RIDGID R5011 Operator's Manual

1/2 in. hammer drill double insulated
Hide thumbs Also See for R5011:
Table of Contents

Advertisement

Quick Links

See also: Operator's Manual
Your
hammer drill
has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using this product.
Thank you for buying a RIDGID product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
1/2 in. HAMMER DRILL
DOUBLE INSULATED
R5011
1

Advertisement

Table of Contents
loading

Related Manuals for RIDGID R5011

Summary of Contents for RIDGID R5011

  • Page 1 When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product. Thank you for buying a RIDGID product. SAVE THIS MANUAL FOR FUTURE REFERENCE OPERATOR’S MANUAL 1/2 in.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS  Introduction ... 2  General Safety Rules ...3-4  Specific Safety Rules ... 4  Symbols ...5-6  Electrical ... 7  Features ...8-9  Assembly ...9-10  Operation ...11-15  Maintenance ...15-16  Warranty ... 17 ...

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES WARNING: Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term “power tool” in all of the warnings listed below refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

  • Page 4: Specific Safety Rules

    GENERAL SAFETY RULES SERVICE  Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. WARNING! To reduce the risk of injury, user must read instruction manual.

  • Page 5: Symbols

    SYMBOLS Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME Volts Amperes Hertz Watt Minutes Alternating Current Direct Current...

  • Page 6: Symbols

    To avoid serious personal injury, do not attempt to use this product until you read thoroughly and understand completely the operator’s manual. If you do not understand the warnings and instructions in the operator’s manual, do not use this product. Call RIDGID customer service for assistance.

  • Page 7: Electrical

    ELECTRICAL DOUBLE INSULATION Double insulation is a concept in safety in electric power tools, which eliminates the need for the usual three-wire grounded power cord. All exposed metal parts are isolated from the internal metal motor components with protect- ing insulation. Double insulated tools do not need to be grounded.

  • Page 8: Features

    FEATURES PRODUCT SPECIFICATIONS Chuck Capacity ... 1/2 in. Input ...120 V, 60 Hz, AC only, 8.5 Amps Switch ...VSR (Variable Speed Reversible) DEPTH STOP ROD CHUCK CHUCK KEY STORAGE P0WER CHUCK CORD Hammer Speed ... 0-19,000/0-57,000 BPM No Load Speed ...Low (0-1,000 r/min. (RPM)) & High (0-3,000 r/min.

  • Page 9: Assembly

    The two-speed gear train is designed for drilling or driving at LO (1) or HI (2) speeds. A slide switch is located on the side of your drill for selecting either LO (1) or HI (2) speed. Use low speed for high torque and high speed for faster operation during low torque applications.
  • Page 10 ASSEMBLY INSTALLING AUXILIARY HANDLE ASSEMBLY See Figure 2. An auxiliary handle is packed with the drill for ease of op- eration and to help prevent loss of control.  Open the clamping ring by turning the handle counter- clockwise.  Slide the ring of the auxiliary handle onto the spindle collar of the drill.

  • Page 11: Operation

     Drilling in metals  Mixing paint SWITCH TRIGGER See Figure 4. To turn the drill ON, depress the switch trigger. To turn it OFF, release the switch trigger. VARIABLE SPEED The variable speed switch delivers higher speed with increased trigger pressure and lower speed with decreased trigger pressure.
  • Page 12 The drill has a two-speed gear train designed for drilling or driving at LO (1) or HI (2) speeds. A switch is located on the side of the drill to select either LO (1) or HI (2) speed. When using drill in the LO (1) speed range, speed will decrease and unit will have more power and torque.
  • Page 13 To adjust for type of drilling, slide the selector on top of the motor housing to hammer mode or drilling mode. The ham- mer mode symbol is on the right and the drill bit symbol is on the left. NOTE: The hammer drill has not been designed for reverse hammering.
  • Page 14 DRILLING See Figure 13  Depress and release the switch trigger to be sure the drill is in the OFF position before connecting it to a power supply.  Check the direction of rotation selector for the correct setting (forward or reverse).

  • Page 15: Maintenance

    This will prevent the drill bit from slipping off-center as the hole is started.  When drilling metals, use a light oil on the drill bit to keep it from overheating. The oil will prolong the life of the bit and increase the drilling action.
  • Page 16  Open chuck jaws using the provided chuck key.  Insert a 5/16 inch (8 mm) or larger hex key into the chuck of the drill and tighten the chuck jaws securely.  Tap the hex key sharply with a mallet in a clockwise direction.

  • Page 17: Warranty

    Tools covers all defects in workmanship or materials and normal wear items such as brushes, chucks, motors, switch- es, cords, gears and even cordless batteries in this RIDGID tool for three years following the purchase date of the tool. Warranties for other RIDGID products may vary.
  • Page 18 NOTES...
  • Page 19 NOTES...

  • Page 20: Customer Service Information

    DOUBLE INSULATED R5011 Customer Service Information: For parts or service, contact your nearest RIDGID authorized service center. Be sure to provide all relevant information when you call or visit. For the location of the authorized service center nearest you, please call 1-866-539-1710 or visit us online at www.ridgid.com.
