York Predator ZT037 Technical Manual

R-410a, zt series, 3 - 5 ton, 60 hertz
Hide thumbs Also See for Predator ZT037:

Advertisement

Table of Contents

See also: Instruction and Installation Manual
TECHNICAL GUIDE
R-410A
ZT SERIES
3 - 5 TON
60 Hertz
ZT 3 THROUGH 5 TON
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE

Description

ASHRAE 90.1 COMPLIANT
®
®
YORK
Predator
units are convertible single packages with a
common footprint cabinet and common roof curb for all 3
through 5 ton models. The units were designed for light
commercial applications and can be easily installed on a roof
curb, slab, or frame.
®
All Predator
units are self-contained and assembled on rigid
full perimeter base rails allowing for 3-way forklift access and
overhead rigging. Every unit is completely charged, wired,
piped, and tested at the factory to provide a quick and easy field
installation.
®
Predator
units in all tonnage sizes are convertible between
side airflow and down airflow, with corresponding economizer if
economizer option is desired.
®
Predator
units are available in the following configurations:
cooling only, cooling with electric heat and cooling with gas
heat. Electric heaters are available as factory-installed options
or field-installed accessories.
All units meet ASHRAE 90.1 single-zone variable supply air
volume standard. Featuring a variable frequency drive on 3
through 5 ton ZT models.
Tested in accordance with:
5167821-YTG-J-0518

Advertisement

Table of Contents
loading

Related Manuals for York Predator ZT037

Summary of Contents for York Predator ZT037

  • Page 1: Description

    R-410A Description ZT SERIES ASHRAE 90.1 COMPLIANT ® ® YORK Predator units are convertible single packages with a 3 - 5 TON common footprint cabinet and common roof curb for all 3 60 Hertz through 5 ton models. The units were designed for light commercial applications and can be easily installed on a roof curb, slab, or frame.

  • Page 2: Table Of Contents

    Roof curbs in eight-and steel tubular heat fourteen-inch heights. exchanger for long life Roof curbs for transitioning (stainless steel option) from York Sunline™ footprint to the ZT Series footprint Two stage gas heating to are available Side entry power maintain warm, comfortable...

  • Page 3: Nomenclature

    5167821-YTG-J-0518 Nomenclature ® 3-5 Ton York Model Number Nomenclature Z T 037 C A 2 A 1 Product Generation Product Category 1 = First Generation 2 = Second Generation Z = A/C, Single Pkg., R-410A Cabinet Options Product Identifier A = Std Cabinet...

  • Page 4: Prior Nomenclature

    049 = 4 Ton Honeywell Controller, DFS, APS 061 = 5 Ton Novar Controller, DFS, APS York Commercial Comfort System (YCCS) Rtu Controller Simplicity®Smart Equipment w/Comm Card (BACnet, N2, Mod-Bus) Heat Type and Nominal Heat Capacity Fault Detection and Diagnostics (FDD) C00 = Cooling Only.

  • Page 5: Features And Benefits

    5167821-YTG-J-0518 ® Features and Benefits • Balanced Heating – The Predator two stage gas heating offers “Ultimate Heating Comfort” with a balance between Standard Features for Ultra High Efficiency 3-5 Ton and 2 stage gas heating. The first stage of a gas heat ®...
  • Page 6 0°F outdoor ambient without additional components or intervention. Factory Installed Options Optionally, the control board can be programmed to ® YORK offers several equipment options factory installed, for lockout the compressors when the outdoor air ® line.
  • Page 7 • Smart Equipment™ with Communication Option trouble-free operation in corrosive environments. Control - The York® Smart Equipment™ with • Electric Heaters - The electric heaters range from 3kW to Communication Option Control is factory installed. It 24kW and are available in all the voltage options of the includes all the features of the Smart Equipment™...
  • Page 8 Field Installed Accessories • Coil Guard - Field installed decorative wire coil guard. ® YORK offers several equipment accessories for field • Hail Guard - This kit includes a sloped hood which installs ® installation, for the Predator line.
  • Page 9 5167821-YTG-J-0518 • Burglar Bars - Mount in the supply and return openings Ultra High Efficiency 3-5 Ton units (with or without an to prevent entry into the duct work. economizer) operate with two-stage heat/two-stage cool or two-stage cooling only thermostats, depending upon •...
  • Page 10 5167821-YTG-J-0518 Accessories (Continued) Field Installed Accessories - Electric Heat MODEL VOLTAGE DESCRIPTION WHERE USED 2TP04510325 3kW Electric Heat All 42" Cabinet 3 Ton Models 2TP04510346 2TP04510625 6kW Electric Heat All 42" Cabinet 3, 4 and 5 Ton Models 2TP04510646 2TP04510825 2TP04510846 9kW Electric Heat All 42"...

