  • Page 3: Trademarks

    Preface N otice The company reserves the right to revise this publication or to change its contents without notice. Infor- mation contained herein is for reference only and does not constitute a commitment on the part of the man- ufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be dam- aged.
  • Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 8: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply. If you are unsure of your local power specifi- Power Safety cations, consult your service representative or local power company.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the com- puter. • Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode. • Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service personnel.

  • Page 10: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 11: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshoot- ing, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 14 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

  • Page 15: Table Of Contents

    Preface Contents Notice ................I LCD Panel ............1-7 Trademarks ............I LED Power & Communication Indicators ... 1-7 FCC Statement ...........II Stereo Speakers ............ 1-7 Close Cover Switch ..........1-8 Instructions for Care and Operation ....IV LED Status Indicators ........... 1-8 Power Safety .............
  • Page 16 Preface 2 * USB 2.0/1.1 Ports ..........1-15 LED Power & Communication Indicators .... 2-6 PC Card Slot ............1-15 Check Mail Program ..........2-7 Right Side View .............1-16 Hard Disk Drive ............. 2-10 USB 2.0/1.1 Port ..........1-16 CD/DVD Device ............ 2-11 Serial Port ............1-16 Loading Discs ............
  • Page 17 Preface Overview ..............3-1 Battery Life ............3-24 Advanced Video Controls ........3-2 Battery FAQ ............3-25 Opening the LCD ...........3-2 Drivers & Utilities Video Driver Controls ..........3-3 Making Adjustments for the Display .....3-4 Overview ..............4-1 Display Devices ............3-8 What to Install ............4-1 Switching/Enabling Displays (Keyboard) ....3-8 Module Driver Installation ........
  • Page 18 Preface Check Mail (Win2000) ........4-11 Working with the Pull-Down Menu ......5-6 PC Camera (Win2000) ........4-12 Working with Sub-Menus ........5-7 Windows XP ............4-13 Startup Menu ............5-8 Chipset (WinXP) ..........4-14 Fast Boot (Startup Menu) ........5-8 Audio (WinXP) ...........4-14 Boot Device (Startup Menu) ........
  • Page 19 Preface Exit Menu ...............5-16 Driver Installation (WinXP) ......... 7-5 Save and Exit (Exit Menu) ........5-16 802.11b/g Wireless LAN Exit (No Save) - (Exit Menu) .........5-17 Driver Installation (Win2000) ......7-7 Default Settings (Exit Menu) .........5-17 802.11b/g Wireless LAN Restore Settings (Exit Menu) .........5-17 Driver Installation (WinXP) .........
  • Page 20 Preface Display ..............8-9 Power Management ..........B-4 Boot Password ............8-10 Power ................B-5 Audio & CD Device ..........8-11 Buttons ..............B-5 Keyboard ..............8-12 Environmental Spec..........B-5 Operation ..............8-13 Physical Dimensions & Weight........B-5 Modules ..............8-14 Optional ..............B-5 Advanced Power Saving Power Schemes & Processor Performance .....A-2 Intel CPU SpeedStep Controls ........A-3 Specifications Processor Types............

  • Page 21: Introduction

    Introduction Chapter 1: Introduction Overview Notes Check the light colored This manual refers to the hardware and essential software required to run your boxes with the mark computer. Depending on how your system is configured, some or all of the above to find detailed features described may already be set up.

  • Page 22: Warning Boxes

    Introduction Warning Boxes No matter what your level please pay careful attention to the warning and safe- ty information indicated by the symbol. Also please note the safety and handling instructions as indicated in the Preface . Not Included Operating Systems (e.g. Windows 2000 Professional, Windows XP etc.) have their own manuals, as do applications (e.g.

  • Page 23: Quick Start Guide

    Introduction Quick Start Guide This guide assumes that you are already familiar with computers and can tell at a glance what and where all the key components are. If you are not that com- Peripheral Devices fortable with this type of device, then please refer to the following pages, Please note that pe- which give an overview of the system.

  • Page 24: System Map

    Introduction System Map Your computer has a lot of built-in features. Most of these are enabled by your operating system. Further explanations of the various subsystems are covered in the chapter or pages indicated. Getting to Know Your Computer The following graphics will help you to become familiar with the basic func- tions, and to learn the location of the various ports and components of your computer.

  • Page 25: Top View

    Introduction Top View Figure 1 - 1 Top View with LCD Panel Closed LCD Latches LED Power & Communication Indicators To open the LCD display: Place the computer on a stable surface. Move the LCD latches in the direction of the arrows to release the top cover (the left latch will lock in position and is clearly marked with locked unlocked icons).

  • Page 26: Top View With Lcd Panel Open

    Introduction Top View with LCD Panel Open Figure 1 - 2 Top View with LCD Panel Open Optional Built-In PC Camera LED Power & Communication Indicators Speakers Close Cover Switch LED Status Indicators Power Button Keyboard Built-In Microphone 10. TouchPad and Buttons 11.

  • Page 27: Pc Camera

    Introduction PC Camera If you have purchased the optional PC Camera, make sure you install the soft- ware application (see “PC Camera” on page 7 - 16). The Module ON/OFF Button will enable/disable the PC Camera (see “Module ON/OFF Button” on page 1 - 12).

  • Page 28: Close Cover Switch

    Introduction Close Cover Switch This switch acts as a sensor to tell when the LCD Panel is closed. When this LCD cover sensor is activated the default setting of your operating system’s power scheme sends the computer into a power saving state (see Figure 3 - 16 on page 3 - 23).

  • Page 29: Keyboard

    Introduction Keyboard The computer has a “Win Key” keyboard including a numeric keypad. It has the same features as a full-sized desktop keyboard and can easily be replaced with a different language keyboard should you desire. Microphone Record on your computer with the built-in microphone. TouchPad &...

  • Page 30: Front View

    Introduction Front View Figure 1 - 3 Front View LCD Latches Mini-IEEE 1394 port 4 5 6 4-in-1 Card Reader S/PDIF Out Port Microphone-In Jack Inserting Cards Headphone-Out Jack When inserting digital storage cards Hot-Key Buttons make sure that the readable side of the card is facing upwards, as indicated by 4 5 6 the icon on the card reader (illustrated...

