Section 2: Installation
To mount the camera with the DCS-37-1 mount, follow the instructions below.
Step 1
Place the DCS-37-1 mounting sticker in the desired location, then use a 6 mm
drill bit to drill the required holes 25 mm deep and insert the wall anchors into
the holes. If you plan to pass cables through the wall, you will also need to drill
a hole for the cable channel.
Note: The camera in the corresponding graphics may be different from your
product, but the basic process is the same.
Step 2
Use the provided screws to mount the DCS-37-1 to the wall.
Step 3
Guide the camera connectors through the back or bottom cable channel on
the DCS-37-1. Then screw the mounting plate to the bracket using the set of
mounting holes marked B.