  • Page 11: Guide Specifications

    Job site selected brake horsepower shall not ® exceed the motors nameplate horsepower rating plus the ser- YORK® Predator units are convertible single packages with a vice factor. Units shall be designed to operate within the service common footprint cabinet and common roof curb for all 3 factor.
  • Page 12 5167821-YTG-J-0518 Unit Controls: excessive temperature. The Heating Section assembly shall slide out of the unit for easy maintenance and service. Units a. Unit shall be complete with self-contained low-voltage with Electric Heating Sections shall be wired for a single point control circuit protected by a resettable circuit breaker on power supply with branch circuit fusing (where required).
  • Page 13 5167821-YTG-J-0518 optional indoor blower motors that provide higher static • STAINLESS STEEL HEAT EXCHANGER – For output and/or higher airflow. applications in a corrosive environment, this option provides a full stainless steel heat exchanger assembly. • CONVENIENCE OUTLET (POWERED/NON-POWERED)– Unit can be provided with an optional 120VAC GFCI outlet •...

  • Page 14: Physical Data

    5167821-YTG-J-0518 Physical Data ZT037-061 Models Component ZT037 ZT049 ZT061 Nominal Tonnage AHRI COOLING PERFORMANCE Gross Capacity @ AHRI A point (MBh) 38000 51200 61600 AHRI net capacity (MBh) 37000 50000 60000 13.05 14.0 13.00 SEER (208/230 & 460V) 17.0 17.5 16.3 SEER (575V) 15.95...
  • Page 15 5167821-YTG-J-0518 ZT037-061 (Continued) Models Component ZT037 ZT049 ZT061 Nominal Tonnage CONDENSER FAN DATA Quantity of fans Fan diameter (Inch) Type Prop Prop Prop Drive type Direct ECM Direct ECM Direct ECM Quantity of motors Motor HP each No. speeds Var. Var.

