Quick Start Guide
RPX Electronic Radiant Panel Radiator
This guide is for quick reference only. Refer to the RPXN installation and operating instructions for further information
RPX radiant panel radiator
Heater controls
(A)
Function selector: see table below for functions available
(B)
Function display: will illuminate to show which function
has been selected with the function selector
(C)
Thermostat: set the thermostat control to the appropriate
position to give comfort level required. Heater will switch on
and off as necessary, and a higher setting will make the
room warmer.
(D)
Thermostat indicator: will illuminate to show when heater
is delivering heat
(E)
Cover opening tab
Function selector table
Symbol
0
*Note: If the programme function is selected but no programming device is being used, the heater will function in comfort mode.
Dimplex UK Ltd, Millbrook House, Hedge End, Southampton, SO30 2DF. For further assistance please contact Dimplex customer services on 0845 600 5111. Web-site: www.dimplex.co.uk
Function
Comfort
Background (setback)
Off
Programme
General
•
Use the heater in comfort mode
occupied.
•
Use the heater in set back (background) mode
room is unoccupied. It is more energy efficient to do this than
switch the heater off.
•
Use the heater in frost protection mode
for long periods of time.
Description
Heater will maintain the temperature set on the thermostat
dial
Heater will maintain a lower temperature level for background
heating (preset to –3.5ºC)
Heater will not function
Heater will be controlled by a programming device
QS021
when the room is
when the
if you are away
