Samsung ML-4600/XET Service Manual page 61

Main Parts Lists
Location No.
1 ELA-HOU-SHIELD ENGINE
2 SMPS-4500 V1
SMPS-4500 V2
3 PBA MAIN CTRL-PCL
4 ELA HOU-RX DRIVE
5 MEC-TRAY(P)
5-1 PMO-TRAY_AUTO
5-2 PMO-ADJUST_AUTO, L
5-3 PMO-ADJUST_AUTO, R
5-4 PMO-GEAR_ADJUST RACK
5-5 PMO-GEAR_PINION
5-6 PMO-ADJUST MANUAL, L
5-7 PMO-ADJUST MANUAL, R
5-8 TRAY MANUAL, PAPER
5-9 FILM MANUAL
5-10 TAPTITE-SCREW
6 MEC-COVER REAR
6-1 PMO-TRAY_LARGE
6-2 PMO-COVER REAR
7 PMO-COVER TOP
8 PMO-COVER SIDE(L)
9 PMO-COVER SIDE(R)
10 ELA HOU-COVER FRONT
11 UNIT-LSU
12 MEC-PLATE UPPER
13 IPR-PLATE_CHANNEL
14 PBA SUB-MOTOR
15 ELA HOU-FRAME LOWER
ELA HOU-FRAME LOWER
16 ELA UNIT-DEVE SET
17 CBF HARNESS-MAIN PANEL
18 CBF HARNESS-THERMISTOR
19 CBF HARNESS-MAIN_HVPS
20 CBF HARNESS-LSU
Indicate part is for electrical safety components
Samsung Electronics
Description
Exploded Views and Parts Lists
SEC. Code Q'ty
* 1
JC44-00015A 1
JC44-00016A 1
JC92-01281A 1
JC96-01755A 1
JC75-00099A 1
* 1
* 1
* 1
* 4
* 2
* 1
* 1
* 1
* 1
* 6
JC75-00094A 1
* 1
* 1
JC72-00522A 1
JC72-00523A 1
JC72-00524A 1
JC96-01758C 1
JC59-00006A 1
JC75-00111A 1
JC70-00058A 1
JC92-01273A 1
JC96-01756A 1
JC96-01757A 1
* 1
JC39-00112A 1
JC39-00045A 1
JC39-00109A 1
JC39-00043A 1
O: Service available X: Service not available
SA. : Service Available
SA Remark
X
O 110V
O 220V
O
O
O
X
X
X
X
X
X
X
X
X
X
O
X
X
O
O
O
O
O
O
O
O
O 110V
O 220V
X
O
O
O
O
5-3
