Summary of Contents for Clevo M815P

  • Page 1 V09.1.00...
  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 5: Fcc Rf Radiation Exposure Statement

    Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
  • Page 6: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
  • Page 9: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a Power Safety steady, uninterrupted power supply. If you are unsure of your local power specifications, Warning consult your service representative or local power company.
  • Page 10: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 11: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
  • Page 12: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 13 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 14 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 15: Lcd Screen Care

    Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
  • Page 16 Preface...
  • Page 17: Table Of Contents

    Preface Contents Notice .................I System Map: Left & Right Views .......1-11 FCC Statement ..............II System Map: Bottom View ..........1-12 FCC RF Radiation Exposure Statement: ......III 3.75G/HSPA Module USIM Card Installation ....1-13 Instructions for Care and Operation ........ V Windows 7 Start Menu & Control Panel .....1-14 Power Safety ..............VII Video Features .............1-15 Battery Precautions ............
  • Page 18 Preface Parallel Printer .............2-12 Drivers & Utilities What to Install ..............4-1 Power Management Module Driver Installation ..........4-1 Overview ................3-1 Driver Installation ............4-2 The Power Sources ............3-2 Updating/Reinstalling Individual Drivers ......4-4 AC/DC Adapter .............3-2 User Account Control ............4-4 Battery ................3-2 Windows Security Message ...........4-4 Turning On the Computer ..........3-3 New Hardware Found ............4-5 Power Plans ..............3-4...
  • Page 19 Preface BIOS Utilities Boot Menu ..............5-12 Exit Menu ..............5-13 Overview ................5-1 The Power-On Self Test (POST) ........5-2 Upgrading The Computer Failing the POST ............5-3 Overview ................6-1 Fatal Errors ..............5-3 When Not to Upgrade ............6-2 Non-Fatal Errors ............5-3 Removing the Battery ............6-3 The Setup Utility ............5-4 Upgrading the HDD ............6-4 Entering Setup ...............5-4...
  • Page 20 Preface 3G Watcher Application Installation ......7-21 Interface (Ports & Jacks) Setting Up a Carrier Profile .........7-22 Notebook Ports and Jacks ..........A-2 Short Messaging Service ..........7-27 HSPA Modem Interface ..........7-28 Intel Video Driver Controls HSPA Modem Interface Installation ......7-28 Intel Video Driver Installation ........B-1 HSPA Modem Interface ..........7-29 Video ................
  • Page 21 Preface Keyboard ............... C-2 Operating System ............C-3 Card Reader ..............C-3 Slot ................C-3 Dimensions & Weight ..........C-3...
  • Page 22 Preface...
  • Page 23: Quick Start Guide

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
  • Page 24: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
  • Page 25: Not Included

    Quick Start Guide Not Included Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...
  • Page 26: System Software

    Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find that this manual refers to the Windows 7 operating system version as indicated below.
  • Page 27: System Startup

    Quick Start Guide System Startup Remove all packing materials, and place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
  • Page 28: System Map: Lcd Panel Open

    Quick Start Guide System Map: LCD Panel Open Figure 1 - 2 LCD Panel Open Built-In PC Camera Wireless Device Operation Aboard Speakers Aircraft Power Button Keyboard The use of any portable elec- tronic transmission devices Built-In Microphone aboard aircraft is usually pro- Touchpad &...
  • Page 29: Keyboard

    Quick Start Guide Keyboard The keyboard has a numerical keypad for easy numeric data input, and features function keys to allow you to change operational features instantly. See Table 1 - 2, on page 1 - 8 for details on the function keys. Special Characters Some software applications allow the number-keys to be used with Alt to pro-...
  • Page 30: Function/Hot Key Indicators

    Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. Keys Function Keys Function Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F7 Display Toggle 3.75G Module Power Brightness Decrease/...
  • Page 31: System Map: Front & Rear Views

    Quick Start Guide System Map: Front & Rear Views Figure 1 - 4 Front & Rear Views LED Power & Communication Indicators 7-in-1 Card Reader Microphone-In Jack Headphone-Out Jack Battery 7-in-1 Card Reader The card reader allows you to use the most popular digital storage card formats: MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) / MS Pro (Memory Stick Pro) / MS Duo (requires PC adapter) / Mini SD (requires PC adapter) / RS MMC (requires PC adapter)
  • Page 32: Led Indicators

