Installation Manual
Indoor Unit
Model name:
High-Wall Type
MMK-AP0057HP-E, MMK-AP0057HP-E1
MMK-AP0077HP-E, MMK-AP0077HP-E1
MMK-AP0097HP-E, MMK-AP0097HP-E1
MMK-AP0127HP-E, MMK-AP0127HP-E1
When the E1 model (MMK-AP*HP-E1) is installed,
PMV Kit (RBM-PMV0363E) is necessary
1121250199
For commercial use
Installation Manual
English
1
Advertisement
Table of Contents
Related Manuals for Toshiba MMK-AP0057HP-E1
Summary of Contents for Toshiba MMK-AP0057HP-E1
-
Page 1: Installation Manual
Installation Manual Indoor Unit Model name: 1121250199 High-Wall Type For commercial use MMK-AP0057HP-E, MMK-AP0057HP-E1 MMK-AP0077HP-E, MMK-AP0077HP-E1 MMK-AP0097HP-E, MMK-AP0097HP-E1 MMK-AP0127HP-E, MMK-AP0127HP-E1 When the E1 model (MMK-AP*HP-E1) is installed, PMV Kit (RBM-PMV0363E) is necessary English Installation Manual... -
Page 2: Table Of Contents
Installation Manual Please read this Installation Manual carefully before installing the Air Conditioner. • This Manual describes the installation method of the indoor unit. • For installation of the outdoor unit, follow the Installation Manual attached to the outdoor unit. ADOPTION OF NEW REFRIGERANT This Air Conditioner is a new type which adopts a new refrigerant HFC (R410A) instead of the conventional refrigerant R22 in order to prevent destruction of the ozone layer. -
Page 3: Owner's Manual
The qualified service person is a person who installs, repairs, maintains, relocates and removes the air conditioners made by Toshiba Carrier Corporation. He or she has been trained to install, repair, maintain, relocate and remove the air conditioners made by Toshiba Carrier Corporation... - Page 4 Installation Manual Definition of Protective Gear When the air conditioner is to be transported, installed, maintained, repaired or removed, wear protective gloves and ‘safety’ work clothing. In addition to such normal protective gear, wear the protective gear described below when undertaking the special work detailed in the table below.
-
Page 5: Warning Indications On The Air Conditioner Unit
Installation Manual Warning indications on the air conditioner unit Warning indication Description WARNING WARNING ELECTRICAL SHOCK HAZARD ELECTRICAL SHOCK HAZARD Disconnect all remote electric power supplies Disconnect all remote electric power supplies before servicing. before servicing. WARNING WARNING Moving parts. Moving parts. -
Page 6: Precautions For Safety
Installation Manual PRECAUTIONS FOR SAFETY • Ensure that all Local, National and International regulations are satis ed. • Read this “PRECAUTIONS FOR SAFETY” carefully before Installation. • The precautions described below include the important items regarding safety. Observe them without fail. •... - Page 7 Installation Manual • Do not touch the aluminium n of the unit. You may injure yourself if you do so. If the n must be touched for some reason, rst put on protective gloves and safety work clothing, and then proceed. •...
-
Page 8: Electrical Wiring
Installation Manual Installation • Install the air conditioner securely in a location where the base can sustain the weight adequately. If the strength is not enough, the unit may fall down resulting in injury. • Follow the instructions in the Installation Manual to install the air conditioner. Failure to follow these instructions may cause the product to fall down or topple over or give rise to noise, vibration, water leakage or other trouble. - Page 9 Installation Manual • Connect earth wire. (grounding work) Incomplete grounding causes an electric shock. • Do not connect earth wires to gas pipes, water pipes, and lightning conductor or telephone earth wires. • After completing the repair or relocation work, check that the earth wires are connected properly.
- Page 10 Installation Manual Explanations given to user • Upon completion of the installation work, tell the user where the circuit breaker is located. If the user does not know where the circuit breaker is, he or she will not be able to turn it off in the event that trouble has occurred in the air conditioner.
- Page 11 Installation Manual CAUTION New refrigerant air conditioner installation • This air conditioner adopts the new HFC refrigerant (R410A) which does not destroy ozone layer. • The characteristics of R410A refrigerant are; easy to absorb water, oxidizing membrane or oil, and its pressure is approx. 1.6 times higher than that of refrigerant R22.