  • Page 31: 4-In-1 Card Reader

    Introduction 4-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards (SD/ MS/MS PRO/MMC). Push the card into the slot and it will appear as a remov- able device. Card Reader Cover Make sure you keep the cover in the card reader when not is use. This will help pre- vent foreign objects and/or dust getting in to the card reader.

  • Page 32: Hot-Key Buttons

    Introduction Hot-Key Buttons The three hot-keys allow you instant access to your default Internet browser and default e-mail program, and to toggle the power on/off to the Wireless LAN/Bluetooth/PC Camera modules (see below). To learn how to set the but- tons, see “Hot-Key Buttons”...

  • Page 33: Left Side View

    Introduction Left Side View Figure 1 - 4 Left Side View Vent External Monitor (VGA) Port S-Video Out Port RJ-11 Phone Jack RJ-45 LAN Jack Vent 2 * USB 2.0 Ports Infrared Transceiver This enables airflow to prevent the computer from overheating. PC Card Slot PC Card Eject Button...

  • Page 34: S-Video-Out Port

    Introduction S-Video-Out Port Connect your television to your computer and view DVDs, VCDs or anything else your computer can display. You will need an S-Video cable to make the connection. Enable this port from the video driver controls. RJ-11 Phone Jack This port connects to the built-in modem.

  • Page 35: Usb 2.0/1.1 Ports

    Introduction 2 * USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high- speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.

  • Page 36: Right Side View

    Introduction Right Side View Figure 1 - 5 Right Side View USB 2.0/1.1 Port Serial Port Optical Device Bay DC-In Jack USB 2.0/1.1 Port These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high- speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.

  • Page 37: Optical Device Bay

    Introduction Optical Device Bay The optical device bay will contain a 5.25" (12.7mm height) CD/DVD type device. The actual device will depend on your purchase option (see “Storage” on page B - 3 for options). For more information on using the drive please refer to “CD/DVD Device”...

  • Page 38: Rear View

    Introduction Rear View Figure 1 - 6 Rear View Security Lock Slot Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store. 1 - 18 Rear View...

  • Page 39: Bottom View

    Introduction Bottom View Figure 1 - 7 Bottom View Vent/Fan Intake Battery RAM Bay Cover Hard Disk, WLAN The CPU is not a user & Bluetooth serviceable part. Module Bay Cover Opening this compart- ment, or accessing the CD Device Screw CPU in any way, may Cover violate your warranty.

  • Page 40: Hard Disk Drive

    Introduction Hard Disk Drive 6 - 4 The internal hard disk drive is used to store your data. See page for in- formation on upgrading/replacing your hard disk drive. Wireless LAN & Bluetooth Modules The optional Wireless Bluetooth modules (and the op- Drive Warning tional Camera...

  • Page 41: Using The Computer

    Using The Computer Chapter 2: Using The Computer Overview To learn more about using your computer, please read this chapter. This chapter includes: • The Power Sources • Turning on the Computer • The LED Indicators • The Check Mail Program •...

  • Page 42: The Power Sources

    Using The Computer The Power Sources The computer can be powered by either an AC adapter or a battery pack. Power Button as Standby or Hibernate AC Adapter Button Use only the AC adapter that comes with your computer. The wrong type of If you are using a fully AC adapter will damage the computer and its components.

  • Page 43: Battery

    Using The Computer Battery The battery allows you to use your computer while you are on the road or when an electrical outlet is unavailable. Battery life varies depending on the Low Battery Warning applications and the configuration you're using. To increase battery life, let the When the battery is battery discharge completely before recharging.

  • Page 44: Turning On The Computer

    Using The Computer Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the power button on the front panel. Shutdown Note that you should When the computer is on, you can use the power button as a Standby/Hiber- always shut your com- nate/Shutdown hot-key button when it is pressed for less than 4 seconds puter down by choos-...

  • Page 45: Led Indicators

    Using The Computer LED Indicators There are two sets of LED indicators (LED Power & Communication Indi- cators and LED Status Indicators) on your computer that will display help- ful information about the current status of the computer. The LED Power & Communication Indicators are also visible when the top of your computer is closed.

  • Page 46: Led Power & Communication Indicators

    Using The Computer LED Power & Communication Indicators Table 2 - 2 Icon Color Description LED Power & Communication Orange DC power is plugged in Indicators Green The computer is on Blinking Green The computer is in standby mode Orange The battery is being charged Green The battery is fully charged...

  • Page 47: Check Mail Program

    Using The Computer Check Mail Program After you have installed the driver for the Check Mail program (see “What to Install” on page 4 - 1) you may then configure it to give notification when new mail is received. You must be online to receive this notification (note that this program only supports the POP3 protocol), and your default mail pro- gram does not need to be open.
  • Page 48 Using The Computer Clicking on Check Mail will bring up the following options menu. Note Check with your Inter- net Service Provider, network administrator or Mail Service provid- er for details on what to put on these pages. Figure 2 - 2 You may then configure the options for your mail server, user name, and pass- word.
  • Page 49 Using The Computer Figure 2 - 3 Check Mail Enabled You may also enable an audible warning for received mail by clicking on Set Mail Wave, and browsing to a .WAV sound file to use for mail notification. Click Enable play wave for mail arrival, and SAVE to save the settings. Figure 2 - 4 Set Mail Wave Check Mail Program 2 - 9...

  • Page 50: Hard Disk Drive

    Using The Computer Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be taken out to accommodate other 2.5" IDE hard disk drives with a height Power Safety of 9.5 mm. Before attempting to access any of the inter- The hard disk...

  • Page 51: Cd/Dvd Device

    Using The Computer CD/DVD Device There is a bay for a 5.25" CD/DVD device (12.7mm height). The actual device Sound Volume will depend on the model you purchased (see “Storage” on page B - 3). The Adjustment CD Device is usually labeled “Drive D:” and may be used as a boot device if properly set in the BIOS (see “Startup Menu”...

  • Page 52: Handling Cds Or Dvds

    Using The Computer Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/ CD Emergency Eject DVDs can be accessed. If you need to manually Remember to: eject a CD (e.g.

  • Page 53: Dvd Regional Codes

    Using The Computer DVD Regional Codes DVD region detection is device dependent, not OS-dependent. You can select your module’s region code 5 times. The fifth selection is permanent. This can- not be altered even if you change your operating system or you use the module in another computer.

