Belkin F1U400 User Manual

4x4 usb peripheral switch
Hide thumbs Also See for F1U400:
Table of Contents

Advertisement

Quick Links

Download this manual
P74077-D_F1U400_man.qxd
11/13/02
Compton • CA • 90220 • USA
Belkin Components, Ltd.
Express Business Park • Shipton Way • Rushden
Starparc Building • Boeing Avenue 333
1119 PH Schiphol-Rijk • The Netherlands
Belkin Components, Ltd.
7 Bowen Crescent • West Gosford
Australia: 1800 666 040
© 2002 Belkin Corporation. All rights reserved. All trade names are registered
trademarks of respective manufacturers listed. Mac OS, Mac, and Macintosh are
trademarks of Apple Computer, Inc., registered in the U.S. and other countries.
4:14 PM
Page 1
Belkin Corporation
501 West Walnut Street
Tel: 310.898.1100
Fax: 310.898.1111
NN10 6GL • United Kingdom
Tel: +44 (0) 1933 35 2000
Fax: +44 (0) 1933 31 2000
Belkin Components B.V.
Tel: +31 (0) 20 654 7300
Fax: +31 (0) 20 654 7349
NSW 2250 • Australia
Tel: +61 (0) 2 4372 8600
Fax: +61 (0) 2 4372 8603
Belkin Tech Support
US: 310.898.1100 ext. 2263
800.223.5546 ext. 2263
Europe: 00 800 223 55 460
P74077-D
4x4 USB
Peripheral Switch
Share four USB devices with up to
four computers

User Manual

F1U400
