Broadata LBC-H-R-SCL-ICP User Manual

Link bridge hdbaset hdmi receiver with inline control processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LBC-H-R-SCL-ICP
TM
L
B
HDB
T HDMI R
INK
RIDGE
ASE
ECEIVER
I
C
P
WITH
NLINE
ONTROL
ROCESSOR
BCI reserves the right to make changes to the products described herein without prior
notice or consent. No liability is assumed as a result of their use or application. All
rights reserved.
©2013 Broadata Communications, Inc.

Advertisement

Table of Contents
loading

Related Manuals for Broadata LBC-H-R-SCL-ICP

Summary of Contents for Broadata LBC-H-R-SCL-ICP

  • Page 1 WITH NLINE ONTROL ROCESSOR BCI reserves the right to make changes to the products described herein without prior notice or consent. No liability is assumed as a result of their use or application. All rights reserved. ©2013 Broadata Communications, Inc.
  • Page 2 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor SAFETY INSTRUCTIONS AND COMPLIANCE DECLARATIONS SURGE PROTECTION DEVICE RECOMMENDED This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend the life of your equipment.

  • Page 3: Table Of Contents

    5.0 LB-ICP WEB SERVER DESCRIPTION ......19 6.0 SPECIFICATIONS ............43 7.0 SERVICE PROCEDURE ..........46 7.1 REPLACEMENT POLICY ..........46 7.2 RETURN AND REPAIR SERVICE ......... 46 8.0 LIMITED WARRANTY ............ 47 9.0 APPENDIX ..............48 Broadata Technical Support, (800) 214-0222...

  • Page 4: Product Description

    LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor 1.0 PRODUCT DESCRIPTION Overall • An HDBaseT HDMI video scaling receiver with multiple control I/O ports • Not only scale HDMI video, but also provide in-line control I/O...
  • Page 5 Figure 1-1 shows a typical application diagram. LBC-HDBT-T LBC-HDMI-R-SCL-ICP HDBaseT HDMI HDMI Link RS-232/IR RS-232/IR Extender 1 CAT-5/6e Ethernet RS-232 RS-232 GPIO Relay Control Keypad LB-KP8 Figure 1-1 ORDERING INFORMATION LBC-H-R-SCL-ICP Link Bridge HDBaseT Scaling Receiver with Control I/O Ports Broadata Technical Support, (800) 214-0222...

  • Page 6: Operation Control And Functions

    LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor OPERATION CONTROLS AND FUNCTIONS 2.1 Scaling Receiver Front Panel 1. SERVICE: This port is reserved for firmware update only. 2. IR: IR Receiver window (accepts the remote control signal of this device only).

  • Page 7: Scaling Receiver Rear Panel

    CAT5e/6/7 port. Doing so may trigger power shut down and ruin the device 5. IR Blaster: Connect to the supplied IR Blaster cable for IR signal transmission. Place the IR Blaster in direct line-of-sight of the equipment to be controlled. 6. IR Extender: Broadata Technical Support, (800) 214-0222...

  • Page 8: Icp Front And Rear Panel

    LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor Connect to the supplied IR Receiver cables for IR signal reception. Ensure that remote being used is within the direct line-of-sight of the IR Extender. 7. MODE LED: This LED will illuminated when the power is connected.

  • Page 9: Connector Pinout Assignment

    11. RESET: Press the button to reset the device back to factory default settings. 3.0 CONNECTOR PINOUT ASSIGNMENT 3.1 Scaling Receiver 3.1.1 IR Pin Assignment IR Blaster Power 5V IR Blaster Signal IR Receiver IR Signal Power Grounding Broadata Technical Support, (800) 214-0222...

  • Page 10: Rs-232 Pin Assignment

    LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor 3.1.2 RS-232 Pin Assignment Baud Rate: 9600bps Data Bit: 8 bits Parity: None Flow Control: None Stop Bit: 1 Broadata Technical Support, Sales@Broadatacom.com...

  • Page 11: Icp

    LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT Receiver with Inline Control Processor 3.2 ICP Front Broadata Technical Support, (800) 214-0222...
  • Page 12 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor IR detector IR OUT for behind holes external emitter Rear Reset button: push to reset to default settings RJ-45 DIP SW CONFIG/Keypad IR Learn LED 1 - TX+ Position 1: Local/Remote 1.

  • Page 13: On Screen Display (Osd) Menu

    1920x1080I 60, 1920x1080P 60 (setting upon shipment), 720x576P 50, 1280x720P 50, 1920x1080I 50, 1920x1080P 50 SIZE: OVERSCAN, FULL (Factory Default upon reset), UNDERSCAN, LETTERBOX, PANSCAN, ASPECT RATIO (setting upon shipment), UNDER 2, UNDER 1 MODE INFO: INFO, ON, OFF Broadata Technical Support, (800) 214-0222...

