- Page 1 MULTI-CAMERA CONTROL UNIT MCU-200S Instruction Manual w w w . d a t a v i d e o . c o m...
-
Page 2: Table Of Contents
SERVICE & SUPPORT ..............................24 Disclaimer of Product & Services The information offered in this instruction manual is intended as a guide only. At all times, Datavideo Technologies will try to give correct, complete and suitable information. However, Datavideo Technologies cannot exclude that some information in this manual, from time to time, may not be correct or may be incomplete. -
Page 3: Fcc Compliance Statement
AC adapter. If you are not sure of the type of power available, consult your Datavideo dealer or your local power company. 8. Do not allow anything to rest on the power cord. Do not locate this unit where the power cord will be walked on, rolled over, or otherwise stressed. -
Page 4: Warranty
• The product warranty period begins on the purchase date. If the purchase date is unknown, the product warranty period begins on the thirtieth day after shipment from a Datavideo office. • All non-Datavideo manufactured products (product without Datavideo logo) have only one year warranty from the date of purchase. -
Page 5: Disposal
Disposal For EU Customers only - WEEE Marking This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. -
Page 6: Introduction
Its useful and user-friendly design allows you to connect a maximum of 4 SONY camcorders through the Ethernet cables and an adapter box. Major functions of several SONY camcorders can be easily operated and controlled using the MCU-200S at up to 300m away from the controller unit. -
Page 7: System Diagram
2. System Diagram... -
Page 8: Connections And Controls
The adapter box acts as an interface between the MCU-200S and SONY cameras or camcorders. One side of the box connects to the MCU-200S via an Ethernet cable and the other side connects to SONY cameras or camcorders via a SONY CAM/BS cable. Users are allowed to use an Ethernet cable that runs 300 meters to connect the MCU-200S to this adapter box which in turn connects a SONY camera. - Page 9 This unit allows you to operate the functions of the camera up to 300m away with the MCU-200S unit. The AD-1S adaptor connects the MCU-200S via RJ-45 cabling to the chosen Sony camera. This adaptor changes the Ethernet connection to a Sony CAM/BS cable run with a multi-pin connector.
-
Page 10: Front View
Functions Enable Keyboard Control Guide Power switch Use this switch to power the MCU-200S On or Off. Camera selection Select the button for the camera that you wish to control. MCU-200S Memory stores Using the LOAD SAVE button it is possible to transfer the current setting from one camera to another. - Page 11 With a DVCPRO HD camera recorder, the tape is cued to provide continuity from one shot to the next when this button is pressed while playback is paused. Note: The REW and FF functions may be modified during the firmware upgrade process. SHORT MARK Press this button during recording or playback to record shot mark 1.
- Page 12 CANCEL In Camera Menu mode, press this button to cancel the set value. SHUTTER In Remote Control mode, Moving this switch to enable the Shutter function. The current shutter speed is displayed on the adjustment value indicator and the shutter speed can be adjusted with the adjustment knob (rotary encoder).
- Page 13 CAM A.KNEE switch To select the video signals to be output from the camera. BARS Camera generated colour bar signals are output. CAM. AUTO KNEE OFF The images shot by camera are output. The AUTO KNEE circuit does not work. MANUAL KNEE is set as the camera recorder's initial setting.
- Page 14 CHECK button is pressed. If the CHECK button is pressed and held down for over two seconds the MCU-200S unit will switch in to LOCK mode. Note: The Check function may be modified during the firmware upgrade process.
-
Page 15: Seven Segment Display And Led Indicators
LED display The IRIS value, Shutter degree, speed, Gain and Filter positions can be displayed here by using the CHECK button. *The M. PED, PAINTING GAIN R/B and BLACK R/G/B values can also be displayed sequentially here. See CHECK button also. When in LOCK mode this display will show Lock. -
Page 16: Operation Modes - Lock And Normal
When the Iris function is accessed in this way, if the MCU-200S unit is left idle for 3 seconds or more then the unit will automatically return to full LOCK mode. -
Page 17: Camera Setups
4.1 How to copy settings set by the MCU-200S from one camera to another When the MCU-200S is used to control more than one camera, it is possible to copy the settings set by the unit on one camera to another via the Memory Stores functions of the unit. -
Page 18: How To Save Load The Camcorder Settings To From Apc
4.3 How to save / load the camcorder settings to / from a PC It is possible to save the current settings on all four cameras from MCU-200S to a PC for later use. Also any previously saved MCU-200S settings stored on a PC can also be loaded back to the MCU- 200S unit. -
Page 19: Firmware Update Procedure
USB 2.0 cable (USB A type-to-Micro USB). A Windows computer (Vista / 7) with USB 2.0 port. Note: It is best to update the firmware of the AD-1S unit(s) at the same time as the MCU-200S. 5.1 How to update the MCU-200S firmware Turn off the MCU-200S power. -
Page 20: Dimensions
6. Dimensions MCU-200S AD-1S All measurements in millimeters (mm) -
Page 21: Specifications
7. Specifications Model Name MCU-200P Product Name Multi-Camera Control Unit RJ45 x 4 Input / Output Interface CV x 4 Camera Adapter AD-1P Remote Control Interface Ethernet Number of Cameras Controlled Maximum Transmission Distance Up to 300m (CAT-5 or CAT6) Record and Playback Camera User Memory Functions Camera OSD Menu Navigation... -
Page 22: Note
NOTE... - Page 23 NOTE...
-
Page 24: Service & Support
Service & Support It is our goal to make owning and using Datavideo products a satisfying experience. Our support staff is available to assist you to set up and operate your system. Contact your local office for specific support requests. Plus, DATAVIDEO WORLDWIDE OFFICES please visit www.datavideo.com to access our FAQ section.