  • Page 54: Changing Dvd Regional Codes

    Using The Computer Changing DVD Regional Codes Go to the Control Panel in WindowsXP/Windows 2000 and double-click Sys- tem > Hardware (tab), click Device Manager, then click the + next to DVD/ CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties menu, and select the DVD Region (tab) to bring up the control panel as seen in “DVD Regional Codes (Windows XP)”...

  • Page 55: Pc Card Slot

    Using The Computer PC Card Slot The computer is equipped with a PCMCIA 3.3V/5V slot for one type II PC Card. Make sure you install the driver for the PC Card (see “What to Install” on page 4 - Inserting and Removing PC Cards •...

  • Page 56: Hot-Key Buttons

    Using The Computer Hot-Key Buttons These keys access the Internet and e-mail, and enable you to toggle power on/ off to the optional module(s) (WLAN/Bluetooth/PC Camera) with one quick button press. Make sure you install the Hot-Key driver. Refer to “What to In- stall”...

  • Page 57: Function Keys And Numeric Keypad

    Using The Computer Function Keys and Numeric Keypad Function Keys Other Keyboards On the bottom-left of the keyboard is the Fn key or Function key. The Fn key If your keyboard is allows you to change operational features instantly. To use the functions press damaged or you just and hold the Fn key, then press the appropriate function key (F5 - F12 etc.) want...

  • Page 58: Numeric Keypad

    Using The Computer Numeric Keypad The keyboard has an embedded numerical keypad for easy numeric data input. The numeric keys are highlighted by a yellow typeface. Special Characters Activate the Number Lock feature by pressing the Num Lock key at the top Some software appli- right of the keyboard.

  • Page 59: Touchpad And Buttons/Mouse

    Using The Computer TouchPad and Buttons/Mouse The TouchPad is a device for pointing (controlling input positioning) on the computer’s display screen by sensing finger movement, and downward pres- Mouse Driver sure. It is an alternative to the mouse; however, you can also add a mouse to If you are using an ex- your computer through one of the USB ports.

  • Page 60: Configuring The Touchpad And Buttons

    Using The Computer Configuring the TouchPad and Buttons Once you have installed the TouchPad drivers (see “What to Install” on page 4 - 1) you can configure the functions by double-clicking the TouchPad driver icon on the taskbar. You may then configure the TouchPad tapping, buttons, scrolling, pointer motion and sensitivity options to your preferences.

  • Page 61: Adding A Printer

    Using The Computer Adding a Printer The most commonly used peripheral is a printer. The following conventions will help you to add a printer, however it is always best to refer to the printer manual for specific instructions and configuration options. USB Printer Most new printers have a USB interface connection.

  • Page 62: Parallel Printer

    Using The Computer Parallel Printer This is still the most common type of printer. A Parallel to USB converter may be purchased at most computer stores (see “Left Side View” on page 1 - 13/“Right Side View” on page 1 - 16 for USB 2.0 port information).

  • Page 63: Advanced Controls

    Advanced Controls Chapter 3: Advanced Controls Overview This chapter covers: Drivers • Advanced Video Controls • Power and Battery Management Features You are unable to use most advanced con- trols until the neces- sary drivers utilities are properly in- stalled. If your system hasn’t been properly configured (your ser- vice...

  • Page 64: Advanced Video Controls

    Advanced Controls Advanced Video Controls This section is about making adjustments for the LCD, and switching display devices. You can switch display devices with the Fn + Display (F6) toggle. Protecting the LCD Do not allow any for- Opening the LCD eign objects (i.e.

  • Page 65: Video Driver Controls

    Advanced Controls Video Driver Controls The video interface lets you change the screen resolution and color output to whatever is most comfortable/efficient for you. This is a matter of hardware, Screenshots video memory and the driver for your operating system. The driver interface All screenshots in this shows the available options.

  • Page 66: Making Adjustments For The Display

    Advanced Controls Making Adjustments for the Display The higher the resolution you set the LCD for, the more information the LCD can display on screen. To change the LCD’s resolution and color depth go to Screen Resolution/ the Display Properties control panel: Area Note Click Start, point to Settings and click Control Panel (or just click Control You may set the reso-...
  • Page 67 Advanced Controls Figure 3 - 3 Advanced Display Properties ATI Mobility Radeon 9700 Series Properites You can also access ATI Mobility Radeon 9700 Series Proper- ties by right-clicking the ATI icon in the Open the Display Properties control panel, and click the Advanced (button) taskbar.
  • Page 68 Advanced Controls Figure 3 - 4 ATI Mobility Radeon 9700 Properties Option Tabs Help Menu Help Menus Right-click on almost any item in the tabs to bring up the “What’s This?” button. Click “What’s This?” button to bring up the help menu. 3 - 6 Video Driver Controls...
  • Page 69 Advanced Controls Access the menus from ATI taskbar to get further help on display options, TV options etc. Right-click the ATI icon in the taskbar and point to Help or Troubleshooting (Figure 3 - 5). You can also switch between the displays and go to the ATI Mobility Radeon 9700 Series Properties.

  • Page 70: Display Devices

    Advanced Controls Display Devices Figure 3 - 6 Left Side View Besides the built-in LCD, you can also use an external VGA monitor or TV as your display device. A VGA monitor connects to the external monitor (VGA) port a TV to the S-Video Out port (Figure 3 - Using the Driver to Switch Displays...

  • Page 71: Display Devices & Options

    Advanced Controls Display Devices & Options Besides the built-in LCD, you can also use an external monitor connected to the VGA port as your display device. You may also connect a TV. The fol- TV Support lowing are the display options: You cannot set your flat panel display and The built-in LCD.

  • Page 72: Attaching A Monitor

    Advanced Controls Attaching a Monitor If you prefer to use a monitor, connect it to the external monitor (VGA) port on the left side of the computer (see Figure 3 - 6). You can use the Fn + F6 Function Key keys to toggle through the display options.

  • Page 73: Enabling Other Displays

    Advanced Controls Enabling Other Displays Other displays are enabled from Display in the ATI Mobility Radeon 9700 Series Properties Window (see Figure 3 - 8 Primary & Clone Displays Attach your external monitor to the external monitor (VGA) port (or TV to the S-Video connector), and turn it on.

