Sherwood RV-4060R Operating Instructions Manual

Sherwood audio/video receiver operating instructions.
O P E R A T I N G I N S T R U C T I O N S
AUDIO/VIDEO RECEIVER RV-4060R
AUDIO/VIDEO RECEIVER RV-4060R
POWER
POWER
STANDBY/OFF
STANDBY/OFF
PHONES
PHONES
MEMORY
MODE
MEMORY
MODE
REMOTE SENSOR
REMOTE SENSOR
FM
AM
STANDBY
STANDBY
VOL
TUNING/PRESET
TUNING/PRESET
RESET
RESET
FM
FM
AM
AM
R R V V - - 4 4 0 0 6 6 0 0 R R
AUDIO/VIDEO RECEIVER
PRO LOGIC
PRO LOGIC
BASS
BASS
AUTO
MEMO
MHz
STEREO
TREBLE
TREBLE
KHz
MONO
SLEEP CH
3-STEREO
MUTE
TAPE M
3-STEREO
TEST
VIDEO12
NR
WI
PH
BALANCE
BALANCE
SURROUND
SURROUND
TAPE
TAPE
VCR 1
VCR 1
TV/AUX
TV/AUX
VCR 2
VCR 2
MONITOR
MONITOR
VOLUME/TONE/BALANCE
VOLUME/TONE/BALANCE
VCR 2/CAMCORDER INPUT
VCR 2/CAMCORDER INPUT
CD
CD
VIDEO
VIDEO
L -AUDIO- R
L -AUDIO- R

   Related Manuals for Sherwood RV-4060R

   Summary of Contents for Sherwood RV-4060R

  • Page 1

    O P E R A T I N G I N S T R U C T I O N S AUDIO/VIDEO RECEIVER RV-4060R AUDIO/VIDEO RECEIVER RV-4060R POWER POWER STANDBY/OFF STANDBY/OFF PHONES PHONES TUNING/PRESET TUNING/PRESET MEMORY MODE MEMORY MODE REMOTE SENSOR...

  • Page 2

    INTRODUCTION UNPACKING AND INSTALLATION Congratulations on Your Purchase! Your new high fidelity Receiver is designed to deliver maximum enjoyment and years of trouble free service. Please take a few moments to read this manual thoroughly. It will explain the features and operation of your unit and help ensure a trouble free installation.

  • Page 3

    29Z3 LISTED LISTED PLAY PLAY PLAY PLAY MODEL NO. RV-4060R MODEL NO. RV-4060R AUDIO EQUIPMENT AUDIO EQUIPMENT This device complies with Part 15 of the FCC Rules. This device complies with Part 15 of the FCC Rules. AUDIO/VIDEO RECEIVER AUDIO/VIDEO RECEIVER...

  • Page 4

    16. DIGI LINK SYSTEM CONTROL (colored green) – remote control jacks for connection to the corresponding DIGI LINK Sherwood CD (Compact Disc) or tape player. Connect this jack to the DIGI LINK Sherwood equipment that uses the DIGI LINK remote control system.

  • Page 5

    AUDIO/VIDEO RECEIVER RV-4060R AUDIO/VIDEO RECEIVER RV-4060R REMOTE SENSOR REMOTE SENSOR POWER POWER STANDBY/OFF STANDBY/OFF PHONES PHONES TUNING/PRESET TUNING/PRESET MEMORY MODE MEMORY MODE FRONT PANEL 11. POWER SWITCH For switching the unit on and off. 12. PHONES For connecting headphones. 13. MEMORY BUTTON For storing preset stations.

  • Page 6

    SLEEP CH 1.5V The remote control (supplied) can be used to operate functions of the receiver. In addition, it can be used to operate any other Sherwood equipment that uses the DIGI LINK remote control system. BATTERIES Open the battery compartment and insert two batteries as indicated, size AAA cells.

  • Page 7

    STANDBY/ON). 12. SLEEP – for setting a time period after which the system will automatically be switched to standby. 13. SYSTEM DISPLAY – for dimming displays of Sherwood components connected by DIGI LINK 25. INPUT SELECTORS 33. MUTE – for muting the sound.

  • Page 8

    AMPLIFIER POWER ON/OFF Press the POWER switch to turn the power on. – The receiver enters the operating mode and the respective indicators lights up. To turn the power off, press the POWER switch again. – The power is cut off and the respective indicators lights off. POWER STANDBY/ON In the operating mode, press the POWER button on the remote control.

  • Page 9

    DOLBY 3 STEREO : Choose this setting to play back movies and music (especially Laser Discs, video cassettes and TV broadcasts with DOLBY SURROUND sound) when not using the rear speakers. You get a clear perception of the position and direction of the sound. DOLBY 3 STEREO combines the front and rear signals so that you can enjoy a regenerated sound field, which has comparatively more lively presence and a more expansive...

  • Page 10

    TUNER GENERAL Select the waveband by pressing the FM or the AM button Tune to a radio station or select a preset number. The correct procedure is described in the following chapters. – While tuning, the audio signal will be muted to eliminate interfering background noises. Once a station is found, the audio signal will be set to normal volume again.

  • Page 11

    SLEEP The sleep mode allows the system to continue to operate for a specified period of time before automatically shutting off. Press the SLEEP button on the remote control to set the receiver to automatially turn off after 10, 20, 30, 60 or 90 minutes.

  • Page 12

    TROUBLESHOOTING If a fault occurs, run through the points listed below before taking your receiver for repair. If the fault persists, attempt to solve it by switching the receiver off and on again . If this fails to resolve the situation, consult your dealer.

  • Page 13

    O P E R A T I N G I N S T R U C T I O N S R R V V - - 4 4 0 0 6 6 0 0 R R AUDIO/VIDEO RECEIVER 5707-04699-003-0...
