100 Mbps Fast Ethernet Cable Lengths; 10 Mbps Ethernet Cable Lengths; Table 4-5 Maximum Fast Ethernet Cable Length; Table 4-6 Maximum Ethernet Cable Length - SMC Networks SMC TigerAccess SMC7824M/ESW Installation Manual

Table 4-3 Maximum 1000BASE-LX Gigabit Ethernet Cable Length

Fiber Size
9/125 micron
single-mode duplex fiber

Table 4-4 Maximum 1000BASE-ZX Gigabit Ethernet Cable Length

Fiber Size
9/125 micron
single-mode fiber
* For link spans exceeding 70 km, you may need to use premium single mode fiber or
dispersion shifted single mode fiber

100 Mbps Fast Ethernet Cable Lengths

Type
100BASE-TX

10 Mbps Ethernet Cable Lengths

Type
100ASE-T
Fiber Bandwidth Maximum Cable
N/A
Fiber Bandwidth Maximum Cable
N/A

Table 4-5 Maximum Fast Ethernet Cable Length

Cable Type
Category 5 or better
100-ohm UTP or STP

Table 4-6 Maximum Ethernet Cable Length

Cable Type
Twisted Pair,
Categories 3, 4, 5 or
better 100-ohm UTP
C
ONNECTIVITY
Length
2 m - 10 km
(7 ft - 6.2 miles)
Length
70* - 100 km
(43.5 - 62.1 miles)
Max. Cable Length
100 m (328 ft)
Maximum Length
100 m (328 ft)
R
ULES
Connector
LC
Connector
LC
Connector
RJ-45
Connector
RJ-45
