Varytec Easy Move XS HP Wash User Manual

7x8w rgbw, moving head
Hide thumbs Also See for Easy Move XS HP Wash:
Table of Contents

Advertisement

Quick Links

See also: User Manual
Easy Move XS HP
Wash 7x8W RGBW
moving head

Advertisement

Table of Contents
loading

Related Manuals for Varytec Easy Move XS HP Wash

Summary of Contents for Varytec Easy Move XS HP Wash

  • Page 1 Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 18.10.2017, ID: 301511...

  • Page 3: Table Of Contents

    Starting up..............................21 Connections and controls........................24 Operating..............................27 7.1 Starting the device........................... 27 7.2 Operating modes..........................28 7.3 System settings..........................30 7.4 Menu overview..........................33 7.5 Functions in 8-channel DMX mode................... 34 Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 4 Table of contents 7.6 Functions in 13-channel DMX mode..................35 Technical specifications........................39 Plug and connection assignments....................40 Troubleshooting............................41 Cleaning............................... 43 Protecting the environment......................44 Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 5: General Notes

    If you sell the unit please make sure that the buyer also receives this manual. Our products are subject to a process of continuous development. Thus, they are subject to change. Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 6: Further Information

    Our online guides provide detailed information on technical basics Online guides and terms. Personal consultation For personal consultation please contact our technical hotline. If you have any problems with the device the customer service will Service gladly assist you. Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 7: Notational Conventions

    Examples: ‘24ch’ , ‘OFF’ . 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 8 This combination of symbol and signal word indicates a pos- sible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – high-voltage. Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 9 General notes Warning signs Type of danger Warning – suspended load. Warning – danger zone. Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 10: Safety Instructions

    This device may be used only by persons with sufficient physical, sensorial, and intellectual abilities and having corresponding knowledge and experience. Other persons may use this device only if they are supervised or instructed by a person who is responsible for their safety. Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 11 Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. Do not use the device if covers, protectors or optical components are missing or damaged. Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 12 Eye damage caused by high light intensity Never look directly into the light source. WARNING! Risk of epileptic shock Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons should avoid looking at strobe lights. Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 13 The carrying capacity of the truss or other mounting must be sufficient for the intended number of devices. Note that the movement of the head may addition- ally stress the load-bearing structures. Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 14 NOTICE! Risk of fire Do not block areas of ventilation. Do not install the device near any direct heat source. Keep the device away from naked flames. Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 15 Failure to do so could result in damage to the device and possibly injure the user. Unplug the device before electrical storms occur and when it is unused for long periods of time to reduce the risk of electric shock or fire. Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 16 PVC floor and after some time cause permanent dark stains. In case of doubt, do not put the rubber feet directly on the floor, but use felt-pad floor protectors or a carpet. Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 17: Features

    Control via DMX (seven or twelve channels) as well as buttons and display on the unit Auto mode with eight preprogrammed show programmes Sound control with eight preprogrammed show programmes Master/Slave mode Strobe effect Movement resolution 8 Bit or 16 Bit Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 18: Installation

    Work from a stable platform whenever you install or move the device or when you perform any kind of maintenance. Block access under the work area. Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 19 Note that the movement of the head may addition- ally stress the load-bearing structures. NOTICE! Risk of overheating Always ensure sufficient ventilation. The ambient temperature must always be below 40 °C (104 °F). Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 20 For error-free operation make use of dedicated DMX cables and do not use ordi- nary microphone cables. Never connect the DMX input or output to audio devices such as mixers or ampli- fiers. Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 21: Starting Up

    Starting up Starting up Establish all connections as long as the unit is switched off. Use the shortest possible high- quality cables for all connections. Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 22 Always ensure that the output of the last DMX device in the daisy chain is terminated with a resistor (110 Ω, ¼ W). The flashing ‘DMX’ LED indicates an incoming DMX signal. Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 23 Connect the DMX output of the master device to the DMX input of the first slave device. Then connect the DMX output of the first slave device to the DMX input of the second slave device and so on. Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 24: Connections And Controls

    Connections and controls Connections and controls Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 25 Increases the displayed value by one. [DOWN] Decreases the displayed value by one. [ENTER] Selects an option of the respective operating mode. 3 [POWER / FUSE] IEC chassis plug for power supply with fuse holder. Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 26 Connections and controls 4 [INPUT] DMX input 5 [OUTPUT] DMX output Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 27: Operating

