Clevo M350S Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading

Related Manuals for Clevo M350S

Summary of Contents for Clevo M350S

  • Page 3 Preface Notebook Computer M350S/M360S/M362S/M363S/M375S Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.

  • Page 5: About This Manual

    This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the M350S/ M360S/M362S/M363S/M375S series notebook PC.

  • Page 6: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, elec- tric shock and injury to persons, including the following: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 8: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode. • Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service personnel.

  • Page 10: Related Documents

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII...

  • Page 11: Table Of Contents

    Bottom (M350S) ................A-4 Mainboard Overview - Top (Connectors) ........1-13 LCD (M350S) ................A-5 Mainboard Overview - Bottom (Connectors) .......1-14 CD-ROM Drive - QSI (M350S) ............ A-6 Disassembly ..........2-1 CD-ROM Drive - SAMSUNG (M350S) ........A-7 CD-RW Drive - TEAC (M350S) ........... A-8 Overview ..................2-1...
  • Page 12 Preface Schematic Diagrams......... B-1 Bottom (M362S) ................A-24 LCD (M362S) ................A-25 System Block Diagram ..............B-2 CD-ROM Drive - QSI (M362S) ........... A-26 Socket 479 - 1 of 2 ................B-3 CD-ROM Drive - SAMSUNG (M362S) ........A-27 Socket 479 - 2 of 2 ................B-4 CD-RW Drive - TEAC (M362S) ..........
  • Page 13 Preface +VDD5, +VDD3, +1.2V .............. B-32 Multi-Function Board ..............B-33 Audio Jack Board ................. B-34 Click Board .................. B-35...
  • Page 14 Preface...

  • Page 15: Introduction

    1: Introduction Overview This manual covers the information you need to service or upgrade the M350S/M360S/M362S/M363S/M375S series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer.

  • Page 16: System Specifications

    Introduction System Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/speeds) may be changed or updated due to the manufacturer's release schedule. Check with your service center for details. Feature Specifications µ...
  • Page 17 Two 200-pin SODIMM sockets, supporting 266/ 333 512MB/ 1GB DDR modules) MHz DDR modules BIOS One 4MB Flash ROM Phoenix BIOS, Plug and Play (1.0a) M350S/M360S/M362S/M363S M375S 14.1" XGA Flat Panel TFT (1024*768) 15.4" WXGA TFT(1280*800) Display SiS M661MX Integration...
  • Page 18 Power Button as Sleep/Resume Key Supports Resume From Modem Ring Supports Hibernate Mode Supports Wake on LAN Supports Standby Mode Power M350S/M360S/M362S/M363S M375S Full Range AC Adapter Full Range AC Adapter AC-Input 100~240V, 47~63Hz AC-Input 100~240V, 47~63Hz DC Output 20V, 3.25A (65W) DC Output 20V, 3.25A (65W)

  • Page 19: Design Differences

    Introduction Design Differences This notebook series includes two different model types. M350S/M360S/M362S/M363S has a standard screen, M375S has a wide screen (see “LCD” on page 1 - 3 for details). The M350S/M360S/M362S/M363S models include two differ- ent designs (note the touchpad and buttons - see Figure 1) as illustrated.

  • Page 20: Gloss Style Top Cover Designs (M362S/M363S)

    Introduction Gloss Style Top Cover Designs (M362S/M363S) There are two colored (red and blue) gloss style top cover designs incorporated within the design styles of this notebook model. Note the following guidelines for care and attention of this type of top cover. •...

  • Page 21: External Locator - Top View

    Introduction External Locator - Top View Figure 3 Top View 1. Optional Built-In PC Camera 2. LCD 3. LED Power & Communication Indicators 4. Speakers 5. Lid Sensor 6. LED Status Indicators 7. Power Button 8. Keyboard 9. Built-In Microphone 10.

  • Page 22: External Locator - Front & Left Side Views

    Introduction External Locator - Front & Left Side Views Figure 4 Front View 1. LCD Latches 2. Hot-Key Buttons Figure 5 Left Side View 1. Vent 2. External Monitor (CRT) Port 3. RJ-11 Phone Jack 4. RJ-45 LAN Jack 5. 2 * USB 2.0 Ports 6.

  • Page 23: External Locator - Right Side & Rear Views

    Introduction External Locator - Right Side & Rear Views Figure 6 Right Side View 1. Microphone-In Jack 2. Headphone-Out Jack 3. S/P DIF Output Jack 4. Optical Device 5. DC-In Jack Figure 7 Rear View 1. Security Lock Slot 2. Vent External Locator - Right Side &...

  • Page 24: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 8 Bottom View 1. Vent/Fan Intakes 2. Battery 3. CPU Cover 4. RAM & WLAN Module Cover (M350S/M360S/ M350S/M360S/ M362S/M363S) M362S/M363S 5. Optical Device Screw Cover 6. Hard Disk Module Cover (M350S/M360S/ M362S/M363S) 7.

  • Page 25: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 9 Mainboard Top Key Parts 1. PC Card Assembly 2. Southbridge - SiS M661MV 3. Northbridge - SiS 963L 4. H8 Keyboard Controller Mainboard Overview - Top (Key Parts) 1 - 11...

  • Page 26: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 10 Mainboard Bottom Key Parts 1. Memory Sockets (no memory installed) 2. CPU Socket (no CPU installed) 3. Clock Generator 4. BIOS 5. LAN Transformer 6. CardBus ENE 1410 7. ALC202 - Audio Codec 8.

  • Page 27: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 11 Mainboard Top Connectors 1. TouchPad Cable Connector (JTP1) 2. Keyboard Connector (JKB1) Mainboard Overview - Top (Connectors) 1 - 13...

