UP / DOWN / CROSS
CONVERTER
DAC-70
Instruction Manual
w w w . d a t a v i d e o . c o m

Advertisement

Table of Contents
loading

Related Manuals for Datavideo DAC-70

Summary of Contents for Datavideo DAC-70

  • Page 1 UP / DOWN / CROSS CONVERTER DAC-70 Instruction Manual w w w . d a t a v i d e o . c o m...

  • Page 2: Warranty

    Drives, Hard Drives are only covered for the first 10,000 hours, or 1 year (whichever comes first). Any second year warranty claims must be made to your local Datavideo office or one of its authorized Distributors before the extended warranty...

  • Page 3: Table Of Contents

    Further advice on the content of this manual or on the product can be obtained by contacting your local Datavideo Office or dealer.

  • Page 4: Disposal

    7.This product should only be operated from the type of power source indicated on the marking label of the AC adapter. If you are not sure of the type of power available, consult your Datavideo dealer or your local power company.

  • Page 5: Packing List

    Packing List Items Description Q’ty DAC-70 Converter Instruction Manual Accessory List...

  • Page 6: Introdution

    VGA or HDMI or SDI inputs within your chosen HDMI or SDI workflow. Housed in a rugged case, the DAC-70 is tough enough to meet the knocks of fast paced set ups in ENG, studio or live production work. Built to the same dimensions as Datavideo’s range of converters, the DAC-70 can also...

  • Page 7: Front Panel

    DAC-70 Front Panel AUDIO VGA IN HDMI LOOP SDI IN THRU Video In Connects your VGA connector equipment to this connector VGA IN Supported resolutions 800x600 @60Hz, 1024x768 @60Hz, 1280x1024 @60Hz, 1366x768 @60Hz, 1400x1050 @60Hz, 1600x1200 @60Hz HDMI In HDMI...

  • Page 8: Rear Panel

    UP / DOWN / CROSS CONVERTER Rear Panel SOURCE DC IN 7.2W HDMI 1 2 3 4 5 6 7 8 MODE SELECT HDMI OUT SDI OUT Mode Select (Mini switch) Use these Mini switches to manually set the DAC- 1 2 3 4 5 6 7 8 70 mode, see table on page 9.

  • Page 9: Mini Switch Mode Selection

    DAC-70 MINI Switch Mode Selection...
  • Page 10 UP / DOWN / CROSS CONVERTER Mini Switch Pin 8 Up: Full Screen Mini Switch Pin 8 Down: Span Scan 16:9 Span Scan 16:9 Input 4:3, output 16:9 Input 16:9, output 4:3...

  • Page 11: How To Update The Dac-70 Firmware

    As well as a working DAC-70 you will need: 1. The latest update file for the DAC-70. This can be obtained from your local Datavideo dealer or office.

  • Page 12: Dac-70 Center Utility Features

    DAC-70 Center Utility features Please copy the DAC-70 Center.exe utility software from the supplied CD to your Windows computer. Now connect the DAC-70 by USB cable to the same computer. Switch on the DAC-70 and then launch the DAC-70 Center utility software.
  • Page 13 DAC-70 Note1: When “Input Source” set on “VGA“, the Image Adjust can set Horizontal Position & Vertical Position. Note2: When “Aspect Ratio” set on “Under Scan“, the Image Adjust can set Horizontal Size & Vertical Size. 2.3 Click Next Page to set the HDMI output colour &...
  • Page 14 UP / DOWN / CROSS CONVERTER Audio tab 3.1 Click the to set the audio parameters. 3.2 Set the audio mute, audio source & audio level then click Apply. Note 1: Audio Level can also be switched between EBU and SMPTE standards. Note 2: Audio Level setting only for RCA input.

  • Page 15: Dimensions

    DAC-70 Setting tab 5.1 Click the to access the restore factory defaults window. 5.2 Click the Factory Default button to reset the DAC-70 to factory defaults. Dimensions All measurements in mm...

  • Page 16: Specifications

    UP / DOWN / CROSS CONVERTER Specifications Input VGA x 1, HDMI x 1 , HD/SD-SDI x 1, Analog Audio L/R Output SDI x 2, HDMI x 1, SDI Loop thru BNC(front panel) Mini USB ● Firmware upgrade ● Aspect Mode selection Supported Video ●...
  • Page 17 DAC-70 Notes...

  • Page 18: Service & Support

    It is our goal to make your products ownership a satisfying experience. Our supporting staff is available to assist you in setting up and operating your system. Please refer to our web site www.datavideo.com for answers to common questions, support requests or contact your local office below.