  • Page 16: Capacity Performance

    5167821-YTG-J-0518 Capacity Performance ZT037-061 Cooling Capacities ZT037 High Speed Compressor (3.0 Ton) Temperature of Air on Condenser Coil Air on Evaporator Coil Sensible Capacity (MBh) Sensible Capacity (MBh) Total Total Total Total Capacity Input Return Dry Bulb (°F) Capacity Input Return Dry Bulb (°F) (MBh) (kW)
  • Page 17 5167821-YTG-J-0518 ZT037 High Speed Compressor (3.0 Ton) (Continued) Temperature of Air on Condenser Coil Air on Evaporator Coil Sensible Capacity (MBh) Sensible Capacity (MBh) Total Total Total Total Capacity Input Return Dry Bulb (°F) Capacity Input Return Dry Bulb (°F) (MBh) (kW) (MBh)
  • Page 18 5167821-YTG-J-0518 ZT037 Low Speed Compressor (3.0 Ton) Temperature of Air on Condenser Coil Air on Evaporator Coil Sensible Capacity (MBh) Sensible Capacity (MBh) Total Total Total Total Capacity Input Return Dry Bulb (°F) Capacity Input Return Dry Bulb (°F) (MBh) (kW) (MBh) (kW)
  • Page 19 5167821-YTG-J-0518 ZT037 Low Speed Compressor (3.0 Ton) (Continued) Temperature of Air on Condenser Coil Air on Evaporator Coil Sensible Capacity (MBh) Sensible Capacity (MBh) Total Total Total Total Capacity Input Return Dry Bulb (°F) Capacity Input Return Dry Bulb (°F) (MBh) (kW) (MBh)
  • Page 20 5167821-YTG-J-0518 ZT049 High Speed Compressor (4.0 Ton) Temperature of Air on Condenser Coil Air on Evaporator Coil Sensible Capacity (MBh) Sensible Capacity (MBh) Total Total Total Total Capacity Input Return Dry Bulb (°F) Capacity Input Return Dry Bulb (°F) (MBh) (kW) (MBh) (kW)
  • Page 21 5167821-YTG-J-0518 ZT049 High Speed Compressor (4.0 Ton) (Continued) Temperature of Air on Condenser Coil Air on Evaporator Coil Sensible Capacity (MBh) Sensible Capacity (MBh) Total Total Total Total Capacity Input Return Dry Bulb (°F) Capacity Input Return Dry Bulb (°F) (MBh) (kW) (MBh)
  • Page 22 5167821-YTG-J-0518 ZT049 Low Speed Compressor (4.0 Ton) Temperature of Air on Condenser Coil Air on Evaporator Coil Sensible Capacity (MBh) Sensible Capacity (MBh) Total Total Total Total Capacity Input Return Dry Bulb (°F) Capacity Input Return Dry Bulb (°F) (MBh) (kW) (MBh) (kW)
  • Page 23 5167821-YTG-J-0518 ZT049 Low Speed Compressor (4.0 Ton) (Continued) Temperature of Air on Condenser Coil Air on Evaporator Coil Sensible Capacity (MBh) Sensible Capacity (MBh) Total Total Total Total Capacity Input Return Dry Bulb (°F) Capacity Input Return Dry Bulb (°F) (MBh) (kW) (MBh)
