  • Page 1 MAGNUM III MODEL MAG...
  • Page 2 WARNING REMEMBER - YOUR MOWER IS ONLY AS SAFE AS THE OPERATOR! Hazard control and accident prevention are dependent upon the awareness, concern, prudence, and proper training of the personnel involved in the operation, transport, maintenance, and storage of the equipment.

  • Page 3: General Information

    Section 1 GENERAL INFORMATION 1.1 INTRODUCTION Tractor Serial Number Plate Location 1.2 DIRECTION REFERENCE 1.3 SERVICING THE ENGINE AND DRIVE TRAIN COMPONENTS Cutter Deck Serial Number Plate Location Figure 1-1 Serial Plate Locations...

  • Page 4: Safety Information

    Section 2 SAFETY INFORMATION 2.1 INTRODUCTION WARNING: CAUTION: 2.2 SIGNAL WORDS 2.3 BEFORE OPERATION CONSIDERATIONS...
  • Page 5 Section 2 WARNING: This machine is equipped with an interlock system intended to protect the operator and others from injury. This is accomplished by preventing the engine from starting unless the parking brake is applied and the blades are disengaged. The system also shuts off the engine if the operator removes his foot from the interlock pedal with the mower running and the parking brake not engaged.
  • Page 6 Section 2 2.5 MAINTENANCE CONSIDERATIONS...
  • Page 7 Section 2 2.6 SAFETY AND INSTRUCTIONAL DECALS DANGER SPINNING BLADE KEEP CLEAR CONTACT CAN INJURE 48071 WARNING ROTATING BLADES AND BELTS KEEP HANDS, FEET & CLOTHING CLEAR KEEP ALL GUARDS IN PLACE SHUT OFF ENGINE & DISENGAGE BLADE CLUTCH BEFORE SERVICING CLEAR AREA OF DEBRIS BEFORE MOWING USE CAUTION IN DIRECTING DISCHARGE KEEP BYSTANDERS, CHILDREN &...
  • Page 8 Section 3 SPECIFICATIONS 3.1 ENGINE 3.2 ELECTRICAL 3.3 TRACTOR...
  • Page 9 Section 3 3.3 TRACTOR (CONT'D) 3.4 CUTTER DECK 3.5 HYDRAULIC SYSTEM 3.6 WEIGHTS AND DIMENSIONS...

  • Page 10: Operating Instructions

    OPERATING INSTRUCTIONS CAUTION: Do not attempt to drive this mower unless you have read this manual. Learn the location and purpose of all controls and instruments before you operate this mower. 4.1 CONTROLS AND INSTRUMENT IDENTIFICATION A. Instrument Panel (See Figure 4-1) Engine Oil Pressure Switch...
  • Page 11 Section 4 Parking Brake Lever Forward/Reverse Foot Pedal Figure 4-2 C. Foot Pedals B. Levers INTERLOCK PEDAL Figure 4-3 Interlock Pedal...
  • Page 12 Section 4 4.2 SAFETY INTERLOCK SYSTEM 4.3 INITIAL RUN-IN PROCEDURES (First Day of Use or Approximately 10 Hours) WARNING: Never operate the mower with the interlock system disconnected or malfunctioning. Do not disconnect or bypass any switch; injury to yourself and others or property damage could result.
  • Page 13 Section 4 4.4 DIESEL ENGINE BREAK-IN 4.5 STARTING THE DIESEL ENGINE CAUTION: DO NOT USE STARTING FLUIDS. Use of starting fluids in the air intake system may be potentially explosive or cause “Runaway” engine condition that could result in engine damage and/or personal injury.
  • Page 14 Section 4 B. Seat Adjustment Figure 4-6 Forward - Depress Toe End of Pedal Figure 4-5 Seat Adjustment 4.7 ADJUSTING GROUND SPEED AND DIRECTION Figure 4-7 Backward (Reverse) Operation- Depress Heel End of Pedal...
  • Page 15 Section 4 4.8 ENGAGING THE MOWER WARNING: A safety interlock switch (left foot pedal) will cause the engine to stop if the blade brake is disengaged, and the left foot pedal is not depressed. The function of the switch should be checked by the operator raising his left foot and disengaging the blade brake;...
  • Page 16 Section 4 CAUTION: The blade brake stops the blades from rotating. If the blades do not stop, contact your Scag Dealer. CAUTION: Figure 4-8 Proper Operation on Slope Remove the key from the ignition switch when leaving the mower unattended to inhibit children and inexperienced operators from starting the engine.
  • Page 17 Section 4 4.13 RECOMMENDATIONS FOR MOWING 4.12 MOVING MOWER WITH THE ENGINE STOPPED Dump Valve Handle Open Close 4.14 ADJUSTING CUTTING HEIGHT Figure 4-10 Dump Valve Handle...
  • Page 18 Section 4 4.15 TILTING THE MOWER DECK CAUTION: Do not tilt the deck with the mower blades rotating. Engage the blade brake before tilting the deck. Bodily injury or damage to the mower or property could result. Figure 4-11 Mower Cutting Height Gauge...

