HOW THIS BLOOD PRESSURE MONITOR WORKS

This monitor uses innovative technology to detect your
blood pressure. This technology enables the monitor to
automatically inflate and deflate at the appropriate level for
each individual. With one touch of a button, the cuff will
automatically inflate to block the blood flow through your
artery. Next, the deflation process starts. Please note that
any muscle movement during inflation or deflation will cause
measurement error. When measurement is complete, the
monitor will display your systolic pressure, diastolic pressure,
and pulse readings.
The monitor automatically finds where your measurement
results fall on the NIH's National Heart Lung and Blood
Institute's table and provides a cue if your reading falls into
one of the stages that could potentially indicate increased risk.
Please refer to page 20 for more information on this feature.
The appearance of the
irregularity consistent with an irregular heartbeat was detected
during measurement. Refer to page 21 for more information
on the Irregular Heartbeat Detector.
IB-WGNBPA-745_R3.indd 7-8
icon indicates that a pulse
PM
7
NAME/FUNCTION OF EACH PART
Air Tube
and Connector
UltraSoft™ Upper
Arm Cuff
USER-SELECT
Button
Other Accessories:
1 6V DC Output AC Adapter
4 "AA" size, 1.5V alkaline batteries (not included)
Note: Please remove the batteries when operating
with the AC adapter for an extended period of time.
DATE/TIME
SET Buttons
+
LCD Display
Battery Cover
(Located on
bottom of unit)
START/STOP
MEMORY RECALL
Button
Button