  • Page 24 5167821-YTG-J-0518 ZT061 High Speed Compressor (5.0 Ton) Temperature of Air on Condenser Coil Air on Evaporator Coil Sensible Capacity (MBh) Sensible Capacity (MBh) Total Total Total Total Capacity Input Return Dry Bulb (°F) Capacity Input Return Dry Bulb (°F) (MBh) (kW) (MBh) (kW)
  • Page 25 5167821-YTG-J-0518 ZT061 High Speed Compressor (5.0 Ton) (Continued) Temperature of Air on Condenser Coil Air on Evaporator Coil Sensible Capacity (MBh) Sensible Capacity (MBh) Total Total Total Total Capacity Input Return Dry Bulb (°F) Capacity Input Return Dry Bulb (°F) (MBh) (kW) (MBh)
  • Page 26 5167821-YTG-J-0518 ZT061 Low Speed Compressor (5.0 Ton) Temperature of Air on Condenser Coil Air on Evaporator Coil Sensible Capacity (MBh) Sensible Capacity (MBh) Total Total Total Total Capacity Input Return Dry Bulb (°F) Capacity Input Return Dry Bulb (°F) (MBh) (kW) (MBh) (kW)
  • Page 27 5167821-YTG-J-0518 ZT061 Low Speed Compressor (5.0 Ton) (Continued) Temperature of Air on Condenser Coil Air on Evaporator Coil Sensible Capacity (MBh) Sensible Capacity (MBh) Total Total Total Total Capacity Input Return Dry Bulb (°F) Capacity Input Return Dry Bulb (°F) (MBh) (kW) (MBh)
  • Page 28 5167821-YTG-J-0518 Drive Selection Determine side or bottom supply duct Application. Determine desired airflow. Calculate or measure the amount of external static pressure. • Add or deduct any additional static resistance from “Additional Static Resistance Table”. Using the operating point determined from steps 1, 2 & 3, locate this point on the appropriate supply air blower performance table.
  • Page 29 5167821-YTG-J-0518 Altitude and Temperature Correction for CFM, Static Pressure the indoor blower tables for high altitude applications, certain corrections are necessary. and Power. A centrifugal fan is a "constant volume" device. This means that, if The information below should be used to assist in application of the rpm remains constant, the CFM delivered is the same product when being applied at altitudes at or exceeding 1000 feet regardless of the density of the air.
  • Page 30 5167821-YTG-J-0518 Indoor Blower Specifications Motor Motor Sheave Blower Sheave Size Airflow Model Datum Dia. Datum Dia. Belt (Tons) Option Eff. Frame Bore (in.) Model Bore (in.) Model (in.) (in.) Std. 1-1/2 1725 0.86 1.15 2.4 - 3.4 1VL40 AK79 H. Static 1-1/2 1725 0.86 1.15 2.4 - 3.4...
  • Page 31 5167821-YTG-J-0518 Additional Static Resistance Electric Heat kW Size Model CFM Cooling Only Economizer 4” Pleated Filter (Tons) 0.05 -0.05 0.01 0.00 0.00 0.00 0.01 0.01 0.01 1000 0.05 -0.03 0.02 0.00 0.00 0.00 0.02 0.02 0.02 1100 0.04 -0.02 0.03 0.01 0.01 0.01...

