- Page 1 S3009 Navigation Echo Sounder User Manual ENGLISH www.navico-commercial.com...
- Page 3 Compliance statements Regulatory compliance Navico declare under our sole responsibility that the S3009 conforms with the requirements • the requirements of level 2 devices of the Radio communications (Electromagnetic Compatibility) standard 2008 - RCM •...
-
Page 4: About This Manual
The manual will continuously be updated to match new software releases. The latest available manual version can be downloaded from the product website on: www.navico.com/commercial. Change log Part no Date Approved by 4. Jan 2018 Jarl Gaute Vartdal 988-12043-001 First version Preface | S3009 Echo Sounder User Manual... - Page 5 NMEA and NMEA 2000 are registered trademarks of the National Marine Electronics Association. ™ ™ and microSD are trademarks or registered trademarks of SD-3C, LLC in the United States, other countries or both. Preface | S3009 Echo Sounder User Manual...
-
Page 6: Table Of Contents
Contents Introduction The S3009 Navigation Echo Sounder system System components System examples The user interface Front panel and keys The main panel Softkeys The menu system On-screen keyboard 12 Basic operation Turning the system on and off Adjusting display brilliance... - Page 7 Preventive maintenance Cleaning the display unit Cleaning the media port door Checking the keys Checking the connectors Software upgrades Backing up your system data 47 Appendix Menu overview Dimensional drawings Supported data Technical specifications Contents | S3009 Echo Sounder User Manual...
-
Page 8: Introduction
System components S3009 Control unit The S3009 is a dedicated echosounder control unit with a 9-inch portrait display. The unit is fitted with a high brightness screen, suited for pilothouse installation. Transducers The system is certified with the following transducers: •... -
Page 9: The User Interface
Press once to turn the system on. When the system is running: press once to display the Brilliance pop-up. Press and hold to display the Power off pop-up. Card reader door SD card reader The user interface | S3009 Echo Sounder User Manual... -
Page 10: The Main Panel
More details about the softkey functionality are available in the separate sections describing the functions later in this manual. Softkey pop-ups If you press the Range or Gain softkey twice, their corresponding pop-up is displayed. The user interface | S3009 Echo Sounder User Manual... -
Page 11: The Menu System
Select a virtual key by using the arrow keys followed by the Enter key to confirm the selection • Complete the entry and close the dialog by selecting the Enter virtual key You remove the virtual keyboard without entering information by pressing the Exit key. The user interface | S3009 Echo Sounder User Manual... -
Page 12: Basic Operation
You can show the depth referenced to the surface, the keel or to the transducer. The depth reference is indicated in the echosounder information panel (A) as either DBS (Depth Below Surface), DBK (Depth Below Keel) or as DBT (Depth Below Transducer). Basic operation | S3009 Echo Sounder User Manual... -
Page 13: Zooming The Image
(B) is activated. The two upper softkeys (C) change to show cursor relevant options. To remove the cursor and cursor elements from the panel, press the Clear softkey or the Exit key. Basic operation | S3009 Echo Sounder User Manual... -
Page 14: Viewing The Depth History
The history bar shows the image you are currently viewing in relation to the total depth history stored. • Use the arrow keys to pan the image to show image history. To resume normal scrolling, press the Clear softkey or the Exit key. Basic operation | S3009 Echo Sounder User Manual... -
Page 15: Setting Up The Echosounder Image
In Auto mode, the gain offset can be manually fine-tuned by turning the rotary knob. The text within the control icon will then change from AUTO to A ± XX indicating that the auto setting is manually adjusted. Setting up the echosounder image | S3009 Echo Sounder User Manual... -
Page 16: Display Time
Wave action and boat wakes can cause onscreen clutter near the surface. The TVG (Time Variable Gain) option reduces surface clutter by decreasing the sensitivity of the receiver near the surface. Setting up the echosounder image | S3009 Echo Sounder User Manual... - Page 17 Ping speed controls the rate the transducer transmits the signal into the water. By default, the ping speed is set to max. It may be necessary to adjust the ping speed to limit interference. Setting up the echosounder image | S3009 Echo Sounder User Manual...
