Page 1 SpeechLine Digital Wireless System Documentation Sennheiser electronic GmbH & Co. KG Am Labor 1, 30900 Wedemark, Germany, www.sennheiser.com SpeechLine Digital Wireless - v2.2...
Page 2: System Information
SYSTEM INFORMATION SYSTEM PLANNING INSTRUCTION MANUAL CONTACT SpeechLine Digital Wireless - System Documentation v2.2...
Page 3: Table Of Contents
Future-proof, license-free audio transmission 15 Tap-proof audio transmission 15 Extremely long battery life 15 Easy control using the Sennheiser Control Cockpit software 15 The Products of the SpeechLine Digital Wireless Series 16 The SL Rack Receiver DW receiver 16 The handheld transmitter 17...
Page 4 Single room – installation and startup 50 Several rooms – installation and startup 50 SpeechLine Digital Wireless: Instruction manual 52 SL Rack Receiver DW 54 Product overview and operating elements – front panel 55 Product overview and connections – rear panel 57 Connecting the receiver 58...
Page 5 Installing two receivers next to one another in a fixed location 70 GA 4 mounting kit 71 Mounting the jointing plate and the mounting angles 72 Connecting the AWM 2 / AWM 4 remote antenna to the receiver 72 Displays on the receiver’s display panel 73 Home screen 73 Secondary home screen 75 Using the operating menu of the receiver 76...
Page 6 Muting the table stand 103 The SL Tablestand 153-S DW 104 Product overview 105 Starting up and using the table stand 106 Removing/inserting the BA 40 accupack 106 Charging the table stand via USB 107 Charging the table stand using the CHG 2W wireless charging base 107 Charging the table stand with a wireless Qi charging base from a third-par- ty manufacturer 108 Meaning of the charge level LEDs on the table stand 109...
Page 7 Product overview and connections – rear panel 140 Powering the SL DI 4 XLR 141 Power supply via Ethernet cable 141 Power supply via the optional Sennheiser NT 12-50CS power supply unit 141 Daisy-chaining the power supply 142 Connecting audio signals 143...
Page 8 The AWM 2 antenna wall mount 170 Product overview 171 Connecting and mounting the AWM 2 172 To mount the antenna wall mount to a wall 172 To mount the antenna wall mount to a microphone stand 173 The AWM 4 antenna wall mount 175 Product overview 176 Connecting and mounting the AWM 4 177 Attaching the antennas 177...
Page 9: Speechline Digital Wireless: System Information
SpeechLine Digital Wireless: System Information SpeechLine Digital Wireless: System Information ► SpeechLine Digital Wireless is the first digital wireless microphone system designed specifically for the spoken word. SpeechLine Digital Wireless is a future-proof solution that’s easy to set up, use and manage and that lets the presenter concentrate on their words, not on the technology.
Page 10 SpeechLine Digital Wireless: System Information For more information about the individual products in the SpeechLine Dig- ital Wireless series, see „The Products of the SpeechLine Digital Wireless Series“. For information about planning a complete SpeechLine Digital Wireless system, see „SpeechLine Digital Wireless: System planning“. You can find instruction manuals for all products in the SpeechLine Digital Wireless series under „SpeechLine Digital Wireless: Instruction manual“.
Page 11: Focus On The Spoken Word
Focus on the spoken word Focus on the spoken word ► The spoken word is and remains the most personal and powerful instru- ment of communication we know. It allows us to convince people, to impart knowledge and to voice opinions, thoughts and views as well as emotions. That is why it is so important that none of the content is lost when audio devices such as wireless microphones and the associated receivers are used.
Page 12: Speechline Digital Wireless - The Professional Solution For Speakers, Lecturers And Presenters
Focus on the spoken word SpeechLine Digital Wireless – the professional solu- tion for speakers, lecturers and presenters ► The best wireless microphones and receivers are those which the speaker does not need to think about because they are ready for immediate use, au- tomatically establish the most reliable radio link and provide maximum transmission reliability in every application and all day long.
Page 13: Typical Applications
Focus on the spoken word Typical applications Excellent speech intelligibility, easy handling and convenient control are to the fore at all times, regardless of whether SpeechLine Digital Wireless is used in presentations, meetings or telephone conferences. Presentations ► In the case of a presentation held before a large audience, such as in an au- ditorium or a large conference room, it is essential that every word can be understood.
Page 14: Meetings
Focus on the spoken word Meetings ► Good speech intelligibility and easy handling of the microphone system are important requirements for professional meetings. The larger the confer- ence or training room, the more helpful is an audio system which enhances speech intelligibility.
Page 15: Teleconferences
SpeechLine Digital Wireless system can easily be connected to an ex- isting teleconference unit such as the Sennheiser TeamConnect system. This processes the audio signals and establishes the connection to the re-...
Page 16: What Are The Features Of Speechline Digital Wireless
Focus on the spoken word What are the features of SpeechLine Digital Wire- less? Automatic frequency management SpeechLine Digital Wireless finds free transmission frequencies reliably and fully automatically. Manual intervention is not necessary in the search for a free frequency. This means that your wireless microphone and the re- ceiver are ready for use within an extremely short time: connect them, switch them on –...
Page 17: Future-Proof, License-Free Audio Transmission
USB charging cable. Easy control using the Sennheiser Control Cockpit software Sennheiser Control Cockpit is the central software for easy handling, con- trol and maintenance of the entire SpeechLine Digital Wireless system. The easy-to-use Sennheiser Control Cockpit software provides a global overview of all network enabled SpeechLine Digital Wireless devices at all times.
Page 18: The Products Of The Speechline Digital Wireless Series
The SL Rack Receiver DW receiver ► The 9.5" rack receiver (SL Rack Receiver DW) is the core of the SpeechLine Digital Wireless system. Thanks to the bi-directional communication be- tween the rack receiver and the transmitter, all transmitter settings can be adjusted on the receiver.
Page 19: The Handheld Transmitter
The Products of the SpeechLine Digital Wireless Series The handheld transmitter ► The handheld transmitter (SL Handheld DW) is ideal when several persons are speaking at the same time, such as in interviews or when queries come from the audience. You can replace the microphone capsule if necessary. The handheld transmitter is supplied with the high-quality MME 865-1 mi- crophone capsule.
Page 20: The Bodypack Transmitter
► The compact, robust bodypack transmitter (SL Bodypack DW) is compati- ble with all Sennheiser headset and clip-on microphones (e.g. SL Headmic 1 or MKE 1). Thanks to the bi-directional communication between the trans- mitter and the receiver, no settings need to be adjusted on the transmitter.
Page 21: The Clip-On And Headset Microphones
The Products of the SpeechLine Digital Wireless Series The clip-on and headset microphones ► ► The MKE 1 clip-on microphone is attached to clothing by means of a micro- phone clip or with adhesive tape, the SL Headmic 1 headset microphone is a head-worn microphone with an adjustable frame that wraps around the neck.