  • Page 14: Color

    LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor COLOR: Color, Contrast, Brightness, Hue, Saturation, Sharpness, NR COLOR RED: 0 ~ 1023 of Red Color Level GREEN: 0 ~ 1023 of Green Color Level BLUE: 0 ~ 1023 of Blue Color Level...

  • Page 15: Audio

    LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT Receiver with Inline Control Processor AUDIO VOLUME: 0 ~ 100 DELAY: OFF, 40ms, 110ms, 150ms SOUND: ON, MUTE Broadata Technical Support, (800) 214-0222...

  • Page 16: Setup

    LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor SETUP: Factory Reset, Keylock FACTORY RESET: YES, NO KEY LOCK: OFF, ON Broadata Technical Support, Sales@Broadatacom.com...

  • Page 17: Information

    LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT Receiver with Inline Control Processor INFORMATION: Input, Output, Revision INPUT: Input Resolution Displayed OUTPUT: Output Resolution Displayed REVISION: Firmware Revision Displayed Broadata Technical Support, (800) 214-0222...

  • Page 18: Lb-Icp Web Server Description

    LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor 5.0 LB-ICP WEB SERVER DESCRIPTION Introduction The ICP Web Server provides user friendly and intuitive web pages to configure the virtual keypad and automation functions within the ICP. It also provides web pages to manage the IR Learner and IR code import.
  • Page 19 See the following section for Configure System page details. Once logged in, the user is free to open any of the Configure or Settings pages. The default Password can be changed using the BCI Product Configuration program. Broadata Technical Support, (800) 214-0222...
  • Page 20 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor Configure System The Configure System page is used to configure the network keypad, virtual keypad, RS-232 channels, Digital IO channels and remote unit types. On the top menu bar, click Configure and then click System. The following page will be displayed.
  • Page 21 Disable in order to configure Channel 3 as a pass-through channel. Channel 3 (Remote) is the pass-through channel on the remote unit. Baud Rate: Select a baud rate from 9600 to 115200 baud. Broadata Technical Support, (800) 214-0222...
  • Page 22 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor Flow Control: Select On to enable flow control and Off to disable flow control. Flow control is available only on Channel 1. If flow control is enabled, Channel 2 is no longer available.
  • Page 23 Function Key Mode: Select Standard for a “momentary” type key. Only one set of actions is assigned to a Standard key. Select Toggle for a “toggle” type key. A Toggle key has two states: Press and Release. Broadata Technical Support, (800) 214-0222...
  • Page 24 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor One set of actions is assigned to the Press state and another set of actions is assigned to the Release state. Command Action: Select the action number to be defined. Action 1 through Action 10 can be defined.
  • Page 25 Digital Output Channel: Select the digital output channel 1 or 2. Note: this option is not available if both Digital IO channels are set to Inputs in Configure System page. Digital Output State: Select the digital output state: 1 (High) or 0 (Low). Broadata Technical Support, (800) 214-0222...
  • Page 26 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor RS-232 Options RS-232 Channel: Select channel 1, 2, 3, or 3 (Remote). Transmit String: Type in the text string to be transmitted. Strings are terminated with CR or CR+LF, depending on the selection made in Configure System page.
  • Page 27 HBaseT Receiver with Inline Control Processor IR Options IR Preset: Select from list of IR commands stored in memory. IR commands must be learned via Configure IR Code page or imported via Configure IR Import page. Broadata Technical Support, (800) 214-0222...
  • Page 28 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor Telnet Options Telnet ID: Select the telnet connection desired for telnet actions. The connections defined in Configure Telnet Connections page appear in this menu. Commands: Enter the command strings to be transmitted. Up to 4 different command strings can be defined.
  • Page 29 All associated actions for the key release state will be executed. Release All Toggle Buttons: This action sets all toggle keys to the release state without executing any actions. Key Number: Select a key number for the selected keypad action. Broadata Technical Support, (800) 214-0222...
  • Page 30 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor Configure Auto Action The Configure Auto Action page is used to configure a set of auto actions based on a selected trigger. Available triggers are Video Detect, Digital Input 1, Digital Input 2, RS-232 Channel 1, RS-232 Channel 2, Telnet Trigger 1 and Telnet Trigger 2.
  • Page 31 IR code from the IR Preset menu, select the desired IR code and click the Delete button. On the top menu click Configure and then click IR Code. The following page will be displayed: Broadata Technical Support, (800) 214-0222...
  • Page 32 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor Configure IR Code Import The Configure IR Code Import page is used to import an IR pronto code. Once a code is imported, it will be stored in memory and is available as an IR Preset.
  • Page 33 On the top menu click Configure and then click Telnet Connections. The following page will be displayed: Connection Type: Select Persistent or Action. Telnet ID: Select Telnet-1 or Telnet-2. Broadata Technical Support, (800) 214-0222...
  • Page 34 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor Telnet Connection Label: Enter a label for the telnet connection. Connection Status: This box shows the status of a persistent connection. Telnet Options IP Address: Enter IP address of telnet server.
  • Page 35 ICP settings are saved to a file on the local PC using the Save Settings button. ICP settings are restored from a file using the Restore Settings button. On the top menu click Settings and then click View and Manage Settings. The following page will be displayed: Broadata Technical Support, (800) 214-0222...
  • Page 36 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor Click the Key Action Definitions Details button and the following will be displayed: Broadata Technical Support, Sales@Broadatacom.com...
  • Page 37 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT Receiver with Inline Control Processor Click the Auto Action Definitions Details button and the following will be displayed: Broadata Technical Support, (800) 214-0222...
  • Page 38 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor Click the IR Code Definitions Details button and the following will be displayed: Broadata Technical Support, Sales@Broadatacom.com...
  • Page 39 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT Receiver with Inline Control Processor Click the Telnet Definitions Details button and the following will be displayed: Broadata Technical Support, (800) 214-0222...
  • Page 40 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor Examples Example #1: This example configures the F1 key on the virtual keypad as a toggle key to turn on/off Relay channel 1. On the top menu click Configure and then Key Action.
  • Page 41 HBaseT Receiver with Inline Control Processor Configure F1 Key toggle-release action, to turn Relay channel 1 Off as follows: Click Submit Changes. On the top menu click Keypad. The following virtual keypad should be displayed: Broadata Technical Support, (800) 214-0222...