    Quick Start Guide LED Indicators Icon Color Description Orange DC Power is Plugged In Green The Computer is On Blinking Green The Computer is in Sleep Mode Orange The Battery is Charging Green The Battery is Fully Charged Blinking Orange The Battery Has Reached Critically Low Power Status Green Hard Disk Activity...
  • Page 33: System Map: Left & Right Views

    Quick Start Guide System Map: Left & Right Views Figure 1 - 5 Left & Right Views Security Lock Slot DC-In Jack RJ-45 LAN Jack 2 * USB 2.0 Ports External Monitor Port Hard Disk Drive Vent/Fan Intake/ Outlet Overheating External Optical (CD/DVD) Device Drives To prevent your computer from To install applications and drivers etc.
  • Page 34: System Map: Bottom View

    Quick Start Guide System Map: Bottom View Figure 1 - 6 Bottom View Battery 3.75G/HSPA Module USIM Vent/Fan Intake/ Card Outlet Hard Disk Bay The 3.75G/HSPA module’s USIM card location is located under the bat- tery compartment. See page 1 - 13 for instructions on installing the 3.75G/HSPA USIM card.
  • Page 35: 3.75G/Hspa Module Usim Card Installation

    Quick Start Guide 3.75G/HSPA Module USIM Card Installation If you have included an optional 3.75G/HSPA module in your purchase option, follow the instructions below to install the USIM card (which will be provided by your service provider), and then run the 3G Watcher/HSPA Modem Interface application.
  • Page 36: Windows 7 Start Menu & Control Panel

    Quick Start Guide Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are ac- cessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
  • Page 37: Video Features

    Quick Start Guide Video Features You can configure display options from the Display (Control Panel) and Screen Resolution in Windows. For more detailed video information see Chapter B“Intel Video Driver Controls” from page B - To access Display (Control Panel) and Screen Resolution in Windows: Click Start and click Control Panel.
  • Page 38: Screen Resolution & Intel Gma Control Panel

    Quick Start Guide Screen Resolution & Intel GMA Control Panel Figure 1 - 9 - Screen Resolution & Intel GMA Driver for Mobile Control Panel 1 - 16 Video Features...
  • Page 39: Power Options

    Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 14) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
  • Page 40 Quick Start Guide 1 - 18...
  • Page 41: Features & Components

    Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • External USB Optical (CD/DVD) Device • 7-in-1 Card Reader • TouchPad and Buttons/Mouse •...
  • Page 42: Hard Disk Drive

    Features & Components Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) HDDs with a height of 9.5 mm. Before attempting to ac- The HDD is located in the bay on the right of your computer, and this can be opened cess any of the internal...
  • Page 43: External Usb Optical (Cd/Dvd) Device

    Features & Components External USB Optical (CD/DVD) Device An external USB optical (CD/DVD) device is available as an option for this com- USB Cables puter. The optical device may be used as a boot device if properly set in the BIOS (see “Boot Menu”...
  • Page 44: Handling Cds Or Dvds

    Features & Components Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.
  • Page 45: Dvd Regional Codes

    Features & Components DVD Regional Codes Go to the Control Panel and double-click Device Manager (Hardware and Sound), then click the + next to DVD/CD-ROM drives. Double-click on the DVD- ROM device to bring up the Properties dialog box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code.
  • Page 46: 7-In-1 Card Reader

    Features & Components 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
  • Page 47: Touchpad And Buttons/Mouse

    Features & Components TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. If you are using an ex- ternal mouse your op- Once you have installed the TouchPad driver (see...
  • Page 48: Finger Sensing Pad Configurator

    Features & Components Finger Sensing Pad Configurator The Finger Sensing Pad Configurator allows you to use a configure the settings for the Finger Pad device and software. The left pane in the control panel contains all the configurable items, and you can click the “+” to expand the menu selections. You can configure the settings from the Device Settings tab in Mouse Properties: Click Start, and click Control Panel (or point to Settings and click Control Panel).
  • Page 49: Gestures

    Features & Components Gestures Click Gestures and make sure that the Enable Gestures tickbox is clicked. Double- click Gestures and then double-click Advanced to open the submenu. You can con- Play Video figure any of the gestures from this submenu. You can get a clearer view of the gestures in- volved by clicking the...
  • Page 50: Audio Features

    Features & Components Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Adjustment control panel (right-click the taskbar icon to bring up an audio menu).
  • Page 51: Optimizing Audio Recording

    Features & Components Optimizing Audio Recording Follow these instructions to optimize your audio recording. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound). Click Recording (tab). Right-click Microphone (Realtek High Definition Audio) and make sure the item is not disabled.
  • Page 52: Adding A Printer