  • Page 32: Airflow Performance

    5167821-YTG-J-0518 Airflow Performance ZT037-061 Side Duct Application ZT037 (3.0 Ton) Side Duct Available External Static Pressure - IWG Air Flow (CFM) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP Standard 1.5 Hp &...
  • Page 33 5167821-YTG-J-0518 ZT037-061 Bottom Duct Application ZT037 (3.0 Ton) Bottom Duct Available External Static Pressure - IWG Air Flow (CFM) RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP Standard 1.5 Hp & Drive High Static 1.5 Hp &...

  • Page 34: Sound Performance

    5167821-YTG-J-0518 Sound Performance Indoor Sound Power Levels (3 thru 5 Ton) Indoor Sound Power Levels (Horizontal Ducted Inlet, Standard Static Belt Drive) UNIT DESCRIPTION / MODEL ZT037 / 3 Ton / Standard Static Belt Drive TEST CONFIGURATION Horizontal (Side Return) Ducted Inlet Indoor Blower Speed (RPM) 612 - 3 Turns Open Equivalent 709 - 1 Turn Open Equivalent...
  • Page 35 5167821-YTG-J-0518 UNIT DESCRIPTION / MODEL ZT061 / 5 Ton / Standard Static Belt Drive TEST CONFIGURATION Horizontal (Side Return) Ducted Inlet Indoor Blower Speed (RPM) 814 - 3 Turns Open Equivalent 918 - 1 Turn Open Equivalent External Static Pressure (IWG) Airflow (CFM) 1700 1950...
  • Page 36 5167821-YTG-J-0518 UNIT DESCRIPTION / MODEL ZT049 / 4 Ton / Standard Static Belt Drive TEST CONFIGURATION Horizontal (Side Supply) Ducted Discharge Indoor Blower Speed (RPM) 610 - 3 Turns Open Equivalent 710 - 1 Turn Open Equivalent External Static Pressure (IWG) Airflow (CFM) Blower Motor BHP 0.37...
  • Page 37 5167821-YTG-J-0518 Indoor Sound Power Levels (Vertical Ducted Inlet, Standard Static Belt Drive) UNIT DESCRIPTION / MODEL ZT037 / 3 Ton / Standard Static Belt Drive TEST CONFIGURATION Vertical (Bottom Return) Ducted Inlet Indoor Blower Speed (RPM) 609 - 3 Turns Open Equivalent 708 - 1 Turn Open Equivalent External Static Pressure (IWG) Airflow (CFM)
  • Page 38 5167821-YTG-J-0518 UNIT DESCRIPTION / MODEL ZT061 / 5 Ton / Standard Static Belt Drive TEST CONFIGURATION Vertical (Bottom Return) Ducted Inlet Indoor Blower Speed (RPM) 812 - 3 Turns Open Equivalent 915- 1 Turn Open Equivalent External Static Pressure (IWG) Airflow (CFM) 1575 1800...
  • Page 39 5167821-YTG-J-0518 UNIT DESCRIPTION / MODEL ZT049 / 4 Ton / Standard Static Belt Drive TEST CONFIGURATION Vertical (Bottom Supply) Ducted Discharge Indoor Blower Speed (RPM) 609 - 3 Turns Open Equivalent 712 - 1 Turn Open Equivalent External Static Pressure (IWG) Airflow (CFM) Blower Motor BHP 0.32...
  • Page 40 5167821-YTG-J-0518 Indoor Sound Power Levels (Horizontal Ducted Inlet, High Static Belt Drive) UNIT DESCRIPTION / MODEL ZT037 / 3 Ton / High Static Belt Drive TEST CONFIGURATION Horizontal (Side Return) Ducted Inlet Indoor Blower Speed (RPM) 876 - 4 Turns Open Equivalent 1,064 - 1/2 Turn Open Equivalent 1,190 - 2.5 Turns Open Equivalent External Static Pressure (IWG)
  • Page 41 5167821-YTG-J-0518 UNIT DESCRIPTION / MODEL ZT061 / 5 Ton / High Static Belt Drive TEST CONFIGURATION Horizontal (Side Return) Ducted Inlet Indoor Blower Speed (RPM) 1,012- 5.5 Turns Open Equivalent 1,134 - 3 Turns Open Equivalent 1,174 - 2 Turns Open Equivalent External Static Pressure (IWG) Nominal Airflow (CFM) 2,000...
  • Page 42 5167821-YTG-J-0518 UNIT DESCRIPTION / MODEL ZT049 / 4 Ton / High Static Belt Drive TEST CONFIGURATION Horizontal (Side Supply) Ducted Discharge Indoor Blower Speed (RPM) 922 - 6 Turns Open Equivalent 1,069 - 4 Turns Open Equivalent 1,165 - 2.5 Turns Open Equivalent External Static Pressure (IWG) Nominal Airflow (CFM) 1,600...
  • Page 43 5167821-YTG-J-0518 Indoor Sound Power Levels (Vertical Ducted Inlet, High Static Belt Drive) UNIT DESCRIPTION / MODEL ZT037 / 3 Ton / High Static Belt Drive TEST CONFIGURATION Vertical (Bottom Return) Ducted Inlet Indoor Blower Speed (RPM) 927 - 3 Turns Open Equivalent 1,085 - 1/2 Turn Open Equivalent 1,190 - 2.5 Turns Open Equivalent External Static Pressure (IWG)
  • Page 44 5167821-YTG-J-0518 UNIT DESCRIPTION / MODEL ZT061 / 5 Ton / High Static Belt Drive TEST CONFIGURATION Vertical (Bottom Return) Ducted Inlet Indoor Blower Speed (RPM) 1,039 - 5 Turns Open Equivalent 1,143 - 3 Turns Open Equivalent 1,201 - 2 Turns Open Equivalent External Static Pressure (IWG) Nominal Airflow (CFM) 2,000...
  • Page 45 5167821-YTG-J-0518 UNIT DESCRIPTION / MODEL ZT049 / 4 Ton / High Static Belt Drive TEST CONFIGURATION Vertical (Bottom Supply) Ducted Discharge Indoor Blower Speed (RPM) 962 - 5.5 Turns Open Equivalent 1,092 - 3.5 Turns Open Equivalent 1,190 - 2.0 Turns Open Equivalent External Static Pressure (IWG) Nominal Airflow (CFM) 1,600...

