Getting Started with the Configuration Manager
Table
Heading
Device
DSL
WAN
Interfaces
LAN
Interface
34
This table displays basic information about the ADSL Barricade
hardware and software versions, the system uptime (since the last
reboot), and the preconfigured operating mode.
This table displays the operational status, version, and
performance statistics for the DSL line. You can check DSL in the
table or display the [WAN] tab to view additional DSL settings,
which are described in Configuring EOA Interfaces.
This table displays the software name(s) and various settings for
the device interface(s) that communicates with your ISP via DSL.
Even if you only have one physical DSL port, multiple
software-defined interfaces can be configured to use it. See the
ATM VC, PPP, EOA, and IPoA chapters for more information about
the WAN interfaces defined on your system. For each interface, a
[Lower Interface] name, such as [aal5-0], should appear. You can
click on the [Lower Interface] name to view or change the ATM VC
settings that this interface uses.
This table displays the software names and various settings for
the device interfaces that communicate directly with your network.
These typically include an [Ethernet Interface] named [eth-0], and
may include a [USB Interface] named [usb-0]. For information on
how to modify properties of these interfaces, see Configuring the
LAN Ports on page 40 and USB Functionality.
Description
