Page 1: Quick Start Guide
WI-FI SECURITY DOME CAMERA QUICK START GUIDE ENGLISH... - Page 2 WELCOME! Congratulations on your latest purchase and welcome to the Q-See family. This guide includes everything you will need to help get your camera up and running right out of the box. We are excited to have you on board...
-
Page 4: What's Included
WHAT’S INCLUDED Mounting Guide Camera Wi-Fi Antenna Grommet Mounting Wrench Hardware Also included: 1 power supply & 1 weather seal (seal is for custom installs) - Page 5 FEATURES BEST IN CLASS NIGHT VISION EASY SETUP Setting the resolution See what’s happening in Less fuss, more bar higher than 1080p pitch dark monitoring MOTION ALERT MICRO SD CARD SUPPORT ADD-ON Get alerts about Internal back up memory for Expand your current important activity video storage...
-
Page 6: Get Connected
GET CONNECTED Find the desired location for your camera to be placed. If you are going to be mounting the camera, please use the included mounting hardware to secure the camera firmly to the wall. Please make sure to go through all steps and test the system completely before mounting the cameras. - Page 8 STEP 1 REGISTRATION Before installing, please register your device on the Q-See Support Portal at www.q-see.com/register to receive critical updates and support for your system. Registering will also help us to assist you with any technical or warranty issues if ever necessary.
- Page 9 STEP 2 DOWNLOAD & INSTALL THE QC VIEW APP NOTE: Ensure that your mobile device is connected to the Wi-Fi network you wish to use for your camera. Download the QC View App from the App Store on your mobile device. Once the App has been installed select the Menu button in the top left corner, followed by...
- Page 10 STEP 3 ADD A NEW DEVICE In Device Manager, Click “+” to add a new device. Select “Wi-Fi configuration” and create a name for your camera. Tap the code icon in the SN field and then scan the QR code located on the back camera panel (see photo below).
- Page 11 STEP 4 ADD A WI-FI DEVICE Configure the network settings by entering the password of your Wi-Fi network. NOTE: The Wi-Fi network should be the same one used by your mobile device.
- Page 12 STEP 5 START LIVE PREVIEW Once your Device has been added successfully, select Start Live Preview to view the feed from your camera.
- Page 13 STEP 6 VIEW THE LIVE VIDEO FEED Your camera has been set up successfully. You can now access your camera feed anytime and anywhere using the QC View App.
- Page 14 Add. The camera feed will appear on your NVR. The NVR has to be connected to the same network as your mobile device for the initial setup process. Visit www.q-see.com/support to verify if your system is compatible. *This screenshot is from a QC Series NVR.
-
Page 15: Lens Adjustment
LENS ADJUSTMENT The lens of your dome camera can be adjusted based on where you are mounting it by gently loosening its screw and rotating the angle and orientation of the camera. The LEDs denote the bottom half of the camera so be sure to rotate the lens accordingly or the camera view will be sideways. -
Page 16: Additional Features
ADDITIONAL FEATURES RESET BUTTON The reset button on your dome camera is located under the lens cover that can be removed with the included wrench. If you wish to change the existing Wi-Fi network to a different network, while the camera is powered on, hold the reset button for 15 seconds and setup your camera again. -
Page 17: Network Cable
NETWORK CABLE Please do not worry about the additional network cable on your dome camera. This network cable can alternatively be used to hard- wire the camera using an Ethernet cable instead of a Wi-Fi connection. Please make sure that this cable is never exposed to moisture. -
Page 18: Warranty And Support
DISCLAIMER: Although Q-See has made every effort to ensure that the infor- mation in this guide was correct at the time of printing, Q-See does not assume any liability to any party for any loss, damage, or disruption caused by any errors,... -
Page 19: Regulatory Information
• Consult the dealer or an experienced radio/TV technician for help. This equipment should be installed and operated with a minimum distance 20cm between the radiator and your body. 1.2.51.32.Tgz001-000 Check online at www.Q-See.com for more information on our terms of service.