  • Page 46: Electrical Data

    5167821-YTG-J-0518 Electrical Data ZT037-061 Standard Indoor Blower - Without Powered Convenience Outlet OD Fan Supply Max Fuse Compressors Max Fuse Motors Blower Conv Electric Heat Option Breaker (each) Size w/Pwr Breaker (each) Motor Motor Outlet Volt Size w/ (Tons) (Amps) Size Pwr Exh RLA LRA MCC...
  • Page 47 5167821-YTG-J-0518 ZT037-061 Hi Static Indoor Blower - Without Powered Convenience Outlet OD Fan Supply Max Fuse Compressors Max Fuse Motors Blower Conv Electric Heat Option Breaker (each) Size w/Pwr Breaker (each) Motor Motor Outlet Volt Size w/ (Tons) (Amps) Size Pwr Exh (Amps) (Amps)
  • Page 48 5167821-YTG-J-0518 ZT037-061 Standard Indoor Blower - With Powered Convenience Outlet OD Fan Supply Max Fuse Compressors Max Fuse Motors Blower Conv Electric Heat Option Breaker (each) Size w/Pwr Breaker (each) Motor Motor Outlet Volt Size w/ (Tons) (Amps) Size Pwr Exh RLA LRA Model Stages...
  • Page 49 5167821-YTG-J-0518 ZT037-061 Hi Static Indoor Blower - With Powered Convenience Outlet OD Fan Supply Max Fuse Compressors Max Fuse Motors Blower Conv Electric Heat Option Breaker (each) Size w/Pwr Breaker (each) Motor Motor Outlet Volt Size w/ (Tons) (Amps) Size Pwr Exh RLA LRA MCC Model...
  • Page 50 5167821-YTG-J-0518 Electric Heat Multipliers Voltage kW Capacity Multipliers Nominal Applied 0.75 0.92 0.92 0.92 1. Electric heaters are rated at nominal voltage. Use this table to determine the electric heat capacity for heaters applied at lower voltages. Johnson Controls Ducted Systems...

  • Page 51: Typical Wiring Diagrams

    5167821-YTG-J-0518 Typical Wiring Diagrams ZT037-061 Typical Wiring Diagrams Typical ZT037-061 Cooling Unit with Gas Heat 208/230 Volt Wiring Diagram Johnson Controls Ducted Systems...
  • Page 52 5167821-YTG-J-0518 Typical ZT037-061 Cooling Unit with Gas Heat 208/230 Volt Unit (Options) Johnson Controls Ducted Systems...
  • Page 53 5167821-YTG-J-0518 Typical ZT037-061 Cooling Unit with Gas Heat 460/575 Volt Wiring Diagram Johnson Controls Ducted Systems...
  • Page 54 5167821-YTG-J-0518 Typical ZT037-061 Cooling Unit with Gas Heat 460/575 Volt Unit (Options) Johnson Controls Ducted Systems...
  • Page 55 5167821-YTG-J-0518 Typical ZT037-061 Cooling Unit with/without Electric Heat 208/230 Volt Wiring Diagram Johnson Controls Ducted Systems...
  • Page 56 5167821-YTG-J-0518 Typical ZT037-061 Cooling Unit with/without Electric Heat 208/230 Volt Unit Johnson Controls Ducted Systems...
  • Page 57 5167821-YTG-J-0518 Typical ZT037-061 Cooling Unit with/without Electric Heat 460/575 Volt Wiring Diagram Johnson Controls Ducted Systems...
  • Page 58 5167821-YTG-J-0518 Typical ZT037-061 Cooling Unit with/without Electric Heat 460/575 Volt Unit (Options) Johnson Controls Ducted Systems...
  • Page 59 5167821-YTG-J-0518 BAS Controls Typical Wiring Diagrams Typical SURVEYOR BAS Control Wiring Diagram Johnson Controls Ducted Systems...
  • Page 60 5167821-YTG-J-0518 Typical CPC BAS Control Wiring Diagram Johnson Controls Ducted Systems...
  • Page 61 5167821-YTG-J-0518 Typical HONEYWELL BAS Control Wiring Diagram Johnson Controls Ducted Systems...
  • Page 62 5167821-YTG-J-0518 Typical NOVAR BAS Control Wiring Diagram Johnson Controls Ducted Systems...

