Thank you for purchasing a Panasonic product.
Charge the batteries for about 6 hours before initial use.
Please read this guide before using the unit and save it for future reference.
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
KX-TGP500
Model No.
KX-TGP550
Model No.
Document Version: 2010-08
Quick Guide
SIP Cordless Phone
B02
T02
Advertisement
Table of Contents
Related Manuals for Panasonic KX-TGP500B04
Summary of Contents for Panasonic KX-TGP500B04
-
Page 1: Quick Guide
Model No. Model shown is KX-TGP500. Model shown is KX-TGP550. Thank you for purchasing a Panasonic product. Charge the batteries for about 6 hours before initial use. Please read this guide before using the unit and save it for future reference. -
Page 2: Table Of Contents
Table of Contents Introduction About this guide....3 Accessory information ... . . 3 Important Information For your safety . -
Page 3: About This Guide
About this guide This guide explains how to use the basic features of KX-TGP500/KX-TGP550. For further information on operations and customising your phone, please read the User Guide on the Panasonic Web site at: http://panasonic.net/pcc/support/sipphone/ Contact your administrator for further information. -
Page 4: Important Information
Important Information Operating safeguards For your safety L Unplug the product from power outlets before cleaning. Do not use liquid or To prevent severe injury and loss of aerosol cleaners. life/property, read this section carefully before L Do not disassemble the product. using the product to ensure proper and safe L Do not spill liquids (detergents, cleansers, operation of your product. -
Page 5: Important Safety Instructions
L We recommend using the batteries noted Base unit location/avoiding noise on page 3. USE ONLY rechargeable Ni- The base unit and other compatible Panasonic MH batteries AAA (R03) size. units use radio waves to communicate with L Do not mix old and new batteries. -
Page 6: Security Caution
Panasonic Marketing Europe GmbH to blocked access or information leaks). Winsbergring 15, 22525 Hamburg, Refer to the User Guide on the Panasonic Germany Web site. See page 3 for Panasonic URL. L You are responsible for the security... -
Page 7: Emergency Calls
Important Information resources and prevent any potential negative effects on human health and the environment which could otherwise arise from inappropriate waste handling. For more information about collection and recycling of old products and batteries, please contact your local municipality, your waste disposal service or the point of sale where you purchased the items. -
Page 8: Controls
Controls L Charge contacts ■ Control type Handset A Soft keys The handset features 2 soft keys and a joystick. By pressing a soft key, or by pressing the centre of the joystick, you can select the feature shown directly above it on the display. -
Page 9: Base Unit
Controls Base unit KX-TGP500 A STATUS indicator L Indicates the status of the unit and network. B Handset locator button {ALL} L Allows you to page all handsets. VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... - Page 10 Controls KX-TGP550 Q R S T A Corded handset K Soft keys B Receiver L Headset jack C Speaker M Microphone D Handset paging buttons ({j} – N Dial keypad O {SP-PHONE} {HEADSET} {k}) Handset status indicators SP-PHONE indicator P {MUTE} L Allow you to page each handset.
-
Page 11: Status Indicator On The Base Unit
Controls Navigator key/volume key {<} {>} ■ Scrolling through lists or items By pressing this key ({^}, {V}, {<}, or {>}) repeatedly, you can scroll through (up, down, left, or right) various lists or items. ■ Adjusting the volume By pressing this key ({^} or {V}) repeatedly, you can adjust the receiver or speaker volume (up or down) while talking. - Page 12 Controls Status Meaning Colour Light pattern L When the base unit is turned on, the STATUS indicator lights in red for about 10 seconds. Flashing L The base unit is registering a handset. Flashing L The base unit is paging handsets. (KX-TGP500 only) rapidly Amber L The base unit’s IP address may conflict with the IP...