    Features & Components Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- ble to the printer.
  • Page 53: Power Management

    Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
  • Page 54: The Power Sources

    Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-in jack on the left of the computer.
  • Page 55: Turning On The Computer

    Power Management Turning On the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Forced Off er button on the front panel. If the system “hangs”, When the computer is on, you can use the power button as a Stand by/Hibernate/ and the Ctrl + Alt + Del Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and key combination doesn’t...
  • Page 56: Power Plans

    Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
  • Page 57 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.
  • Page 58: Power-Saving States

    Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states. Sleep In Sleep all of your work, settings and preferences are saved to memory before the system sleeps.
  • Page 59: Hibernate

    Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.
  • Page 60: Configuring The Power Buttons

    Power Management Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Click Choose what the power buttons do on Protection the left menu in Power Options to bring up the menu. It is recommended that you enable a password on wake up in order to...
  • Page 61: Resuming Operation

    Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status To Resume Icon Color send the computer to...
  • Page 62: Battery Information

    Power Management Battery Information Follow these simple guidelines to get the best use out of your battery. Low Battery Battery Power Warning Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- grams you are running, and peripheral devices attached. You can set actions to be cally low, immediately connect AC/DC...
  • Page 63: Conserving Battery Power

    Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.
  • Page 64: Battery Life

    Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.
  • Page 65: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
  • Page 66: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
  • Page 67 Power Management Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings. Figure 3 - 8 Change Plan Settings / Change Advanced Power Settings Battery Information 3 - 15...
  • Page 68 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 9 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
  • Page 69 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
  • Page 70 Power Management 3 - 18...
  • Page 71: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual disc of the computer’s subsystems. The system takes ad- contains the drivers and utilities necessary for the vantage of some newer hardware components for proper operation of the computer.
  • Page 72: Driver Installation

    Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc and click Install Drivers/Option Drivers (button).
  • Page 73 Drivers & Utilities Manual Driver Installation Click Browse CD/DVD (button) in the Drivers Install- Driver - Windows 7 Page # er application and browse to the executable file in the Chipset Page 4 - 5 appropriate driver folder. Video Page 4 - 5 Windows Update Audio Page 4 - 5...
  • Page 74: Updating/Reinstalling Individual Drivers

    Drivers & Utilities Updating/Reinstalling Individual Drivers User Account Control If you wish to update/reinstall individual drivers it If a User Account Control prompt appears as part of may be necessary to uninstall the original driver.To do the driver installation procedure, click Continue or this go to the Control Panel in the Windows OS and Allow, and follow the installation procedure as direct- double-click the Programs and Features icon (Pro-...
  • Page 75: New Hardware Found

    Drivers & Utilities New Hardware Found Driver Installation Procedure If you see the message “New Hardware Found” dur- Insert the Device Drivers & Utilities + User’s Manual ing the installation procedure (other than when out- disc and click Install Drivers (button). lined in the driver install procedure), click Cancel Chipset to close the window, and follow the installation proce-...
  • Page 76: Lan

    Drivers & Utilities Hot Key 1. Click 4.Install LAN Driver > Yes. 1. Click 7.Install HotKey Driver > Yes. 2. Click Install > Finish to complete the installa- 2. Click Next > Next. tion. 3. Click Finish > Finish to restart the computer. 3.
  • Page 77: Optional Drivers

    Drivers & Utilities Optional Drivers See the pages indicated overleaf for the driver installa- tion procedures for any modules included in your pur- Windows 7 Update chase option. After installing all the drivers make sure you enable Win- dows Update in order to get all the latest security up- dates etc.
  • Page 78: Bluetooth Module

    Drivers & Utilities Bluetooth Module Note: The operating system is the default setting for Bluetooth control in Windows 7, and does not re- quire a driver. See “Bluetooth Module” on page 7 - for configuration instructions. PC Camera Module See the introduction in “PC Camera Module”...
  • Page 79: Overview

    BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Screens Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured these pages are intend- Diagnostics: The POST (Power-On Self Test) ed for guidance in set- ting up your system’s BIOS.
  • Page 80: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...
  • Page 81: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
  • Page 82: The Setup Utility

    BIOS Utilities The Setup Utility The Phoenix SecureCore Setup Utility tells the system how to configure itself and BIOS Settings manage basic features and subsystems (e.g. port configuration). Warning Entering Setup Incorrect settings can cause your system to To enter Setup, turn on the computer and press F2 during the POST. The prompt malfunction.
  • Page 83: Setup Screens

    BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Phoenix Se- cureCore Setup Utility. Setup Menus Setup menus Along the top of the screen is a menu bar with menu headings. When you select a shown in this section are heading, a new screen appears.
  • Page 84: Main Menu

    BIOS Utilities Main Menu Phoenix SecureCore(tm) Setup Utility Main Figure 5 - 2 Main Advanced Security Boot Exit Main Menu Item Specific Help System Time: [22:12:05] System Date: [11/08/2009] <Tab>, <Shift Tab>, or SATA Port 1 [160GB SATA1] <Enter> selects field. System Memory 633 KB Extended Memory...
  • Page 85: Sata Port 1 (Main Menu)

    BIOS Utilities SATA Port 1 (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a HDD on the com- puter’s Serial ATA Port 1. Use the Auto (Type:) setting to have the items configured automatically for you. System/Extended Memory (Main Menu) This item contains information on the system memory, and is not user configurable.
  • Page 86: Advanced Menu

    BIOS Utilities Advanced Menu Phoenix SecureCore(tm) Setup Utility Main A A dvanced Advanced Security Boot Exit Figure 5 - 3 Item Specific Help Advanced Menu SATA Mode Selection: [AHCI] Legacy USB Support: [Enabled] Determines how SATA Boot-time Diagnostic Screen: [Disabled] controller(s) operate.
  • Page 87: Legacy Usb Support (Advanced Menu)

    BIOS Utilities Legacy USB Support (Advanced Menu) Use this menu item to enable/disable the support for Legacy Universal Serial Bus in non-USB aware operating systems. Boot-time Diagnostic Screen (Advanced Menu) Use this menu item to enable/disable the Boot-time Diagnostic Screen or POST screen (see “The Power-On Self Test (POST)”...
  • Page 88: Security Menu

    BIOS Utilities Security Menu Phoenix SecureCore(tm) Setup Utility Security Menu Main Advanced Security S S e e c c u u r r i i t t y y Boot Exit Item Specific Help changes Supervisor Password Is: Clear make here affect the User Password Is: Clear Supervisor Password...
  • Page 89: Set User Password (Security Menu)

    BIOS Utilities Set User Password (Security Menu) You can set a password for user mode access to the Phoenix SecureCore Setup Utility. This will not affect access to the computer OS, (only the Setup utility) unless Password Warning you choose to set a Password on Boot (see below). Many menu items in the Phoenix If you set a boot pass- SecureCore Setup Utility cannot be modified in user mode.
  • Page 90: Boot Menu

    BIOS Utilities Boot Menu Phoenix SecureCore(tm) Setup Utility Main Advanced Security Boot Exit Item Specific Help Figure 5 - 5 Boot priority order: Boot Menu USB KEY: Keys used to view or IDE HDD: FUJITSU MH22160BH G2-(S1) USB FDC: configure devices: USB CDROM: Up and Down arrows USB HDD:...
  • Page 91: Exit Menu

    BIOS Utilities Exit Menu Phoenix SecureCore(tm) Setup Utility Figure 5 - 6 Main Advanced Security Boot Exit Exit Menu Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to CMOS. Discard Changes Save Changes Help...
  • Page 92 BIOS Utilities 5 - 14...
  • Page 93: Overview

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- lined to make the desired upgrades. If you have any trouble or problems you can con- Warranty Warning tact your service representative for further help. Before you begin you will need: Please check with your service representative...
  • Page 94: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake upgrade proce- • Your system is still under warranty or a service contract dures, make sure that •...
  • Page 95: Removing The Battery

    Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Turn the computer off, and turn it over. Please check with your Slide the latches in the direction of the arrows to unlock the battery.
  • Page 96: Upgrading The Hdd

    Upgrading The Computer Upgrading the HDD The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) HDD System HDDs with a height of 9.5mm (h) and a speed of 5400 RPM or lower. Follow your Warning operating system’s installation instructions, and install all necessary drivers and util- ities (see “Driver Installation”...
  • Page 97: Hard Disk Removal

    Upgrading The Computer Hard Disk Removal Turn off the computer, and remove the battery. Locate the hard disk bay cover and remove screw Hard Disk Drive Slide the hard disk assembly in the direction of the arrow Speeds Carefully lift the hard disk assembly up out of the bay.
  • Page 98 Upgrading The Computer Remove screws from the hard disk assembly. Separate the hard disk from the case. Insert the new hard disk into the case and pay careful attention to the disk’s orientation in the case. Secure the disk with the four screws and then reinsert the hard disk assembly into the computer’s hard disk bay.
  • Page 99: Upgrading The System Memory (Ram)