Page 22: The Wireless Sl Tablestand 133-S Dw
The CHG 2W wireless charging base for two mobile devices is available separately. The SL Tablestand 133-S DW is delivered with a rechargeable battery that lasts up to 10 hours. The Sennheiser Control Cockpit software can be used to monitor and con- trol the wireless table stand remotely.
Page 23: The Wireless Sl Tablestand 153-S Dw
The CHG 2W wireless charging base for two mobile devices is available separately. The SL Tablestand 153-S DW is equipped with dedicated charging status LEDs to clearly show the battery life. The Sennheiser Control Cockpit software can be used to monitor and con- trol the SL Tablestand 153-S DW remotely.
Page 24: The Wireless Sl Boundary 114-S Dw
The CHG 2W wireless charging base for two mobile devices is available separately. The SL Boundary 114-S DW is delivered with a rechargeable battery that lasts up to 10 hours. The Sennheiser Control Cockpit software can be used to monitor and con- trol the wireless boundary microphone remotely.
Page 25: The Dante™ Interface
The Products of the SpeechLine Digital Wireless Series The Dante™ interface ► ► The SL DI 4 XLR is a Dante™ interface with four inputs. This lets you inte- grate wireless microphone receivers or mic/line inputs into a Dante™ sys- tem.
Page 26: The Chg 2 Charger
The Products of the SpeechLine Digital Wireless Series The CHG 2 charger ► The CHG 2 charger allows you to simultaneously charge up to two trans- mitters of the SpeechLine Digital Wireless series. A bi-color LED at each charging slot provides information on the current charge status. The char- ger has universal charging slots for charging both handheld and bodypack transmitters.
Page 27: The Chg 4N Charger
DW. The four LEDs on each charging slot indicate the current charging status. The versatile network interface is compatible with IPv4 and IPv6 for seamless integration. The Sennheiser Control Cockpit soft- ware can be used to monitor and remotely control the settings and status...
Page 28: The Chg 2W Charging Base
The Products of the SpeechLine Digital Wireless Series The CHG 2W charging base ► ► The CHG 2W is a wireless charging base that provides convenient wireless charging. The CHG 2W charging base is compatible with the SL Tablestand 133-S DW, the SL Tablestand 153-S DW and the SL Boundary 114-S DW.
Page 29: Speechline Digital Wireless: System Planning
SpeechLine Digital Wireless installation. To make planning even easier, we offer a planning tool available on the SpeechLine Digital Wireless product page at www.sennheiser.com/ speechline-dw. SpeechLine Digital Wireless product page...
Page 30: Planning
Planning Planning At the start of planning, the following aspects are to be considered. Country-Specific Variants Check which country variant of SpeechLine Digital Wireless is suitable for your location. The following eight country variants are available. -3 EU Variant: ► -3 UK Variant: ►...
Page 31 Planning -4 US Variant: ► -5 US Variant: ► -6 US Variant: ► -7 EU Variant: ► The country variant to be used determines the maximum number of links per range which can be used in the 1.9 GHz frequency band.
Page 32: Number And Size Of The Rooms
Planning Number and size of the rooms • Determine the number of rooms needed for the installation. • Determine how each individual room is to be equipped and used. • Determine the audio equipment for each room, i.e. the desired number of SpeechLine Digital Wireless links.
Page 33: Shared Use Of The 1.9 Ghz Frequency Band
Shared use of the 1.9 GHZ frequency band When SpeechLine Digital Wireless is used in combination with other devic- es using the 1.9 GHz frequency band (e.g. Sennheiser TeamConnect Wire- less or DECT telephones), the maximum number of SpeechLine Digital Wireless links depends on the number of other devices used.
Page 34: Usa, Canada, Latin America, Brazil, Taiwan
Planning USA, Canada, Latin America, Brazil, Taiwan ► SpeechLine Digital Wireless Links - per range (adjustable) seamless cooperation depending on spectrum used by other systems exceeds available spectrum...
Page 35: Japan
Planning Japan ► SpeechLine Digital Wireless Links - per range (adjustable) seamless cooperation depending on spectrum used by other systems exceeds available spectrum...
Page 36: Analysis Of The Environmental Conditions
Planning Analysis of the environmental conditions When planning the installation of a SpeechLine Digital Wireless system, you should also carefully analyze the environmental conditions. Are there any other 1.9 GHz devices (e.g. DECT telephones or DECT access points) already installed? Observe the following aspects when planning an installation •...
Page 37: Recommendations On Antenna Mounting
Recommendations on antenna mounting Recommendations on antenna mount- There are different factors to consider when mounting antennas. This chapter provides instructions and recommendations that you should follow when mounting antennae.
Page 38: Antenna Setup And Planning For Speechline Digital Wireless
Recommendations on antenna mounting Antenna setup and planning for SpeechLine Digital Wireless When planning the installation of SpeechLine Digital Wireless devices for each room, observe the following guidelines. Mount all SpeechLine Digital Wireless receivers together in one rack. ▷ Make sure to have a direct line of sight between the transmitters and ▷...
Page 39: Antenna Mounting Options
Recommendations on antenna mounting Antenna mounting options There are different options for remote mounting the antennas. We recom- mend the following four options in the specified order. >> „Option 1: Connecting the AWM 2 or AWM 4 antenna wall mount directly to the receiver(s)”...
Page 40: Option 1: Connecting The Awm 2 Or Awm 4 Antenna Wall Mount Directly To The Receiver(S)
• For the AWM 2 you can use Sennheiser CL 5/10/20 extension cables. • For the AWM 4 you can use Sennheiser CL 1/5/10/20 PP extension ca- bles. Observe the following information when using extension cables: Signal loss due to extension cables In this scenario, using extension cables for remote antenna mounting re- sults in a loss of transmission power, depending on the cable length.
Page 41: Remote Antenna Distances And Line Of Sight
All antennas A from Ant II sockets Ant I sockets of all SL Rack Receiver DW units of all SL Rack Receiver DW units Distance to reﬂecting surface / obstacle: min. 7.5 cm (3"), recommended 17 cm (7") minimum 7.5 cm (3") recommended 17 cm (7")
Page 42 Recommendations on antenna mounting ▷ If possible, position the antennas so that there is a direct line of sight (without obstacles) between the transmitters and the antennas. ►...
Page 43: Option 2: Combining Multiple Links To One Awm 2/Awm 4
Recommendations on antenna mounting Option 2: Combining multiple links to one AWM 2/ AWM 4 With this option, passive antenna combiners can be used together with the AWM 2 or the AWM 4 in order to combine the antenna signals of several receivers.
Page 44: Combining Up To 4 Links Using The Awm 2
(connected to antenna combiner) The illustration indicates which SMA and R-SMA connectors the ca- bles need to have. You can either use Sennheiser CL 5/10 extension cables together with SMA to R-SMA adapters or you can make your own low-loss cables with the respective couplings.
Page 45: Combining Up To 8 Links Using The Awm 4
(connected to antenna combiner) The illustration indicates which SMA and R-SMA connectors the ca- bles need to have. You can either use Sennheiser CL 5/10 or CL 1/5/ 10 PP extension cables together with SMA to R-SMA adapters or you can make your own low-loss cables with the respective couplings.