  • Page 19: Troubleshooting Cutting Conditions

    Section 5 TROUBLESHOOTING CUTTING CONDITIONS CONDITION Stringers - Occasional Blades of Uncut Grass Width of Deck SGB020 Streaking - Strips of Uncut Grass in Cutting Path Width of Deck SGB018 Streaking - Strips of Uncut Grass Between Cutting Paths Width Width Deck Deck...

  • Page 20: Troubleshooting

    CONDITION Uneven Cut on Flat Lift worn off of blade Ground - Wavy High-Low Blade upside down Appearance, Scalloped Cut, or Rough Contour Deck plugged,grass accumulation Too much blade angle (deck pitch) Adjust pitch and level Deck mounted improperly Bent spindle area Dull blade Width of Deck SGB020...
  • Page 21 Section 5 CONDITION Scalping - Blades Low tire pressures Hitting Dirt or Cutting Very Close to Ground speed too fast the Ground Cutting too low Rough terrain Ground speed too fast Wet grass Width of Deck SGB022 Step Cut Blades not mounted evenly Ridge in Center of Cutting Path Bent blade...
  • Page 22 6.1 PARKING BRAKE ADJUSTMENT WARNING: Do not operate the mower if the parking brake is not operable. Possible severe injury could result. Adjustment Dimension 1/4" Right Foot Pedal Adjustment Nuts ADJUSTMENTS 6.2 FORWARD/REVERSE NEUTRAL ADJUSTMENT Parking Brake Adjustment Nuts Figure 6-1 Adjustments Section 6 Pump Drive Adjustment Nut...
  • Page 23 Section 6 Locknut Bolt Figure 6-2 Throttle Control Adjustment 6.4 CUTTER BRAKE LINKAGE 6.5 FAN BELT ADJUSTMENT 6.3 THROTTLE CONTROL LINKAGE ADJUSTMENT Figure 6-3 Fan Belt Adjustment...
  • Page 24 Figure 6-4 Electric Clutch Drive Belt Adjustment 6.8 ALTERNATOR BELT ADJUSTMENT Adjusting Bolt Adjusting Bolt Location Figure 6-5 Alternator Belt Adjustment 6.9 CUTTER DRIVE BELT ADJUSTMENTS Tension Adjusting Nuts Figure 6-6 Blade Belt Tension Adjustments (Mag-72 Deck Shown) Section 6...
  • Page 25 Section 6 6.10 BELT ALIGNMENT 6.11 CUTTER DECK ADJUSTMENTS Adjusting Nut Figure 6-8 Leveling the Cutter Deck = " Y " " X " = Figure 6-9 Pitch Measurement Figure 6-7 Measuring Height of Deck...
  • Page 26 Adjusting Nut Jam Nut Adjusting Rod Figure 6-10 Adjusting Deck Pitch 6.12 BLADE CUTTING HEIGHT ADJUSTMENT Tape Measure Figure 6-11 Measuring Cutting Edge Height Adjusting Nuts Figure 6-12 Adjusting Nuts Section 6 Blade Height Indicator Rod...
  • Page 27 MAG-61, MAG-72 CUTTER DECK 390S0111...
  • Page 28 MAG-61, MAG-72 CUTTER DECK Ref. Part. No. Number Description 04020-09 Nut, Hex, 5/8-11 43278 Spacer, Cutter Blade 04001-01 Bolt, Hex Head, 1/4-20 x 3/4 Gr.5 48926 Taper Hub, 1.125 Bore 48924 Pulley, 5.75 Dia. 48753 Pulley, 6.35 Dia. 48924 Pulley, 5.75 Dia.
  • Page 29 MAG-61, MAG-72 DECK SUPPORT 29 27 390S0112...