    Upgrading The Computer Upgrading the System Memory (RAM) The computer has one memory socket for 200 pin Small Outline Dual In-line (SO- DIMM) DDRII (DDR2) type memory modules (see “Memory” on page C - 2 details of supported module types). The total memory size is automatically detected by the POST routine once you turn on your computer.
  • Page 100 Upgrading The Computer Gently pull the two release latches on the sides of the memory socket in the direction indicated by the arrows ( & Figure 6 - Figure 6 - 5 RAM Module Release Latches Contact Warning Be careful not to touch the metal pins on the module’s connecting...
  • Page 101 Upgrading The Computer Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. The module’s pin alignment will allow it to only fit one way. Make sure the module is seated as far into the slot as it will go. DO NOT FORCE the module; it should fit Re-Inserting the Keyboard without much pressure.
  • Page 102: Upgrading The Processor

    Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with a fast- Warranty er/new one you will need to contact your customer service representative. We rec- ommend that you do not do this yourself, since if it is done incorrectly you may The CPU is not a user damage the processor or mainboard.
  • Page 103: Overview

    Modules & Options Chapter 7: Modules & Options Overview Important Notice - 3.75G/HSPA & Blue- This chapter contains information on the following modules, which may come with tooth/Wireless LAN your computer, depending on the configuration purchased. If you are unsure please Modules contact your service representative.
  • Page 104: Bluetooth Module

    Modules & Options Bluetooth Module The operating system’s Bluetooth Devices control panel is used to configure the Wireless Device Bluetooth settings in Windows 7 and therefore does not require a driver. Use the Fn Operation Aboard + F12 key combination (see “Function/Hot Key Indicators”...
  • Page 105: Bluetooth Configuration In Windows 7

    Modules & Options Bluetooth Configuration in Windows 7 Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Add a Device Make the device discoverable (to do this check your device documentation). Click Start, and click To Turn the Bluetooth Module On Control Panel and then...
  • Page 106 Modules & Options To Add a Bluetooth Device Access the Bluetooth Devices control panel and click Add a device. Double-click the device you want to pair with the computer. Pairing Options If a device has been pre- viously connected then the pairing option menu will appear when you at- tempt subsequent con-...
  • Page 107 Modules & Options Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing. Figure 7 - 3 Pairing Codes Pairing Code Example The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection proce- dure, and may require you to confirm a pairing code is correct on both devices.
  • Page 108 Modules & Options To Change Settings for the Bluetooth Device Click the taskbar icon and select Show Bluetooth Devices. Right-click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click Bluetooth, type a new name and click OK). •...
  • Page 109: Pc Camera Module

    Modules & Options PC Camera Module The PC Camera application captures video files and takes pictures. Before installing PC Camera Screen the driver, make sure that the optional PC Camera is on. Refresh Use the Fn + F10 key combination (see “Function/Hot Key Indicators”...
  • Page 110 Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
  • Page 111 Modules & Options Camera Application The camera application is a video viewer for general purpose video viewing and test- ing, and for capturing video files to .avi format. Pre-Allocating File Size/Space Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see “Set Capture File”...
  • Page 112 Modules & Options Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
  • Page 113 Modules & Options Eliminating Screen Flicker If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. Latest PC Camera Driver Information Run the camera application from the desktop shortcut. Go to Options and scroll down to select Video Capture Filter..
  • Page 114 Modules & Options Zoom The camera program allows you to zoom the camera in and out (note the zoom function is not available in all camera model applications). Run the camera application from the desktop shortcut. Go to Zoom and select Zoom Out/Zoom In. Figure 7 - 7 Zoom/Setting Taking Still Pictures...
  • Page 115: Wireless Lan Module

    Modules & Options Wireless LAN Module If you have included an Intel® Wi-Fi Link 1000 Series (802.11 b/g/n) or 3rd Party Wireless Device 802.11b/g/n WLAN module in your purchase option, make sure that the Wireless Operation Aboard LAN module is on before installing the driver (the WLAN module’s default power Aircraft state is off).
  • Page 116: Intel® Wi-Fi Link Series Driver Installation

    Modules & Options Intel® Wi-Fi Link Series Driver Installation If you see the message “Found New Hardware” click Cancel to close the window. 1. Make sure the module is powered on, then insert the Device Drivers & Util- ities + User’s Manual disc into the CD/DVD drive. 2.
  • Page 117: Connecting To A Wireless Network