  • Page 28: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 12 Mainboard Bottom Connectors 1. Battery (JBATT1) 2. RTC (JBAT1) 3. Power Cable (JPWR1) 4. Multi-function Board Cable (JMFC1) 5. CD-ROM (JCD1) 6. Hard Disk (JHDD1) 7. Audio Board Cable (JAUDIO1) 8. Int. MIC (JMIC1) 9.

  • Page 29: Disassembly

    2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the M350S/M360S/M362S/M363S/M375S series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 30: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 31: Maintenance Precautions

    Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 32: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Wireless LAN Module: 1. Remove the battery page 2 - 7 1.
  • Page 33 Disassembly To remove the Audioboard: To remove the TouchPad & Click Board: 1. Remove the battery page 2 - 7 1. Remove the battery page 2 - 7 2. Remove the HDD page 2 - 8 2. Remove the HDD page 2 - 8 3.
  • Page 34 Disassembly To remove the LCD Panel: 1. Remove the battery page 2 - 7 2. Remove the HDD page 2 - 8 3. Remove the optical device page 2 - 12 4. Remove the processor page 2 - 13 5. Remove the wireless LAN module page 2 - 16 6.

  • Page 35: Removing The Battery

    Disassembly Removing the Battery 1. Turn the computer off, and turn it over. 2. Locate the battery bay at point (Figure 1a). Figure 1 3. Slide the battery lock in the direction of the arrow (towards the unlock symbol ), and hold it in place (Figure Battery Removal 1b).

  • Page 36: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" IDE hard disk drives Figure 2 with a height of 9.5mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and HDD Assembly utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 37 Disassembly 3. Pull the tab to slide the hard disk assembly in the direction of the arrow Figure 3a). 4. Lift the hard disk assembly up out off the computer Figure 3b). 5. Remove screws , and separate the hard disk cover from the hard disk (Figure 3c).

  • Page 38: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) The computer has two memory sockets for 200 pin (SO-DIMM) Small Outline Dual In-line Memory Modules support- Figure 4 ing DDR 266MHz (see “Memory” on page 1 - 3). The main memory can be expanded up to 2GB. The SO-DIMM mod- Memory Socket ules supported are 128MB, 256MB, 512MB and 1024MB.
  • Page 39 Disassembly 5. Gently pull the two release latches ( & Figure toward the sides of the computer. Figure 5 Removing/ Installing a RAM Module a. Pull release latches. b. Remove the mod- ule. 6. The module (Figure 5b) will pop-up, and you can remove it. 7.

  • Page 40: Removing The Optical Device

    Disassembly Removing the Optical Device 1. Turn off the computer, turn it over and remove the battery (page 2 - Figure 6 2. Remove screw (Figure 6a) and carefully lift up the optical device cover (Figure 6b). Optical Device 3. Use a screwdriver to carefully push the optical device assembly out of the computer at point (Figure 6c).

  • Page 41: Removing The Processor

    Disassembly Removing the Processor 1. Turn off the computer, remove the battery (page 2 - 7) and turn it over. 2. Remove screws from the CPU cover 3. Carefully lift up the CPU cover off the computer. Figure 7 4. Remove screws (Figure 7c) from the heat sink in the order indicated on the label Processor Removal...
  • Page 42 Disassembly 8. Turn the release latch towards the unlock symbol , to release the CPU (Figure 8a). 9. Carefully (it may be hot) lift the CPU up out of the socket (Figure 8b). 10. When re-inserting the CPU, pay careful attention to the pin alignment; it will fit only one way (don’t force it!). Figure 8 Processor Removal (cont’d)

  • Page 43: Removing The Keyboard

    Disassembly Removing the Keyboard 1. Turn off the computer, remove the battery (page 2 - 2. Press the three keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you Figure 9 may need to use a small screwdriver to do this). Keyboard Removal 3.

  • Page 44: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 10 Wireless LAN 1. Turn off the computer, turn it over and remove the battery (page 2 - 7), and RAM cover (page 2 - 10). Removal 2. Gently pull the two release latches ( &...

  • Page 45: Removing The Bottom Case

    Disassembly Removing the Bottom Case 1. Turn off the computer, remove the battery (page 2 - 7), hard disk (page 2 - 8), RAM (page 2 - 10), Optical Device Figure 11 (page 2 - 12), CPU (page 2 - 13), and WLAN module (page 2 - 16).

  • Page 46: Removing The Modem

    Disassembly Removing the Modem Figure 12 1. Turn off the computer, turn it over and remove the battery (page 2 - 7), hard disk (page 2 - 8), RAM (page 2 - 10), Modem Removal Optical Device (page 2 - 12), CPU (page 2 - 13), WLAN module...

  • Page 47: Removing The Audioboard

    Disassembly Removing the Audioboard 1. Turn off the computer, remove the battery (page 2 - 7), hard disk (page 2 - 8), RAM (page 2 - 10), Optical Device Figure 13 (page 2 - 12), CPU (page 2 - 13), WLAN module (page 2 - 16), and bottom case (page 2 -...

  • Page 48: Removing The Multi-Function Board

    Disassembly Removing the Multi-function board 1. Turn off the computer, remove the battery (page 2 - 7), hard disk (page 2 - 8), RAM (page 2 - 10), Optical Device Figure 14 (page 2 - 12), CPU (page 2 - 13), WLAN module (page 2 - 16), and bottom case...

  • Page 49: Removing The Mainboard

    Disassembly Removing the Mainboard 1. Turn off the computer, remove the battery (page 2 - 7), hard disk (page 2 - 8), RAM (page 2 - 10), Optical Device Figure 15 (page 2 - 12), modem (page 2 - 18), CPU (page 2 - 13), keyboard (page 2 -...

