PRE OUT connections
Power amplifier
FRONT
PRE
REAR
OUT
SUB
CENTER
WOOFER
Power amplifier
Power amplifier
Use these jacks when adding additional amplifiers.
Connect the PRE OUT jacks to the powered speakers or the
power amplifiers connected to speakers respectively.
To emphasize deep bass sounds, connect a powered
subwoofer.
FRONT
COAXIAL
AM
LOOP
PRE AC-3/PCM
REAR
OUT
OPTICAL VIDEO
FM
SUB MON.
CENTER
75Ω WOOFER OUT
FRONT
DIGITAL
INPUTS
ANTENNA
6-CH
DIRECT REAR
INPUT
SUB
CENTER
WOOFER
L R
VIDEO L R

CONNECTING DIGITAL INPUTS

Component with
COAXIAL DIGITAL OUT
COAXIAL
AC-3/PCM
OPTICAL
Component with
OPTICAL DIGITAL OUT
DIGITAL
INPUTS
The COAXIAL or the OPTICAL DIGITAL OUTs of
the components that are connected to "CD", "VCR2"
and "DVD/TV" of this unit can be connected to these
DIGITAL INPUTS.
A digital input should be connected to the components
such as LD player, CD player or DVD, etc. capable of
outputing Dolby Digital(AC-3) or PCM format digital
signals.
For details, refer to the operating instructions of the
component connected.
When making the COAXIAL DIGITAL connection,
be sure to use a 75Ω COAXIAL cord, not a
conventional AUDIO cord.
Front speakers
Rear speakers
Center speaker
Powered subwoofer
CD
AC INPUT
120V~60Hz
2.1A
PLAY FRONT
SPEAKERS R L MODEL NO. RVD-6090R
(8Ω)
TAPE MON. C A U T I O N
AUDIO/VIDEO RECEIVER
R I S K O F E L E C T R I C S H O C K
D O N O T O P E N
REC MADE IN KOREA
DESIGNED IN USA
W A R N I N G : " S H O C K H A Z A R D - D O N O T O P E N "
A V I S : " R I S Q U E D E C H O C - E L E C T R I Q U E - N E P A S
REAR
S E R . N O
O U V R I R "
SPEAKERS R L
AUX
(8Ω)
Manufactured under license from Dolby Laboratories. "Dolby",
"PRO LOGIC" and the double-D symbol are trademarks of Dolby
Laboratories. Confidential Unpublished Works. ©1992-1997 Dolby
DVD/ Laboratories, Inc. All rights reserved.
TV
T h i s d e v i c e c o m p l i e s w i t h P a r t 1 5 o f t h e F C C R u l e s .
O p e r a t i o n i s s u b j e c t t o t h e f o l l o w i n g t w o c o n d i t i o n s :
AC OUTLET ( 1 ) T h i s d e v i c e m a y n o t c a u s e h a r m f u l i n t e r f e r e n c e , a n d
IN ( 2 ) t h i s d e v i c e m u s t a c c e p t a n y i n t e r f e r e n c e r e c e i v e d ,
i n c l u d i n g i n t e r f e r e n c e t h a t m a y c a u s e u n d e s i r e d o p e r a t i o n .
VCR1
E85649
29Z3
OUT
LISTED
CENTER SPEAKER(8Ω) AUDIO EQUIPMENT
SWITCHED
DIGI-LINK
120V~60Hz
R
100W 1A MAX
Rear
right
Never short circuit the + and - speaker cords.
Be sure to connect speakers firmly and correctly according to the
channel (left and right) and the polarity (+ and -).
Be sure to use the speakers with the impedance of over 8 Ω.
For installing the speakers, refer to "Speaker placement" on page 14.
6
CONNECTING SYSTEM CONTROL
Sherwood component
with DIGI LINK II or III
CD player
Tape deck
Graphic equalizer
DIGI-LINK
Connect this jack to the DIGI LINK jack of the
external Sherwood component that uses the DIGI
LINK II or III remote control system.
AC INPUT CORD
Plug this cord into a wall AC
outlet.
SWITCHED AC OUTLET
This outlet is switched on(power on mode) and
off(standby mode) according to power controls as
follows(Maximum total capacity is 1A, 100W):
Standby mode – switched AC outlet off
C
R
Power on mode – switched AC outlet on

CONNECTING SPEAKERS

Front right
FRONT
SPEAKERS R
(8Ω)
REAR
R
SPEAKERS
(8Ω)
CENTER SPEAKER(8Ω)
System
control
cord
Front left
L
L
Rear
left
Center