    Modules & Options Connecting to a Wireless Network Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then double-click an access point to con- Network and nect to or click to Open Network and Sharing Center if you do not see a network Sharing Center you want to connect to in the taskbar menu (a list of options will appear allowing You can also use the Net-...
  • Page 118 Modules & Options You may need to enter a security key for any access point to which you are trying to connect. Click to select a network location (e.g. Home, Work or Public). Click “View or change settings in Network and Sharing Center” to access further options for the connection.
  • Page 119 Modules & Options Click the taskbar icon to see any currently connected networks. To disconnect from the wireless network you can click the taskbar wireless icon , click the active connection and then click Disconnect (button). Security Enabled Networks You should try to make sure that any network you are connecting to is a se- cure network.
  • Page 120: Windows Mobility Center

    Modules & Options Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
  • Page 121: 3.75G/Hspa Module

    Modules & Options 3.75G/HSPA Module If you have included an optional 3.75G/HSPA (High Speed Packet Access) module in your purchase option, you will have the appropriate application (3G Watcher, 3.75G/HSPA Module Options HSPA Modem Interface or Mobile Partner) provided for your particular module. Follow the instructions on page 1 - 13 to install the USIM card (supplied by your...
  • Page 122 Modules & Options Before installing the application, make sure that the 3.75G/HSPA module is ON (installing the driver with the module off will not allow the software to detect the module hardware correctly). Use the Fn + key combination (see “Function/Hot 3.75G/HSPA Key Indicators”...
  • Page 123: G Watcher

    Modules & Options 3G Watcher With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the 3G Watcher application. The 3G Watcher appli- Wireless Device cation allows you to directly access your HSPA internet service from the computer. Operation Aboard Aircraft 3G Watcher Application Installation...
  • Page 124: Setting Up A Carrier Profile

    Modules & Options Setting Up a Carrier Profile Although the connection information is stored on the USIM card supplied by the ser- vice provider, you may need to set up the appropriate carrier profile in 3G Watcher. Power on the 3.75G/HSPA module using the Fn + key combination.
  • Page 125 Modules & Options You can then enter a new profile name or choose a profile from the drop-down list provided by the software (see the sidebars for information on the profile details). Figure 7 - 13 User Options Profile Information Profile Details Click General and/or Ad- vanced (and the sub-...
  • Page 126 Modules & Options Connecting to the Service Provider Power on the 3.75G/HSPA module using the Fn + key combination. You can access the 3G Watcher application from the Start menu (Start > Programs/All Programs > Sierra Wireless > 3G Watcher), or by double-clicking the desktop icon The software will run and display the service provider name (see “Setting Up a...
  • Page 127 Modules & Options When the connection is successful a taskbar notification will appear (as below). Figure 7 - 17 Connected Taskbar Notification You can then access the internet, download e-mail etc. as per any internet connection. While you are connected the taskbar icon will be green (it will be red when the program is running but not connected).
  • Page 128 Modules & Options 12. If you click the 3G Watcher close icon a message will be displayed asking you to click OK to confirm the program exit. Figure 7 - 19 Exit Warning 13. Exiting the program DOES NOT turn off the 3.75G/HSPA module, and you will need to press the Fn + key combination to turn off the module (pay careful attention to this aboard aircraft - see...
  • Page 129: Short Messaging Service

    Modules & Options Short Messaging Service In addition to standard internet services you may also send and receive SMS text messages using the 3G Watcher program, if your service supports SMS. Reading SMS Messages The SMS message indicator in the main window will notify you of any new messages received.
  • Page 130: Hspa Modem Interface

    Modules & Options HSPA Modem Interface With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the HSPA Modem Interface. The HSPA Modem In- Wireless Device terface allows you to directly access your HSPA internet service from the computer. Operation Aboard Aircraft HSPA Modem Interface Installation...
  • Page 131: Hspa Modem Interface

    Modules & Options HSPA Modem Interface The connection information is stored on the USIM card supplied by the service pro- vider. HSPA Modem Help Power on the 3.75G/HSPA module using the Fn + key combination. To get help on 3.75G/ Access the HSPA Modem Interface from the Start menu (Start >...
  • Page 132 Modules & Options Click Connect to connect to your service provider. Figure 7 - 21 Connecting to Network The message “Network is connected” will be displayed when the network connection is successful. Figure 7 - 22 Network is Connected You can then access the internet, download e-mail etc. as per any internet connection.
  • Page 133: Adding A Profile