-
Page 12: Accessory Parts
Installation Manual ACCESSORY PARTS Part name Q’ty Shape Usage (Hand over to customers) (For other languages that do not appear in Installation Manual This manual this installation Manual, please refer to the enclosed CD-R.) (Hand over to customers) (For other languages that do not appear in Owner’s Manual this installation Manual, please refer to the enclosed CD-R.) -
Page 13: Selection Of Installation Place
Installation Manual SELECTION OF INSTALLATION PLACE WARNING • Install the air conditioner at enough strong place to withstand the weight of the unit. If the strength is not enough, the unit may fall down resulting in injury. CAUTION • Do not install the air conditioner in a location subject to a risk of exposure to a combustible gas. -
Page 14: Battery
Installation Manual Installation diagram of Indoor and outdoor units For the rear left and left piping Before installing the wireless remote controller Hook Wall 1. Remove the battery Installation cover. plate 2. Insert 2 new batteries (R03 [AAA] type) following the (+) and (−) Insert the cushion between the positions. -
Page 15: Installation Of Indoor Unit
Installation Manual Wireless remote controller • A place where there are no obstacles such as a curtain that may block the signal from the indoor unit. • Do not install the remote controller in a place exposed to direct sunlight or close to a heating source, such as a stove. -
Page 16: Cutting A Hole And Mounting Installation Plate
Installation Manual CUTTING A HOLE AND MOUNTING INSTALLATION PLATE Cutting a hole When the installation plate is directly mounted on the wall In case of installing the refrigerant pipes from the rear: 1. Securely fit the installation plate onto the 1. -
Page 17: Piping And Drain Hose Installation
Installation Manual PIPING AND DRAIN HOSE INSTALLATION Piping and drain hose forming * Apply heat-insulation for both refrigerant pipe and drain hose surely so that no dew generates inside of the equipment. (Use polyethylene foam for insulating material.) Rear right Rear left Bottom left Left... - Page 18 Installation Manual How to remove the drains cap Clip the drain cap by needle-nose pliers and pull out. How to fix the drains cap 1) Insert hexagonal wrench (dia. 4mm) in a centre head. 2) Firmly insert drains cap. Do not apply lubricating oil (refrigerant machine oil) when inserting the drain cap.
- Page 19 Installation Manual q In case of bottom right or bottom left piping • After scribing slits of the front panel with a knife or a marking-off pin, cut them with a pair of nippers or an equivalent tool. Slit q Left-hand connection with piping Bend the connecting pipe so that it is laid within 43mm above the wall surface.
-
Page 20: Indoor Unit Fixing
Installation Manual INDOOR UNIT FIXING DRAINAGE 1. Pass the pipe through the hole in the wall, 1. Run the drain hose sloped downwards. and hook the indoor unit on the installation NOTE plate at the upper hooks. • Hole should be made at a slight downward 2. -
Page 21: Refrigerant Piping
Installation Manual REFRIGERANT PIPING Refrigerant Piping Permissible Piping Length and Height Difference 1. Use copper pipe with 0.8mm or more thickness. (In case pipe size is dia. 15.9, They vary according to the outdoor unit. with 1.0mm or more.) For details, refer to the Installation Manual attached 2. - Page 22 Installation Manual Tightening connection Heat insulation Heat insulation for the pipes should be done CAUTION separately for the liquid side and gas side. Because both of the liquid and gas side pipes • Do not apply excessive torque. Otherwise, the become a low temperature during cooling nut may crack depending on the conditions.
-
Page 23: Electric Work
Installation Manual ELECTRIC WORK • Run the refrigerant piping line and control wiring WARNING line in the same line. • Do not turn on the power of the indoor unit until 1. Using the specified wires, ensure to vacuuming of the refrigerant pipes completes. connect the wires, and fix wires securely so that the external tension to the wires do not affect the connecting part of the terminals. - Page 24 Installation Manual Power supply wire and communication wires specifications Power supply wire and communication wires are procured locally. For the power supply specifications, follow the table below. Power supply wiring and communication wiring are to be procured locally. For specifications of the power capacity of the outdoor unit and the power supply wires, refer to the Installation Manual supplied with the outdoor unit.
