Page 1: Quick Start Guide
HD/SD-SDI TO HDMI CONVERTER DAC-8P Quick Start Guide w w w . d a t a v i d e o . c o m... -
Page 2: Warranty
Drives, Hard Drives are only covered for the first 10,000 hours, or 1 year (whichever comes first). Any second year warranty claims must be made to your local Datavideo office or one of its authorized Distributors before the extended warranty expires. -
Page 3: Front Panel
DAC-8P Front Panel HD/ SD-SDI AUDIO OPTION LOOP THRU AUDIO IN HD/ SD-SDI HD/SD - SDI Input & Output (LOOP THRU) LOOP THRU HD/SD-SDI transfers professional level video signals and it can connect to long distance transmission systems. Left BNC connector: HD/SD-SDI Input... -
Page 4: Rear Panel
HD/SD-SDI TO HDMI CONVERTER Rear Panel DC IN HDMI OUT 12V 4W POWER DC In Socket DC IN 12V 4W Connecting the power supply 12V/ 500mA PSU to this socket. The connection can be secured by screwing the outer fastening ring of the DC In plug to the socket. -
Page 5: Specification
DAC-8P Specification Input Interface • 1x HD/SD-SDI input Outputs Interface • 1x HD/SD-SDI output (Loop Thru) • 1x HDMI (V1.2) output Supported HDMI • 720x480 Interlace Output Formats • 720x576 Interlace • 1280x720 / 50Hz Progressive • 1280x720 / 59.94Hz Progressive •... - Page 6 HD/SD-SDI TO HDMI CONVERTER Notes...
- Page 7 DAC-8P Notes...
-
Page 8: Service And Support
Service & Support It is our goal to make owning and using Datavideo products a satisfying experience. Our support staff is available to assist you to set up and operate your system. Contact your local office for specific support requests.