  • Page 74: Clone Mode

    Advanced Controls Clone Mode Clone Mode simply shows an exact copy of the Primary display desktop on the other display(s). This mode will drive multiple displays with the same con- Display Data Channel tent. Use this feature to display the screen through a projector for a presenta- Information tion.

  • Page 75: Extended Desktop Mode

    Advanced Controls Extended Desktop Mode The system supports Extended Desktop (the LCD and a monitor showing dif- ferent views) in multiple display environments in Windows XP, but this mode is NOT supported in Windows 2000 . An Extended Desktop creates a desktop spanning multiple displays and acts as a large workspace.
  • Page 76 Advanced Controls 11. In the example shown in Figure 3 - 10 the primary monitor is on the left, the other display is on the right. Click either the Display pop- up menu, or click the icon for the appropriate display. Figure 3 - 10 Then click the tick box to ex- Extended Desktop...
  • Page 77 Advanced Controls 13. One display will be set to 1 (Primary), and the other to 2 (Clone). The displays may be switched as long as one as set to Primary. Figure 3 - 11 Displays Tab (Extended Desktop Mode) 14. To switch from Extended Desktop mode back to Clone mode, first uncheck the tick box to disable the Extended Desktop (via the settings tab in the Display Properties control panel) and click Apply (see “Extended Desktop...

  • Page 78: Enabling Tv Display

    Advanced Controls Enabling TV Display To display desktop images on a TV display, connect the TV to your computer by using an S-Video cable from the TV to the S-Video Out port on the com- TV Format puter (see Figure 3 - 6)).

  • Page 79: Power Management Features

    Advanced Controls Power Management Features To conserve power, especially when using the battery, your computer uses the ACPI power management system. Power management conserves power by OS Note controlling individual components of the computer (the monitor and hard disk Power management drive) or the whole system.

  • Page 80: Enabling Power Options

    Advanced Controls Enabling Power Options Power Options are enabled through the control panel in your Windows sys- tem (Power Options). With other operating systems you may have power management available, so check your documentation. Figure 3 - 13 Power Options Control Panel You may conserve power through individual components or throughout the whole system.

  • Page 81: Power Schemes

    Advanced Controls Power Schemes You can set your computer to conserve power through individual components by means of Power Schemes. You can also adjust the settings for each Resuming Operation scheme to set the monitor to turn off after a specified time, and the computer's The system can re- hard disk motor to turn off if the hard disk drive has not been accessed for a sume from Monitor or...
  • Page 82 Advanced Controls Each Windows Power Scheme will also adjust the processor performance of your machine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office scheme for maximum performance when the com- puter is powered from an AC power source.

  • Page 83: Conserving Power (System)

    Advanced Controls Conserving Power (System) With this function you can stop the computer’s operation and restart where you left off. This system features Standby and Hibernate sleep mode levels (Hibernate mode will need to be enabled by clicking the option in the Hiber- nate tab in the Power Options control panel - Figure 3 - 15 on page 3 - 22).

  • Page 84: Standby

    Advanced Controls Standby Standby saves the least amount of power, but takes the shortest time to return to full operation. During Standby the hard disk is turned off, and the CPU is System Resume made to idle at its slowest speed. All open applications are retained in memo- The system can resume ry.

  • Page 85: Configuring The Power Button

    Advanced Controls Configuring the Power Button The power button may be set to send the computer in to either Standby or Hi- bernate mode. In Standby mode, the LED will flash green. In Hiber- Sleep Button nate mode the LED will be off. If you are in a power saving mode set to save You may also config- power through individual components (e.g.

  • Page 86: Battery Information

    Advanced Controls Battery Information Please follow these simple guidelines to get the best use out of your battery. Caution New Battery Danger of explosion if Always completely discharge, then fully charge, a new battery (see “Battery battery is incorrectly FAQ” on page 3 - 25 for instructions on how to do this).

  • Page 87: Battery Faq

    Advanced Controls Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. Conserving Battery Power We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason see “Removing the Battery”...
  • Page 88 Advanced Controls 3 - 26...

  • Page 89: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities Overview What to Install This chapter deals with installing the drivers and The Device Drivers & Utilities + User’s Manual utilities essential to the operation or improvement CD-ROM contains the drivers and utilities neces- of some of the computer’s subsystems.
  • Page 90 Drivers & Utilities Navigate (Browse..) to D: You will notice that many of the instructions for driver installation require you to “Navigate (Browse) to D:”. We assume that you will install all drivers and utilities from the built-in CD device and it is assigned to “Drive D:”.

  • Page 91: Service Packs

    Drivers & Utilities Service Packs Check the warnings on the following pages regard- ing installation of the appropriate Service Pack for Windows 2000 Service Pack 4 your Windows OS. If you are unsure of the Service Pack currently installed see below. Make sure you Make sure that your Windows 2000 version in- have installed the appropriate Service Pack before cludes Service Pack 4 on the installation CD as this...
  • Page 92 Drivers & Utilities Windows XP Service Pack 1 Make sure you install Windows XP Service Pack 1 (or a Windows XP version which includes Service Pack 1) before installing any drivers. Service Pack 1 includes support for USB 2.0. If you have upgraded the system by installing Service Pack 1 (i.e. your Windows XP version does not include Service Pack 1) then follow these instructions: 1.If you can see the My Computer icon on your desktop (if you cannot see the My Computer icon go to step 2) click on it once to select it, then right-click it to make the sub-menu appear and scroll down to Properties and...

  • Page 93: Authorized Driver Message

    Drivers & Utilities Authorized Driver Message Updating/Reinstalling Individual Drivers If you receive a message telling you that the driver you are installing is not authorized (Digital Signa- If you wish to update/reinstall individual drivers it ture Not Found), just click Yes or Continue Any- may be necessary to uninstall the original driver.To way to ignore the message and continue the do this go to the Control Panel in the Windows OS...

