Icom IC-PCR1500 Instruction Manual page 76

SSB/CW
(10 dB S/N)
0.495–1.799 MHz : Less than 5 µV
1.800–14.999 MHz : Less than 0.5 µV
15.000–49.999 MHz : Less than 0.5 µV
50.000–699.999 MHz : Less than 0.4 µV
700.000–1299.999 MHz : Less than 0.5 µV
• Sensitivity :
(threshold)
FM
(1 kHz/3.5 kHz Dev.; 12 dB SINAD)
28.000–29.999 MHz : Less than 0.63 µV
30.000–49.999 MHz : Less than 0.63 µV
50.000–239.999 MHz : Less than 0.5 µV
240.000–279.999 MHz : Less than 0.5 µV
280.000–299.999 MHz : Less than 0.5 µV
300.000–699.999 MHz : Less than 0.5 µV
700.000–1299.999 MHz : Less than 0.63 µV
1300.000–2299.999 MHz : Less than 5.6 µV
2300.000–3000.000 MHz : Less than 18 µV
WFM (1 kHz/52.5 kHz Dev.; 12 dB SINAD)
50.000–699.999 MHz : Less than 5.6 µV
700.000–1299.999 MHz : Less than 7.1 µV
1300.000–2299.999 MHz : Less than 71 µV
2300.000–3000.000 MHz : Less than 220 µV
AM (1 kHz/30% MOD.; 10 dB S/N)
0.495–1.799 MHz : Less than 18 µV
1.800–14.999 MHz : Less than 0.89 µV
15.000–49.999 MHz : Less than 0.89 µV
50.000–299.999 MHz : Less than 0.71 µV
300.000–699.999 MHz : Less than 0.71 µV
700.000–1299.999 MHz : Less than 0.89 µV
SPECIFICATIONS AND OPTIONS
SSB/CW
(10 dB S/N)
0.495–1.799 MHz : Less than 71 µV
1.800–14.999 MHz : Less than 7.1 µV
15.000–49.999 MHz : Less than 7.1 µV
50.000–699.999 MHz : Less than 5.6 µV
700.000–1299.999 MHz : Less than 7.1 µV
• Selectivity :
SSB/CW/AM More than 2.8 kHz/–6 dB (typical)
SSB/CW/AM/FM More than 6.0 kHz/–6 dB (typical)
AM/FM More than 15 kHz/–6 dB (typical)
AM/FM/WFM More than 50 kHz/–6 dB (typical)
WFM More than 230 kHz/–6 dB (typical)
• AF output power : More than 0.5 W
(at 12.0 V DC)
load
• Ext. speaker connectors : 2-conductor 3.5 (d) mm (
• Data connectors : 2-conductor 3.5 (d) mm (
16
1
2
3
4
5
6
7
8
9
at 10% distortion with an 8 Ω
10
")/8 Ω
1
⁄
8
")/100 K Ω