-
Page 13: Basic Operations
L For further details, please read the waiting to redial, the ringer User Guide on the Panasonic Web indicator flashes. To cancel, press site. See page 3 for Panasonic URL. {OFF}. Using the speakerphone Dial the phone number and press Making calls using the {s}. -
Page 14: Answering Calls Using The Handset
L For further details, please read the {SP-PHONE}. User Guide on the Panasonic Web L If {SP-PHONE} is pressed and site. See page 3 for Panasonic URL. the other party’s line is engaged, the unit automatically redials Using the speakerphone multiple times. -
Page 15: Answering Calls Using The Base Unit (Kx- Tgp550 Only)
Basic Operations : Base unit Answering calls using Available for: KX-TGP550 the base unit (KX- Press {HOLD} during an outside TGP550 only) call. L If you are using the corded Lift the corded handset or press handset, you can place it on the {CALL} or {SP-PHONE} when the cradle. -
Page 16: Using The Base Unit
Basic Operations L To correct the number, press {CANCEL} to clear the number and enter again. Wait for the paged party to answer. L If the paged party does not answer, press {CANCEL} 2 times to return to the outside call. {TRANS} Using the base unit Available for: KX-TGP550... -
Page 17: Setting Up
Connecting the base unit Important: L Use only the supplied Panasonic AC adaptor PQLV219E. L KX-TGP550 only: Do not connect the Ethernet cable connected to the PoE hub to the PC port of the unit. Doing so may cause severe damage to the unit. - Page 18 Setting Up KX-TGP550 Press plug firmly. Correct “Click” Hook Base unit “Click” Wrong C C C C C Base unit “Click” (220-240 V AC, 50/60 Hz) AC adaptor To a hub/router Ethernet cable To a computer Ethernet cable VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
-
Page 19: Setting Up The Handset
Battery charge Setting up the handset Charge for about 6 hours. L When the batteries are fully charged, Connecting the charger the charge indicator goes off. L Use only the supplied Panasonic AC Charge indicator adaptor PQLV219E. Confirm “Charging” is displayed. -
Page 20: Setting Network
& for further information. Medium Automatic setup (default) Needs charging. Turning the DHCP connection mode Empty Y Handset Panasonic Ni-MH battery performance (supplied batteries) {MENU} (centre of joystick) i {#}{5}{0}{0} Operation Operating time {V}/{^}: “On” i {SAVE} In continuous 5 hours max. - Page 21 Setting Up {V}/{^}: “Off” i {SAVE} i {OFF} Setting the static IP address and other settings {MENU} (centre of joystick) i {#}{5}{0}{1} Set the IP address, subnet mask, default gateway, DNS1, and DNS2. L Push the joystick down {V} or up {^} to move between the items.
-
Page 22: Open Source Software
Open Source Software Open Source Software Parts of this product use Open Source Software. Relevant conditions apply to this software. Panasonic cannot accept inquiries regarding the content of the following copyright and licence information. <<NetBSD kernel>> This product uses a part of NetBSD kernel. - Page 23 Open Source Software Copyright (c) 1980, 1986, 1991, 1993 The Regents of the University of California. All rights reserved. Copyright (c) 1980, 1986, 1993 The Regents of the University of California. All rights reserved. Copyright (c) 1982, 1985, 1986, 1988, 1993, 1994 The Regents of the University of California.
- Page 24 Open Source Software Copyright (c) 1987, 1993 The Regents of the University of California. All rights reserved. Copyright (c) 1988 Regents of the University of California. All rights reserved Copyright (c) 1988 Stephen Deering. Copyright (c) 1988 University of Utah. Copyright (c) 1988, 1989, 1993 The Regents of the University of California.
- Page 25 Open Source Software Copyright (c) 1998, 1999, 2000, 2001 The NetBSD Foundation, Inc. All rights reserved. Copyright (c) 1998, 2000 The NetBSD Foundation, Inc. All rights reserved. Copyright (c) 1998, 2000, 2001 The NetBSD Foundation, Inc. All rights reserved. Copyright (c) 1999 The NetBSD Foundation, Inc. All rights reserved. Copyright (C) 1999 WIDE Project.
- Page 26 Open Source Software * Copyright (c) 1998-2004 The OpenSSL Project. All rights reserved. * Redistribution and use in source and binary forms, with or without * modification, are permitted provided that the following conditions * are met: * 1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
- Page 27 Open Source Software * All rights reserved. * This package is an SSL implementation written * by Eric Young (eay@cryptsoft.com). * The implementation was written so as to conform with Netscapes SSL. * This library is free for commercial and non-commercial use as long as * the following conditions are aheared to.
- Page 28 Open Source Software * derivative of this code cannot be changed. i.e. this code cannot simply be * copied and put under another distribution licence * [including the GNU Public Licence.] <<MD5>> This software uses the Source Code of RSA Data Security, Inc. described in the RFC1321 (MD5 Message-Digest Algorithm).
- Page 29 Open Source Software LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;...
-
Page 30: Guarantee
8. The guarantee period applicable to this product shall be 12 months. Please keep these operating instructions with your receipt. Panasonic Business Systems U.K. Receipt No. Date of purchase Model No. - Page 31 Notes VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