  • Page 42: Specifications

    LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor 6.0 SPECIFICATIONS Video (Transmission) HDMI Up to 1080p@60Hz or 1920x1200@60Hz Connector HDMI Female Plug Protocols DDC/EDID/HDCP Capable Supported Resolutions Resolution Vertical Refresh Rate (Hz) 640x480 800x600 1360x768 1280x720...
  • Page 43 Threshold low to high: 2 VDC Threshold high to low: 0.8 VDC Digital Output Output voltage high: 3 VDC min Output voltage low: 0.55 VDC max (64 mA sink max) Programmable open collector Connector Terminal block Broadata Technical Support, (800) 214-0222...
  • Page 44 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor IR (Control) Channel Capacity 1 in and 1 out Connector 3.5mm jack (for IR blaster) Carrier Frequency 30 kHz to 60 kHz (Output) 30 kHz to 60 kHz (IR learning)

  • Page 45: Service Procedure

    U.S. Please call Customer Service at 800-214-0222 for information. 7.2 Return/Repair Service The Link Bridge LBC-H-R-SCL-ICP System contains no user serviceable components. If you have a problem with your unit, please contact the Customer Service Department. To facilitate our return/repair processing please contact Broadata Communications, Inc.

  • Page 46: Limited Warranty

    HBaseT HDMI Receiver with Inline Control Processor 8.0 LIMITED WARRANTY Broadata Communications, Inc. (BCI) warrants, for a period of one year from date of shipment, each product sold shall be free from defects in material and workmanship. BCI will correct, either by repair, or at BCI’s election, by replacement, any said products that in our sole...

  • Page 47: Appendix

    LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT Receiver with Inline Control Processor 9.0 APPENDIX: RS-232 COMMANDS FOR SCALING RECEIVER Broadata Technical Support, (800) 214-0222...
  • Page 48 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor Note: 1. RS-232 commands will not execute unless followed with carriage return and LF (Line Feed). 2. Commands are not case-sensitive 3. Resolutions 1~16 are RGB encoded and 17~25 are YUV encoded.
  • Page 49 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT Receiver with Inline Control Processor Broadata Technical Support, (800) 214-0222...
  • Page 50 LBC-H-R-SCL-ICP User Manual Link Bridge HBaseT HDMI Receiver with Inline Control Processor Broadata Technical Support, Sales@Broadatacom.com...
  • Page 51 Broadata Communications, Inc. 2545 West 237th Street, Suite K Torrance, CA 90505 1-800-214-0222 (310) 530-1416 (310) 530-5958 (Facsimile) e-mail: CustomerService@Broadatacom.com Website: www.broadatacom.com 60000-LBCHRSCLICP...