    Modules & Options While you are connected the upper right corner of the HSPA Modem interface will display the upload and download rates, and the taskbar icon will display the connection information. Figure 7 - 23 Uploading/ Downloading Rates and Speed 10.
  • Page 134 Modules & Options Click Add (button) and input any Network Settings required by your service provider. Click OK to save the profile. Figure 7 - 25 Network Settings & Profiles You can Edit or Delete profiles from the Profiles tab. To use a profile click to select it, and then click Apply (button) and the settings will be transferred to Connection Manager.
  • Page 135: Contacts

    Modules & Options Contacts Access the HSPA Modem Interface from the Start menu (Start > Programs/All Programs > HSPA Modem > HSPA Modem), or by clicking the desktop icon. Click Contacts (button). Figure 7 - 26 Network Settings & Profiles Click Refresh (button) to download the contacts from the USIM card to the computer.
  • Page 136: Messages

    Modules & Options Messages Access the HSPA Modem Interface from the Start menu (Start > Programs/All Programs > HSPA Modem > HSPA Modem), or by clicking the desktop icon. SMS Service Click Messages (button). In addition to standard in- ternet services you may also send and receive SMS text messages us- ing the HSPA Modem In-...
  • Page 137: Settings

    Modules & Options Click to select a contact from the list and then click Add (button) and the phone number will automatically be added to the recipient field. Type the message information into the message body and click Send (button) to send it, or Save to draft (button) to save the message.
  • Page 138 Modules & Options Click OK alongside any of the options to configure the settings. The Network can be configured for an Automatic (usually from the USIM card) or Manual connection. The Network Mode can be configured for any appropriate mode required. Figure 7 - 29 Settings - Network/ Network Mode...
  • Page 139: Mobile Partner

    Modules & Options Mobile Partner With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the Mobile Partner application. The Mobile Partner Wireless Device application allows you to directly access your HSPA internet service from the com- Operation Aboard puter.
  • Page 140: Mobile Partner Application

    Modules & Options Mobile Partner Application You will need to contact your service provider to obtain the exact details of how ex- actly to configure the settings on this page. Mobile Partner Help Profile Management To get help on Mobile Partner configuration Power on the 3.75G/HSPA module using the Fn +...
  • Page 141 Modules & Options Connecting to the Service Provider Power on the 3.75G/HSPA module using the Fn + key combination. Access the Mobile Partner application from the Start menu (Start > Programs/ All Programs > Mobile Partner), or by double-clicking the Mobile Partner icon on the desktop The software will run and you can select the Profile Name from the menu.
  • Page 142 Modules & Options When the connection is successful you can move the cursor over the network icon in the taskbar to display the connection information. Figure 7 - 33 Connected Taskbar Notification You can then access the internet, download e-mail etc. as per any internet connection.
  • Page 143 Modules & Options To disconnect click the Disconnect icon, or right click the taskbar icon and select Disconnect. Figure 7 - 34 Disconnect 10. The program will disconnect from the service provider. 11. The module will still be on, and you will need to press the Fn + combination to turn it off.
  • Page 144 Modules & Options 12. If you click the Mobile Partner close icon a message will be displayed asking you to click OK to confirm the program exit and to terminate the connection. Figure 7 - 35 Exit Prompt 13. Exiting the program terminates the connection, but DOES NOT turn off the 3.75G/ HSPA module, and you will need to press the Fn + key combination to turn off the module (pay careful attention to this aboard aircraft - see...
  • Page 145: Text Messaging Service

    Modules & Options Text Messaging Service In addition to standard internet services you may also send and receive SMS text messages using the Mobile Partner program, if your service supports SMS. Reading SMS Messages An icon will blink at the bottom of the Mobile Partner interface to notify you of any new messages received.
  • Page 146 Modules & Options 7 - 44...
  • Page 147: Overview

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
  • Page 148: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
  • Page 149: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
  • Page 150: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
  • Page 151: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 152 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...
  • Page 153: Problems And Possible Solutions

    Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power but it doesn’t Battery missing / incorrectly installed. Check the battery bay, make sure the work. battery is present and seated properly (the design of the battery only allows it to go in one way).
  • Page 154: Troubleshooting

