Washing Machine user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/global/register WF-J1254(V/S/C/R) WF-J1054(V/S/C/R) WF-J854(V/S/C/R) WF-B1254(V/S/C/R) WF-B1054(V/S/C/R) WF-B854(V/S/C/R)
1. Child Lock The Child Lock function keeps curious little hands out of the washer. This safety feature ensures, that children do not toy with the operation of the washer. A beep will alert you when the Child Lock is activated.
Always observe Safety Precautions when using your washer. See “Important Safety Instructions” on the next page. WARNING Never try to repair the washer on your own. There is dangerous voltage inside this washer. If the washer needs to be repaired, call an authorized service center near you. SAVE THESE INSTRUCTIONS...
Any material on which you have used a cleaning solvent, or which is saturated with flammable liquids or solids, should not be placed in the clothes washer until all traces of these liquids or solids and their fumes have been removed.
16. Before the appliance is removed from service or discarded, remove the door to the washing compartment. 17. Do not sit on top of the clothes washer. 18. Do not use heat to dry articles containing foam rubber or similarly textured rubber-like materials.
Page 6
Do not cut or remove the third (ground) prong from the power cord under any circumstances. WARNING PREFERRED METHOD OF GROUNDING Plug the three-prong power cord into a properly grounded outlet of standard 120 VAC, 60 Hz. Your washer should be the only appliance on this circuit. SAVE THESE INSTRUCTIONS 6_ Safety information...
contents INSTALLING THE WASHING WASHING A LOAD OF LAUNDRY MAINTAINING THE WASHING TROUBLESHOOTING PROGRAM CHART Unpacking the Washing Machine MACHINE Overview of the washing machine Selecting a location Adjusting the leveling feet Removing the shipping bolts Connecting the water supply hose Positioning the drain hose Overview of the control panel Putting detergent in the washing machine...
Unpack your washing machine and inspect it for transit damage. Also make sure that you have received all of the items shown below. If the washing machine was damaged during transport or you do not have all of the items, contact your Samsung dealer immediately. OVERVIEW OF THE WASHING MACHINE...
2. Tighten the locking nut by turning it with the supplied wrench. • Place the washer on a sturdy, flat surface. If the washer is placed on an uneven or weak surface, noise or vibration occurs. (Only a l degree angle is allowed.) REMOVING THE SHIPPING BOLTS Before using the washing machine, you must remove all of the shipping bolts from the back of the unit.
The drain pipe branch must be above the sink siphon so that the end of the hose is at least 24 inches above the ground. ln a drain pipe Samsung recommends that you use a 26 inch high vertical pipe; it must be no shorter than 24 inches and no longer than 35 inches. 10_ Installing the washing machine...
washing a load of laundry OVERVIEW OF THE CONTROL PANEL Digital graphic Displays the remaining wash cycle time, all washing information and error display messages. When the selected wash cycle is finished, a melody will sound. Signal key Press the button repeatedly to cycle through the available melody options. (Melody1 .
Page 12
Press and hold down the Soil Level + Spin button for 2-3 seconds. The “Child Lock” can only be activated when the washer is on. Once you set the Child Lock function, no button will be active except the Child Lock POWER button.
WASHING CLOTHES USING FUZZY LOGIC Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Logic” automatic control system. When you select a wash program, the machine will set the correct temperature, washing time, and washing speed.
washing a load of laundry WASHING CLOTHES MANUALLY You can wash clothes manually without using the “Fuzzy Logic” feature. To do so: 1. Turn on your sink’s water faucet. 2. Press the POWER button on the washing machine. 3. Open the door. 4.
WASHING TIPS AND HINTS Sorting your laundry: Sort your laundry according to the following characteristics: • Type of fabric care label symbol: Sort laundry into cottons, mixed fibers, synthetics, silks, wools and rayon. • Color: Divide whites and colors. Wash new, colored items separately. Size: Placing items of different sizes in the same load will improve the washing action.
4. Allow all the water to flow into a bowl. Keep a bucket on hand to empty water from the bowl. While emptying the washer, the water flow can be stopped by pinching the tube. 5. Reinsert the drain tube and screw the cap back on.
CLEANING THE DETERGENT DRAWER AND RECESS 1. Press the release lever on the inside of the detergent drawer and pull it out. 2. Remove the cap from compartment 3. Wash all of the parts under running water. 4. Clean the drawer recess with an old toothbrush. 5.
maintaining the washing machine CLEANING THE WATER HOSE MESH FILTER You should clean the water hose mesh filter at least once a year, or when you see the following error message on the display: To do this: 1. Turn off the water source to the washing machine. 2.