    (pan) and inclination (tilt), the screen displays a start message. After a few more seconds, the device operates in the last set mode. Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 28: Operating Modes

    Press [MODE/ESC] repeatedly until the display shows ‘NStS’ . Confirm with [ENTER]. The display shows ‘SrUn’ , the unit is now in sound control mode. To close the sub menu and the main menu without making changes, press [MODE/ESC] or wait for several seconds. Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 29 Mode Highest possible DMX address 8 channels 13 channels Confirm with [ENTER]. To close the sub menu and the main menu without making changes, press [MODE/ESC] or wait for several seconds. Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 30: System Settings

    ‘t.9’ , maximum inclination angle 90° ‘t.18’ , maximum inclination angle 180° Confirm with [ENTER]. To close the sub menu and the main menu without making changes, press [MODE/ESC] or wait for several seconds. Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 31 ‘t.L’ , normal tilt direction ‘rt.L’ , reversed tilt direction Confirm with [ENTER]. To close the sub menu and the main menu without making changes, press [MODE/ESC] or wait for several seconds. Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 32 Press [MODE/ESC] repeatedly until the display shows ‘rEST’ . Confirm with [ENTER] to reset the user settings. Reset to factory defaults Press [MODE/ESC] repeatedly until the display shows ‘LoAD’ . Confirm with [ENTER] to reset the unit to factory defaults. Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 33: Menu Overview

    Operating 7.4 Menu overview Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 34: Functions In 8-Channel Dmx Mode

    Intensity red (0 % to 100 %) 0…255 Intensity green (0 % to 100 %) 0…255 Intensity blue (0 % to 100 %) 0…255 Intensity white (0 % to 100 %) 0…255 Increasing rotation and inclination speed Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 35: Functions In 13-Channel Dmx Mode

    Dimmer (0 % to 100 %) 135…239 Strobe effect (0 Hz to 40 Hz) 240…255 open 0…255 Intensity red (0 % to 100 %) 0…255 Intensity green (0 % to 100 %) Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 36 Intensity white (0 % to 100 %) Basic colours 1…15 16…63 Yellow 64…79 Green 80…127 Cyan 128…143 Blue 144…175 Purple 176…191 Bright blue 192…223 White 106…119 Pink 224…237 Colour fade, increasing speed Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 37 Auto programme 3 54…67 Auto programme 4 68…82 Auto programme 5 83…97 Auto programme 6 98…112 Auto programme 7 113…127 Auto programme 8 128…142 Sound programme 1 143…157 Sound programme 2 Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 38 Channel Value Function 158…172 Sound programme 3 173…187 Sound programme 4 188…202 Sound programme 5 203…217 Sound programme 6 218…232 Sound programme 7 233…255 Sound programme 8 0…254 No function Reset Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 39: Technical Specifications

    8 or 13 channels Operating supply voltage AC 230 V 50 Hz Power consumption 75 W W × D × H 177 mm × 238 mm × 176 mm Weight 5 kg Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 40: Plug And Connection Assignments

    The unit offers a 3-pin XLR socket for DMX output and a 3-pin XLR plug for DMX input. Please refer to the drawing and table below for the pin assignment of a suitable XLR plug. Configuration Ground, shielding Signal inverted (DMX–, ‘cold signal’) Signal (DMX+, ‘hot signal’) Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 41: Troubleshooting

    Never connect the DMX input or output to audio devices such as mixers or ampli- fiers. In the following we list a few common problems that may occur during operation. We give you some suggestions for easy troubleshooting: Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 42 DMX interface circuits. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 43: Cleaning

    The fan grids of the device must be cleaned on a regular basis to remove dust and dirt. Before cleaning, switch off the device and disconnect AC-powered devices from the mains. Use a lint- free damp cloth for cleaning. Never use solvents or alcohol for cleaning. Easy Move XS HP Wash 7x8W RGBW moving head...

  • Page 44: Protecting The Environment

    Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 45 Notes Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 46 Notes Easy Move XS HP Wash 7x8W RGBW moving head...
  • Page 48 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