    Troubleshooting Problem Possible Cause - Solution The computer feels too hot. Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
  • Page 155 Troubleshooting Problem Possible Cause - Solution You forget the boot password. If you forget the password, you may have to discharge the battery of the CMOS. Contact your service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
  • Page 156 Troubleshooting Problem Possible Cause - Solution Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically. However special functions/hot keys unique to the system’s regular keyboard may not work.
  • Page 157 Troubleshooting Problem Possible Cause - Solution The Wireless LAN, Bluetooth or PC The driver(s) for the module(s) have not been installed. Make sure you have Camera modules cannot be configured. installed the driver for the appropriate module (see the instructions for the appropriate module in “Modules &...
  • Page 158 Troubleshooting 8 - 12...
  • Page 159 Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
  • Page 160 Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer.
  • Page 161 Interface (Ports & Jacks) Item Description USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc. Devices can be plugged into the computer, and unplugged from the computer, without the need to turn the system off (if the power rating of your USB device is 500mA or above, make sure you use the power supply which comes with the device).
  • Page 162 Interface (Ports & Jacks) A - 4...
  • Page 163: Intel Video Driver Installation

    Appendix B: Intel Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - DVMT Notes Intel Video Driver Installation DVMT is not local video Make sure you install all the drivers in the order indicated in Table 4 - 1, on page 4 - memory.
  • Page 164: Intel Gma Driver For Mobile

    Intel GMA Driver for Mobile Advanced video configuration options are provided by the Intel(R) Graphics Me- Taskbar Icon dia Accelerator Driver for Mobile. To access the Intel(R) Graphics Media Accel- erator Driver for mobile control panel: You can also access the controller properties Click Advanced settings in the Screen Resolution control panel in Windows.
  • Page 165 You may make changes to the devices, color, schemes, Hot Keys etc. by clicking the appropriate menu item or button. Help Menus Right-click on many of the items in the tabs to bring up the “What’s This?” button. Click “What’s This?”...
  • Page 166: Scheme Options

    Scheme Options Use Scheme Options to configure quick settings for applications which require spe- cific resolution and color settings in order to run properly e.g. games, multimedia Application.exe programs. To set the scheme options: You will need to locate Go to the GMA for mobile control panel (see page the actual application executable (.exe) file, Configure your display configuration, resolution etc.
  • Page 167: Display Devices & Options

    Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT) or ex- ternal Flat Panel Display as your display device. A VGA monitor/Flat Panel Dis- Function Key Combination play connects to the external monitor port. The following display modes are available.
  • Page 168: Attaching Other Displays

    Attaching Other Displays If you prefer to use a monitor or flat panel display, connect it to the external monitor Multiple Display port on the left of the computer. At least one other dis- To Enable Intel(R) Dual Display Clone Mode play must be attached in Attach your external display to the external monitor port, and turn it on.
  • Page 169 To Enable Extended Desktop Mode: Attach your external display to the external monitor port, and turn it on. Go to the Intel(R) GMA Driver for mobile control panel and click Display Display Settings Devices. Extended Desktop Click to choose Extended Desktop (Operating Mode). Click Apply, and OK to confirm the settings change.
  • Page 170: Attaching Other Displays

    Attaching Other Displays Configuring an External Display in Windows 7 Function Key Attach your external display to the external monitor port and turn it on. Combination Go to the Screen resolution control panel. Click the Detect button. You can use the Fn + The computer will then detect any attached displays.
  • Page 171 You can configure the displays from the Multiple Displays menu. Figure B - 7 Screen Resolution Multiple Display Options (Win 7) • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) • Extend these displays - Treats both connected displays as separate devices •...
  • Page 172 Using the Windows Logo Key + P Key Combination to Switch Displays You can also use the + P key combination to quickly change display configura- tion and modes (this is particularly useful when attaching a projector) in Windows 7. Attach your external display to the external monitor port and turn it on.
  • Page 173 Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, delayed or updated due to the manufacturer's release schedule. Check with your service center for details.
  • Page 174: Processor

    Specifications Processor Video Adapter Audio Intel® Atom® Processor N450 Intel NM10 Integrated Video High Definition Audio Compliant Interface 1.67 GHz, 512KB On-die L2 Cache & Compliant with Microsoft UAA (Universal Supports DirectX 9.0 667MHz FSB, 5.5W - BGA Package, Audio Architecture) Shared Memory Architecture 45nm (45 Nanometer) Process Direct Sound 3D™...
  • Page 175: Operating System

    Specifications Communication Slot Environmental Spec 10Mb/100Mb Base-T Ethernet LAN Two Mini-Card Slots (USB & PCIe) Temperature ° ° Slot 1: for Wireless LAN Module (Half Mini- Operating: C - 35 802.11b/g/n Wireless LAN Half Mini-Card Card) with PCIe Interface Non-Operating: -20°C - 60°C Module (Factory Option) Slot 2: for 3.75G/HSPA Module with USB Relative Humidity...
  • Page 176 Specifications C - 4...

Table of Contents