  • Page 94: Driver Installation

    Drivers & Utilities Driver Installation The following chapter contains instructions for us- ing the Driver Installation application, and for Insert the Device Drivers & Utilities + User’s Man- manual installation. ual CD-ROM and the Driver Installation applica- tion will run automatically. You can double-click Driver Installation Application the driver name on the left of the screen to begin the Table 4...
  • Page 95 Drivers & Utilities Feature Windows 2000 (SP4) Windows XP (SP1) Service Pack Install the appropriate Service Pack for your system if not included in your Windows version Chipset page 4 - 8 page 4 - 14 Internet Explorer Install IE 5.5 or higher DirectX 8.1 Install DirectX 8.1 or higher (download from the Microsoft website)

  • Page 96: Windows 2000 Professional

    Drivers & Utilities Windows 2000 Professional Chipset (Win2000) This section covers driver and utility installation in- structions for Windows 2000 Professional. 1. Double-click Chipset from the Driver Installa- tion menu . OR New Hardware Found Click Start (menu) > Run ... and navigate (Browse..) to If you see the message “New Hardware Found”...

  • Page 97: Audio (Win2000)

    Drivers & Utilities Audio (Win2000) LAN (Win2000) 1. Double-click Audio from the Driver Installa- 1. Double-click Lan from the Driver Installation tion menu . menu . Click Start (menu) > Run ... and navigate Click Start (menu) > Run ... and navigate (Browse..) to D:\Drivers\Audio\Setup.exe and (Browse..) to D:\Drivers\Lan\SETUP.EXE click OK.

  • Page 98: Modem (Win2000)

    Drivers & Utilities Modem (Win2000) Hot-Key (Win2000) 1. Double-click Modem from the Driver Installa- 1. Double-click Quick-Key from the Driver tion menu . Installation menu . Click Start (menu) > Run ... and navigate Click Start (menu) > Run ... and navigate (Browse..) to D:\Driv- (Browse..) to D:\Drivers\Quick- ers\Modem\WIN2K\Setup.exe and click OK.

  • Page 99: Pc Card/Pcmcia (Win2000)

    Drivers & Utilities PC Card/PCMCIA (Win2000) Check Mail (Win2000) 1. Double-click PCMCIA_CardReader from the 1. Double-click E-MAIL LED from the Driver Driver Installation menu . Installation menu . Click Start (menu) > Run ..and navigate Click Start (menu) > Run ... and navigate (Browse..) to D:\Drivers\PCMCIA-Car- (Browse..) to D:\Drivers\E-mail dReader\setup.exe and click OK.

  • Page 100: Pc Camera (Win2000)

    Drivers & Utilities PC Camera (Win2000) See install procedure in “PC Camera Driver In- stallation (Win2000)” on page 7 - Latest PC Camera Driver Information Check the PC Camera CD, and any accompanying insert pages, for the latest updated information on the PC Camera driver, which may override the infor- mation provided here.

  • Page 101: Windows Xp

    Drivers & Utilities Windows XP This section covers driver and utility installation instructions for Windows XP (Professional & Home). Windows XP Service Pack 1/1a Make sure you install Windows XP Service Pack 1/1a (or a Windows XP version which includes Service Pack 1/1a) before installing any drivers.

  • Page 102: Chipset (Winxp)

    Drivers & Utilities Chipset (WinXP) Video (WinXP) 1. Double-click Chipset from the Driver Installa- 1. Double-click VGA from the Driver Installation tion menu . menu . Click Start (menu) > Run ... and navigate Click Start (menu) > Run ... and navigate (Browse..) to D:\Driv- (Browse..) to D:\Drivers\VGA\Setup.exe and ers\inf_update\infinst_autol.exe and click...

  • Page 103: Modem (Winxp)

    Drivers & Utilities Modem (WinXP) Hot-Key (WinXP) 1. Double-click Modem from the Driver Installa- 1. Double-click Quick-Key from the Driver tion menu . Installation menu . Click Start (menu) > Run ... and navigate Click Start (menu) > Run ... and navigate (Browse..) to D:\Driv- (Browse..) to D:\Drivers\Quick- ers\Modem\WINXP\Setup.exe and click OK.

  • Page 104: Pc Card/Pcmcia (Winxp)

    Drivers & Utilities PC Card/PCMCIA (WinXP) Check Mail (WinXP) 1. Double-click PCMCIA_CardReader from the 1. Double-click E-MAIL LED from the Driver Driver Installation menu . Installation menu . Click Start (menu) > Run ... and navigate Click Start (menu) > Run ... and navigate (Browse..) to D:\Drivers\PCMCIA-Car- (Browse..) to D:\Drivers\E-mail dReader\setup.exe and click OK.

  • Page 105: Bios Utilities

    BIOS Utilities Chapter 5: BIOS Utilities Overview Settings Warning This chapter is about the computer’s built-in software. Incorrect settings can cause your system to Your computer comes with built-in BIOS (Basic Input Output System) malfunction. To correct which is an essential set of software routines stored on a chip in your comput- mistakes return to the SCU, go to the Exit er.

  • Page 106: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to con- duct a POST, including a quick test of the on-board RAM. As the POST pro- The POST Screen ceeds, the computer will tell you if there is anything wrong.

  • Page 107: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non-fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 108: The System Configuration Utility

    BIOS Utilities The System Configuration Utility The SCU program tells the system how to configure itself and manage basic features and subsystems (e.g. port configuration and power management). The BIOS Settings V’s OS settings are stored in a nonvolatile battery and written to the CMOS RAM. Settings This means that the settings are saved even when the computer is turned off.

  • Page 109: Working With The Menu Bar

    BIOS Utilities Working with the Menu Bar You can use the mouse to navigate around the various menus and submenus of the SCU, or alternatively, you can use the following key combinations: Table 5 - 1 Keys Action SCU Menu Activates the menu bar Navigation Keys →...

  • Page 110: Working With The Pull-Down Menu

    BIOS Utilities Working with the Pull-Down Menu Once your desired menu bar item is highlighted, press Enter or left-click with the mouse to see the pull-down menu items. The following keys allow you to move about the pull-down menu: Table 5 - 2 Pull-Down Menu Keys Keys...

  • Page 111: Working With Sub-Menus

    BIOS Utilities Working with Sub-Menus Some pull-down menu options have an arrow to the right of the entry which indicates a sub-menu is available. Choose these sub-menus by pressing Enter SCU Screens and the screen will be displayed. Navigate through these screens by using the The screens which ap- keys in the table below: pear on the following...

  • Page 112: Startup Menu

    BIOS Utilities Startup Menu Insyde Software SCU For Intel chipset Jan 7, 2004 9:40:02 am Startup Disks Components Power Exit Date and Time Figure 5 - 2 Devices System √ Fast Boot Floppy Drive A = 1.44MB Startup Menu Boot Device Hard Drive C = 20005MB CPU Clock...

