7
FX/SYSTEM Knob
Selects the "INS-FX" (Insertion Effects) or "REV/DELAY" (Reverb/
Delay) parameters to be set.
When this is set to "SYSTEM," you can make changes to the settings
that govern the SH-32's overall behavior (system parameters).
90)
When you select a parameter for which you want to make
settings, the indicator on the left begins to blink, indicating that
the SH-32 is ready for changes in the settings.
8
MIDI Settings Knob
Selects the parameter to be set when modifying sounds as the result
of messages (Modulation, Pitch Bend, Aftertouch, Velocity) received
from an external MIDI device.
When you select a parameter for which you want to make
settings, the indicator on the left begins to blink, indicating that
the SH-32 is ready for changes in the settings.
9
[ANALOG FEEL]/[INS > REV SERIES]
ANALOG FEEL: Press this button, causing the indicator to light, to
set the degree to which analog-like modulation is applied to the
pitch.
(p. 62)
INS > REV SERIES: Press this button, causing the indicator to blink,
to select the way the Insertion Effects and Reverb/Delay are
connected.
(p. 64)
[LEGATO]/[PORTA TIME]
LEGATO: Press this button, causing the indicator to light, to turn the
Legato function on and off.
PORTA TIME: Press this button, causing the indicator to blink, to set
the time over which the pitch changes when playing portamento.
(p. 62)
[LEVEL]/[PAN]
LEVEL: Press this button, causing the indicator to light, to set the
volume of the Patch or Performance.
PAN: Press this button, causing the indicator to blink, to set the
panning.
(p. 63)
Additionally, when used simultaneously with [EXIT], this allows
you to listen to the demo songs.
[WRITE (EXEC)]
This is pressed when saving (WRITE) tone, Arpeggiator, and other
settings, or when executing (EXEC) various functions.
(p. 65, p. 66)
(p. 85)
(p. 61)
(p. 59)
(p. 18)
[PATCH]/[PERFORM]
PATCH: Press this button, causing the indicator light to go off, to
switch to Patch mode.
PERFORM: Press this button, causing the indicator to light, to
switch to Performance mode. When in Performance mode, hold
(p.
down [PERFORM] and press [EXIT] to switch to Part Assign mode.
(p. 20, p. 71)
[EXIT]
Pressed to cancel settings and other various operations.
Additionally, when used simultaneously with [LEVEL/PAN], this
allows you to listen to the demo songs.
Display
A variety of information, including the number of the selected sound
and the values of various parameter settings, is displayed here.
[VALUE
/ ]
These change the various settings values.
To rapidly increase the value, hold down [ ] and press [ ].
To rapidly decrease the value, hold down [ ] and press [ ].
10
[PREVIEW]
Switches the Preview function on and off.
[-OCT], [+OCT]
These shift the register played using the Preview function in octave
units.
(p. 21)
[HOLD]
Switches the Preview function's Hold On and Hold Off.
[MANUAL]
Switches the Manual function on and off.
[BANK]
This is pressed when tone banks and numbers are switched.
23)
[CHORD]
Switches the Chord Memory function on and off.
[SOLO]
Switches the Solo function on and off.
[UNISON]
Switches the Unison function on and off.
[PORTAMENTO]/[LEG. ONLY]
PORTAMENTO: Press this button, causing the indicator to light, and
portamento will be turned on.
LEG. ONLY: Press this button, causing the indicator to blink, to use
portamento only when playing legato.
Panel Descriptions
(p. 20)
(p. 18)
(p. 21)
(p. 52)
(p. 81)
(p. 61)
(p. 62)
(p. 62)
(p. 62)
(p. 21)
(p.
