1. Dial keypad
2. Handset paging buttons (1-6)
Handset paging indicators
Allow you to page each handset
Shows the status of each handset
3. Function keys: HOLD, REDIAL/PAUSE, MUTE
4. Soft Keys
5. EXIT: to stop operation
6. VOICE MAIL indicator
7. Navigator Key(
,
,
VOL. (Volume:
,
)
8.STATUS indicator
Indicates the status of the unit and network
9. SP-PHONE/HEADSET: Speaker phone indicator
1. Charge/Ringer/Message indicator
2. TALK: to make calls
3. SP-PHONE: Speakerphone, to talk hands free
4. OFF: to stop operation
5. REDIAL/PAUSE
6. A: Soft Keys: The handset features 2 soft keys and a joystick. By pressing a soft key, or
by pressing the center of the joystick, you can select the feature shown directly above it
on the display.
B: Joystick: By pushing the joystick repeatedly, you can:
1.
Scroll through (up, down, left, or right) various lists or items
2.
Adjust the receiver or speaker volume (up or down) while talking
Handset paging button (ALL)
LINE STATUS: tells the
status of each line on the
display
,
)