  • Page 113: Boot Device (Startup Menu)

    BIOS Utilities Boot Device (Startup Menu) Specify which device your computer should look on for an operating system by priority. The most common setting is to look for the diskette “A:” first, then the CD-ROM Drive (CD device), and lastly the Hard Disk “C:”. In most cas- es your computer “boots”...

  • Page 114: Display Oem Logo (Startup Menu)

    BIOS Utilities Display OEM logo (Startup Menu) Enable or disable (enabled by default) the display of the OEM logo (if appli- cable) during the POST process. Password Warning Fast Boot for Windows XP (Startup Menu) If you choose to set a Enable or disable (disabled by default) the fast system startup option if you boot password, NEV- ER forget your pass-...

  • Page 115: Disks Menu

    BIOS Utilities Disks Menu Figure 5 - 3 Insyde Software SCU For Intel chipset Jan 7, 2004 6:40:02 am Disks Menu Startup Disks Components Power Exit (IDE Settings) Devi IDE Settings System _ Virus Alert Hard ive C = 20005M IDE Settings CPU Cl ck = 100...

  • Page 116: Components Menu

    BIOS Utilities Components Menu Figure 5 - 4 Insyde Software SCU For Intel chipset Jan 7, 2004 6:40:02 am Components Menu Startup Disks Components Power Exit COM Ports Devices System LPT Port Hard Drive C = 20Keyboard Repeat √ Keyboard Numlock CPU Clock = 1400MHz Keyboard Repeat...

  • Page 117: Lpt Port

    BIOS Utilities LPT Port Configure the Printer/parallel port from this menu. Keyboard Numlock (Components Menu)] Enable this mode to start the computer up with Number Lock enabled. Keyboard Repeat (Components Menu) Change the keyboard repeat rate and key delay from this menu. Keyboard Type (Components Menu) Change the keyboard language setting here (English or Japanese).

  • Page 118: Power Menu

    BIOS Utilities Power Menu Figure 5 - 5 Insyde Software SCU For Intel chipset Jan 7, 2004 6:40:02 am Power Menu Startup Disks Components Power Exit _ Low Power Saving Devices System m _ Medium Power Saving _ High Power Saving Hard Drive C = 20057 M √...

  • Page 119: Low/Medium/High/Customize Power Saving (Power Menu)

    BIOS Utilities Low/Medium/High/Customize Power Saving (Power Menu) You may choose to set power saving options for Low, Medium or High power savings in this menu, or alternatively you may Customize the settings to CPU SpeedStep change the time until the hard disk goes in to standby. These settings apply to Controls &...

  • Page 120: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 6 Insyde Software For Intel chipset Jan 7, 2004 6:40:02 am Exit Menu Startup Disks Components Power Exit Devices System m Save and Exit Exit (No Save) Hard Drive C = 20005 MB CPU Clock = 1400MHz Default Settings...

  • Page 121: Exit (No Save) - (Exit Menu)

    BIOS Utilities Exit (No Save) - (Exit Menu) This option allows you to exit the SCU without saving any changes made. Default Settings (Exit Menu) This option allows you to reset the SCU settings to the original defaults before any changes were made to the system. Restore Settings (Exit Menu) This option will allow you to restore the SCU settings to the last changes you had made.
  • Page 122 BIOS Utilities 5 - 18...

  • Page 123: Upgrading The Computer

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps outlined to make the desired upgrades. If you have any trouble or prob- Warranty Warning lems you can contact your service representative for further help. Before you Please check with your begin you will need: service representative...

  • Page 124: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replacing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake any upgrade proce- • Your system is still under warranty or a service contract dures, make sure that •...

  • Page 125: Removing The Battery

    Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons it is best to remove the battery. Warranty Warning Battery Removal Process Please check with your service representative Turn the computer off, and turn it over. before undertaking any Locate the battery bay at point upgrade procedures to...

  • Page 126: Upgrading The Hard Disk Drive

    Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" IDE hard disk drives with a height of 9.5mm (h) (see “Storage” on page B - 3). Follow your HDD System operating system’s installation instructions, and install all necessary drivers Warning and utilities (as outlined in...

  • Page 127: Hard Disk Upgrade Process

    Upgrading The Computer Hard Disk Upgrade Process Turn off the computer, and turn it over and remove the battery. Locate the hard disk) bay cover and remove screws from the bay cover. Remove the bay cover Slide the hard disk assembly in the direction of the arrow Figure 6 - 2 HDD Cover Removal Upgrading the Hard Disk Drive 6 - 5...
  • Page 128 Upgrading The Computer Carefully lift the hard disk assembly up out off the computer. Remove screws in order to separate the cover from the hard disk Reverse the process to install a new hard disk (pay careful attention to the orientation of the disk under the cover).

  • Page 129: Upgrading The System Memory (Ram)

    Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line (SO-DIMM) - DDR 266/333 MHz - type memory modules. The main memo- ry can be expanded up to 2GB. The SO-DIMMs supported are 128MB, 256MB, 512MB and 1024MB in size, and the total memory size is automati- cally detected by the POST routine once you turn on your computer.

  • Page 130: Memory (Ram) Upgrade Process

    Upgrading The Computer Memory (RAM) Upgrade Process Turn off the computer, and turn it over and remove the battery. Locate the memory (RAM) bay cover, remove screws , and remove Contact Warning the bay cover. Gently pull the two release latches ( &...
  • Page 131 Upgrading The Computer The RAM module (see Figure 6 - 4) will pop-up, and you can remove it. Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot.

  • Page 132: Upgrading The Cd Device

    Upgrading The Computer Upgrading the CD Device Turn off the computer, and turn it over and remove the battery. Remove the screw at point Remove CD Device screw cover Apply pressure at point to push the CD Device out of the computer. Reverse the process to install the new device.

  • Page 133: Upgrading The Processor

    Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with a faster/new one you will need to contact your customer service representa- Warranty tive. We recommend that you do not do this yourself, since if it is done incor- The CPU is not a user rectly you may damage the processor or mainboard.
  • Page 134 Upgrading The Computer 6 - 12...