  • Page 30 MAG-61, MAG-72 CUTTER DECK SUPPORT Ref. Part No. Number Description 45733 Cover, Belt 04029-03 Wingnut, Plastic, 3/8-16 04001-52 Bolt, Hex Head, 1/2-13 x 2-1/2 481195 Actuator, Deck Lift 04019-06 Serr. Fl. Hex Nut, 1/2-13 04050-05 Retaining Ring, 1.125 Ext 43356...
  • Page 31 RIDER FRAME 390S0113...
  • Page 32 Ref. Part No. Number Description 46029 Handle, Steering (Includes 2) 48159 Handle Grip 04021-10 Hex Locknut, Elastic Stop, 5/16-18 04040-15 Flatwasher, 5/16 (.375 x .875 x .083) 04001-12 Bolt, Hex Head, 5/16-18 x 1.75 481156 Seat (with Adjuster Rails) 421976 Plate, Seat Mount 04003-11 Carriage Bolt, 3/8-16 x 1-1/4...
  • Page 33 ENGINE DECK 38 10 390S0114...
  • Page 34 Ref. Part No. Number Description 422002 Catch, Hood Latch 04010-01 Screw, Round Head Washer, #10-32 x 1/2 481309 Latch, Hood 04020-01 Hex Nut, #10-32 421801 Stiffener, Hood Engine, Kubota, 28 HP Diesel 422236 Hood 421802 Mounting Plate, Engine 04030-05 Lockwasher, 7/16 04002-10 Bolt, Hex Head, M10 - 1.25 x 25 04021-11...
  • Page 35 RADIATOR/OIL COOLER 390S0115...
  • Page 36 Ref. Part No. Number Description 481207 Hose, Upper Radiator 48136-06 Clamp, Hose 45783 Shroud, Fan 04019-03 Serr. Fl. Hex Nut, 5/16-18 Tank, Coolant Overflow 422192 Mounting Bracket, Coolant Tank 04003-12 Carrage Bolt, 5/16-18 x .75 481286 Radiator with Oil Cooler 45784 Frame, Debris Screen 45785...
  • Page 37 MUFFLER AND AIR CLEANER 390S0116...
  • Page 38 MUFFLER AND AIR CLEANER Ref. Part No. Number Description 48136-08 Hose Clamp 481191 Hose, Air Intake 481333 Cap. Precleaner 04100-03 U-Bolt 481192 Air Cleaner 421981 Mounting Bracket, Air Cleaner 04030-03 Lockwasher, 5/16 04020-03 Nut, Hex, 5/16-18 Gasket, Manifold 481340 Adapter, Manifold 04015-07 Capscrew, Socket Head, M8-1.125 x 20 422029...
  • Page 39 DECK DRIVE SYSTEM 390S0117...
  • Page 40 Ref. Part No. Number Description 04001-101 Bolt, Hex Head, 7/16-20 x 2-1/2 04030-05 Lockwasher, 7/16 481204 Clutch, Electric 481104 Belt, Deck Drive 46827 Spindle, Deck Drive (Includes 6 thru 16) 43321 Shaft, Deck Drive 481024 Seal, 2.00 O.D. 1-1/2 Bore 481022 Roller Bearing (Replace as a set only) 48114-04...
  • Page 41 PUMP AND FAN DRIVE SYSTEMS PART OF ENGINE 390S0118...
  • Page 42 PUMP AND FAN DRIVE SYSTEMS Ref. Part No. Number Description 04021-16 Hex Locknut, 1/2-20 43335 Spacer, Fan 48442 Bearing 04003-19 Carriage Bolt, 1/2-13 x 1-1/4 46872 Bracket, Fan Mounting (Includes 3, 48) 422017 Idler Bracket, Fan Drive 04021-09 Hex Locknut, Elastic Stop, 3/8-16 04041-07 Flat Washer, 3/8 (.391 x .938 x .105) 04003-06...
  • Page 43 INSTRUMENT PANEL 12 11 390S0119...
  • Page 44 Ref. Page No. Number Description 48023 Hourmeter 481183 Gauge, Water Temperature 481306 Gauge, Fuel Level 481184 Voltmeter 46873 Instrument Panel with Decal 42413 Bracket, Fuse Holder 04021-01 Hex Locknut, Elastic Stop, #10-32 04010-11 Screw, Round Head, #10-32 x 1-1/2 04010-01 Screw, Round Head, #10-32 x 1/2 Timer, Glow Plug 04031-01...