Page 46: Signal Loss Due To Extension Cables And Antenna Combiners
You can compensate this signal loss by configuring the transmission pow- er of the receiver accordingly. Observe the following minimum transmis- sion power settings (SL Rack Receiver DW: System Settings menu -> RF Power) for the respective cable lengths. The antenna combiner produces a signal loss which is equivalent to 15 m of extension cable.
Page 47: Option 3: Rack Mounting - Front
Recommendations on antenna mounting Option 3: Rack mounting - front If you wish to install the antennae together with the receivers in a rack, we recommend mounting the antennae on the front side of the rack using the GA 4 mounting kit. ▷...
Page 48: Option 4: Rack Mounting - Rear
Recommendations on antenna mounting Option 4: Rack mounting - rear If you cannot mount the antennas at the front of the rack (option 3), you can also mount them at the rear of the receiver in the rack. When mounting, ob- serve the following information.
Page 49: Further Important Information On Antenna Usage
Recommendations on antenna mounting Further important information on antenna usage Reflecting surfaces Electrically conducting surfaces (e.g. ceilings with metal constructions) can reflect the RF signal. ► The signal is reflected by the electrically conducting surface. At worst, the blue signal and the red reflected signal are out of phase when they reach the receiver so that the two signals cancel each other out.
Page 50 Recommendations on antenna mounting Rule of thumb for distance from the blocking area: ► Blocking range Free range ratio 1:1 Example: ►...
Page 51: Multi-Room Mode
Multi-room mode Multi-room mode SpeechLine Digital Wireless, by taking into account the installation size as well as country-specific regulations, allows to optimally use the 1.9 GHz frequency band. SpeechLine Digital Wireless offers two operating modes for different types of installation: the automatic mode with adaptive transmission power for single-room installations (Adaptive Power Mode) and the manual mode for multi-room installations, which is known as Multi-Room Mode.
Page 52: Single Room - Installation And Startup
Multi-room mode Single room – installation and startup ▷ Install all receivers in a one rack. Wire all receivers. ▷ ▷ Mount all antennas as recommended (see „Recommendations on an- tenna mounting”). ▷ Make sure that all receivers are switched off. ▷...
Page 53 Multi-room mode ▷ After this rack has been configured, the receivers must only be switched on and off together – not individually. Switch the complete rack on and off using the on/off switch of the multi-outlet power strip. ▷ Switch off the rack in this room and repeat the above steps for config- uring the rack in the next room.
Page 54: Speechline Digital Wireless: Instruction Manual
SpeechLine Digital Wireless: Instruction manual SpeechLine Digital Wireless: Instruction manual This manual provides detailed information about installation and usage of the individual products in the SpeechLine Digital Wireless series. ► SL Rack Receiver DW ► SL Handheld DW ► SL Bodypack DW ►...
Page 55 SpeechLine Digital Wireless: Instruction manual ► MKE 1 ► SL DI 4 XLR ► CHG 2 ► CHG 4N ► CHG 2W ► AWM 2 ► AWM 4...
Page 56: Sl Rack Receiver Dw
SL Rack Receiver DW SL Rack Receiver DW The 9.5" rack receiver (SL Rack Receiver DW) is the core of the SpeechLine Digital Wireless system. Thanks to the bi-directional communication be- tween the rack receiver and the transmitter, all transmitter settings can be adjusted on the receiver.
Page 57: Product Overview And Operating Elements - Front Panel
SL Rack Receiver DW Product overview and operating elements – front panel ► ► ► 1 PAIR button • Short-press to identify the paired transmitter. • Long-press to pair with a different transmitter. • See „Pairing”. Display panel • See „Displays on the receiver’s display panel”.
Page 58 SL Rack Receiver DW To switch the receiver off: Long-press the STANDBY button. ▷ ► The display panel and the status LED go off. Status LED lights up green: • A radio link to the transmitter is established. The accupack of the re- ceived transmitter is sufficiently charged.
Page 59: Product Overview And Connections - Rear Panel
SL Rack Receiver DW Product overview and connections – rear panel ► ► 7 ANT I ANT II antenna sockets (R-SMA) • Antenna inputs for connecting the supplied rod antennae • Alternatively, the antennae can be mounted using extension cables and the AWM 2 antenna wall mount or using the GA 4 mounting kit.
Page 60: Connecting The Receiver
SL Rack Receiver DW Connecting the receiver Connecting the receiver to the power supply system Only use the included power supply unit (NT 12-4 C or NT 2-3) to connect the receiver to the power supply system. ► ► If you use the NT 2-3 power supply unit: ▷...
Page 61: Connecting An Amplifier Or Mixing Console To The Receiver
SL Rack Receiver DW ▷ Plug the power supply unit into the wall socket. ► ► Connecting an amplifier or mixing console to the receiver The unbalanced audio output (RCA) and the balanced audio output (XLR) at the rear of the receiver are connected in parallel, allowing you to simulta- neously connect two devices (e.g.
Page 62: Controlling And Monitoring The Receiver Via The Network
Sennheiser Control Cockpit software, refer to the instruction manual of the software. Please note that the host PC on which the Sennheiser Control Cockpit Service is installed must be in the same network as the devices that are to be monitored and controlled.
Page 63: Integrating The Receiver Into A Network With Dhcp
Set the Mode to Automatic in the receiver’s Network Settings menu. ▷ ▷ Ensure that the host PC on which the Sennheiser Control Cockpit ser- vice is installed is configured so that the IP address is assigned auto- matically, rather than a static configuration.
Page 64: Integrating The Receiver Into A Network Without Dhcp Using Fixed Ip
▷ Settings menu. To add the receiver in the Sennheiser Control Cockpit: Use the Add Device function in the Sennheiser Control Cockpit and ▷ enter the IP address you selected. Activate the mDNS function in the receiver’s Network Settings menu ▷...
Page 65: Setting Up The Receiver
SL Rack Receiver DW Setting up the receiver This sections describes how to set up the receiver. You can also install the receiver in a fixed location, e.g. in a 19" rack. You can find more information about installing the receiver in a fixed location under: „Installing a single receiver in a fixed location”.
Page 66: Attaching The Mounting Angles
SL Rack Receiver DW Attaching the mounting angles The mounting angles are designed to help protect the operating elements from damage or deformation, e.g. if the receiver is dropped. We therefore recommend always attaching the mounting angles, even if you do not want to mount the receiver into a rack.
Page 67: Connecting The Rod Antennae To The Receiver
SL Rack Receiver DW Connecting the rod antennae to the receiver To connect the supplied rod antennae to the receiver: Screw the two rod antennae into the receiver's two antenna sockets, ▷ ANT I II, as shown. ▷ Align the rod antennae vertically.
Page 68: Installing A Single Receiver In A Fixed Location
SL Rack Receiver DW Installing a single receiver in a fixed location This chapter describes how to install a single receiver in a fixed location, e.g. in a 19" rack. You can also install two receivers next to one another in a rack. You can find more information about installing two receivers next to one another under: „Installing two receivers next to one another in a fixed location”.