  • Page 135: Wireless & Pc Camera Modules

    Wireless & PC Camera Modules Chapter 7: Wireless & PC Camera Modules Overview This chapter contains the information on the optional wireless LAN, op- tional Bluetooth and optional PC Camera modules which may come with your computer, depending on the configuration purchased. If you are un- sure please contact your service representative.

  • Page 136: Intel Pro/Wireless Mini Pci Wlan Module

    Wireless & PC Camera Modules Intel PRO/Wireless Mini PCI WLAN Module Your computer may have either an Intel PRO/Wireless 2100 (802.11b) OR Wireless Device 2200BG (802.11b/g) Mini PCI WLAN module, depending on your purchase Operation Aboard option. You will have the appropriate software CD provided for your module. Aircraft The use of any porta- Before installing the Intel PRO/Wireless 2100 (802.11b) OR 2200BG...

  • Page 137: Wireless Lan Driver Installation (Win2000)

    Wireless & PC Camera Modules 802.11b Wireless LAN Driver Installation (Win2000) 1. Make sure the module is powered on, then insert the Intel PRO CD- ROM into the CD drive. 2. Click Wireless LAN Adapters (button). 3. Click Install Software (button). 4.
  • Page 138 Wireless & PC Camera Modules 1. Insert the Intel PRO CD-ROM into the CD drive. 2. Click Wireless LAN Adapters (button). 3. Click Install Administration Tools (button). 4. Click Next. Windows 2000 Internet Explorer 5.5 5. Click the button to accept the license and click Next > Next > Install > Finish.

  • Page 139: Wireless Lan

    Wireless & PC Camera Modules 802.11b Wireless LAN Driver Installation (WinXP) 1. Make sure the module is powered on, then insert the Intel PRO CD- ROM into the CD drive. 2. Click Wireless LAN Adapters (button). 3. Click Install Software (button). 4.
  • Page 140 Wireless & PC Camera Modules 1. Insert the Intel PRO CD-ROM into the CD drive. 2. Click Wireless LAN Adapters (button). 3. Click Install Administration Tools (button). 4. Click Next. 5. Click the button to accept the license and click Next > Next > Install > Finish.

  • Page 141: B/G Wireless Lan Driver Installation (Win2000)

    Wireless & PC Camera Modules 802.11b/g Wireless LAN Driver Installation (Win2000) 1. Make sure the module is powered on, then insert the Intel PRO CD- ROM into the CD drive. Windows 2000 2. Click Install Software (button). Internet Explorer 5.5 3.
  • Page 142 Wireless & PC Camera Modules You can view the User Guides by inserting the Intel PRO CD-ROM and click- ing View User Guides (button). Figure 7 - 3 View User Guides 7 - 8 Intel PRO/Wireless Mini PCI WLAN Module...

  • Page 143: B/G Wireless Lan Driver Installation (Winxp)

    Wireless & PC Camera Modules 802.11b/g Wireless LAN Driver Installation (WinXP) 1. Make sure the module is powered on, then insert the Intel PRO CD- ROM into the CD drive. 2. Click Install Software (button). 3. Click Next. 4. Click the button to accept the license and click Next > Next > Install > Finish.
  • Page 144 Wireless & PC Camera Modules 14. An Intel Configuration Service control panel will appear, and you can choose Yes to have Intel PROset software to manage the wireless adapter. 15. A list of available networks will appear (click Finish to exit the Wizard). 16.

  • Page 145: Bluetooth Module

    Wireless & PC Camera Modules Bluetooth Module Before installing the Bluetooth driver, make sure that the optional Bluetooth Wireless Device module is on (the LED will be green). Use the Module ON/OFF Button Operation Aboard (see “Module ON/OFF Button” on page 1 - 12) to toggle power to the Blue- Aircraft tooth module.

  • Page 146: Bluetooth Driver Audio Setup (Win2000)

    Wireless & PC Camera Modules Bluetooth Driver Audio Setup (Win2000) After installing the Bluetooth driver in Windows 2000 you may no longer hear any sound, nor see the Volume icon in the taskbar. If this is the case then fol- low this procedure: 1.

  • Page 147: Bluetooth Driver Installation (Winxp)

    Wireless & PC Camera Modules Bluetooth Driver Installation (WinXP) 1. Insert the Bluetooth CD-ROM into the CD drive. 2. The program will run automatically. 3. Click Install Drivers and Application Software and click Next. 4. Click the button to accept the license agreement, then click Next. 5.

  • Page 148: Bluetooth Control Panel Options

    Wireless & PC Camera Modules Bluetooth Control Panel Options You may need to change some control panel options after installing the Blue- tooth driver: Audio Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double-click the Sounds &...
  • Page 149 Wireless & PC Camera Modules FAX (Win2000) Go to the Start menu and point to Settings and click Control Panel, then double-click the Fax icon. Click Advanced Options (tab) and click the Open Fax Service Management Console (button). Click Devices in the Tree window on the left. The fax devices will be displayed in the right window, with the device with the highest priority displayed at the top.

  • Page 150: Pc Camera

    Wireless & PC Camera Modules PC Camera If your purchase includes the optional PC Camera you will need to install the device driver for it as indicated on the following pages (make sure you install Taking Still Pictures the drivers in the order indicated in Table 4 - 1 - Install Procedure’...

  • Page 151: Pc Camera Driver Installation (Win2000)

    Wireless & PC Camera Modules PC Camera Driver Installation (Win2000) 1. Insert the PC Camera CD-ROM into the drive. 2. The program will run automatically. 3. Click Next (click Yes if asked if you want to continue at any time). 4.

  • Page 152: Pc Camera Audio Setup

    Wireless & PC Camera Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. (WinXP) Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double-click the Sounds &...
  • Page 153 Wireless & PC Camera Modules Figure 7 - 5 Audio Setup (Windows XP) PC Camera 7 - 19...

  • Page 154: Amcap

    Wireless & PC Camera Modules AMCAP AMCAP is a video viewer useful for general purpose video viewing and test- ing, and can capture video files to .avi format. Pre-Allocating File Space Run the AMCAP program from the Start > Programs/All Programs > You may pre-allocate CMM PC Camera menu (it is recommended that you set the capture file the file size for the cap-...
  • Page 155 Wireless & PC Camera Modules Eliminating Screen Flicker If you find that the video screen in the AMCAP program is flickering, you can try to adjust the option from the Video Capture Filter options. Run the AMCAP program from the Start > Programs/All Programs > CMM PC Camera menu.
  • Page 156 Wireless & PC Camera Modules 7 - 22...

