INSTALLATION AND OPERATION INSTRUCTIONS
FR-700F
MODEL
IMPORTANT
READ AND UNDERSTAND INSTRUCTIONS BEFORE INSTALLING OR USING HEATER.
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE. CHECK LOCAL CODES AND ORDINANCES FOR PERMITTED USE.
Specifications ····························································· 2
Safety Tips for Operation ············································ 3
Fuel Guide ··································································· 4
Operation ···································································· 5
Error Messages ························································ 10
Installation ································································ 11
Fuel Storage and Supply System ······························ 23
VENTED HEATING SYSTEM
CONTENTS

Advertisement

Table of Contents
loading

Summary of Contents for Toyotomi FR-700F

  • Page 1: Table Of Contents

    VENTED HEATING SYSTEM INSTALLATION AND OPERATION INSTRUCTIONS FR-700F MODEL IMPORTANT READ AND UNDERSTAND INSTRUCTIONS BEFORE INSTALLING OR USING HEATER. RETAIN INSTRUCTIONS FOR FUTURE REFERENCE. CHECK LOCAL CODES AND ORDINANCES FOR PERMITTED USE. CONTENTS SECTION A: Specifications ····························································· 2 SECTION B: Safety Tips for Operation ············································...
  • Page 2: Section A

    SECTION A: SPECIFICATIONS Model: FR-700F Heater Efficiency: 92.4% (1) Heat Rating: High - 7.00 kW (23,900 BTU/h) Low - 1.75 kW ( 5,980 BTU/h) Fuel Consumption: High - 0.791 L/h Low - 0.198 L/h Fuel system: External tank (2) Fuel Type: Kerosene only Dimensions (W ×...
  • Page 3: Section B

    SECTION B: SAFETY TIPS FOR OPERATION CAUTION: Heater and vent pipe system must be properly installed before operation. Please follow instructions under “Installation”, Section F. 1. Never use any fuel other than Kerosene. NEVER USE GASOLINE. Use of gasoline RIGHT WRONG can lead to uncontrollable flames, resulting in destructive fire.
  • Page 4: Section C

    SECTION C: FUEL GUIDE The FF-70AQ is designed for use with Kerosene. Use of low-quality fuel will cause burner performance to drop, leading to abnormal combustion and reduced heater life. Purchase only Kerosene, in non-red cans reserved exclusively for fuel and marked accordingly with the word “KEROSENE”.
  • Page 5: Section D

    SECTION D: OPERATION 1. Introduction The heater is an easy to use vented petroleum heater. It provides considerable quantities of heat, automatically regulates the room temperature, uses very little fuel and electricity and has options for automatic or manual operation. This section provides all the information required for the operation of the Vented heating system.
  • Page 6 2. Operating elements and lights 4. Information display 1. ON/OFF button 2. Adjustment buttons 7. Childproof button 8. Filter button 6. Timer button 5. Save button 3. Heat adjusting slide knob Fig. D-1 Operation panel 1. ON/OFF button: 5. SAVE button: The main switch to turn the heater on and off.
  • Page 7 3. Prior to use Step 1: Open the Valve(s) Open the valve(s) of the external fuel tank. Step 2: Start the Fuel flow If using heater for the first time, or after heater has Reset Button been out of fuel, press the red reset button once for a period of one second in order to send fuel to the fuel...
  • Page 8 4. Igniting the heater When the room temperature reaches the chosen The heater is operated directly by the user. You can setting the heater automatically switches to the “MED” choose the heat yield is controlled automatically in or “LOW” operating mode in order to maintain the accordance with the room temperature registered by the desired temperature.
  • Page 9 5. Timer operation 7. Childproof lock The timer allows you to switch on the heater automati- The childproof lock can be used to prevent children cally at a preset time. accidentally changing the heater settings. When the In order to switch on the timer, the correct time must heater is burning and the childproof lock is on, the have been set and the heater should be off.
  • Page 10 Step 4: Look for the source of the overheating. 11. Before consulting an expert Overheating is usually caused by objects that The following situations do not indicate defects. obstruct the free flow of air. Check that the circulation ventilator or exhaust pipes are not While switching the heater on or off.
  • Page 11: Section E

