I Band scope option
The following optional functions are available for the band
scope function. These settings can be defined using the
[Band Scope] screen.
G WFM Monitor function
The band scope function is normally used in AM and FM
modes only. this function allows it to be used as waveform
monitor in WFM mode.
G 1/2 sweep step function
This function sets the sweep step in half of the tuning step,
doubling the sweep resolution.
qRight-click the [FREQ] button to call up the Band Scope
setting screen if it is not displayed.
wCheck the desired check boxes in [Option], then click the
close ([X]) button to close the setting screen.
eClick the close ([X]) button to close the setting screen.
I Pick up signal function
When you find a signal you want to listen to when using the
band scope function, click over the signal location in the band
scope display. The receive frequency moves to that fre-
quency.
While pausing the band scope, you can also select the dis-
played signal frequency by clicking the waveform. In this
case, the receive frequency is marked by a dotted line and
the previously received frequency is displayed at center.
