User Guide
The function consists of 2 programs:
P1 with 4 events in 5 days (Mon. Tue. Wed. Thu. Fri.)
P1: Press
to display Mo. Tu. We. Th. Fr.
P1, Event 1:
1. Use < or > to select the start time.
2. Press
to accept the setting.
3. Use < or > to select the temperature.
4. Press
to accept the setting.
P1, Event 2-4:
Repeat the Event 1 procedure for programming
Event 2-4.
The thermostat will continue the 4-event program based on the present time and day.
To set and change the room temperature temporarily:
1. Press < or > at any time to change the desired temperature value. SET is shown in the display.
2. When releasing the < or >, the display returns to showing the actual temperature. This temperature change is
only temporary and will be maintained only until the next programmed setting!
A default program provides timer control if the customer does not create own programs:
Days
Event 1
Start time
Mon - Fri
6:30
Sat - Sun
7:30
* Floor temperature control mode.
7
Check Floor Temperature
• Press M and hold. Press < within 6 seconds.
•
flashes and the current floor temperature is displayed. Operate again, then exit (automatic exit after 6
seconds with no operation).
8
Child Safety Lock
• Press M and hold. Press > within 6 seconds to lock all buttons.
• Press again to exit the child safety lock.
9
Set Control Parameters
Press M button for 6 seconds to enter the parameter setting mode. Press M for parameter selection and set the
parameter range via < or >. Complete all adjustments.
To exit WT-P/PR, press
To exit WT-D/DR, wait for automatic exit (30 seconds). The upper digits indicate the parameter number.
03/2015
BasicPlus
Event 2
Temp.
Start time
20° C
8:30
(27° C)*
20° C
9:30
(27° C)*
, which is available for this purpose (automatic exit after 30 seconds with no operation).
Room Thermostats
2
P2 with 4 events in 2 days (Sat. Sun.).
P2: Sa. Su. are now shown in the display.
P2, Event 1:
1. Use < or > to select the start time.
2. Press
to accept the setting.
3. Use < or > to select the temperature.
4. Press
to accept the setting.
P2, Event 2-4:
Repeat the Event 1 procedure for programming
Event 2-4.
Event 3
Temp.
Start time
15° C
16:30
(25° C)*
20° C
16:30
(27° C)*
VUCUA212
Event 4
Temp.
Start time
20° C
22:30
(27° C)*
21° C
22:30
(28° C)*
Danfoss Floor Heating Hydronics
Temp.
15° C
(25° C)*
15° C
(25° C)*
3