  • Page 50: Removing The Touchpad And Click Board

    Disassembly Removing the TouchPad and Click Board 1. Turn off the computer, remove the battery (page 2 - 7), hard disk (page 2 - 8), RAM (page 2 - 10), Optical Device Figure 16 (page 2 - 12), modem (page 2 - 18), CPU (page 2 - 13), keyboard...

  • Page 51: Removing The Inverter

    Disassembly Removing the Inverter 1. Turn off the computer, remove the battery (page 2 - Figure 17 2. Remove the rubber covers and screws from the LCD (Figure 17a). Inverter Removal 3. Run your finger around the middle of the frame to carefully unsnap the LCD front panel module from the back.

  • Page 52: Removing The Speakers

    Disassembly Removing the Speakers Figure 18 1. Turn off the computer, remove the battery (page 2 - 7), hard disk (page 2 - 8), Optical Device (page 2 - 12), CPU (page 2 - 13), WLAN module (page 2 - 16), bottom case (page 2 - 17), mainboard...

  • Page 53: Removing The Lcd Panel

    Disassembly Removing the LCD Panel 1. Turn off the computer, remove the battery (page 2 - 7), hard disk (page 2 - 8), Optical Device (page 2 - 12), CPU Figure 19 (page 2 - 13), WLAN module (page 2 - 16), bottom case (page 2 - 17), mainboard...
  • Page 54 Disassembly 2 - 26...

  • Page 55: Part Lists

    Part Lists Appendix A:Part Lists This appendix breaks down the M350S/M360S/M362S/M363S/M375S series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 56: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table 1 - 1 Part List Illustration Part M350S M360S M362S M363S M375S Location page A - 3 page A - 12...

  • Page 57: Top (M350S

    Part Lists Top (M350S) Figure 1 Top (M350S) Top (M350S) A - 3...

  • Page 58: Bottom (M350S

    Part Lists Bottom (M350S) Figure 2 Bottom (M350S) A - 4 Bottom (M350S)

  • Page 59: Lcd (M350S

    Part Lists LCD (M350S) Figure 3 LCD (M350S) LCD (M350S) A - 5...

  • Page 60: Cd-Rom Drive - Qsi (M350S

    Part Lists CD-ROM Drive - QSI (M350S) Figure 4 CD-ROM Drive - QSI (M350S) A - 6 CD-ROM Drive - QSI (M350S)

  • Page 61: Cd-Rom Drive - Samsung (M350S

    Part Lists CD-ROM Drive - SAMSUNG (M350S) Figure 5 CD-ROM Drive - SAMSUNG (M350S) CD-ROM Drive - SAMSUNG (M350S) A - 7...

  • Page 62: Cd-Rw Drive - Teac (M350S

    Part Lists CD-RW Drive - TEAC (M350S) Figure 6 CD-RW Drive - TEAC (M350S) A - 8 CD-RW Drive - TEAC (M350S)

  • Page 63: Combo Drive - Qsi (M350S

    Part Lists Combo Drive - QSI (M350S) Figure 7 Combo Drive - QSI (M350S) Combo Drive - QSI (M350S) A - 9...

  • Page 64: Dvd-Rom Drive - Qsi (M350S

    Part Lists DVD-ROM Drive - QSI (M350S) Figure 8 DVD-ROM Drive - QSI (M350S) A - 10 DVD-ROM Drive - QSI (M350S)

  • Page 65: Dvd-Rom Drive - Teac (M350S

    Part Lists DVD-ROM Drive - TEAC (M350S) Figure 9 DVD-ROM Drive - TEAC (M350S) DVD-ROM Drive - TEAC (M350S) A - 11...

  • Page 66: Top (M360S

    Part Lists Top (M360S) Figure 10 Top (M360S) A - 12 Top (M360S)

  • Page 67: Bottom (M360S

    Part Lists Bottom (M360S) Figure 11 Bottom (M360S) 鋁箔 Bottom (M360S) A - 13...

  • Page 68: Lcd (M360S

    Part Lists LCD (M360S) Figure 12 LCD (M360S) A - 14 LCD (M360S)

  • Page 69: Cd-Rom Drive - Qsi (M360S

    Part Lists CD-ROM Drive - QSI (M360S) Figure 13 CD-ROM Drive - QSI (M360S) CD-ROM Drive - QSI (M360S) A - 15...

  • Page 70: Cd-Rom Drive - Samsung (M360S

    Part Lists CD-ROM Drive - SAMSUNG (M360S) Figure 14 CD-ROM Drive - SAMSUNG (M360S) A - 16 CD-ROM Drive - SAMSUNG (M360S)

  • Page 71: Cd-Rw Drive - Teac (M360S

    Part Lists CD-RW Drive - TEAC (M360S) Figure 15 CD-RW Drive - TEAC (M360S) CD-RW Drive - TEAC (M360S) A - 17...

  • Page 72: Combo Drive - Qsi (M360S

    Part Lists Combo Drive - QSI (M360S) Figure 16 Combo Drive - QSI (M360S) A - 18 Combo Drive - QSI (M360S)

  • Page 73: Dvd-Rom Drive - Qsi (M360S

    Part Lists DVD-ROM Drive - QSI (M360S) Figure 17 DVD-ROM Drive - QSI (M360S) DVD-ROM Drive - QSI (M360S) A - 19...

  • Page 74: Dvd-Rom Drive - Teac (M360S

    Part Lists DVD-ROM Drive - TEAC (M360S) Figure 18 DVD-ROM Drive - TEAC (M360S) A - 20 DVD-ROM Drive - TEAC (M360S)

  • Page 75: Dvd-Dual Drive (M360S

    Part Lists DVD-Dual Drive (M360S) Figure 19 DVD-Dual Drive (M360S) DVD-Dual Drive (M360S) A - 21...

