Hoshizaki FM-120EE User & Installation Manual

Self-contained ice maker

Hide thumbs Also See for FM-120EE:

Download this manual See also: Service Manual, Instruction Manual

SELF-CONTAINED ICE MAKER

MACHINE A GLACE A BACINTEGRE

EISBEREITER MIT EINGEBAUTEM VORRATSBEHÄLTER

IJSMACHINE MET INGEBOUWDE BUNKER

MÁQUINA DE CUBITOS DE HIELO AUTÓNOMA

MACCHINA PER LA PRODUZIONE DI GHIACCIO AUTOCONTENUTA

INSTALLATION MANUAL

NOTICE D'INSTALLATION

INSTALLATIONSANLEITUNG

INSTALLATIE VOORSCHRIFT

MANUAL DE INSTALACION

MANUALE PER L'INSTALLAZIONE

FOR QUALIFIED INSTALLER ONLY

RESERVE A L'INSTALLATEUR

FÜR DEN INSTALLATEUR

VOOR DE BEVOEGDE INSTALLATEUR

SOLAMENTE PARA INSTALADOR CUALIFICADO

SOLTANTO PER INSTALLATORI QUALIFICATI

FM-120EE

FM-120EE-N

CM-110EE

FM-120EE-50

FM-120EE-50-N

FM-80EE

FM-80EE-N

92E2EB20B (101008)

Table of Contents

Page 1 SELF-CONTAINED ICE MAKER FM-120EE FM-120EE-N MACHINE A GLACE A BACINTEGRE CM-110EE EISBEREITER MIT EINGEBAUTEM VORRATSBEHÄLTER FM-120EE-50 IJSMACHINE MET INGEBOUWDE BUNKER FM-120EE-50-N MÁQUINA DE CUBITOS DE HIELO AUTÓNOMA FM-80EE MACCHINA PER LA PRODUZIONE DI GHIACCIO AUTOCONTENUTA FM-80EE-N INSTALLATION MANUAL NOTICE D’INSTALLATION...
Page 2 ENGLISH 1) After removing the packaging, make sure that the IMPORTANT icemaker is in good condition. If in doubt, please 1. In order to carry out safe and proper installation do not use the equipment but apply to professionally of the product, please read this booklet qualified personnel.
Page 3: Installation
Supply of replacement fuse covers can be obtained * This icemaker must have a separate power supply from Hoshizaki Parts/Service Centres. or receptacle of 220 - 240V. Fuses should be rated at 13A and approved to BS * The main control box circuit breaker is rated at 6A 1362.
Page 4: Water Supply And Drain Connections
Water Supply Inlet G3/4 Inlet Hose Control Box * 3A (FM-120EE, CM-110EE) 1A (FM-80EE) Drain Outlet R3/4 Fig. 6 3) Replace the Front Panel (Left) and Top Panel in their correct position.
Page 5: Final Checks
ENGLISH 5) Connect the power supply and energise. 6) The following should occur in sequence: a) Water Reservoir will fill. b) Gear Motor will start. c) Compressor will start. IMPORTANT 1. Check the conditions and quality of the ice production. 2.

Fm-120ee-50 Cm-110ee Fm-120ee-n Fm-80ee Fm-80ee-n Fm-120ee-50-n
