Pioneer GM-D8701 Owner's Manual

Owner's Manual
Manual de instrucciones
CLASS D MONO AMPLIFIER
AMPLIFICADOR MONO DE LA CLASE D
GM-D8701
GM-D9701
http://pioneer.jp/en/info/globalnetwork/
PIONEER CORPORATION
28-8, Honkomagome 2-chome, Bunkyo-ku,
Tokyo 113-0021, JAPAN
PIONEER ELECTRONICS (USA) INC.
P.O. Box 1540, Long Beach, California 90801-1540, U.S.A.
TEL: (800) 421-1404
PIONEER EUROPE NV
Haven 1087, Keetberglaan 1, B-9120 Melsele, Belgium/Belgique
TEL: (0) 3/570.05.11
PIONEER ELECTRONICS ASIACENTRE PTE. LTD.
2 Jalan Kilang Barat, #07-01, Singapore 159346
TEL: 65-6378-7888
PIONEER ELECTRONICS AUSTRALIA PTY. LTD.
5 Arco Lane, Heatherton, Victoria, 3202 Australia
TEL: (03) 9586-6300
PIONEER ELECTRONICS DE MÉXICO S.A. DE C.V.
Blvd.Manuel Ávila Camacho 138, 10 piso
Col.Lomas de Chapultepec, México, D.F. 11000
TEL: 52-55-9178-4270
FAX: 52-55-5202-3714
先鋒股份有限公司
English 台北市內湖區瑞光路407號8樓
電話： 886-(0)2-2657-3588
Español 先鋒電子（香港）有限公司
香港九龍長沙灣道909號5樓
電話： 852-2848-6488
<KYTZ18I>
Before you start
Thank you for purchasing this PIONEER
product
To ensure proper use, please read through this
manual before using this product. It is espe-
cially important that you read and observe
WARNINGs and CAUTIONs in this manual.
Please keep the manual in a safe and accessible
place for future reference.
Visit our website
Visit us at the following site:
http://pioneer.jp/en/info/globalnetwork/
We offer the latest information about
PIONEER CORPORATION on our website.
If you experience problems
Should this product fail to operate properly,
please contact your dealer or nearest author-
ized Pioneer Service Station.
About This Product
This product is a mono amplifier for subwoofer. If
both L (left) and R (right) channels are connected
to the RCA input of this product, output is mixed
because this product is a mono amplifier.
Before connecting/
installing the amplifier
WARNING
! Slots and openings in the cabinet are provided
for ventilation to ensure reliable operation of
© 2018 PIONEER CORPORATION.
All rights reserved. the product, and to protect it from overheat-
© 2018 PIONEER CORPORATION. ing. To prevent fire hazard, the openings
Todos los derechos reservados.
should never be blocked or covered with items
(such as papers, floor mat, cloths).
<5707000012780V>
ES
Before you start
! This unit is for vehicles with a 12 V battery and ! Always disconnect the negative * terminal of
negative grounding. Before installing in re- the battery beforehand to avoid the risk of
creational vehicles, trucks or buses, check the electric shock or short circuit during installa-
battery voltage. tion.
! When installing this unit, make sure to con- ! Do not attempt to disassemble or modify this
nect the ground wire first. Ensure that the unit. Doing so may result in fire, electric
ground wire is properly connected to metal shock or other malfunction.
parts of the car's body. The ground wire of the ! When installing the amplifier, make sure to
one of this unit must be connected to the car leave space around the amplifier for ventila-
separately with different screws. If the screw tion to improve heat radiation. And install to a
for the ground wire loosens or falls out, it location where it cannot be touched during
could result in fire, generation of smoke or operation.
malfunction.
! Be sure to install the fuse to the battery wire.
CAUTION
! Always use a fuse of the rating prescribed.
! Always keep the volume low enough to hear
The use of an improper fuse could result in
outside sounds.
overheating and smoke, damage to the pro-
! Extended use of the car stereo while the en-
duct and injury, including burns.
gine is at rest or idling may exhaust the bat-
! Check the connections of the power supply
tery.
and speakers if the fuse of the separately sold
! This product is evaluated in moderate and tro-
battery wire or the amplifier fuse blows. Deter-
pical climate condition under the Audio, video
mine and resolve the cause, then replace the
and similar electronic apparatus - Safety re-
fuse with and identical equivalent.
quirements, IEC 60065.
! Always install the amplifier on a flat surface.
! The graphical symbol
Do not install the amplifier on a surface that
product means direct current.
is not flat or on a surface with a protrusion.
! Connect either of three subwoofers to the am-
Doing so could result in malfunction.
plifier; 1: a subwoofer with a 300 W (GM-
! When installing the amplifier, do not allow
D8701) / 500 W (GM-D9701) or larger nominal
parts such as extra screws to get caught be-
input and an impedance 4 W, 2: a subwoofer
tween the amplifier and the automobile.
with a 500 W (GM-D8701) / 800 W (GM-D9701)
Doing so could cause malfunction.
or larger nominal input and an impedance 2 W
! Do not allow this unit to come into contact
or 3: a subwoofer with a 800 W (GM-D8701) /
with liquids. Electrical shock could result.
1 200 W (GM-D9701) or larger nominal input
Also, damage to this unit, smoke, and over-
and an impedance 1 W.
heating could result from contact with liquids.
If the nominal input and impedance are out of
The surfaces of the amplifier and any attached
the above ranges, the subwoofer may catch
speakers may also heat up and cause minor
fire, emit smoke or become damaged.
burns.
! In the event of any abnormality, the power
About the protection function
supply to the amplifier is cut off to prevent
This product has protection function. When this
equipment malfunction. If this occurs, switch
product detects something abnormal, the follow-
the system power off and check the power
ing functions will operate to protect the product
supply and speaker connections. If you are un-
and speaker output.
able to determine the cause, please contact
your dealer.
En
! The POWER/PROTECT indicator will turn red
and the amplifier will shut down in the situa-
tions outlined below.
— If the temperature inside the amplifier gets
too high.
— If a DC voltage is applied to the speaker
output terminal.
! The POWER/PROTECT indicator will turn red
and the output will be muted in the situations
outlined below.
— If the speaker output terminal and speaker
wire are short-circuited.
