Broadata LBC-H/O-R-ICP User Manual

Link bridge hbase t/hdmi receiver with inline control processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LBC-H/O-R-ICP
TM
L
B
HB
T/HDMI
INK
RIDGE
ASE
R
ECEIVER WITH
I
C
P
NLINE
ONTROL
ROCESSOR
BCI reserves the right to make changes to the products described herein without prior
notice or consent. No liability is assumed as a result of their use or application. All
rights reserved.
©2015 Broadata Communications, Inc.

Advertisement

Table of Contents
loading

Related Manuals for Broadata LBC-H/O-R-ICP

Summary of Contents for Broadata LBC-H/O-R-ICP

  • Page 1 ECEIVER WITH NLINE ONTROL ROCESSOR BCI reserves the right to make changes to the products described herein without prior notice or consent. No liability is assumed as a result of their use or application. All rights reserved. ©2015 Broadata Communications, Inc.
  • Page 2 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor SAFETY INSTRUCTIONS AND COMPLIANCE DECLARATIONS PLEASE OBSERVE THE FOLLOWING SAFETY PRECAUTIONS SURGE PROTECTION DEVICE RECOMMENDED This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.

  • Page 3: Table Of Contents

    3.3 LB-KP8 ................11 4.0 LB-ICP WEB SERVER DESCRIPTION ......13 5.0 SPECIFICATIONS ............39 6.0 SERVICE PROCEDURE ..........42 6.1 REPLACEMENT POLICY ..........42 6.2 RETURN AND REPAIR SERVICE ......... 42 7.0 LIMITED WARRANTY ............ 43 Broadata Technical Support, (800) 214-0222...

  • Page 4: Product Description

    LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor 1.0 PRODUCT DESCRIPTION Overall • A selectable HDBT or HDMI receiver with multiple control I/O ports • Provides in-line control I/O paths Receiver • Receive HDMI, audio, IR, and RS-232 up to 100 meters over 1 CAT-5e/6 cable •...

  • Page 5: Operation Control And Functions

    HDBT RJ-45 connector – Connect a CAT5e/6/7 cable from this port to the HDBT output port of a compatible transmitter. The yellow LED indicates that the unit has a good HDBT connection with the transmitter. The green LED indicates the port is active. Broadata Technical Support, (800) 214-0222...
  • Page 6 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Terminal Block A Audio In L/R - Connect a stereo audio source to the Audio In (L), Audio In (R) and GND pins. This audio input can be selected as a source for the Audio Out.
  • Page 7 +24V power, such as an occupancy sensor. 11. Terminal Block C Connect a cable, terminated per Figure 3-5, in order to connect to an LB-KP8/LB-KP4 keypad. 12. Reset button – Press button to reset unit to factory default settings. Broadata Technical Support, (800) 214-0222...

  • Page 8: Connector Pinout Assignment

    LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor 3.0 CONNECTOR PINOUT ASSIGNMENT 3.1 Terminal Block A (Front view) 3.2 Terminal Block B (Front view) Broadata Technical Support, Sales@Broadatacom.com...
  • Page 9 3.4 LAN 1 and 2 Rear LAN 2 LAN 1 POWER 24V/2.7A RESET RJ-45 1 - TX+ 2 - TX- 3 - RX+ 4 - N/C 5 - N/C 6 - RX- 7 - N/C 8 - N/C Broadata Technical Support, (800) 214-0222...

  • Page 10: Lb-Kp8

    LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor 3.5 LB-KP8/LB-KP4 Rear RJ-45 Control Pin 1: RS-232 OUT Pin 2: RS-232 IN Pin 3: --no connect-- Pin 4: +12v Pin 5: +12v Pin 6: --no connect-- Pin 7: GND Pin 8: GND The cable connection between LB-KP8 and LB-ICP is shown below.