  • Page 76: Dvd-Dual Drive - Liteon (M360S

    Part Lists DVD-Dual Drive - LITEON (M360S) Figure 20 DVD-Dual Drive - LITEON (M360S) A - 22 DVD-Dual Drive - LITEON (M360S)

  • Page 77: Top (M362S

    Part Lists Top (M362S) Figure 21 Top (M362S) Top (M362S) A - 23...

  • Page 78: Bottom (M362S

    Part Lists Bottom (M362S) Figure 22 Bottom (M362S) 鋁箔 A - 24 Bottom (M362S)

  • Page 79: Lcd (M362S

    Part Lists LCD (M362S) Figure 23 LCD (M362S) LCD (M362S) A - 25...

  • Page 80: Cd-Rom Drive - Qsi (M362S

    Part Lists CD-ROM Drive - QSI (M362S) Figure 24 CD-ROM Drive - QSI (M362S) A - 26 CD-ROM Drive - QSI (M362S)

  • Page 81: Cd-Rom Drive - Samsung (M362S

    Part Lists CD-ROM Drive - SAMSUNG (M362S) Figure 25 CD-ROM Drive - SAMSUNG (M362S) CD-ROM Drive - SAMSUNG (M362S) A - 27...

  • Page 82: Cd-Rw Drive - Teac (M362S

    Part Lists CD-RW Drive - TEAC (M362S) Figure 26 CD-RW Drive - TEAC (M362S) A - 28 CD-RW Drive - TEAC (M362S)

  • Page 83: Combo Drive - Qsi (M362S

    Part Lists Combo Drive - QSI (M362S) Figure 27 Combo Drive - QSI (M362S) Combo Drive - QSI (M362S) A - 29...

  • Page 84: Dvd-Rom Drive - Qsi (M362S

    Part Lists DVD-ROM Drive - QSI (M362S) Figure 28 DVD-ROM Drive - QSI (M362S) A - 30 DVD-ROM Drive - QSI (M362S)

  • Page 85: Dvd-Rom Drive - Teac (M362S

    Part Lists DVD-ROM Drive - TEAC (M362S) Figure 29 DVD-ROM Drive - TEAC (M362S) DVD-ROM Drive - TEAC (M362S) A - 31...

  • Page 86: Dvd-Dual Drive (M362S

    Part Lists DVD-Dual Drive (M362S) Figure 30 DVD-Dual Drive (M362S) A - 32 DVD-Dual Drive (M362S)

  • Page 87: Dvd-Dual Drive - Liteon (M362S

    Part Lists DVD-Dual Drive - LITEON (M362S) Figure 31 DVD-Dual Drive - LITEON (M362S) DVD-Dual Drive - LITEON (M362S) A - 33...

  • Page 88: Top (M363S

    Part Lists Top (M363S) Figure 32 Top (M363S) A - 34 Top (M363S)

  • Page 89: Bottom (M363S

    Part Lists Bottom (M363S) Figure 33 Bottom (M363S) 鋁箔 Bottom (M363S) A - 35...

  • Page 90: Lcd (M363S

    Part Lists LCD (M363S) Figure 34 LCD (M363S) A - 36 LCD (M363S)

  • Page 91: Cd-Rom Drive - Qsi (M363S

    Part Lists CD-ROM Drive - QSI (M363S) Figure 35 CD-ROM Drive - QSI (M363S) CD-ROM Drive - QSI (M363S) A - 37...

  • Page 92: Cd-Rom Drive - Samsung (M363S

    Part Lists CD-ROM Drive - SAMSUNG (M363S) Figure 36 CD-ROM Drive - SAMSUNG (M363S) A - 38 CD-ROM Drive - SAMSUNG (M363S)

  • Page 93: Cd-Rw Drive - Teac (M363S

    Part Lists CD-RW Drive - TEAC (M363S) Figure 37 CD-RW Drive - TEAC (M363S) CD-RW Drive - TEAC (M363S) A - 39...

  • Page 94: Combo Drive - Qsi (M363S

    Part Lists Combo Drive - QSI (M363S) Figure 38 Combo Drive - QSI (M363S) A - 40 Combo Drive - QSI (M363S)

  • Page 95: Dvd-Rom Drive - Qsi (M363S

    Part Lists DVD-ROM Drive - QSI (M363S) Figure 39 DVD-ROM Drive - QSI (M363S) DVD-ROM Drive - QSI (M363S) A - 41...

  • Page 96: Dvd-Rom Drive - Teac (M363S

    Part Lists DVD-ROM Drive - TEAC (M363S) Figure 40 DVD-ROM Drive - TEAC (M363S) A - 42 DVD-ROM Drive - TEAC (M363S)

  • Page 97: Dvd-Dual Drive (M363S

    Part Lists DVD-Dual Drive (M363S) Figure 41 DVD-Dual Drive (M363S) DVD-Dual Drive (M363S) A - 43...

  • Page 98: Dvd-Dual Drive - Liteon (M363S

    Part Lists DVD-Dual Drive - LITEON (M363S) Figure 42 DVD-Dual Drive - LITEON (M363S) A - 44 DVD-Dual Drive - LITEON (M363S)

  • Page 99: Top (M375S

    Part Lists Top (M375S) Figure 43 Top (M375S) Top (M375S) A - 45...

  • Page 100: Bottom (M375S

    Part Lists Bottom (M375S) Figure 44 Bottom (M375S) A - 46 Bottom (M375S)

  • Page 101: Lcd 152 (M375S

    Part Lists LCD 152 (M375S) Figure 45 LCD 152 (M375S) LCD 152 (M375S) A - 47...