Page 69: Ga 4 Mounting Kit
SL Rack Receiver DW GA 4 mounting kit You need the GA 4 mounting kit to install the receiver in a rack. The GA 4 mounting kit is available separately as an accessory and is also supplied with the following sets: •...
Page 70: Attaching The Mounting Angles
SL Rack Receiver DW Attaching the mounting angles To fasten the mounting angles: Unscrew and remove the two recessed head screws on each side of the ▷ receiver. ▷ Secure the mounting angles to the sides of the receiver using the pre- viously removed recessed head screws.
Page 71: Mounting The Rod Antennae To The Front Of The Rack
SL Rack Receiver DW Mounting the rod antennae to the front of the rack To mount the rod antennae to the front of the rack: Connect the included antenna cables to the antenna sockets at the rear ▷ of the receiver.
Page 72: Installing Two Receivers Next To One Another In A Fixed Location
SL Rack Receiver DW Installing two receivers next to one another in a fixed location This chapter describes how to install two receivers next to one another in a fixed location, e.g. in a 19" rack. You can also install just a single receiver in a rack. You can find more infor- mation about installing a single receiver under: „Installing a single receiver...
Page 73: Ga 4 Mounting Kit
SL Rack Receiver DW GA 4 mounting kit You need the GA 4 mounting kit to install two receivers in a rack. The GA 4 mounting kit is available separately as an accessory and is also supplied with the following sets: •...
Page 74: Mounting The Jointing Plate And The Mounting Angles
SL Rack Receiver DW Mounting the jointing plate and the mounting angles To fasten the mounting angles: Unscrew and remove the two recessed head screws on the outward- ▷ facing sides of the receiver. ▷ Secure the mounting angles to the outward-facing sides of the receiver using the previously removed recessed head screws.
Page 75: Displays On The Receiver's Display Panel
SL Rack Receiver DW Displays on the receiver’s display panel Home screen The home screen appears automatically after switch-on or when no button has been pressed on the receiver for a long period of time. If there is no radio link between the receiver and a transmitter, No Link ap- pears on the display panel and the display brightness is automatically dimmed.
Page 76 Expected remaining battery life of the received transmitter • Displays the remaining battery life of the received transmitter in hours (only when the original Sennheiser BA 10, BA 30 and BA 40 ac- cupacks are used). • The remaining battery life is not displayed when batteries or re- chargeable AA size batteries are used.
Page 77: Secondary Home Screen
SL Rack Receiver DW Secondary home screen When you turn the jog dial to the left from the home screen, the secondary home screen appears. ► 11Audio output level of the receiver 12Pick-up pattern of the microphone used 13Status of the low-cut filter (ON/OFF)
Page 78: Using The Operating Menu Of The Receiver
SL Rack Receiver DW Using the operating menu of the receiver Using the buttons for navigation Press the STANDBY button • Short-press: Switches the receiver on • Long-press: Switches the receiver off Short-press the button SHORT • Navigates to the next higher level in the menu •...
Page 79: The Menu Structure Of The Receiver
SL Rack Receiver DW The menu structure of the receiver ► Home Home Screen Secondary Home Screen Level 1 Audio System Network Device Help Settings Settings Settings Identiﬁcation Level 2 Display Low Cut Mode Link Name Brightness Mute Sound Location...
Page 80: The Audio Settings Menu
SL Rack Receiver DW The Audio Settings menu The Audio Settings menu at menu level 1 allows you to adjust the following settings. Low Cut • On: The low cut filter is activated. Low-frequency noise is filtered out. • Off: The low cut filter is deactivated.
Page 81: The Network Settings Menu
SL Rack Receiver DW Auto Lock • On: The automatic lock mode is activated. If no button is actuated on the receiver for approx. 10 minutes, the lock mode is automatically activat- • Long-press the jog dial to temporarily deactivate the lock mode.
Page 82: The Device Identification Menu
SL Rack Receiver DW Gateway • Input of the gateway in Fixed IP mode IPv6 • Displays the IPv6 address • Displays the MAC address The Device Identification menu The Device Identification menu at menu level 1 allows you to adjust the following settings.
Page 83: The Sl Handheld Dw
The SL Handheld DW The SL Handheld DW The handheld transmitter (SL Handheld DW) is ideal when several persons are speaking at the same time, such as in interviews or when queries come from the audience. You can replace the microphone capsule if necessary. The handheld transmitter is supplied with the high-quality MME 865-1 mi- crophone capsule.
Page 84: Product Overview
The SL Handheld DW Product overview ► Unscrewable microphone head with microphone capsule The handheld transmitter is available with or without the MME 865-1 mi- crophone capsule. The MME 865-1 has a pre-polarized condenser micro- phone capsule with super-cardioid pick-up patterns. ►...
Page 85 The SL Handheld DW To mute the handheld transmitter: Slide the MUTE switch to the position MUTE. ▷ Muted appears on the display panel of the receiver. The status LED on both the handheld transmitter and the receiver lights up yellow. ►...
Page 86: Displays On The Display Panel Of The Sl Handheld Dw
The SL Handheld DW Displays on the display panel of the SL Handheld ► Name of the radio link • Can be entered in the Device Identification menu of the receiver. 7-step display of the accupack or battery capacity • Graphically displays the current charge status of the accupack or the batteries.
Page 87 The SL Handheld DW If you use the optional B 10 battery compartment: Insert the batteries into the B 10 battery compartment. ▷ ▷ Please observe correct polarity when inserting the batteries. ► To insert the accupack or the battery compartment: Slide the accupack or the battery compartment onto the handheld ▷...
Page 88: Switching The Handheld Transmitter On And Off
The SL Handheld DW Switching the handheld transmitter on and off After switch-on, the receivers and transmitters will take approx. 10 seconds to establish the radio links. To switch the handheld transmitter on: Short-press the ON/OFF button in the direction of the transmitter ▷...
Page 89: Meaning Of The Status Led On The Handheld Transmitter
The SL Handheld DW Meaning of the status LED on the handheld transmitter lights up green: • A radio link to the receiver is established. The accupack of the handheld transmitter is sufficiently charged. flashes green: • PAIR button has been short-pressed. Paired devices are being iden- tified.
Page 90: Using The Handheld Transmitter
The SL Handheld DW Using the handheld transmitter If you touch the antenna of the handheld transmitter during transmission, the transmission range will be considerably reduced. If you cover the mi- crophone capsule during transmission, this will change the pick-up pattern of the microphone and consequently the sound.
Page 91: The Sl Bodypack Dw
The SL Bodypack DW The compact, robust SL Bodypack DW bodypack transmitter is compatible with all Sennheiser headset and clip-on microphones (e.g. SL Headmic 1 or MKE 1). Thanks to the bi-directional communication between the transmit- ter and the receiver, no settings need to be adjusted on the transmitter.
