE ___________________________ 29
6.
REACTIVE MAINTENANCE________________________________ 31
INSTRUCTIONS FOR THE INSTALLER: these are intended for the
qualified
commissioning it and making a final test.
INSTRUCTIONS FOR THE USER: these contain advice for the user,
description of the commands and the correct procedures for cleaning
and maintenance of the appliance.
18
Contents
technician
charged
with
installing
the
appliance,

Advertisement

loading

Related Manuals for Smeg ALFA31XE

Summary of Contents for Smeg ALFA31XE

  • Page 1: Table Of Contents

    INSTRUCTIONS FOR SAFE AND PROPER USE_______________ 19 INSTALLATION OF THE OVEN_____________________________ 21 DESCRIPTION OF CONTROLS ____________________________ 23 USE OF THE OVEN ______________________________________ 24 CLEANING AND MAINTENANCE ___________________________ 29 REACTIVE MAINTENANCE________________________________ 31 INSTRUCTIONS FOR THE INSTALLER: these are intended for the...

  • Page 2: Instructions For Safe And Proper Use

    THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE OVEN. WE ADVISE READING THIS MANUAL AND ALL THE INSTRUCTIONS HEREIN...
  • Page 3 BEFORE USE, THE OVEN DISHES MUST BE WASHED WITH A SUITABLE DISHWASHING DETERGENT (DO NOT USE ABRASIVE PRODUCTS). THE OVEN IS SIZED FOR A MAXIMUM LOAD OF 3.5 KG. THIS APPLIANCE IS MARKED ACCORDING TO THE EUROPEAN DIRECTIVE 2002/96/EC ON WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE).

  • Page 4: Installation Of The Oven

    Instructions for the installer 2. INSTALLATION OF THE OVEN The oven must be set up on a perfectly flat surface and left standing free. Make sure to allow enough room at the back for easy access to the terminal block for connection of the power cable to the mains.
  • Page 5 Instructions for the installer Levelling Adjust the four feet so as to level the oven. To do this, loosen the lock nut and unscrew the foot. The range of adjustment of the screw is 10 2.3 Steam exhaust pipe An exhaust pipe is fitted on the back of the oven to allow the discharge of steam during cooking.

  • Page 6: Description Of Controls

    Instructions for the user 3. DESCRIPTION OF CONTROLS START BUTTON Use this button to set the time when turning on the appliance for the first time or after a power failure, scroll through preset programs and start cooking cycles. On 90 cm models, it also selects the operating power.

  • Page 7: Use Of The Oven

    4. USE OF THE OVEN Warnings and general advice When using for the first time, it is advisable to heat up the oven to its maximum temperature for enough time to burn off any possible oily manufacturing residues. This means that, if the food being cooked needs...
  • Page 8 10 minutes, after which it will start to drop for a period up to a maximum time of 20 minutes, counted from when the beep sounded. After this the oven switches off. During this stage, the display shows the parameters of the selected program).
  • Page 9 20-second BEEP the word "End" will flash for 20 minutes, during which time the temperature will gradually fall, stabilising at 100°C. After 20 minutes, the oven switches off. Manual cooking Use the knob to select the "easy" program (P10 *).
  • Page 10 Instructions for the user 4.6 Editing a program The programs the user is able to edit are: P6 P7 P8 P9 A number of parameters can be edited for each program: • preheating temperature [Uprh] :User pre heating • cooking temperature [U t°C] User heating •...
  • Page 11 Instructions for the user Press STOP to display the next parameter. The display shows U t°C. Press START to display the cooking temperature. Press START or keep it pressed to increase the preheating temperature; each time START is pressed the temperature increments by 1°C (from 30° to 300°).

  • Page 12: Cleaning And Maintenance

    Instructions for the user 5. CLEANING AND MAINTENANCE Important: Never spray water directly on to the oven. Never use pressure jets of water. Before working on the oven, disconnect it from the power supply. 5.1 Cleaning stainless steel parts To maintain stainless steel parts in perfect condition, clean regularly at the end of the work day.
  • Page 13 Instructions for the user Cleaning the inside of the oven To maintain the oven in perfect condition, clean it regularly at the end of the work day. Allow it to cool first. Take off all removable parts. Remove the side guides by unscrewing the ring nut A and sliding them out of the rear hole B.

  • Page 14: Reactive Maintenance

    Before any intervention, disconnect the oven from its power supply. 6.1 Replacing the light bulb Remove the protective cover A. Replace the bulb B with a similar one. Refit the protective cover A. Use only oven light bulbs (suitable for a temperature of up to 300°C).
  • Page 15 B. At this stage the door can be closed normally. Oven door seal To permit thorough cleaning of the oven, the gasket may be removed. Before removing the gasket, take off the door as described above. Once the door has been taken...