  • Page 157: Troubleshooting

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 158: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer appears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 159: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g.

  • Page 160: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the definitions file updates are usually downloadable directly from the internet.

  • Page 161: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 162 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 163: Power

    Troubleshooting Power Problem Possible Cause - Solution You turned on the power Battery missing / incorrectly installed. Check the battery bay, make sure the battery is but it doesn’t work. present and seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
  • Page 164 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If hot. this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...

  • Page 165: Display

    Troubleshooting Display Problem Possible Cause - Solution Nothing appears on The system is in a power saving mode. Toggle the sleep/resume key combination, Fn + screen. Esc (see “Function Keys and Numeric Keypad” on page 2 - 17). The screen controls need to be adjusted. Toggle the screen control key combinations Fn + F9/F10 (see “Advanced Video Controls”...

  • Page 166: Boot Password

    Troubleshooting Boot Password Problem Possible Cause - Solution You forget the boot If you forget the password, you may have to discharge the battery of the CMOS. Contact password. your service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.

  • Page 167: Audio & Cd Device

    Troubleshooting Audio & CD Device Problem Possible Cause - Solution The sound cannot be The volume might be set too low. Check the volume control in the Volume Control Panel heard or the volume is in the Windows taskbar, or use the key combination Fn + F11 and F12 (see “Function very low.

  • Page 168: Keyboard

    Troubleshooting Keyboard Problem Possible Cause - Solution Unwelcome numbers If the LED is lit, then Num Lock is turned ON. Check that Padlock mode is not enabled appear when typing. (see “Numeric Keypad” on page 2 - 18). Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard.

  • Page 169: Operation

    Troubleshooting Operation Problem Possible Cause - Solution The system freezes or The system’s power saving features have timed-out. Use the AC adapter, press the sleep the screen goes dark. (Fn + Esc) key combination, or press the power button if no LEDs are lit. The system never goes Power Options features are not enabled.

  • Page 170: Modules

    Troubleshooting Modules Problem Possible Cause - Solution The Wireless LAN/ The modules are off. Check the LED indicator to see if the modules are on or off (see Bluetooth/PC Camera “LED Status Indicators” on page 2 - 5). If the LED indicator is off, then press the Module modules cannot be On/Off button in order to enable the modules (see “Intel PRO/Wireless Mini PCI WLAN...

  • Page 171: Advanced Power Saving

    Appendix A: Advanced Power Saving This Appendix contains information on Power Schemes and how they affect the computer’s CPU performance, and information on Intel CPU Speed Step controls. A - 1...

  • Page 172: Power Schemes & Processor Performance

    Power Schemes & Processor Performance Windows defines four control policies (see sidebar) used with each Power Scheme (see “Power Schemes” on page 3 - 19). Windows Control Policies Constant CPU’s Power Scheme AC Power DC Power performance always runs at lowest level Home/Office Desk None Adaptive...

  • Page 173: Intel Cpu Speedstep Controls

    Intel CPU SpeedStep Controls Additional controls are available to support the Intel Pentium M processor’s Windows XP Service mobile power management features. These controls may be adjusted in the In- Pack 1 Drivers to tel CPU SpeedStep settings in the BIOS. See “BIOS Utilities”...
  • Page 174 2. If you cannot see the My Computer icon click Start (menu), then point to (don’t click just highlight it) My Computer. Right-click it to make the sub-menu appear and scroll down to Properties and click on it (go to step 3.

  • Page 175: Installing The Driver

    Installing the Driver 1. If you can see the My Computer icon on your desktop (if you cannot see the My Computer icon go to step 2) click on it once to select it, then CPU Performance with right-click it to make the sub-menu appear and scroll down to Properties SpeedStep and click on it (go to step 3).
  • Page 176 Windows XP Service Pack 1 Windows 2000 or Windows XP with Enhanced Power with Basic Service Pack 1 Management Drivers Installed SpeedStep CPU SpeedStep Control Control Settings Setting Power Power CPU Speed CPU Speed You can adjust the Source Source SpeedStep control set- tings from the BIOS 600MHz ~ Max...

  • Page 177: Specifications

    Appendix B: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly proces- sor types/speeds) may be changed or updated due to the manufacturer's release schedule. Check with your service center for details.

  • Page 178: Processor Types

    Feature Specification µ Processor Types Intel® Pentium® M Processor (478-pin) Micro- 0.13) 0.13 Micron Process Technology, FCPGA Package 1MB On-die L2 Cache & 400MHz Front Side Bus - 1.3/ 1.4/ 1.5/ 1.6/ 1.7 GHz µ 0.09) 0.09 Micron Process Technology, 2MB On-Die L2 Cache &...

  • Page 179: Storage

    Feature Specification Storage One Changeable 12.7mm (h) Optical Device (CD-ROM/ DVD-ROM/ CD-RW/ DVD-RW /Combo/ DVD-Dual etc.) One Changeable Primary 2.5" 9.5mm (h) Hard Disk Drive Supporting LBA Mode Supports Master Mode IDE, PIO Mode 4 / ATA-33/66/100 Audio AC’97 2.2 Compliant Device S/PDIF Digital Output (5.1 CH) Advanced Wavetable Synthesizer Built-In Microphone...

  • Page 180: Indicators

    Feature Specification Interface & Three USB 2.0/1.1 Ports One 4-in-1 Built-In Card Reader (SD/ MS/ Communication One Mini IEEE1394 Ports MMC) One External Monitor (VGA) Port One RJ-11 Jack (Modem) One S-Video Jack for TV Output Integrated V.90/56K MDC Modem (V.92) One Serial Port One RJ-45 Jack (Local Area Network) One Infrared Transceiver (IrDA 1.1/FIR/SIR/...

  • Page 181: Power

    Feature Specification Power Universal AC Adapter - AC-In 100~240V, 47~63Hz, DC Output 65W Easy Changeable Main Battery Smart Lithium-Ion (6 cells) Buttons email/ browser/ power/ WLAN+ Bluetooth Environmental Temperature Relative Humidity ° ° Spec Operating: C ~ 35 Operating: 20% ~ 80% Non-Operating: -20°C ~ 60°C Non-Operating:...
  • Page 182 B - 6...

Table of Contents