1. Try to remedy the problem (See “Troubleshooting” on this page). 2. Repeat what was done before the malfunction occured. 3. If the malfunction persists, call after-sales service and describe the problem. Call 1-800-SAMSUNG (726-7864) or visit the website at www.samsung.com Make sure the door is firmly closed.
program chart PROGRAM CHART user option) Program WF-J1254 WF-B1254 Normal 1200 Colors 1200 Perm Press Delicates Wool Handwash Quick 1200 Towels 1200 Heavy Soil 1200 Mixed Load Calm Wash PROGRAM TYPE OF WASH Normal Average or lightly soiled cottons, bed linen, table linen, underwear, towels, shirts, etc.
appendix WASH/RINSE TEMPERATURE WASH/RINSE TEMPERATURE LOAD TYPE Hot/Warm Hot/Cold Warm/Warm Warm/Cold Cold/Cold FABRIC CARE CHART Resistant material Delicate fabric Item may be washed at 194 ˚F Item may be washed at 140 ˚F Item may be washed at 104 ˚F Item may be washed at 86 ˚F Item may be hand washed Dry clean only...
DIMENSION WATER PRESSURE NET WEIGHT PAPER PACKAGE Wt PLASTIC MODEL SPIN REVOLUTION 22_ Appendix FRONT LOADING WASHER WF-B1254/B1054/B854 W23.54 x D21.65 x H33.23 inches 50 kPa ~ 800 kPa 156.53 lb 5.51 lb 2.20 lb WF-J1254/B1254 1200 WF-J1254/J1054/J854 W23.54 x D23.62 x H33.23 inches...
Parts: 1 year Samsung further warrants that if this product fails to operate properly within the specified warranty period and the failure is due to improper workmanship or defective material, Samsung will repair or replace the product at its option.
Page 24
QUESTIONS OR COMMENTS? Country CALL OR VISIT US ONLINE AT 1-800-SAMSUNG(7267864) www.samsung.com Code No. DC68-02455C_EN...
Page 25
Lavadora manual del usuario imagine las posibilidades Gracias por comprar un producto Samsung. Para recibir un servicio más completo, registre su producto en www.samsung.com/global/register WF-J1254(V/S/C/R) WF-J1054(V/S/C/R) WF-J854(V/S/C/R) WF-B1254(V/S/C/R) WF-B1054(V/S/C/R) WF-B854(V/S/C/R)
Desarrollado por el servicio de tecnología en procesos digitales de reconocimiento mundial de Samsung, la función Easy Iron es un programa de lavado especializado que le ayudará a disminuir las arrugas de las prendas delicadas, gracias a lo cual contará...
Page 27
Felicitaciones por la compra de la nueva lavadora de Samsung. Este manual contiene información importante acerca de la instalación, el uso y el cuidado del electrodoméstico. Lea detenidamente estas instrucciones a fin de aprovechar al máximo los múltiples beneficios y funciones de la lavadora.
información sobre seguridad Registre el número de serie que se encuentra en la parte posterior de la lavadora y la fecha de compra en el espacio que se brinda a continuación. Se recomienda guardar el recibo de su compra junto con este manual para contar con los beneficios del servicio de garantía.
Page 29
c. En ciertas circunstancias, se puede producir gas hidrógeno en un sistema de agua caliente que no se ha usado durante 2 semanas o más. EL GAS HIDRÓGENO ES EXPLOSIVO. Si el sistema de agua caliente no fue utilizado durante dicho período, antes de usar la lavadora o la lavadora y la secadora combinadas, abra las llaves de agua caliente y deje correr el agua por varios minutos.
Page 30
información sobre seguridad INSTRUCCIONES DE CONEXIÓN A TIERRA Este electrodoméstico debe conectarse a tierra. En caso de que el electrodoméstico funcione mal o se descomponga, la conexión a tierra reducirá el riesgo de descarga eléctrica al ofrecer una vía de menos resistencia a la corriente eléctrica. Este electrodoméstico está equipado con un cable que incluye un conductor y un enchufe de conexión a tierra.
Page 31
contenido INSTALACIÓN DE LA LAVADORA LAVADO DE UNA CARGA DE ROPA MANTENIMIENTO DE LA LAVADORA SOLUCIÓN DE PROBLEMAS TABLA DE PROGRAMAS Desembalaje de la lavadora Descripción general de la lavadora Seleccionar una ubicación Ajuste de las patas niveladoras Retirar los tornillos de transporte Conexión de la manguera de suministro de agua Colocación de la manguera de desagüe...
Compruebe además que haya recibido todos los elementos que se muestran a continuación. Si la lavadora sufrió daños durante el transporte, o si falta algún elemento, comuníquese con su distribuidor de Samsung de inmediato. DESCRIPCIÓN GENERAL DE LA LAVADORA Cajón para el...
SELECCIONAR UNA UBICACIÓN Antes de instalar la lavadora, seleccione una ubicación que reúna las siguientes características: • Una superficie dura y nivelada (si la superficie es irregular, consulte “Ajuste de las patas niveladoras” más adelante) • Alejada de la luz solar directa. •...
24 pulgadas del suelo. En una tubería de desagüe Samsung recomienda que utilice una tubería vertical de al menos 26 pulgadas de altura; en cualquier caso no debe tener menos de 24 pulgadas ni más de 35 pulgadas.
lavado de una carga de ropa DESCRIPCIÓN GENERAL DEL PANEL DE CONTROL Pantalla gráfica Muestra el tiempo restante de lavado, toda la información del proceso de lavado y digital los mensajes de error. Presione este botón repetidamente para rotar entre las opciones de melodías Dispositivo de disponibles: señalización...
