- Page 1 Magnus VLF With ContinuousLoad Platesetter Visual Reference Guide Original instructions English 653-00832E-EN Rev A Internal 732-00027E-EN Rev A...
- Page 2 Start buttons Flashing green Solid green Wait—the platesetter is unloading and ejecting a plate. An error has occurred and the job is suspended. Follow Flashing yellow Solid green the instructions on the Messages tab in the Kodak® Print Console software.
-
Page 3: Emergency Stop Locations
Emergency stop locations Activate an emergency stop device to stop mechanical movement and laser operation. Power/emergency stop switch The power switch disconnects power to the platesetter so To turn on the power, The switch can be used as an emergency Insert a padlock here. - Page 4 Using Print Console Status mode—perform daily tasks Miniview mode—monitor plates For information about all screen elements, see the Print Console Help. and workflow at the same time Important messages appear here. The status light and text are visible from a distance. Queue tab—displays the status of plates as they move through each stage in the platesetter...
- Page 5 In the workflow software, submit the file. Ensure that the correct plate size is available Ready status. for loading. Kodak Prinergy® Connect™ workflow Kodak Prinergy Evo™ workflow Kodak Brisque® workflow Note: You must have a Prinergy Evo TIFF output template and hot folder already set up.
-
Page 6: Operator Maintenance Schedule
Operator maintenance schedule Operation Turn on the platesetter These operations are required for some of the Turn off the platesetter maintenance procedures below. Reset the platesetter Date work Maintenance procedure Work to be done How often completed Weekly Exterior surfaces Clean Edge detection strip Clean... - Page 7 Replacing the air supply particulate filter Open the rear hood: Particulate filter In Print Console, unlock Turn the handle counterclockwise and lift the hood. the panels. Use a slotted screwdriver Turn off the compressed air. Unscrew the bowl. Pull the tab down and turn Install the new filter.
- Page 8 Cleaning inside the platesetter Ensure that the platesetter Open the rear hood: is in an idle state. In Print Console, unlock the panels. Turn the handle counterclockwise and lift the hood. The interior of the platesetter is exposed for cleaning. Cleaning the plate roller Dampen a lint-free cloth with water, Close the rear hood:...
- Page 9 Replacing the power box intake air filter Open the power box filter panel: Remove the old intake air filter Install the new intake air filter. Close the power box filter panel: from the panel. Loosen the thumb screws. Replace the panel. Power box intake air filter Remove the panel.
- Page 10 Replacing the rear fan filters The Magnus VLF platesetter has two fans at the rear of the platesetter. Replace the filters for these fans every six months. Open the hood: Use a slotted screwdriver to loosen the two screws that secure the rear panel In Print Console, unlock the panels.
- Page 11 Raising the punch assembly You may need to raise the punch assembly to perform a recovery procedure. Raising the punch assembly provides access to the unload table, the load table, and the top of the drum. Open the rear hood: Standing in front of the punch assembly, pull it toward you.
- Page 12 Lowering the punch assembly from the raised position Attach the lifting handle to the crankshaft and slowly turn the lifting handle counterclockwise. Return the lifting handle to its storage location. Push the punch assembly forward until you Continue lowering the punch assembly until the blue light turns off. hear a click.
- Page 13 Replacing the debris removal filter Print Console indicates when the debris removal filter is full and needs to be replaced. When the full filter message appears, you will not be able to continue imaging until the filter is replaced. Always have a spare filter on hand. Pull the debris panel toward Shut down the Lift the panel up and away...
- Page 14 Removing a plate flyoff Pull the cooling fans away An error message about the Open the hood: Use a slotted screwdriver from the drum. flyoff appears. to loosen the two screws In Print Console, unlock the Push the black button and lift the rear hood. that secure the rear panel panels.
-
Page 15: Registration Method
Plate registration Correct Plate positioned on the punch table using Kodak registration. (An X represents the platesetter registration Plate pins, and the square shapes represent the punch registration pins.) Kodak side registration point Punch table The image is correctly aligned (parallel) The image and punched holes are with the punched holes or bend. - Page 16 Eastman Kodak Company 343 State Street Rochester, NY 14650 U.S.A. © Kodak, 2010. All rights reserved. TM: Kodak To learn more about solutions from Kodak, visit graphics.kodak.com Subject to technical change without notice.