Page 92: Product Overview
The SL Bodypack DW Product overview ► 1 ON/OFF button • Short-press to switch the bodypack transmitter on • Long-press to switch the bodypack transmitter off 2 MIC/LINE jack socket (3.5 mm) • for connecting the clip-on or headset microphone Status LED •...
Page 93 The SL Bodypack DW Antenna Display panel • See „Displays on the display panel of the SL Bodypack DW” Catches • for releasing the accupack or the battery compartment BA 30 accupack or optional B 30 battery compartment • See „Removing/inserting the accupack or the optional battery pack” 9 PAIR button •...
Page 94: Displays On The Display Panel Of The Sl Bodypack Dw
The SL Bodypack DW Displays on the display panel of the SL Bodypack ► ► Name of the radio link • Can be entered in the Device Identification menu of the receiver. 7-step display of the accupack or battery capacity •...
Page 95: Starting Up And Using The Bodypack Transmitter
The SL Bodypack DW Starting up and using the bodypack transmitter Removing/inserting the accupack or the optional battery pack You can power the bodypack transmitter either with the supplied BA 30 ac- cupack or with the optional B 30 battery compartment. The accupack must be charged before the first use.
Page 96: Connecting The Clip-On Microphone Or The Headset Microphone To The Bodypack Transmitter
► Connecting the clip-on microphone or the headset microphone to the bodypack transmitter Only connect the clip-on microphone or the headset microphone recom- mended by Sennheiser. These microphones are optimized for the bodypack transmitter. ► ▷ Connect the jack plug of the clip-on microphone or headset micro- phone to the 3.5 mm jack socket (MIC/LINE) of the bodypack transmit-...
Page 97: Switching The Bodypack Transmitter On And Off
The SL Bodypack DW Switching the bodypack transmitter on and off After switch-on, the receivers and transmitters will take approx. 10 seconds to establish the radio links. To switch the handheld transmitter on: Short-press the ON/OFF button. ▷ ► The home screen appears on the display panel (see „Displays on the display panel of the SL Bodypack DW”).
Page 98: Meaning Of The Status Led On The Bodypack Transmitter
The SL Bodypack DW Meaning of the status LED on the bodypack transmitter lights up green: • A radio link to the receiver is established. The accupack of the bodypack transmitter is sufficiently charged. flashes green: • PAIR button has been short-pressed. Paired devices are being iden- tified.
Page 99: Sl Tablestand 133-S Dw
The SL Tablestand 133-S DW is delivered with a rechargeable battery that lasts up to 10 hours. The Sennheiser Control Cockpit software can be used to monitor and con- trol the wireless table stand remotely. Return to first page of the instruction manual...
Page 100: Product Overview
SL Tablestand 133-S DW Product overview ► XLR-3 socket for connecting a goose neck microphone 2 ON/OFF button with mute function Charge level LEDs • See „Meaning of the charge level LEDs on the table stand” Button for displaying the charge level Alignment LED •...
Page 101: Starting Up And Using The Table Stand
SL Tablestand 133-S DW Starting up and using the table stand Removing/inserting the BA 40 accupack The included BA 40 accupack is used to power the table stand. The accu- pack must be charged before the first use. The accupack can either be charged with the optional CHG 2W charging base (see „The CHG 2W charging base”) or with the supplied USB cable.
Page 102: Charging The Table Stand Via Usb
SL Tablestand 133-S DW Charging the table stand via USB To charge the table stand via USB: ► Connect the USB cable’s Micro-USB plug to the Micro-USB socket of ▷ the accupack. Plug the other end of the USB cable into a USB power supply unit. ▷...
Page 103: Charging The Table Stand With A Wireless Qi Charging Base From A Third- Party Manufacturer
SL Tablestand 133-S DW Charging the table stand with a wireless Qi charging base from a third- party manufacturer You can charge the SL Tablestand 133-S DW with any charging base that uses the wireless Qi charging standard. Place the table stand on the third- party Qi charging base.
Page 104: Meaning Of The Charge Level Leds On The Table Stand
SL Tablestand 133-S DW Meaning of the charge level LEDs on the table stand The charge level LEDs indicate the charge level of the SL Tablestand 133- S DW. At 100 % charge, the SL Tablestand 133-S DW has an operating time of about 10 hours.
Page 105: Switching The Table Stand On/Off
SL Tablestand 133-S DW Switching the table stand on/off To switch the table stand on: ► Press the ON/OFF button for 1 second. ▷ The button lights up green when a goose neck microphone is connect- To switch the table stand off: Press the ON/OFF button for 3 seconds.
Page 106: The Sl Tablestand 153-S Dw
The SL Tablestand 153-S DW is equipped with dedicated charging status LEDs to clearly show the battery life. The Sennheiser Control Cockpit software can be used to monitor and con- trol the SL Tablestand 153-S DW remotely. Return to first page of the instruction manual...
Page 107: Product Overview
The SL Tablestand 153-S DW Product overview ► XLR-5 socket for connecting a goose neck microphone 2 ON/OFF button with mute function Charge level LEDs • See „Meaning of the charge level LEDs on the table stand” Button for displaying the charge level Alignment LED •...
Page 108: Starting Up And Using The Table Stand
The SL Tablestand 153-S DW Starting up and using the table stand Removing/inserting the BA 40 accupack The included BA 40 accupack is used to power the table stand. The accu- pack must be charged before the first use. The accupack can either be charged with the optional CHG 2W charging base (see „The CHG 2W charging base”) or with the supplied USB cable.
Page 109: Charging The Table Stand Via Usb
The SL Tablestand 153-S DW Charging the table stand via USB To charge the table stand via USB: ► ▷ Connect the USB cable’s Micro-USB plug to the Micro-USB socket of the accupack. ▷ Plug the other end of the USB cable into a USB power supply unit. The charge level LEDs indicate the charge level.
Page 110: Charging The Table Stand With A Wireless Qi Charging Base From A Third- Party Manufacturer
The SL Tablestand 153-S DW Charging the table stand with a wireless Qi charging base from a third- party manufacturer You can charge the SL Tablestand 153-S DW with any charging base that uses the wireless Qi charging standard. Place the table stand on the third- party Qi charging base.
Page 111: Meaning Of The Charge Level Leds On The Table Stand
The SL Tablestand 153-S DW Meaning of the charge level LEDs on the table stand The charge level LEDs indicate the charge level of the SL Tablestand 153- S DW. At 100 % charge, the SL Tablestand 153-S DW has an operating time of about 10 hours.
Page 112: Switching The Table Stand On/Off
The SL Tablestand 153-S DW Switching the table stand on/off To switch the table stand on: ► ▷ Press the ON/OFF button for 1 second. The button lights up green when a goose neck microphone is connect- To switch the table stand off: ▷...
Page 113: The Sl Boundary 114-S Dw
The SL Boundary 114-S DW is delivered with a rechargeable battery that lasts up to 10 hours. The Sennheiser Control Cockpit software can be used to monitor and con- trol the wireless boundary microphone remotely. Return to first page of the instruction manual...
Page 114: Product Overview