  • Page 102: Lcd 154 (M375S

    Part Lists LCD 154 (M375S) Figure 46 LCD 154 (M375S) A - 48 LCD 154 (M375S)

  • Page 103: Cd-Rom Drive - Qsi-Teac (M375S

    Part Lists CD-ROM Drive - QSI-TEAC (M375S) Figure 47 CD-ROM Drive - QSI-TEAC (M375S) CD-ROM Drive - QSI-TEAC (M375S) A - 49...

  • Page 104: Cd-Rw Drive - Teac (M375S

    Part Lists CD-RW Drive - TEAC (M375S) Figure 48 CD-RW Drive - TEAC (M375S) A - 50 CD-RW Drive - TEAC (M375S)

  • Page 105: Combo Drive - Teac (M375S

    Part Lists Combo Drive - TEAC (M375S) Figure 49 Combo Drive - TEAC (M375S) Combo Drive - TEAC (M375S) A - 51...

  • Page 106: Dvd-Rom Drive - Teac-Toshiba (M375S

    Part Lists DVD-ROM Drive - TEAC-TOSHIBA (M375S) Figure 50 DVD-ROM Drive - TEAC-TOSHIBA (M375S) A - 52 DVD-ROM Drive - TEAC-TOSHIBA (M375S)

  • Page 107: Dvd-Rw Drive - Toshiba (M375S

    Part Lists DVD-RW Drive - TOSHIBA (M375S) Figure 51 DVD-RW Drive - TOSHIBA (M375S) DVD-RW Drive - TOSHIBA (M375S) A - 53...

  • Page 108: Dvd-Dual Drive (M375S

    Part Lists DVD-Dual Drive (M375S) Figure 52 DVD-Dual Drive (M375S) A - 54 DVD-Dual Drive (M375S)

  • Page 109: Card Reader (M375S

    Part Lists Card Reader (M375S) Figure 53 Card Reader (M375S) Card Reader (M375S) A - 55...
  • Page 110 Part Lists A - 56...
  • Page 111 Schematic Diagrams Appendix B:Schematic Diagrams This appendix has circuit diagrams of the M350S/M360S/M362S/M363S/M375S notebook’s PCB’s. The following ta- ble indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Table 1 Schematic System Block Diagram - Page B - 2 HDD;...

  • Page 112: Schematic Diagrams

    Schematic Diagrams System Block Diagram CLEVO M360S System Block Diagram MEMORY TERMINATIONS Multi Function Board Banias CPU CORE Processor DDR SDRAM SOCKET POEWR (VCORE) DC/DC BD ACIN;POWER BUTTON 479 uFCPGA PG3,4 SO-DIMM0 SO-DIMM1 Host Bus Charger CLOCK GEN. Sheet 1 of 34...

  • Page 113: Socket 479 - 1

    Schematic Diagrams Socket 479 - 1 of 2 H_D#[0:63] H_D#[0:63] 4 H_REQ#[4:0] H_D#0 H_D#32 D32# H_A20M# H_D#1 AA24 H_D#33 A20M# H_A20M# 14 D33# H_REQ#0 H_FERR# H_D#2 H_D#34 REQ0# FERR# H_FERR# 14 D34# H_REQ#1 H_IGNNE# H_D#3 H_D#35 H_IGNNE# 14 REQ1# IGNNE# D35# H_REQ#2 H_STPCLK#...

  • Page 114: Socket 479 - 2

    Schematic Diagrams Socket 479 - 2 of 2 V_CORE +1.8VS_PROC VSS0 VSS96 VSS1 VSS97 VSS2 VSS98 VSS3 VSS99 VSS4 VSS100 C387 VSS5 VSS101 0 0 0 0 0 0 1.708 0 0 0 0 0 1.196 VSS6 VSS102 10u_0805 0.01u_04 VSS7 VSS103 0 0 0 0 0...

  • Page 115: M661Mx-1

    Schematic Diagrams M661MX-1 +VCCP VAD[0..11] VAD[0..11] 12 R364 HNCOMP VBD[0..11] VBD[0..11] 12 Rds-on(n) = 10 ohm VBCTL[0..1] VBCTL[0..1] 12 BCLK R361 HNCVERF = 1/3 VCCP VBCLK R129 VAHSYNC HPCOMP VAHSYNC 12 VAVSYNC 110_1% Rds-on(p) = 56 ohm VAVSYNC 12 HPCVERF = 2/3 VCCP BHSYNC VBHSYNC 12 BVSYNC...

  • Page 116: M661Mx-2

    Schematic Diagrams M661MX-2 +2.5V /RMD[0..63] /RMD[0..63] 8,9 /RDQM[0..7] /RDQM[0..7] 8,9 /RDQS[0..7] C197 R188 /RDQS[0..7] 8,9 /RMA[0..14] 0.01u_04 150_1% /RMA[0..14] 8,9 /RCS#[0..3] DDRVREFB /RCS#[0..3] 8,9 CKE[0..5] CKE[0..5] 8,9 C198 R189 Rs place close to DIMM1 U32B 0.01u_04 150_1% /RMD2 RN42 /RDQS0 DQS0 AN35 /RMD1...

  • Page 117: M661Mx-3

    Schematic Diagrams M661MX-3 U32C ZCLK0 ZCLK0 ZCLK VOSCI REFCLK0 10 ZUREQ ZUREQ ZUREQ ZDREQ ZDREQ ZDREQ ZSTB0 ZSTB0 ZSTB0 ROUT DAC_RED 11 ZSTB0# ZSTB0# ZSTB0# GOUT DAC_GREEN 11 BOUT DAC_BLUE 11 ZSTB1 ZSTB1 ZSTB1 Z0601 ZSTB1# R358 33_04 ZSTB1# ZSTB1# HSYNC DAC_HSYNC 11 ZAD[0..16]...