  • Page 45 WIRING HARNESS AND ELECTRICAL COMPONENTS 390S0120...
  • Page 46 WIRING HARNESS AND ELECTRICAL COMPONENTS Ref. Page No. Number Description 481216 Actuator, Cutting Height 481185 Wire Harness 481182 Indicator Light, Oil Pressure 48023 Hourmeter 481183 Gauge, Water Temperature 481306 Gauge, Fuel Level 481316 Timer, Delay Circuit 481322 Fuse, 30 Amp Timer, Glow Plug 481182 Indicator Light, Glow Plug...
  • Page 47 CUTTER BRAKE LINKAGE 390S0121...
  • Page 48 Ref. Part No. Number Description 04041-08 Flatwasher, 3/4 (.766 x 1.250 x .060) 04041-08S Flatwasher, 3/4 (.766 x 1.250 x .035) 04050-02 Retaining Ring - .75 Ext 45702 Lever, Clutch Engage 04021-10 Hex Locknut, Elastic Stop, 5/16-18 481163 Spring, Clutch Lever 04019-03 Serr.
  • Page 49 PARKING BRAKE LINKAGE MAG008...
  • Page 50 Ref. Part No. Number Description 48093 Grip, Handle 45716 Lever, Brake 48114-04 Grease Fitting 04050-01 Retaining Ring, .625 Ext 04020-05 Hex Locknut, Elastic Stop, 3/8-16 04041-07 Washer, Flat, 3/8 (.391 x .938 x .105) 48464 Ball Joint, 3/8-24 RH Thd 04021-09 Hex Locknut, Elastic Stop, 3/8-16 45782...
  • Page 51 THROTTLE LINKAGE 390S0123...
  • Page 52 Ref. Part Number Description 04003-02 Carriage Bolt, 1/4-20 x .75 421776 Mounting Base, Throttle 04019-02 Serr. Fl. Hex Nut, 1/4-20 04001-13 Bolt, Hex Head, 5/16-18 x 2-3/4 46877 Lever, Throttle (Includes 6, 7) 48114-05 Grease Fitting 48100-04 Bushing, Oilite - .50 I.D. 44115 Rod, Throttle Control 04002-11...
  • Page 53 FORWARD/REVERSE LINKAGE 390S0124...
  • Page 54 FORWARD/REVERSE LINKAGE Ref. Part No. Number Description 04021-09 Hex Locknut, Elastic Stop, 3/8-16 48544 Ball Joint, 3/8-24 LH Thread 04041-07 Flatwasher, 3/8 (.391 x .938 x .105) 04003-05 Carriage Bolt, 3/8-16 x 1-1/2 04004-22 Rod, Transmission Control 45708 Bellcrank, Pump Control 04021-08 Hex Locknut, Elastic Stop, 1/4-20 04001-59...
  • Page 55 FUEL TANK AND LINES 390S0125...
  • Page 56 Ref. Part No. Number Description 46933 Fuel Tank (Includes 2, 3, 4) 481313 Fitting, Return Line 481304 Sender Unit, Fuel Level (Includes Gasket and Screws) 481312 Fitting, Hose 04017-16 Serr. Fl. Hex Head Capscrew, 5/16-18 x 3/4 481298 Cap, Diesel Fuel 45864 Fill Neck Wlmt.
  • Page 57 HYDRAULIC CIRCUITS 390S0126...
  • Page 58 Ref. Part No. Number Description 481292 Hose, Pump to Oil Cooler, 5/8 Hose Barb 48136-04 Clamp, Hose 481301-01 Elbow, 90°, 481202 Hose, Oil Cooler to Reservoir, 5/8 & 3/8 Hose Barb 48939 Elbow, 90° 48059-01 Clamp, Hose 48936-02 Coupling, Hose, 7/8-14 SAE x 5/8 Hose Barb 48350-13 Elbow, 90°, 1-1/16-12 JIC x 7/8-14 O-Ring 481203-01...