  • Page 11: Lb-Icp Web Server Description

    Type in the unit’s IP address in the web browser. The ICP Virtual Keypad page will be displayed. All 8 keys of the Virtual Keypad are un- programmed by default. The keys are configured in the Configure Keypad Control page. Broadata Technical Support, (800) 214-0222...
  • Page 12 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Before configuring the Virtual Keypad, the system first needs to be set up using the Configure System page. On the top menu bar, click Configure and then click System. This brings up the ICP Login.
  • Page 13 The Configure System page is used to configure the network keypad, virtual keypad, RS-232 channels, and Digital IO channels. On the top menu bar, click Configure and then click System. The following page will be displayed: Broadata Technical Support, (800) 214-0222...
  • Page 14 HBaseT/HDMI Receiver w/Inline Control Processor System The first three lines in this panel show the LBC-H/O-R-ICP model number, the Tx unit model number if one is connected and the software version. Below that is the address setup and status for the Network Keypad.
  • Page 15 Digital IO Direction: Select channel as a digital Input or Output. If the Digital IO Direction is set to Input, there is an option for Pullup Resistor. Pullup Resistor: Select Enable or Disable pull-up resistor. Broadata Technical Support, (800) 214-0222...
  • Page 16 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Configure Key Action The Configure Key Action page is used to configure the keys on the virtual keypad. On the 8-key keypad, each function key can be defined as a macro for up to 10 different actions. On the 16-key keypad, each function key can be defined as a macro for up to 5 actions.
  • Page 17 Digital Output, RS-232, IR, Telnet, Keypad, Video Control and Audio Control. Relay Options Relay Channel: Select the relay channel 1 or 2. Relay State: Select the relay channel state, On (energized) or Off (de- energized). Broadata Technical Support, (800) 214-0222...
  • Page 18 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Digital Output Options Digital Output Channel: Select the digital output channel 1 or 2. Note: this option is not available if both Digital IO channels are set to Inputs in Configure System page.
  • Page 19 CR, CR+LF or no termination, depending on the selection made in Configure System page. Characters enclosed by <> will be treated as hex. For example to transmit the string “8C 00 00 02 00 8E” in hex, enter <8C><00><00><02><00><8E>. Broadata Technical Support, (800) 214-0222...
  • Page 20 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor IR Options IR Preset: Select from list of IR commands stored in memory. IR commands can be imported via Configure IR Code Import page. Broadata Technical Support, Sales@Broadatacom.com...
  • Page 21 The combined maximum number of characters for all 4 strings is 100. Select the check box if the response to one of the commands is to be used as an auto trigger. Broadata Technical Support, (800) 214-0222...
  • Page 22 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Keypad Action Action: Select Press, Release, Press (no actions), Release (No actions), Release All Toggle Buttons, Lock Buttons or Unlock Buttons. Press: This action presses the key selected in Key Number menu. All associated actions for the key press state will be executed.
  • Page 23 Input Select: This action selects automode (auto switching) or manually selects the Tx HDMI (HDBT) or local HDMI. Output On: This action turns on the video output. Output Off: This action turns off the video output. Broadata Technical Support, (800) 214-0222...
  • Page 24 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Audio Control Action: Select Audio Output Source, HDMI Audio Mute, HDMI Audio Unmute, Analog Audio Mute, Analog Audio Unmute, Volume Up, Volume Down, Set Volume. Audio Output Source: This action selects the source for the analog audio output.
  • Page 25 Digital IOs are configured as outputs in the Configure System page. All auto triggers work independently and can be triggered simultaneously. On the top menu click Configure and then click Automated Control. The following page will be displayed: Broadata Technical Support, (800) 214-0222...
  • Page 26 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Trigger: Select the auto action trigger. Available triggers are Video Detect (Local HDMI), Video Detect (Remote HDMI), Video Detect (DisplayPort), Digital Input 1, Digital Input 2, RS-232 Channel 1, RS-232 Channel 2, Telnet Trigger 1 and Telnet Trigger 2.
  • Page 27 On the top menu click Configure and then click IR Codes Management. The following page will be displayed: Status: Indicates the status of the IR module. IR Preset: Select from list of user imported IR codes. Broadata Technical Support, (800) 214-0222...
  • Page 28 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Configure IR Code Import The Configure IR Code Import page is used to import an IR pronto code. Once a code is imported, it will be stored in memory and is available as an IR Preset.
  • Page 29 On the top menu click Configure and then click Telnet Connections. The following page will be displayed: Connection Type: Select Persistent or Action. Telnet ID: Select Telnet-1, 2 (Persistent type); Telnet-3, 4, 5, 6, 7, 8, 9, 10 (Action type). Broadata Technical Support, (800) 214-0222...
  • Page 30 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Telnet Connection Label: Enter a label for the telnet connection. Connection Status: This box shows the status of a persistent connection. Telnet Options IP Address: Enter IP address of telnet server.
  • Page 31 Trigger Event 1/2/3: Select the desired trigger from pull-down menu. Trigger When 1/2/3: Select High or Low for digital input triggers. Select Asserted or De-asserted for video detect triggers. OR/AND: Select the logical OR or AND function. Broadata Technical Support, (800) 214-0222...
  • Page 32 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Configure Video Switching The Configure Video Switching page is used to manually select the video input. The video inputs can be automatically selected if Automode is selected. HDCP and EDID management functions are also configured on this page.
  • Page 33 HDMI input from the drop down menu. EDID Settings - HDBT Input: Select the desired EDID for the HDBT input port from the drop down menu. The selected EDID will pass through to the remote transmitter. Broadata Technical Support, (800) 214-0222...
  • Page 34 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Configure Audio Settings The Configure Audio Settings page is used for configuring the audio settings of the analog audio output available in Terminal Block A. The analog audio output source selection, down mix, volume, muting and mixer functions are controlled on this page.
  • Page 35 HDMI audio input to the mixer. The gain range is 0 to 15 dB. Mixer Gain - External audio: Set the gain level for the external analog audio input to the mixer. The gain range is 0 to 15 dB. Broadata Technical Support, (800) 214-0222...
  • Page 36 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Configure Video Settings The Configure Video Settings page is only available on the LBC-H/O- R-ICP-SCL model. This page is used to configure the various video settings of the scaler. On the top menu click Configure and then click Video Settings. The...
  • Page 37 Save Settings button. ICP settings are restored from a file using the Restore Settings button. On the top menu click Settings and then click View and Manage Settings. The following page will be displayed: Broadata Technical Support, (800) 214-0222...
  • Page 38 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Click the Key Action Definitions Details button and the following will be displayed: Broadata Technical Support, Sales@Broadatacom.com...
  • Page 39 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Click the Auto Action Definitions Details button and the following will be displayed: Broadata Technical Support, (800) 214-0222...
  • Page 40 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Click the IR Code Definitions Details button and the following will be displayed: Broadata Technical Support, Sales@Broadatacom.com...
  • Page 41 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Click the Telnet Definitions Details button and the following will be displayed: Broadata Technical Support, (800) 214-0222...
  • Page 42 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Click the Combination Triggers Details button and the following will be displayed: Broadata Technical Support, Sales@Broadatacom.com...
  • Page 43 Relay channel 1. On the top menu click Configure and then Key Action. Configure F1 Key toggle-press action, to turn Relay channel 1 On as follows: Click Submit Changes. Broadata Technical Support, (800) 214-0222...
  • Page 44 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Configure F1 Key toggle-release action, to turn Relay channel 1 Off as follows: Click Submit Changes. On the top menu click Keypad. The following virtual keypad should be displayed: Broadata Technical Support, Sales@Broadatacom.com...