  • Page 118: M661Mx-4

    Schematic Diagrams M661MX-4 660 bottom side +1.8VS +1.8VS +1.8VS +1.8VS +VCCP +1.8VS +3VS C176 C172 C193 0.1u_04 0.1u_04 0.1u_04 U32D C173 C177 +1.8V 0.1u_04 0.1u_04 C154 C160 AB12 AUX_IVDD AC12 AUX3.3 +1.8V 0.1u_04 0.1u_04 CT42 C163 VDDQ +1.8VS CT45 CT48 VDDQ VDDQ 10u_0805...

  • Page 119: Sodimm1 / Sodimm2

    Schematic Diagrams SODIMM1 / SODIMM2 +2.5V +2.5V DIMM2 DIMM1 Lower Upper /RMD[0:63] 5,9 /RMA[0..14] /RMA[0..14] /RMA0 /RMD0 /RMA0 /RMD0 /RMA1 /RMD1 /RMA1 /RMD1 /RMA2 /RMD2 /RMA2 /RMD2 /RMA3 /RMD3 /RMA3 /RMD3 /RMA4 /RMD4 /RMA4 /RMD4 /RMA5 /RMD5 /RMA5 /RMD5 /RMA6 /RMD6 /RMA6 /RMD6...

  • Page 120: Sstl-2 Terminatior

    Schematic Diagrams SSTL-2 Terminatior SSTL-2 Termination 1104 Resistors /RMD[0..63] C584 C585 C586 C587 C588 C589 C590 C591 /RMD[0..63] 5,8 MD/DQM(/DQS) LV-CMOS 0/10/- SSTL-2 +2.5V /RDQM[0..7] MA/Control LV-CMOS SSTL-2 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 /RDQM[0..7] 5,8 LV-CMOS SSTL-2 /RDQS[0..7] OD 3.3V OD 2.5V...

  • Page 121: Main Clock Generator

    Schematic Diagrams Main Clock Generator +3VS By-Pass Capacitors VDDREF HCB1608K-121T25 Damping Resistors Place near to the Clock Outputs VDDZ Place near to the VDDPCI CLK_CPU_BCLK Clock Outputs 49.9_1%_04 VDDPCI CLK_CPU_BCLK# 49.9_1%_04 VDD48 0.1u_04 0.1u_04 0.1u_04 0.1u_04 VDDAGP 661CLK 49.9_1%_04 VDDCPU CT26 Z1007 CLK_CPU_BCLK...

  • Page 122: Lvds; Crt

    Schematic Diagrams LVDS; CRT +1.8VS +1.8VS +1.8VS Z1104 4.7K_04 +5VS 2N7002 SCS751V 4.7K_04 Z1101 DAC_DDCADATA +5VS DAC_DDCADATA 6 JVGA1 VGA-DSUB BAV99 BAV99 BAV99 DAC_RED FRED DAC_RED DAC_GREEN FGRN DAC_GREEN DAC_BLUE FBLU DAC_BLUE 8P4LXFCA3216K4-121 MID1 DAC_HSYNC DAC_HSYNC 6 DAC_VSYNC DAC_VSYNC 6 MID3 8P4LXFCA3216K4-121 1000p...

  • Page 123: Sis302Elv

    Schematic Diagrams SIS302ELV +3VS +3VS DVDD +5VS +3VS clock source:R25/R38:crystal/mainboard OVDD LVDD1 HCB1608K-121T25 HCB1608K-121T25 HCB1608K-121T25 R349 C395 C411 CT28 C393 CT31 C398 C401 VBOSCO VBRCLK CT89 0.1u_04 0.1u_04 10u_0805 0.1u_04 10u_0805 0.1u_04 0.1u_04 *14.318MHZ 10u_0805 0.1u_04 0.1u_04 DGND C400 C397 *27p *27p +3VS...
  • Page 124 Schematic Diagrams 963L-1 (1 of 4) +3VS PCI_AD[31:0] 22,24 PCI_AD[31:0] INT_PIRQA# RN44 8P4RX8.2K INT_PIRQB# +1.8VS INT_PIRQC# INT_PIRQD# R219 C491 C492 C235 PCI_GNT4# R447 4.7K_04 U36A 0.01u_04 0.1u_04 0.1u_04 PCI_GNT1# R446 4.7K_04 IDEAVDD PREQ4# IDEAVSS RN46 PCI_REQ3# PREQ3# PCI_STOP# 8P4RX4.7K PCI_REQ2# IDE_PIORDY 18 PREQ2# ICHRDYA...
  • Page 125 Schematic Diagrams 963L-2 (2 of 4) U36B MCLK25I MCLK25O OSC25MHI H_INIT# MCLK25O MCLK25I H_INIT# INIT# OSC25MHO H_A20M# R208 *10M H_A20M# A20M# H_SMI# H_SMI# TXCLK SMI# TXCLK H_INTR H_INTR INTR H_NMI CPU_S H_NMI H_IGNNE# Z1401 R216 22_04 H_IGNNE# TXEN IGNNE# TXEN H_FERR# H_FERR# FERR#...
  • Page 126 Schematic Diagrams 963L-3 (3 of 4) U36C SCLK UCLK48M UCLK48M USBCLK48M R421 LINKON USB_PP0 4.7K_04 USB_PP0 UV0+ LREQ USB_PN0 USB_PN0 UV0- USB_PP1 USB_PP1 UV1+ USB_PN1 USB_PN1 UV1- USB_PP2 EESK EECS USB_PP2 UV2+ GPIO21/EESK USB_PN2 EEDI EESK Z1928 USB_PN2 UV2- GPIO22/EEDI USB_PP3 EEDO EEDI...
  • Page 127 Schematic Diagrams 963L-4 (4 of 4) +3VS +1.8VS +1.8V U36D +1.8VS CT53 10u_0805 C169 VDDZ CT59 10u_0805 C226 VDDZ 1N4148 VDDZ C225 C242 0.1u_04 VDDZ CT61 10u_0805 C251 R228 VDDZ AUXOK AUXOK 6,14,21 VDDZ C227 0.1u_04 VDDZ C209 0.1u_04 C241 0.1u_04 1K_04 PVDDZ...