  • Page 63: Weights And Dimensions

    5167821-YTG-J-0518 Weights and Dimensions ZT037-061 Unit Weights Unit 4 Point Load Weight FRONT LEFT FRONT LEFT Weight (lbs.) Center of Gravity 4 Point Load Location (lbs.) Size Model (Tons) Shipping Operating 42.4 24.7 42.5 25.5 41.6 25.5 Johnson Controls Ducted Systems...
  • Page 64 5167821-YTG-J-0518 ZT037-061 Unit Accessory Weights Weight (lbs.) Unit Accessory Shipping Operating Economizer Power Exhaust Electric Heat Gas Heat Variable Frequency Drive 1. Weight given is for the maximum heater size available (24KW). 2. Weight given is for the maximum number of tube heat exchangers available (8 tube).
  • Page 65 5167821-YTG-J-0518 ZT037-061 Unit Physical Dimensions Dimension (in.) Unit Model Number ZT037, 049, 061 22 1/8 18 3/16 15 3/16 6 3/16 Detail A Detail B 3.184 Gas Pipe Inlet Ø 2.000 Gas Exhaust Vent 5-3/8 Ø 3.126 3/4” FPT 14.594 ZT037-061 Unit Clearances 7.705 Direction...
  • Page 66 5167821-YTG-J-0518 ZT037-061 Unit Bottom Duct Openings TOP VIEW 32 11/16 6 13/16 6 13/16 SUPPLY RETURN 27 1/2 LEFT RIGHT 20 1/8 19 1/8 17 1/8 12 5/16 Bottom condensate drain 14 1/2 25 9/16 Bottom gas supply entry 16 3/8 18 1/16 FRONT Bottom power, control...
  • Page 67 5167821-YTG-J-0518 ZT037-061 Unit Electrical Entry Disconnect Swith Cover Power Entry Ø 2-1/2 Control Entry Ø 7/8 Power Entry Ø 2-1/2 Convenience Outlet Cover Convenience Outlet Power Entry Ø 7/8 FRONT ZT037-061 Unit Side Duct Openings 1 8 - 1 /4 D o t P l u g s Return Supply Air...

  • Page 68: Compressors

    5167821-YTG-J-0518 ZT037-061 Unit Left/End Duct Opening 4-5/16 ZT037-061 Left/End Duct Dimensions Dimension (in.) Unit Model Number ZT037, 049, 061 30.357 13.365 22.516 ZT037-061 Unit Accessory Dimensions ZT037-061 Roof Curb RIGHT 80-5/8 INSULATED DECK UNDER CONDENSER SECTION SUPPLY RETURN 2 TYP. 50-1/2 INSULATED DECK UNDER COMPRESSOR SECTION...
  • Page 69 5167821-YTG-J-0518 ZT037-061 Transition Roof Curb 2 TYP 23 4 30-1/2 50-1/2 80-5/8 RETURN SUPPLY 76-5/8 59-1/4 FRONT RIGHT 64-1/4 ZT037-061 Roof Curb Cutaway 2“ 3/4” X 1-1/4” WIDE GASKETING FOR CURB FRAME AND ALL DUCT SUPPORT SURFACES UNIT BASE 3.75” WOOD NAILER 3.56”...

  • Page 70: Economizer Options

    5167821-YTG-J-0518 Economizer Options Economizer Usage Application Cabinet Height Description Model Side Return Horizontal economizer without barometric relief 2EE04706924 Downflow, End Return 42" Economizer, 42” tall cabinet 2EE04717424 Horizontal or ERV 1. Barometric relief must be ordered separately and installed in duct work. 2.
  • Page 71 Power Exhaust Barometric Barometric Fresh Air Hood Relief Damper Relief Hood Subject to change without notice. Printed in U.S.A. 5167821-YTG-J-0518 Copyright © 2018 by Johnson Controls, Inc. All rights reserved. Supersedes: 5167821-YTG-I-0717 York International Corporation 5005 York Drive Norman, OK 73069...

This manual is also suitable for:

Predator zt049Predator zt061