The SL Boundary 114-S DW Product overview ► 1 ON/OFF button with mute function Charge level LEDs • See „Meaning of the charge level LEDs on the boundary microphone” Button for displaying the charge level Alignment LED • Lights up when the SL Boundary 114-S DW is correctly positioned for charging on the CHG 2W charging base BA 40 accupack •...
Page 115: Starting Up And Using The Boundary Microphone
The SL Boundary 114-S DW Starting up and using the boundary microphone Removing/inserting the BA 40 accupack The included BA 40 accupack is used to power the boundary microphone. The accupack must be charged before the first use. The accupack can ei- ther be charged with the optional CHG 2W charging base (see „The CHG 2W charging base”) or with the supplied USB cable.
Page 116: Charging The Boundary Microphone Via Usb
The SL Boundary 114-S DW Charging the boundary microphone via USB To charge the boundary microphone via USB: ► ▷ Connect the USB cable’s Micro-USB plug to the Micro-USB socket of the boundary microphone. ▷ Plug the other end of the USB cable into a USB power supply unit. The charge level LEDs indicate the charge level.
Page 117: Charging The Boundary Microphone With A Wireless Qi Charging Base From A Third-Party Manufacturer
The SL Boundary 114-S DW Charging the boundary microphone with a wireless Qi charging base from a third-party manufacturer You can charge the SL Boundary 114-S DW with any charging base that uses the wireless Qi charging standard. Place the boundary microphone on the third-party Qi charging base.
Page 118: Meaning Of The Charge Level Leds On The Boundary Microphone
The SL Boundary 114-S DW Meaning of the charge level LEDs on the boundary microphone The charge level LEDs indicate the charge level of the SL Boundary 114-S DW. At 100 % charge, the SL Boundary 114-S DW has an operating time of about 10 hours.
Page 119: Pairing
Pairing Pairing The receiver and the transmitter of a set are factory pre-paired and there- fore ready for immediate use. The radio link is automatically established as soon as both devices are switched on and within the transmission range. You can disconnect the existing radio link and establish new radio links to two other devices.
Page 120: Identifying Paired Devices
Pairing Identifying paired devices You can perform a pairing identification to see which transmitter is paired with which receiver. Switch on all devices whose pairing you want to identify. ▷ ▷ Short-press the PAIR button of the receiver or of the transmitter. ►...
Page 121: Pairing A Receiver With A Transmitter
Pairing Pairing a receiver with a transmitter To establish a new radio link between a receiver and a transmitter, proceed as follows: Long-press the PAIR button of the receiver until its status LED flashes ▷ alternately green and red. First, Identify appears on the display panel of the receiver. The Pairing message then appears.
Page 122 Pairing ► Once the radio link is successfully established, Paired appears on the display panel of both the receiver and the transmitter (only for SL Handheld DW and SL Bodypack DW) and the status LEDs on the transmitter and the receiver light up green. If no radio link was successfully established, Pairing failed appears on the display panel of both the receiver and the transmitter (only for SL Handheld DW and SL Bodypack DW) and the status LEDs on...
Page 123: Performing A Walk Test (Reception Quality)
Performing a walk test (reception quality) Performing a walk test (reception quali- The Walk Test menu item allows you to check the reception quality of your radio links within the operating environment. By performing a walk test, you can verify the range and coverage of the radio link. To perform the walk test: ▷...
Page 124 Performing a walk test (reception quality) If the result of the walk test is not satisfying, you can take the following re- medial measures: • If possible, reposition the receivers so that there is always a direct line of sight between the receiving antennae and the paired transmitter. •...
Page 125: The Sl Headmic 1 Headset Microphone
The SL Headmic 1 headset microphone The SL Headmic 1 headset microphone The SL Headmic 1 is a high-quality omni-directional condenser headset mi- crophone designed for professional “hands free” applications. Its adjust- able neckband is visually unobtrusive and very comfortable to wear. The SL Headmic 1 is available in black and beige.
Page 126: Preparing The Sl Headmic 1 For Use
The SL Headmic 1 headset microphone Preparing the SL Headmic 1 for use To connect the cable to the headset microphone: ▷ Plug the connector into the socket. ► Slide the silicone tube onto the connector. ▷ ►...
Page 127: Changing The Microphone Position (Left/Right)
The SL Headmic 1 headset microphone Changing the microphone position (left/right) You can wear the microphone on either the left or right side. ► The neckband has a total of five clips which are designed so that the mi- crophone boom can be worn on either side of the mouth. ATTENTION Damage to the microphone boom The microphone boom can break or be impaired in its function when you...
Page 128: Modifying The Microphone Boom
The SL Headmic 1 headset microphone Modifying the microphone boom To remove the microphone boom: and 2. First remove the microphone boom from the two clips ▷ By turning the microphone boom, remove it from the third clip 3. ▷ To reattach the microphone boom: First attach the end of the microphone boom where the microphone ▷...
Page 129 The SL Headmic 1 headset microphone and 4. ▷ Press the microphone boom into the two clips...
Page 130: Adjusting The Microphone Boom And The Neckband
The SL Headmic 1 headset microphone Adjusting the microphone boom and the neckband For best possible comfort and optimum fit of the headset microphone, the neckband padding and the microphone boom have to be adjusted to prop- erly fit your head. ATTENTION Damage to the microphone boom The microphone boom can break or be impaired in its function when you...
Page 131: Adjusting The Neckband
The SL Headmic 1 headset microphone Adjusting the neckband The neckband is adjustable in width and ensures an optimum fit. Change the length of the neckband by moving the ear hooks until a ▷ snug but comfortable fit is achieved. ►...
Page 132: Using The Frequency Response Caps
The SL Headmic 1 headset microphone Using the frequency response caps The MZC 2 frequency response cap allows you to adjust the micro- phone’s sensitivity in the presence area. The MZC 2 gives a treble boost of 4 dB. Use this cap if the microphone cannot be positioned close to the mouth, if the sound is too muffled or if you want to increase the speech in- telligibility.
Page 133: Using The Windshield
The SL Headmic 1 headset microphone Using the windshield The SL MZW 1 windshield attenuates annoying wind noise by 10 dB. ▷ Slip the SL MZW 1 windshield onto the MZC 2 frequency response cap 7. ►...
Page 134: Attaching The Connection Cable To Clothing
The SL Headmic 1 headset microphone Attaching the connection cable to clothing The MZQ 02 cable clip is available as accessory. ▷ Press the connection cable into the strain relief grip of the MZQ 02 ca- ble clip. ▷ Attach the cable clip to the rear of your collar. Run the connection cable under your clothing.
Page 135: Connecting The Sl Headmic 1 To The Sl Bodypack Dw
The SL Headmic 1 headset microphone Connecting the SL Headmic 1 to the SL Bodypack ► ▷ Connect the jack plug of the SL Headmic 1 to the 3.5 mm jack socket (MIC/LINE) of the bodypack transmitter. Lock the jack plug by screwing down the coupling ring. ▷...
Page 136: The Mke 1 Clip-On Microphone