  • Page 128: Usb 2.0, Wireless Lan

    Schematic Diagrams USB 2.0, Wireless LAN +5VS VCCUSB HCB1608K-121T25 VCCUSB R255 330K USB_OC0# VOUT VCCUSB USB_OC1# R253 CT64 C302 560K VCCUSB VOUT JUSB1 10u_0805 0.1u_04 Z1701 C267 CT65 RT9701CBL PLW3216S GND1 Z1702 0.1u_04 10u_0805 GND2 USB_PN0 DATA- GND3 Z1703 GND4 USB_PP0 DATA+ C266...

  • Page 129: Hdd; Cd-Rom

    Schematic Diagrams HDD; CD-ROM IDE_PDD[0:15] IDE_PDD[0:15] 13 IDE_SDD[0:15] IDE_SDD[0:15] 13 JCD1 JHDD1 Z1805 R268 33_04 PCIRST# PCIRST# 6,12,13,14,19,20,21,22,24 INT_CD_R INT_CD_L 23 Z1806 IDE_PDD8 IDE_PDD7 CD_GND IDE_PDD9 IDE_PDD6 IDE_SDD8 Z1810 R269 PCIRST# IDE_PDD10 IDE_PDD5 IDE_SDD9 IDE_SDD7 IDE_PDD11 IDE_PDD4 R266 IDE_SDD10 IDE_SDD6 IDE_PDD12 IDE_PDD3 IDE_SDD11...

  • Page 130: Lan Rtl8201Cl

    Schematic Diagrams LAN RTL8201CL +A3V_LAN CT113 C540 C536 C517 10u_0805 0.1u_04 0.1u_04 0.1u_04 Place close to RTL8201CL Z1908 MODEM C535 PCB Footprint = 53398-0290LA R468 R466 JMODEM1 JMLAN1 0.1u_04 Z1939 BK2125HS121_0805 Z1941 R460 1.5K 49.9_1%_04 49.9_1%_04 Z1940 BK2125HS121_0805 Z1942 +A3V_LAN RING MODEM_CON =8mil...

  • Page 131: Rom

    Schematic Diagrams +3VH8 +3VS R152 10K_04 C143 C141 C149 C452 +3VS 0.1u_04 0.1u_04 0.1u_04 0.1u_04 BT_SW +3VS BT_SW C131 HCH STS-02 0.1u_04 PCIRST# 6,12,13,14,18,19,21,22,24 PCIRST# RST# R/#C(CLK) PCLK_FWH 10 Z2117 R177 *10K_04 A9(GPI3) A10(GPI4) Z2118 Z2121 R169 *10K_04 R149 4.7K_04 A8(GPI2) MODE Z2119...
  • Page 132 Schematic Diagrams +5VH8 +VDD5 +3VH8 +3VH8 +3VH8 +3VH8 H8MD1 H8MD1 +3VH8 +3VH8 R411 0_0805 C449 CT103 R402 R396 C110 C448 C142 C109 C427 CT34 10K_04 C430 0.1u_04 10u_0805 2N7002 150K C428 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 10u_0805 Z2110 C424 R412 R392 Z2111 Z2112...

  • Page 133: Con; Mini-Pci

    Schematic Diagrams CON; Mini-PCI PCI_AD[31:0] 13,24 PCI_AD[31:0] +3VS +5VS +3VS C269 C265 C270 C262 C258 C263 C282 C272 JMINIPCI1 C300 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 R515 10K_04 +3VS WLAN_EN R241 INT_PIRQA# 6,13,24 R231 Z2201 R242 INT_PIRQB# INT_PIRQD# 12,13 R238 Z2202...

  • Page 134: Audio Codec Alc202

    Schematic Diagrams Audio Codec ALC202 Z2376 R290 0_04 +3VS PLEASE PLACE CLOSE THE +5VS AUD_VDD PLEASE PLACE CLOSE CODEC & AUD5V POWER INPUT PINS +3VS R289 10K_04 AMP THE POWER INPUT PINS EAPD_MUTE AUD_AGND HCB3216K-800T30 CT70 C338 C335 SPDIFO CT66 CT63 C333 C319...

  • Page 135: Pcmcia (Ene1410

    Schematic Diagrams PCMCIA (ENE1410) +3VS +3VS VCCCB PCUVCC VCCP HCB2012K-121T30_0805 HCB2012K-121T30 C264 C508 C271 C277 C561 C569 C273 CT118 C276 C268 C562 C528 C507 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 10u_0805 0.1u_04 0.1u_04 0.1u_04 0.1u_04 VCCP VCCP VPPD0 VCCCB VPPD1 VCCCB PCUVCC...

  • Page 136: Pcmcia Socket

    Schematic Diagrams PCMCIA Socket VPPCB R483 C543 C560 CT117 CAD0 D3 - CAD0 100K_1% 1000p 0.1u_04 10u/25V_1206 CAD1 D4 - CAD1 CAD3 D5 - CAD3 CAD5 D6 - CAD5 CAD7 D7 - CAD7 CCBE#0 +3VS CE1- CCBE0 CAD9 A10- CAD9 CAD11 CCD1# R451...