-
Page 18: Panel Setup
Change the zoom level by pressing the Zoom softkey and then turning the rotary knob. Zoom bars (A) are available from the View menu. The bars indicate the range that is magnified and displayed on the left side. Panel setup | S3009 Echo Sounder User Manual... -
Page 19: Show Or Hide The Softkey Bar
- Active gauge is indicated with a border • Press the Enter key to select preferred data • Select the finish editing option in the menu to confirm the changes and leave edit mode Panel setup | S3009 Echo Sounder User Manual... -
Page 20: Advanced Options
You can select which data files that are used by the simulator. It can be either pre-recorded data files included in your device, your own recorded log files, or files on a card inserted in the unit's card reader. Advanced options | S3009 Echo Sounder User Manual... -
Page 21: Data Logging
Exporting the log files The log file can be exported from the Files dialog to a memory card in the card reader. Data logging | S3009 Echo Sounder User Manual... -
Page 22: The Alert System
The audible alert signal is by default turned ON. You can select to disable the audible signal when service mode is active, but the audible signal will be reactivated when service mode is deactivated. The alert system | S3009 Echo Sounder User Manual... -
Page 23: The Alerts Dialog
Supply voltage <10 V (12V-15%) No time data from NMEA 2000 or NMEA 0183 position No time source sensor. Only relevant if the time setting is Auto. Shallow water Depth shallower then set limit The alert system | S3009 Echo Sounder User Manual... -
Page 24: Mounting
If the material is too thin for self- tappers, reinforce it, or mount the bracket with machine screws and large washers. Use only 304 or 316 stainless steel fasteners. Screw down the bracket. Mounting | S3009 Echo Sounder User Manual... -
Page 25: Transducers
For dimensional drawings refer to "Dimensions - TGM60-50-xxL and TGM50-200-xxL transducers" on page S5100 echosounder module For S5100 echosounder module mounting information, refer to separate installation instructions included with the module. Mounting | S3009 Echo Sounder User Manual... -
Page 26: Wiring
The positive supply wire (red) should always be connected to (+) DC with a fuse or a circuit breaker. System examples Single transducer system S3009 control unit TGM50-200-xxL or TGM60-50-xxL transducer S5100 sonar module NMEA 0183/IEC61162-1 NMEA 2000/IEC61162-3 NC isolated alarm circuit Wiring | S3009 Echo Sounder User Manual... -
Page 27: Transducer Wiring
Transducer wiring The transducers are shipped with a 20 meter long cable. An extension cable can be installed if a total length of more than 20 meters is required between the transducer and the S3009 or S5100 module. For dual transducer installations, an S5100 module has to be installed. - Page 28 Ú Note: A 2 x 2,5/2,5 mm² or a 2 x 1,5/1,5 mm² cable shall be used. S3009 transducer wiring The S3009 is equipped with a 7-pin transducer connector at the back of the unit. Not used 6 / 7 Shield...
- Page 29 For more details, refer to "Extension cable" on page 28 and "Junction details" on page 30. Echosounder 9-pin connector details Unit socket (female) Cable plug (male) Purpose Drain/Ground Starboard + Starboard - Transducer TX/RX - Transducer TX/RX + Port + Port - Temp Transducer ID Wiring | S3009 Echo Sounder User Manual...
- Page 30 Pull the provided braided shield sleeve over the joint • Seal the joint with self-vulcanizing tape • The joint is now ready to be sealed in the junction box. Refer to "Junction box assembly" on page 32 Wiring | S3009 Echo Sounder User Manual...
- Page 31 Apply self-vulcanizing tape over the cut cables and the joint • Pull the braided shield and shield wires over the joint • Pull the provided braided shield sleeve over the joint • Seal the joint with self-vulcanizing tape Wiring | S3009 Echo Sounder User Manual...
-
Page 32: Power Wiring
12.0 mm • Place the cable and joint centered in the junction • Attach the junction box lid • Secure the junction box lid with the supplied screws Power wiring Wiring | S3009 Echo Sounder User Manual... - Page 33 For S5100 echosounder module grounding and power connection, refer to separate wiring instructions included with the module. Ú Note: For transducer connection refer to "Transducer wiring" on page 27. Separate documentation included with the S5100 echosounder module shall not be used for transducer wiring. Wiring | S3009 Echo Sounder User Manual...
-
Page 34: Ethernet Wiring
Ethernet wiring Both the S3009 and S5100 are equipped with a 5-pin Ethernet connector and can be connected with a 5-pin Ethernet cable. S3009 control unit S5100 echosounder module 5-pin Ethernet cable Ethernet connector details Unit socket (female) Cable plug (male) -
Page 35: Nmea 2000 Wiring
(Listeners). The number of receivers is finite, and depends on the receiving hardware. Typically three devices is possible. NMEA 2000 wiring The NMEA 2000 data port allows the receiving and sharing of a multitude of data from various sources. Wiring | S3009 Echo Sounder User Manual... -
Page 36: External Alarm Wiring
Bridge Alert System Power connector details Unit socket (male) Cable plug (female) Purpose Color DC negative Black External alarm output (N/C isolated contact) Blue External alarm output negative return Yellow +12/24 V DC Wiring | S3009 Echo Sounder User Manual... - Page 37 External alarm Purpose Color External alarm output negative return Yellow External alarm output (N/C isolated contact) Blue Alert management system Wiring | S3009 Echo Sounder User Manual...