Page 36
lavado de una carga de ropa Presione el botón Spin (Centrifugar) para seleccionar la velocidad de centrifugado adecuada en cada carga. La luz que se encuentra junto a la velocidad de centrifugado se encenderá. Presione la tecla repetidamente para desplazarse por las opciones de velocidad de centrifugado. Extra High (Extra Alto): Utilícela para la ropa interior y los algodones resistentes.
Su nueva lavadora facilita el lavado de la ropa gracias al sistema de control automático “Fuzzy Logic” de Samsung. Cuando seleccione un programa de lavado, la lavadora elegirá la temperatura correcta, el tiempo de lavado y la velocidad de lavado.
lavado de una carga de ropa LAVADO MANUAL DE ROPA Se puede lavar la ropa manualmente sin usar la función “Fuzzy Logic”. Para hacerlo: 1. Abra la llave de agua del fregadero. 2. Presione el botón POWER (ENCENDIDO) de su lavadora. 3.
SUGERENCIAS Y CONSEJOS DE LAVADO Clasificación de la ropa: Clasifique la ropa de acuerdo con las siguientes características: • Etiqueta de indicaciones del tipo de tela: Clasifique la ropa según su composición: algodón, mezclas, sintética, seda, lana y rayón. • Color: Separe la ropa blanca de la ropa de color.
mantenimiento de la lavadora DESAGÜE DE LA LAVADORA EN CASO DE EMERGENCIA 1. Desenchufe la lavadora. 2. Abra la tapa del filtro utilizando una moneda o una llave. 3. Desenrosque el tapón del desagüe de emergencia girándolo hacia la izquierda. Sujete el tapón del extremo del tubo de desagüe de emergencia y tire hacia fuera lentamente hasta que el tubo salga unos 6 pulgadas.
LIMPIEZA DEL CAJÓN DE DETERGENTE Y EL HUECO DEL CAJÓN 1. Presione la palanca de seguridad en el interior del cajón de detergente y extráigalo. 2. Retire el tapón de compartimiento 3. Lave todas las partes con agua corriente. 4. Limpie el hueco del cajón con un cepillo de dientes viejo. 5.
mantenimiento de la lavadora LIMPIEZA DEL FILTRO DE MALLA DE LA MANGUERA DE AGUA Debe limpiar el filtro de malla de la manguera de agua al menos una vez por año, o cuando vea el siguiente mensaje de error en la pantalla: Para hacerlo: 1.
1. Intente solucionar el problema (Consulte “Solución de problemas” en esta página). 2. Repita lo que hizo antes de que el desperfecto ocurriera. 3. Si el problema persiste, llame al servicio posventa y describa el problema. 1-800-SAMSUNG(7267864) www.samsung.com Asegúrese de que la puerta esté bien cerrada.
tabla de programas TABLA DE PROGRAMAS opción del usuario) Programa Normal (Normal) Colors (Ropa de Color) Perm Press (Liviano) Delicates (Delicada) Wool (Lana) Handwash (Lavar a Mano) Quick (Rápido) Towels (Toallas) Heavy Soil (Super Pesado) Mixed Load (Carga Mezclada) Calm Wash (Lavado Suave) PROGRAMA TIPO DE LAVADO...
apéndice TEMPERATURA DE LAVADO/ENJUAGUE TEMPERATURA DE TIPO DE CARGA LAVADO/ENJUAGUE Prendas demasiado sucias. Hot/Warm (Fría/Tibia) Hot/Cold (Caliente/Fría) Ropa blanca y prendas muy sucias que no destiñen. Warm/Warm (Tibia/Tibia) Algunas prendas delicadas y que no destiñen. Prendas de color moderadamente sucias; la mayoría de las prendas de Warm/Cold (Tibia/Fría) fácil cuidado (EASY CARE) y de plancha permanente.
apéndice ADVERTENCIAS ELÉCTRICAS Para reducir el riesgo de incendio, descarga eléctrica y otras lesiones, tome las siguientes precauciones: • Utilice la lavadora únicamente con el tipo de fuente de alimentación que se indica en la etiqueta de características técnicas. Si no está seguro del tipo de alimentación de su vivienda, consulte al distribuidor del electrodoméstico o a la compañía de suministro eléctrico local.
Asimismo, Samsung garantiza que si este producto no funciona adecuadamente dentro del período de la garantía especificado y la falla se debe a una mano de obra inapropiada o a material defectuoso, Samsung reparará o reemplazará el producto a su discreción.
Page 48
¿TIENE ALGUNA PREGUNTA O ALGÚN COMENTARIO? País LLAME AL O VISÍTENOS EN LÍNEA EN 1-800-SAMSUNG(7267864) www.samsung.com Código N.° DC68-02455C_MES...
