- Page 1 PTIC CATV R ECEIVER BCI reserves the right to make changes to the products described herein without prior notice or consent. No liability is assumed as a result of their use or application. All rights reserved. ©2008 Broadata Communications, Inc.
- Page 2 This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend the life of your equipment. Broadata Technical Support, CustomerService@Broadatacom.com...
-
Page 3: Table Of Contents
Indoor Fiber Optic CATV Receiver TABLE OF CONTENTS PRODUCT DESCRIPTION .......... 5 BLOCK DIAGRAM ............6 SPECIFICATIONS ............7 INSTALLATION & ADJUSTMENTS ......9 SERVICE PROCEDURE ..........10 REPLACEMENT POLICY ........... 10 RETURN AND REPAIR SERVICE ......10 LIMITED WARRANTY ..........11 Broadata Technical Support, (800) 214-0222... -
Page 4: Product Description
Indoor Fiber Optic CATV Receiver 1.0 PRODUCT DESCRIPTION 730E-R-ID is a stand alone AM optical receiver which may be mounted in a 19" rack. Located at either a headend or a remote site, the unit is a versatile, cost effective alternative to devices with bulkier environmentally sealed and ruggedized housings. -
Page 5: Block Diagram
BCI 730E User’s Manual Indoor Fiber Optic CATV Receiver 2.0 BLOCK DIAGRAM Optical Receive Fiber SP Port 1# Digital Display Port 2# Optical Return Transmitter +24V Power Supply Figure 2-1 730E-R-ID Block Diagram Broadata Technical Support, (800) 214-0222... -
Page 6: Specifications
Return Path, RF (optional) Bandwidth 5 - 200MHz RF input power 80dBµV Flatness ±1dB Return Loss >14dB General Power 220VAC/110VAC RF Connector Dimensions (W x D x H) 18.98” x 9.25” x 1.73” Operating Temperature 0ºC to +50ºC Broadata Technical Support, CustomerService@Broadatacom.com... - Page 7 SC/APC adapter. 5. This machine should be grounded before operation. The Ω. Ω. Ω. Ω. grounded resistence should be <4Ω. 6. Please carefully bend the fiber. Broadata Technical Support, (800) 214-0222...
-
Page 8: Installation & Adjustments
When front panel LED status light is red, it indicates that the input optical power is lower than –8dBm. In this case, you should check the optical link, the SC/APC connector and the output optical power of the transmitter. Broadata Technical Support, CustomerService@Broadatacom.com... -
Page 9: Service Procedure
The 730E System contains no user serviceable components. If you have a problem with your unit, please contact the Customer Service Department. To facilitate our return/repair processing please contact Broadata Communications, Inc. to obtain a Return Material Authorization (RMA). Please include the following information: •... -
Page 10: Limited Warranty
Indoor Fiber Optic CATV Receiver 6.0 LIMITED WARRANTY Broadata Communications, Inc. (BCI) warrants, for a period of one year from date of shipment, each product sold shall be free from defects in material and workmanship. BCI will correct, either by repair, or at BCI’s... - Page 11 Broadata Communications, Inc. 2545 West 237th Street, Suite K Torrance, CA 90505 1-800-214-0222 (310) 530-1416 (310) 530-5958 (Facsimile) e-mail: CustomerService@Broadatacom.com Website: www.broadatacom.com 60000-730E...
