GMC CADILLAC USER EXPERIENCE System Manual page 33

32 REAR SEAT INFOTAINMENT
device, or to view the other screen
that is already connected
through Wi-Fi.
Miracast (If Equipped)
1. Make sure the Android smart
device Wi-Fi is enabled.
2. From the RSI Wireless Display
menu, select Miracast.
3. From the Android smart device,
enter the Miracast, Screen
Mirroring or Android Wireless
Display application.
4. Once the Android smart device
attempts to connect, the RSI will
display a Request to Connect
acceptance screen. Press OK to
continue.
After the connection has completed,
the screen from the smart device will
be duplicated on the RSI screen. Any
audio associated with the screen
shown will be available through the
RSI headphones.
Once the connection process is done
for the first time, the smart device
should appear on the RSI as available
whenever this device is near the
vehicle and the Wi-Fi is turned on.
From the smart device, make the
connection as before.
Accessing the Miracast function varies
from device to device. Usually this
function can be found in the Settings
menu, under Display or Wireless &
Networks.
The other RSI display may connect to
an existing Miracast session. Go to the
Home menu, select Wireless Display,
then select View Screen (1 or 2) s
Wireless Connection.
Digital Living Network Alliance
(DLNA) (If Equipped)
To establish an initial connection:
1. From the RSI Wireless Display
menu, select DLNA. The RSI
screen will display a Wi-Fi
network name, such as
DIRECT-xx-Rear Seat , as well as
the required password necessary
to complete the connection.
2. Make sure the smart device s
Wi-Fi is enabled, and open the
device s Wi-Fi menu.
3. From the smart device s Wi-Fi
menu, select the
DIRECT-xx-Rear Seat network.
If this network is not shown at
the smart device, it will be
necessary to re-scan for available
networks.
4. Enter the RSI Password at the
smart device to complete the
connection. Once entered, the
DIRECT-xx-CUE network will
display as connected.
5. From the smart device s DLNA
application, select Rear Seat 1 or
2 as the screen to display the
desired video, audio, or picture
files on the RSI.
Once the connection process is done
for the first time, the Wi-Fi
connection will be made whenever the
device is within Wi-Fi range or the
smart device Wi-Fi is turned on.
Select Menu from the remote control
to access the options to switch Wi-Fi
band, disconnect the smart device
from the RSI Wi-Fi, or to remove all
DLNA passwords that have been
saved.
