User Manual
Auxiliary Input Adapter
for 17xx
Power and Energy Loggers
Instructions
Introduction
The Auxiliary Input Adapter (or Product) is an accessory for
the 17xx Power and Energy Loggers. It allows connection of
up to two sensors for analog measurements. These
measurements include temperature, pressure, and level with
an output voltage of 0 V dc to 10 V dc or a current loop of
4 mA to 20 mA (with additional shunt). Alternately, up to two
dc voltage inputs in the range of 1 V dc to 1000 V dc can be
used for other applications such as solar energy systems.
PN 4749275 December 2015
©2015 Fluke Corporation. All rights reserved.
Specifications are subject to change without notification.
All product names are trademarks of their respective companies.
PowerMeterStore
1.888.610.7664
www.
.com
Shop for Power Metering products online at:
Advertisement
Related Manuals for Fluke 1736
Summary of Contents for Fluke 1736
- Page 1 1 V dc to 1000 V dc can be used for other applications such as solar energy systems. PN 4749275 December 2015 ©2015 Fluke Corporation. All rights reserved. Specifications are subject to change without notification. All product names are trademarks of their respective companies.
-
Page 2: Safety Information
Safety Information A Warning identifies conditions and procedures that are dangerous to the user. A Caution identifies conditions and procedures that can cause damage to the Product or the equipment under test. XW Warnings To prevent possible electrical shock, fire, or personal injury: •... - Page 3 • Comply with local and national safety codes. Use personal protective equipment (approved rubber gloves, face protection, and flame-resistant clothes) to prevent shock and arc blast injury where hazardous live conductors are exposed. • Do not use the Product around explosive gas, vapor, or in damp or wet environments.
- Page 4 Symbols Symbol Description WARNING. RISK OF DANGER. WARNING. HAZARDOUS VOLTAGE. Risk of electric shock. Consult user documentation. Double Insulated Earth Measurement Category II is applicable to test and measuring circuits connected directly to utilization points (socket outlets and similar points) of the low-voltage MAINS installation.
- Page 5 Direct Input 0 V DC to 10 V DC Configuration To connect the Adapter: Make sure that all 4 mm safety test leads are disconnected. Loosen the 4 captive screws and remove the lid to open the housing. 10mm 40mm 0,39in...
- Page 6 Insert the sensor cable through the strain relief . The cable diameter must be in the range of 3 mm to 6 mm to ensure proper strain relief. Tighten the strain relief. To connect the wires to the terminals E, press the opening lever.
-
Page 7: How To Clean
How to Clean Clean the Product with a soft cloth, mild soap, and water. Caution To avoid damage, do not clean with abrasives or solvents. Specifications General Calibration Cycle ....2 years Warranty......1 year Dimensions......119 mm x 86 mm x 38 mm (4.69 in x 3.39 in x 1.5 in) Weight ........ - Page 8 Accuracy Intrinsic Accuracy Aux Adapter + Instrument Input Range (% of Reading + % of Range) Direct Input ±10 V see instrument specification Voltage divider input ±1000 V ±(0.5% + 0.002%) Note: Environmental Reference Conditions: 23 °C ±5 °C, instrument operating for at least 30 minutes, no external electrical/magnetic field, RH <65 %.
- Page 9 Block Diagram Voltage Divider Input/1000 V Voltage Divider Input / 1000V 511k Safety plugs Safety plugs AUX1 511k AUX1 Direct Input / 10 V Direct Input / 10V 173x 173x Terminal Blocks Auxiliary Auxiliary Terminal blocks Input Input = 2.92M Voltage Divider Input / 1000 V Voltage Divider Input / 1000V 511k...
-
Page 10: Limited Warranty And Limitation Of Liability
LIMITED WARRANTY AND LIMITATION OF LIABILITY This Fluke product will be free from defects in material and workmanship for one year from the date of purchase. This warranty does not cover fuses, disposable batteries, or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