  • Page 137: Ac In; Power Button

    Schematic Diagrams AC IN; Power Button JPWR1 +3VS TOTAL-I RSS090N03 C571 +2.5V +2.5VS 2.2u/16V_0805 CON7 R509 VSEN C380 C379 CT124 CT125 CT126 0.1u_X7R 0.1u_X7R 0.1u_X7R 0.1u_X7R CT122 10u_0805 100K_1% 10u_0805 10u_0805 10u_0805 +3VH8 VSEN SI3456DV CT123 R507 10u_0805 100K_1% R295 10K_04 RB751V Z2601...

  • Page 138: V_Core

    Schematic Diagrams V_CORE +VCCP 10K_04 H_VID0 R113 10K_04 H_VID2 C108 H_VID1 SCS551V H_VID4 +3VS Z2712 4.7u H_VID3 C429 H_VID5 BST1_VCORE 8P4RX10K R111 R134 R100 CT87 CT21 CT80 CT16 100K_1% 100K_1% 1_1% 0.01u 0.1u_04 10u/25V_1206 10u/25V_1206 10u/25V_1206 10u/25V_1206 +VDD5 C404 IRF7821 IRF7821 VCORE_PWGD BST1...

  • Page 139: V, +Vccp

    Schematic Diagrams +1.8V, +VCCP Z2812 +VDD5 R175 R174 C474 Z2813 R162 C439 CT30 CT97 SCS551V SCS551V C470 1000p 0.1u_04 PGOOD1 PGOOD2 Z2801 Z2802 C441 1000p VDDP1 VCCA1 C469 CT94 CT27 VDDP2 VCCA2 Q17A C442 AO4914 Z2803 Z2814 R195 0.1u_04 10u/25V_1206 TON1 Sheet 28 of 34 Z2804...

  • Page 140: Charger

    Schematic Diagrams Charger 2.5A AO4407 2.5A Z2923 10uF/25V_OSCON Z2920 Z2919 47uH_BCRH124 25m(2512) DTA114EUA SA340A C353 C357 1SS355 R297 SM340A 0.1u_04 0.1u_04 0.1u_04 0.1u_04 0.1u_04 Z2901 R298 100K_1% 10uF/25V_OSCON Z2926 Z2925 JUMP_2MM Z2924 R321 R320 R303 10uF/25V_OSCON R301 R302 10uF/25V_OSCON Z2903 Z2902 1K_1% 1K_1%...

  • Page 141: V, +1.25V

    Schematic Diagrams +2.5V, +1.25V +VDD5_P VIN_P PR26 PR27 PR24 1.5M SM140A 470K SC486 PR28 VDDQ VIN_P VDDQS PC32 PC27 PC37 PR30 PC34 PC30 22u/25V_OSCON 0.1u_04 100p 6.65K_1% PR23 PQ13 . D. VREF AO4408 PR33 10_1% PC50 COMP PC38 0.1u_04 VDDQ PR32 *0.1u_04 VTTS...

  • Page 142: Vdd5, +Vdd3, +1.2V

    Schematic Diagrams +VDD5, +VDD3, +1.2V OPEN_10mil VIN_P 0.1A DTA114EUA 2SC4672 0.1A PR37 +12V_P VIN1_P OPEN VIN_P 1K_04 11.5K_1% PR11 PCT1 2004/3/18 VL_P 11FS2 V+_P PR35 10u/25V_1206 PC18 PC21 PC25 PC41 PC42 2SD1782K 0.1u 0.01u PCT11 PC46 0.1u 0.01u 1.21K_1%_0805 22u/25V_OSCON PC13 DTC114EUA 10u_0805...

  • Page 143: Multi-Function Board

    Schematic Diagrams Multi-Function Board 0.1u MGND MJMFC1 MVIN 2003.8.5 MCON1.2 to MGND MPD1 M+3VS FD10JK4(TO-252) MNUM_LED# MCON1 MPR4 100m(2512) MGND MCAP_LED# Z3014 MVA+ MPF1 MPR2 100m(2512) MSCROLL_LED# MBT_EN MHD_PD_LED# GND1 MPC6 MPC5 MPC4 MPR3 MPR1 MPR12 MPR7 MPR6 MLID_RSUM# GND2 MM_BTN# POWER JACK 0.1u...

  • Page 144: Audio Jack Board

    Schematic Diagrams Audio Jack Board JAUDIO2 AJINTMICSEL AJMIC AJSPKOUTL AJHPSEL AJSPKOUTR AJSPDIF AJSPDIFGND CON8 AJGND JAUDIO3 GND1 SPDIF OUT AJSPDIF AJSPDIFGND AJSPKOUTL Sheet 33 of 34 AJHPSEL (B) SPK OUT AJSPKOUTR Audio Jack Board AJINTMICSEL AJMIC (C) MIC IN GND2 AJC1 AJC2 AJC3...

  • Page 145: Click Board

    Schematic Diagrams Click Board CLICK BOARD TGND TSW1 TTP_DATA TTP_CLK TPBUTTON_UP HCH STS-05 CON1_T T+5VS PIN5,6=TGND TGND Sheet 34 of 34 TSW2 TSW4 Click Board T+5VS TPBUTTON_L TPBUTTON_R HCH STS-05 HCH STS-05 PIN5,6=TGND PIN5,6=TGND TGND TGND TTP_DATA TTP_DATA TTP_CLK TSW3 TTP_CLK TPBUTTON_DOWN TPBUTTON_L...
  • Page 146 Schematic Diagrams B - 36...

This manual is also suitable for:

M360sM375sM362sM363s

Table of Contents