-
Page 38: Software Setup
Service mode does not time out, but it is deactivated when you close the Settings dialogs. System settings Use the system settings dialog to set basic settings as described below. Some settings require a reboot of the system. Software setup | S3009 Echo Sounder User Manual... -
Page 39: Echo Settings
When unselected, transducers connected to this unit cannot be shared with other units connected on the network, nor can it see other sources on the network that have this feature enabled. Software setup | S3009 Echo Sounder User Manual... - Page 40 (for example; bottom of the keel, rudder or propeller) in the water or from the transducer to the water surface. Software setup | S3009 Echo Sounder User Manual...
-
Page 41: Units Settings
Data sources provide live data to the system. The data may originate from modules internal to the unit, or external modules connected to the NMEA 2000 or via NMEA 0183 if available on the unit. Software setup | S3009 Echo Sounder User Manual... -
Page 42: Device List
0. Values around 96 upwards indicate a heavily error prone network. If these numbers go too high for a given device, it will automatically drop off the bus. Rx/Tx Messages Shows actual traffic in and out of device. Software setup | S3009 Echo Sounder User Manual... - Page 43 Specifies the baud rate for port for the devices connected to the NMEA 0183. The baud rate should be set to correspond with devices connected to the NMEA 0183 input and output. Software setup | S3009 Echo Sounder User Manual...
- Page 44 BAM - select to communicate with an external Bridge Alert Management system conforming to IEC 61924-2 • Legacy alerts - select to communicate with a legacy BAM, using ALR and ACK sentences Software setup | S3009 Echo Sounder User Manual...
-
Page 45: Maintenance
The latest software is available for download from our website: www.navico.com/ commercial. Start the update by selecting the update file from the Files menu option. The example shows the sequence when updating the S5100 with the file included in the S3009 unit. Maintenance | S3009 Echo Sounder User Manual... -
Page 46: Backing Up Your System Data
It is recommended to regularly copy your system settings files as part of your back-up routine. The files can be copied to a card inserted in the card reader. Refer to "Managing files" on page 20. Maintenance | S3009 Echo Sounder User Manual... -
Page 47: Appendix
Files ... Edit Instrument bar Softkey bar > Hide Auto hide Settings ... View Source Split Display time Palette White marker Bottom line Zoom bars Advanced Frequency Noise rejection Ping speed Record ... Appendix | S3009 Echo Sounder User Manual... - Page 48 Speed Depth Altitude Heading Temperature Volume Economy Pressure Baro pressure Network Info Device name Sources ... Device list Diagnostics Simnet groups ... Damping ... Calibration > NMEA 0183 > Simulator Simulate Files ... Appendix | S3009 Echo Sounder User Manual...
-
Page 49: Dimensional Drawings
Dimensional drawings Dimensions - S3009 Control unit 247 mm (9.72”) 100 mm (3.93”) 224 mm (8.81”) 67 mm (2.63”) 80 mm 219 mm (8.62”) (3.14”) Appendix | S3009 Echo Sounder User Manual... - Page 50 (2.36”) R 4 mm (0.16”) R 8 mm (0.31”) 40 mm (1.58”) 60 mm (2.36”) 20 mm (0.79”) ø22 mm (0.87”) ø25 mm (0.98”) 20 m (65.62’) 15 mm (0.59”) 3 mm (0.12”) Appendix | S3009 Echo Sounder User Manual...
-
Page 51: Supported Data
Dual ground/water speed AIS VHF data-link message AIS VHF data-link own vessel report Water speed and heading Distance traveled through water Course over ground and ground speed Waypoint Location Transducer measurements Time and date Appendix | S3009 Echo Sounder User Manual... - Page 52 Cross Track Error 129284 Navigation Data 129539 GNSS DOPs 129540 AIS Class B Extended Position Report 129794 AIS aids to Navigation 129801 Cross Track Error 129283 Cross Track Error 129284 Navigation Data 129539 GNSS DOPs Appendix | S3009 Echo Sounder User Manual...
- Page 53 GNSS DOPs 129540 GNSS Sats in View 130074 Route and WP Service - WP List - WP Name & Position 130306 Wind Data 130310 Environmental Parameters 130311 Environmental Parameters 130312 Temperature 130577 Direction Data Appendix | S3009 Echo Sounder User Manual...
-
Page 54: Technical Specifications
Shock and vibration According to IEC60945 ed 4.0 and RMS rules (2-020202-040-E Vol 2 Environmental Test of Equipment) Physical Dimensions See "Dimensions - S3009 Control unit" on page 49 Weight 1.95 kg (4.3 lbs) Compass Safe Distance 0.4 m (1.31 feet) Mounting type Panel or bracket mount... - Page 55 Weight 2.09 kg (4.60 lbs) Number of wires 2 x 2,5/2,5 mm Transducer Output Depth Frequency 200 kHz Beam width 11° Max depth 400 m (1 312 ft) Speed 30 knots (35 mph) Appendix | S3009 Echo Sounder User Manual...