The MKE 1 clip-on microphone The MKE 1 clip-on microphone The MKE 1 is a high-quality, sub-miniature, sweat-resistant clip-on con- denser microphone. It features excellent sound quality and rugged design. The frequency response curve has been optimized for stage, studio and re- porting applications (ENG).
Page 137: Treble Boost
The MKE 1 clip-on microphone Treble boost Your microphone is supplied with two different frequency response caps. These caps allow you to adjust the treble response of the microphone. ► In addition, the large frequency response cap attenuates wind noise by ap- prox.
Page 138: Attaching The Microphone
The MKE 1 clip-on microphone Attaching the microphone Depending on the area of application, you can attach the MKE 1 in different ways to either clothing or the body. ► To do so, use the optional MZ 1 accessory kit that offers multiple and se- cure attachment possibilities.
Page 139: Connecting The Mke 1 To The Sl Bodypack Dw
The MKE 1 clip-on microphone Connecting the MKE 1 to the SL Bodypack DW ► ▷ Connect the jack plug of the MKE 1 to the MIC/LINE jack socket (3.5 mm) of the bodypack transmitter. ▷ Lock the jack plug by screwing down the coupling ring. When the jack plug is not firmly locked, crackling noise can appear in the audio signal.
Page 140: The Sl Di 4 Xlr Dante™ Interface
The SL DI 4 XLR Dante™ interface The SL DI 4 XLR Dante™ interface The SL DI 4 XLR is a Dante™ interface with four inputs. This lets you inte- grate wireless microphone receivers or mic/line inputs into a Dante™ sys- tem.
Page 141: Product Overview And Led Indicators - Front Panel
The SL DI 4 XLR Dante™ interface Product overview and LED indicators – front panel ► 1 P48 LEDs • indicate, for each individual XLR input (IN 1, IN 2, IN 3, IN 4), whether the phantom power is activated 2 +45, +30, +15 LEDs •...
Page 142: Product Overview And Connections - Rear Panel
• Terminals for daisy-chaining the power supply to other devices 6 DC INsocket • input socket for an optional power supply unit (Sennheiser NT 12- 50CS) 7 DATA socket • Dante™ Ethernet socket 8 POE + DATA socket •...
Page 143: Powering The Sl Di 4 Xlr
POWER LED lights up when the power supply is established. Power supply via the optional Sennheiser NT 12-50CS power supply unit To power the SL DI 4 XLR via the optional NT 12-50CS power supply unit: ► Connect the NT 12-50CS power supply unit to the...
Page 144: Daisy-Chaining The Power Supply
The SL DI 4 XLR Dante™ interface Daisy-chaining the power supply PWR LINK IN terminals allow you to daisy-chain the power supply to additional devices. The number of devices that can be daisy-chained is limited. • NT 12-50CS power supply ->...
Page 145: Connecting Audio Signals
Connecting audio signals You can connect a total of four analog audio signals (e.g. from microphone receivers (SL Rack Receiver DW) or wired microphones) to the SL DI 4 XLR. You can change the settings for the respective microphone input using the SL DI CONTROL software (see „Configuring the SL DI 4 XLR using the SL...
Page 146: Configuring The Sl Di 4 Xlr Using The Sl Di Control Software
All settings of the input and outputs of the SL DI 4 XLR are adjusted using the SL DI CONTROL software. You can download the software at www.sennheiser.com on the product page for the SL DI 4 XLR or in the global download area on the Sennheiser website at www.sennheiser.com/ download.
Page 147: Selecting The Network Interface
The SL DI 4 XLR Dante™ interface Selecting the network interface If you have a network with several interfaces, you can select the network interface: ▷ Click on the network icon on the left of the navigation bar. ► ▷ Select the desired network interface.
Page 148: Establishing A Connection To A Sl Di 4 Xlr
The SL DI 4 XLR Dante™ interface Establishing a connection to a SL DI 4 XLR To establish a connection to a SL DI 4 XLR: Select the desired SL DI 4 XLR from the drop-down list on the right of ▷...
Page 149: Changing The Settings
The SL DI 4 XLR Dante™ interface Changing the settings The configuration window allows you to adjust the following settings for each analog XLR input (IN 1, IN 2, IN 3, IN ► ► Gain Select the gain setting for the desired input from the drop- down list.
Page 150: Saving And Loading Settings
The SL DI 4 XLR Dante™ interface Saving and loading settings You can save the settings made as presets or as files. To save the settings: ▷ Click on the folder icon on the left of the navigation bar. ► The following dialog box opens.
Page 151: The Dante Debug Mode
The SL DI 4 XLR Dante™ interface The Dante Debug Mode In Dante Debug Mode, the LEDs at the front of the SL DI 4 XLR indicate the diagnostic status. After start-up of the SL DI 4 XLR, the diagnostic status is displayed for ap- prox.
Page 152 The SL DI 4 XLR Dante™ interface IN 3 input: ERR ► The PAD and LEDs of the IN 3 put light up: Capability is corrupted ► LED of the IN 3 input lights Memory Stack Overflow ► IN 4 input: SYS ►...
Page 153: The Chg 2 Charger
The CHG 2 charger The CHG 2 charger The CHG 2 charger allows you to simultaneously charge up to two trans- mitters of the SpeechLine Digital Wireless series. A bi-color LED at each charging slot provides information on the current charge level. The charger has universal charging slots for charging both handheld and bodypack transmitters.
Page 154: Product Overview
The CHG 2 charger Product overview ► Charge level LEDs • lights up green: The accupack is fully charged. • lights up red: The accupack is being charged. Charging slots • each suitable for SL Handheld DW and SL Bodypack DW Power cord •...
Page 155: Connecting The Chg 2 Charger To The Power Supply System
The CHG 2 charger Connecting the CHG 2 charger to the power supply system To connect the CHG 2 charger to the power supply system: ► Connect the cable end of the power supply unit to the socket at the ▷...
Page 156: Charging The Accupack In The Chg 2 Charger
The CHG 2 charger Charging the accupack in the CHG 2 charger To charge an accupack in the CHG 2 charger: ► ▷ Insert the transmitter with the accupack installed and with the charging contacts facing downwards into the charger. Make sure to insert the transmitter the correct way round: The STAND- button of the bodypack transmitter has to point in the direction of...
Page 157: The Chg 4N Charger
DW. The four LEDs on each charging slot indicate the current charging status. The versatile network interface is compatible with IPv4 and IPv6 for seamless integration. The Sennheiser Control Cockpit soft- ware can be used to monitor and remotely control the settings and status messages.
Page 158: Product Overview
The CHG 4N charger Product overview ► Charging slots • Suitable for both SL Handheld DW and SL Bodypack DW Charge level LEDs • See „Meaning of the charging slot status LEDs” Power supply unit • With hollow jack plug for connection to the CHG 4N charger Power cord •...
Page 159: Connecting The Chg 4N Charger To The Power Supply System
The CHG 4N charger Connecting the CHG 4N charger to the power supply system To connect the CHG 4N charger to the power supply system: Connect the cable end of the power supply unit to the socket at the ▷ base of the charger.
Page 160 The CHG 4N charger ▷ Connect one end of the power cord to the power supply unit and the other end to the wall socket. ►...
Page 161: Charging The Accupack In The Chg 4N Charger
The CHG 4N charger Charging the accupack in the CHG 4N charger To charge an accupack in the CHG 4N charger: ► ▷ Insert the transmitter with installed accupack into one of the charger’s four charging slots. Make sure the charging contacts face downward. ▷...