  • Page 59: Control Panel

    PINK FUSE HOLDER *GLOW PLUG TIMER LT. BLU PURP *SYNCHO-START RELAY PINK PURP FUEL SENDER *PARKING BRAKE PINK SWITCH PINK/BLK PURP *SYNCHO-START ENGINE PINK/BLK ORN/WHT *CUTTING HEIGHT ACTUATOR *DELAY MODULE TIMER CONTROL PANEL *VOLTMETER *FUEL GAUGE TEMPERATURE GAUGE PINK *GLOW PLUG LIGHT ORN/WHT *IGNITION...

  • Page 60: Heavy Duty

    REPLACEMENT DECALS AND INFORMATION DANGER SPINNING BLADE KEEP CLEAR CONTACT CAN INJURE 48071 7a, 7b HEAVY DUTY COMMERCIAL 48072 WARNING INSTALL BELT COVER BEFORE OPERATING MACHINE READ OPERATOR'S MANUAL 481039 Ref. Part No. Number Description 48071 Decal, Danger - Spinning Blades 481040 Decal, Warning - Rotating Blades 481326...
  • Page 61 GREASE FITTING LUBRICATION CHART LUBRICATION LOCATION 1. Cutter Drive Spindle 2. Cutter Deck Spindles 3. Caster Wheel Bearing 4. Caster Wheel Pivot 5. Electric Clutch Belt Idler Arm 6. Cutter Drive Shaft 7. Cutter Belt Idler Arms 8. Deck Support Pivot 9.

  • Page 63: Specifications

    ENGINE General Type ... Heavy Duty Industrial/Commercial Diesel Brand ... Kubota 28 HP Super 5 Series, Electric Start Model ... D1105-B Horsepower ... SAE Gross Intermittent, 28 HP @ 3000 RPM Type ... Horizontal Shaft, Water Cooled, 4-Cycle Diesel Displacement ... 1123 cc. Low Idle ...

  • Page 64: Cutter Deck

    Mag-72 ... 72 in. Blade Size: Mag-61 ... 1/4 thick x 21" long, milled edge, 5150 alloy steel Mag-72 ... 1/4 thick x 24-1/2" long, milled edge, 5150 alloy steel Blade Spindles ... Cast Iron with Easy Removable Taper Hubs Deck Drive ...