  • Page 45: Specifications

    CAT-5e/6 or higher Number of Cables Connector/Distance RJ-45/Up to 100m ETHERNET (CONTROL) Channel Capacity Connector Female RJ-45 (integrated Activity and Link LEDs) Data Rate 10/100Base-T, half/full duplex with autodetect Protocols DHCP, HTTP, TCP/IP, UDP/IP, AUTOIP, Telnet Broadata Technical Support, (800) 214-0222...
  • Page 46 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor RS-232 (CONTROL) Channel Capacity 3 (no flow control) or 2 (with RTS/ CTS flow control) Baud Rate 2400 to 115200 baud Connector Terminal block DIGITAL I/O (CONTROL) Channel Capacity 2 digital input/output (configurable)

  • Page 47: Service Procedure

    U.S. Please call Customer Service at 800-214-0222 for information. 6.2 Return/Repair Service The Link Bridge LBC-H/O-R-ICP System contains no user serviceable components. If you have a problem with your unit, please contact the Customer Service Department. To facilitate our return/repair processing please contact Broadata Communications, Inc.

  • Page 48: Limited Warranty

    HBaseT/HDMI Receiver w/Inline Control Processor 7.0 LIMITED WARRANTY Broadata Communications, Inc. (BCI) warrants, for a period of one year from date of shipment, each product sold shall be free from defects in material and workmanship. BCI will correct, either by repair, or at BCI’s election, by replacement, any said products that in our sole...
  • Page 49 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Broadata Technical Support, (800) 214-0222...
  • Page 50 LBC-H/O-R-ICP User Manual Link Bridge HBaseT/HDMI Receiver w/Inline Control Processor Broadata Technical Support, Sales@Broadatacom.com...
  • Page 51 Broadata Communications, Inc. 2545 West 237th Street, Suite K Torrance, CA 90505 1-800-214-0222 (310) 530-1416 (310) 530-5958 (Facsimile) e-mail: CustomerService@Broadatacom.com Website: www.broadatacom.com 60000-LBCHORICPv3.0...
