Greenheck CFSD-211 Installation, Operation And Maintenance Manual

Installation, Operation and Maintenance Instructions
Installation Supplements
Refer to the appropriate Greenheck installation
supplements for special requirements:
• Concrete Floor with Steel Deck
• Drive Slip Breakaway Connection
• Field Installed Sleeve
• Fire Resistant Ventilated Duct Assembly
• Greenheck Test Switch
• Grille Installation
• Metal Stud in Shaftwall
• No Flow Smoke Detector
• Open or Close Indicator
• Quick Connect Breakaway Connections
• Resettable Link
• Sealant Supplement
• Single Side Retaining Angle
• Single 3-Sided Retaining Angle
• Sleeve Extension
• Smoke Detector
• Tunnel Corridor
Safety Warning:
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, injury or
death. Read the installation, operating, and maintenance
instructions thoroughly before installing or servicing this
equipment.
Due to continuing research, Greenheck reserves the right to change specifications without notice.
This manual is the property of the owner, and is required for future maintenance. Please leave it with the owner when
the job is complete.
FSD-XXX, DFD-XXX, DFDTF-XXX
CFSD-XXX, SEDFD-XXX, SEFSD-XXX,
IMO-XXX, anD SSFSD-XXX SErIES
Fire & Combination Fire Smoke Dampers
FSD-XXX, SEFSD-XXX, SSFSD-XXX, DFD-XXX, SEDFD-
XXX, and CFSD-XXX Series Dampers are intended for
installation in accordance with combination fire smoke
damper requirements established by:
national Fire Protection association
NFPA Standards 80, 90A, 92A, 92B, 101, & 105
IBC International Building Codes
new York City (MEA listing #260-91-M)
California State Fire Marshal
Typical Actuator
(Listing #3225-0981:103) & (Listing #3230-0981:104) - FSD
models; (Listing #3225-0981:103) - DFD models;
(Listing #3230-0981:105) & (Listing 3225-0981:106) - CFSD
models;
RRL Control Device
(Listing #3225-0981:109) & (Listing 3230-0981:110 ) -
Standard
SSFSD models
"UL CLaSSIFIED (see complete marking on prod-
uct)"
"UL CLaSSIFIED to Canadian safety standards
(see complete marking on product)"
UL Standard 555 & 555S (Classification #R13317)
Upon receiving dampers, check for both obvious and
hidden damage. If damage is found, record all necessary
information on the bill of lading and file a claim with
the final carrier. Check to be sure that all parts of the
shipment, including accessories, are accounted for.
Dampers must be kept dry and clean. Indoor storage
and protection from dirt, dust and the weather is highly
recommended. Do not store at temperatures in excess of
100°F (38°C).
Greenheck warrants this equipment to be free from
defects in material and workmanship for a period of one
year from the purchase date. Any units or parts which
prove to be defective during the warranty period will
be repaired or replaced at our option. Greenheck shall
not be liable for damages resulting from misapplication
or misuse of its products. Greenheck will not be
responsible for any installation or removal costs.
Greenheck will not be responsible for any service work
or backcharges without prior written authorization.
Part number 461336
(with factory installed sleeve and actuator)
Vertical and Horizontal Mount
receiving and Handling
Warranty
1 ⁄ and 3 Hour
1
2