Page 162: Meaning Of The Charging Slot Status Leds
< 33 % An error has occurred. A corresponding error message is dis- played in the Sennheiser Control Cockpit software. The firmware of the CHG 4N is being updated. This LED status is display only when new firmware for an SL Handheld DW or SL Bodypack DW transmitter is being loaded to the CHG 4N charger.
Page 163: Controlling And Monitoring The Chg 4N Charger Over The Network
You can connect the CHG 4N charger to a network using a router or switch, which allows you to monitor and control the accupack’s charge level using the Sennheiser Control Cockpit software and to modify the CHG 4N char- ger’s network configuration.
Page 164: Integrating The Chg 4N Charger Into A Network With Dhcp
The CHG 4N charger is delivered with automatic IP assignment configured by default. After adding it in the Sennheiser Control Cockpit, you can re- configure it to Fixed IP. To do so, proceed as described above: „Integrating the CHG 4N charger into a network without DHCP using Auto IP”.
Page 165: Connecting A Pre-Configured Chg 4N Charger To The Sennheiser Control Cockpit
If the charger has been reconfigured according to one of the procedures described above and mDNS has been deactivated, you can add the charger manually using the Add Device function in the Sennheiser Control Cock- pit. To add the charger in the Sennheiser Control Cockpit: Use the Add Device function in the Sennheiser Control Cockpit and ▷...
Page 166: Updating The Firmware
The CHG 4N charger Updating the firmware The firmware of the CHG 4N charger is updated using the Sennheiser Control Cockpit software. You can find more information about this pro- cedure in the software instruction manual in the Sennheiser Documenta- tion app or in the download area of the Sennheiser website at www.sennheiser.com/download.
Page 167: The Chg 2W Charging Base
The CHG 2W charging base The CHG 2W charging base The CHG 2W is a wireless charging base that provides convenient wireless charging. The CHG 2W charging base is compatible with the SL Tablestand 133-S DW, the SL Tablestand 153-S DW and the SL Boundary 114-S DW. Return to first page of the instruction manual...
Page 168: Product Overview
The CHG 2W charging base Product overview ► Charging surface for wireless energy transfer • For the SL Tablestand 133-S DW and SL Tablestand 153-S DW units Socket for power supply unit • See „Connecting the CHG 2W charging base to the power supply system”...
Page 169: Connecting The Chg 2W Charging Base To The Power Supply System
The CHG 2W charging base Connecting the CHG 2W charging base to the power supply system To connect the CHG 2W charger to the power supply system: ► Connect the cable end of the power supply unit to the socket at the ▷...
Page 170: Charging A Device Using The Chg 2W Charging Base
The CHG 2W charging base Charging a device using the CHG 2W charging base You can use the CHG 2W charging base to charge the wireless table stands SL Tablestand 133-S DW and SL Tablestand 153-S DW as well as the wire- less boundary microphone SL Boundary 114-S DW.
Page 171: Meaning Of The Status Leds On The Charging Surfaces
The CHG 2W charging base Meaning of the status LEDs on the charging surfac- The two blue status LEDs on the charging surfaces provide the following status information: Flashing normally: the device is charging Flashing rapidly: excess temperature warning Flashing/flickering very rapidly: unknown device on the charger...
Page 172: The Awm 2 Antenna Wall Mount
The AWM 2 antenna wall mount The AWM 2 antenna wall mount With the AWM 2 antenna wall mount, the antennae can be remote mounted – optimally positioned and nearly invisible – from the receiver (e.g. when the receiver has to be installed invisibly or when the receiver position is not the best antenna position for optimum reception).
Page 173: Product Overview
The AWM 2 antenna wall mount Product overview ► Rod antennas • for connection to the R-SMA sockets at the top of the antenna wall mount R-SMA sockets of the antenna cables • Antenna inputs for connecting the rod antennae Antenna holes •...
Page 174: Connecting And Mounting The Awm 2
The AWM 2 antenna wall mount Connecting and mounting the AWM 2 Instead of the rod antennae, you can connect the optional AWM 2 antenna wall mount to the receiver. The AWM 2 is suitable for all applications where the antennae are to be positioned further away from the receiver. ▷...
Page 175: To Mount The Antenna Wall Mount To A Microphone Stand
The AWM 2 antenna wall mount observe a minimum distance of 160 mm between the top of the antenna wall mount and the ceiling. ▷ If necessary, connect extension cables to the R-SMA sockets of the an- tenna wall mount. ▷...
Page 176 The AWM 2 antenna wall mount ing directly trough a wall. When wall mounting the antenna wall mount, observe a minimum distance of 160 mm between the top of the antenna wall mount and the ceiling. If necessary, connect extension cables to the R-SMA sockets of the an- ▷...
Page 177: The Awm 4 Antenna Wall Mount
The AWM 4 antenna wall mount The AWM 4 antenna wall mount With the AWM 4 antenna wall mount, the antennae can be remote mount- ed – optimally positioned and nearly invisible – from the receivers (e.g. when the receivers have to be installed invisibly or when the receiver posi- tion is not the best antenna position for optimum reception).
Page 178: Product Overview
The AWM 4 antenna wall mount Product overview ► Antennas Connections for Link I (receiver 1) Connections for Link II (receiver 2)
Page 179: Connecting And Mounting The Awm 4
The AWM 4 antenna wall mount Connecting and mounting the AWM 4 Attaching the antennas Screw the four supplied rod antennas onto the housing as shown. ▷ ►...
Page 180: Connecting The Antenna Cables
Sennheiser antenna cables: • CL 1 PP • CL 5 PP • CL 10 PP • CL 20 PP These cables can be directly connected to the SL Rack Receiver DW and the AWM 4 without the need for an adapter.
Page 181: Mounting The Awm 4 On A Stand Or On The Wall
The AWM 4 antenna wall mount Mounting the AWM 4 on a stand or on the wall You can either screw the AWM 4 onto a standard microphone stand or use the existing holes in the housing to mount it on the wall as shown. ►...
Page 182: Contact
SpeechLine Digital Wireless product page Feedback Do you have any questions or suggestions about this instruction manual or about the product itself? Write to us at techcomm@sennheiser.com. ► Sennheiser electronic GmbH & Co. KG Am Labor 1, 30900 Wedemark, Germany...
Page 183 Contact...

This manual is also suitable for:

Sl handheld dw Sl tablestand 153-s dw Sl boundary 114-s dw Sl bodypack dw Sl di 4 xlr Chg2 ... Show all

Sennheiser SL Rack Receiver DW Manual

Speechline Digital Wireless: System Information

Focus on the Spoken Word

The Products of the Speechline Digital Wireless Series

Speechline Digital Wireless: System Planning

Planning

Recommendations on Antenna Mounting

Multi-Room Mode

Speechline Digital Wireless: Instruction Manual

SL Rack Receiver DW

The SL Handheld DW

The SL Bodypack DW

SL Tablestand 133-S DW

The SL Tablestand 153-S DW

The SL Boundary 114-S DW

Pairing

Performing a Walk Test (Reception Quality)

The SL Headmic 1 Headset Microphone

The MKE 1 Clip-On Microphone

The SL DI 4 XLR Dante™ Interface

The CHG 2 Charger

The CHG 4N Charger

The CHG 2W Charging Base

The AWM 2 Antenna Wall Mount

The AWM 4 Antenna Wall Mount

Contact

Quick Links

Related Manuals for Sennheiser SL Rack Receiver DW

Summary of Contents for Sennheiser SL Rack Receiver DW