-
Page 25: Wiring Example
Installation Manual Indoor unit Indoor unit Indoor unit Indoor unit Wired remote controller wiring (Max. 8 units) Wired remote Remote controller inter-unit wiring controller Control wiring between indoor and outdoor units NOTE An outdoor unit that is interconnected to the indoor units automatically becomes the header unit. ▼... - Page 26 Installation Manual Wired remote controller wiring • As the wired remote controller wire has non-polarity, there is no problem if connections to indoor unit terminal blocks A and B are reversed. ▼ Wiring diagram Terminal block for remote controller Terminal block wiring of indoor unit Wired remote controller unit...
-
Page 27: Wiring Connection
Installation Manual Wiring Connection Power supply terminal block How to connect the power supply wiring Terminal block for communication/remote and control wiring controller wiring The power supply wire and the control wire can be Screw connected without removing the front panel. Terminal cover REQUIREMENT Earth screw... - Page 28 Installation Manual Wiring connection for flow selector unit How to connect the wiring of flow selector unit Connect the power supply wire and the communication wire supplied with the flow selector unit to the indoor unit. 1. Remove the air inlet grille. Open the air inlet grille upward and pull it toward you.
-
Page 29: Applicable Controls
Installation Manual APPLICABLE CONTROLS A wired remote controller is necessary for this function. This function cannot be operate with a wireless remote controller. Changing of settings of for REQUIREMENT applicable controls • When you use this air conditioner for the first time, it takes approx. - Page 30 Installation Manual Change of lighting time of filter Procedure Each time you push button, indoor unit sign numbers in the control group change cyclically. According to the installation condition, the lighting Select the indoor unit you want to change settings time of the filter sign (Notification of filter cleaning) for.
-
Page 31: Adjustment Of Air Direction
Installation Manual Adjustment of air direction 1. Using the remote controller switch, change the up/down air direction by moving the horizontal louver. 2. Adjust the right/left air direction by bending the vertical grille inside of the air outlet port with hands. REQUIREMENT Do not touch the horizontal louver directly with hands;... -
Page 32: Test Run
Installation Manual TEST RUN A wired remote controller is necessary for this function. This function cannot be operate with a wireless remote controller. Before test run In case of wired remote controller • Before turning on the power supply, carry out the 2, 4 following procedure. - Page 33 Installation Manual In case of wireless remote controller (Forced test operation is performed in a different way.) REQUIREMENT • For the operation procedure, be sure to follow the Owner’s Manual. • Finish the forced cooling operation in a short time because it applies excessive strength to the air conditioner.
-
Page 34: Troubleshooting
Installation Manual TROUBLESHOOTING A wired remote controller is necessary for this function. This function cannot be operate with a wireless remote controller. Confirmation and check Procedure Every pushing of “TEMP.” button used to When a trouble occurred in the air conditioner, the set temperature, the trouble history stored in check code and the indoor UNIT No. -
Page 35: Check Code List
Installation Manual Check method On the remote controller (Wired remote controller, Central control remote controller) and the interface P.C. board of the outdoor unit (I/F), a check display LCD (Remote controller) or 7-segment display (on the outdoor interface P.C. board) to display the operation is provided. Therefore the operation status can be known. - Page 36 Installation Manual Sending error in communication — between outdoor units — Duplicated follower outdoor addresses No. of outdoor units which Decrease of No. of connected outdoor received signal normally units E28 Detected outdoor unit number Follower outdoor unit error 01: IPDU1 error 02: IPDU2 error 03: IPDU1, 2 error 04: Fan IPDU error...
- Page 37 I/F Differs according to error contents of unit with occurrence of alarm Group control branching unit error TCC-LINK — — (L20 is displayed.) Duplicated central control addresses TCC-LINK: TOSHIBA Carrier Communication Link. ‒ 36 ‒ 36-EN...
- Page 38 Installation Manual WARNINGS ON REFRIGERANT LEAKAGE Check of Concentration Limit ▼ NOTE 2 The standards for minimum room volume are as The room in which the air conditioner is to be follows. installed requires a design that in the event of (1) No partition (shaded portion) refrigerant gas leaking out, its concentration will not exceed a set limit.
- Page 39 Installation Manual CONFIRMATION OF INDOOR UNIT SETUP Prior to delivery to the customer, check the address and setup of the indoor unit, which has been installed in this time and fill the check sheet (Table below). Data of four units can be entered in this check sheet. Copy this sheet according to the No.
- Page 40 144 / 9 Moo 5, Bangkadi Industrial Park, Tivanon Road, Tambol Bangkadi, Amphur Muang, Pathumthani 12000, Thailand 112 125 0199...