    SECTION E: ERROR MESSAGE ERROR CODE INFORMATION WHAT TO DO Power interrupted. Re-ignite the heater Ignition safety feature is activated. Contact your dealer Extinguished during operation. Contact your dealer Blower motor malfunction. Contact your dealer E-12 Overheating safety feature is activated. Clean the air filter and remove dust.
  • Page 12: Section F

    SECTION F: INSTALLATION 1. Introduction Recommended tool kit 1. Crosshead screwdriver This section contains all the relevant information, 2. Steel tape measure specifically: 3. Felt-tip pen or pencil 4. Cement for exterior use • Installation specifications 5. Electric drill (clockwise and anti-clockwise recommended) •...
  • Page 13 G ) Check that all parts are present. Only the standard feed and exhaust system is supplied with the heater. More than 60 cm More than 10 cm More than 30 cm More than 30 cm More than 1.5 m FR-700F Fig. 1: Gaps heater/exhaust pipe...
  • Page 14 Combustible object Combustible object Not less than 60 cm Not less than 45 cm Noncombustible object Not less than 45 cm Not less than 60 cm 45˚ Not less than 30 cm Flue pipe * Be sure this clearance will * Not less than 20 cm be maintained after snowfalls,...
  • Page 15 After using the installation template as a guide for the drilling of the hole for the exhaust pipe, the heater can be installed normally, according to the procedure in the illustration. If the template is lost or the heater has to be moved, these are the dimensions and locations of the holes for the fuel pipe and exhaust pipe.
  • Page 16 Standard installation parts The following list of standard installation parts is sup- plied with your heater. It may be necessary to order extra parts from your dealer if other installation methods are required. Wall bracket (2 set) Pipe holder (1) Pipe stopper (1) Flue pipe (1) Bent joint (1)
  • Page 17 Inlet hose (1) Hose band (2) Drip tray (1) Oil catch (1) Top guard assembly (1)
  • Page 18 1. For the standard installation, use the template Use cellotape or small nails to attach the template to sup-plied to position the hole for the flue pipe correctly. the desired position on the wall (see Fig. 1). Tape Fig. 1 Comment: The heater must be installed on a strong and stable floor.
  • Page 19 3. Install the inner flue pipe. a. From inside the room, insert the inner flue pipe through the hole. Make sure the arrow on the inner flue pipe is pointing up. Secure the inner flue pipe to the wall with the three wood screws. (See Fig. 4) Inside Outside 130~230 mm...
  • Page 20 Insert the bent joint to the exhaust opening of the flue pipe. Cut the inlet hose for desired length if necessary. Attach the L-shaped hose to each end of the inlet hose and attach the L-shaped hose to the intake opening of the flue pipe.
  • Page 21 Secure the L-shaped hose to the intake inlet opening with the hose band. Secure the bent joint to the flue pipe with the pipe holder (If the extension pipe is used, also attach the pipe holder to the connection of the bent joint and the extension pipe).
  • Page 22 CHECKLIST • Check whether the heater has been connected to a suitable socket. • Ensure that the fuel is free of water or other contami- nants. • Check outside the building in order to ascertain that there is no fuel or obstructions to the free circulation of air in the area immediately adjacent tothe exhaust pipe.
  • Page 23: Section G

    11) “Fuel tanks must be fitted with an effective fuel filter. 12) Fuel pipe-work must be located or guarded so that it is protected against physical damage in normal service. Secure with pipe saddles as appropriate. Outdoor fuel tank FR-700F Fuel filter 2.5 m maximum 30 cm...
  • Page 24 TOYOTOMI CO., LTD. 5-17, Momozono-cho, Mizuho-ku, Nagoya, Japan Printed in Japan New 07/16 2267002060...
