Summary of Contents for Rangemaster ELTSHDC110SG
- Page 1 ELTSHDC110SG/ Users Guide & Installation Instructions...
-
Page 2: Table Of Contents
IMPORTANT SAFETY INFORMATION YOUR APPLIANCE OPERATING INSTRUCTIONS MAINTENANCE AND CLEANING INSTALLATION INSTRUCTIONS ELECTRICAL CONNECTION INSTALLING THE CHIMNEY HOOD CONTENTS Installation Child Safety Maintenance and service Cooker Hood Controls To Operate Recirculation Extraction Metal Grease Filters Charcoal Filter Lighting Cleaning Technical Information Elecrical Requirements Electrical Connection Components... -
Page 3: Installation
IMPORTANT SAFETY INFORMATION These warnings are provided in the interests of safety. Ensure that you understand them all before installing or using this appliance. Your safety is of paramount importance. If you are unsure about the meaning of any of these warnings contact the Helpline. •... -
Page 4: Maintenance And Service
• MAINTENANCE AND SERVICE This appliance can be a hazard if the • grease filters and charcoal filters are not cleaned and replaced as recommended. • Always insist on genuine RANGEmaster spare parts. • The halogen light and cover lamp might hot. •... -
Page 5: Cooker Hood Controls
OPERATING INSTRUCTIONS The chimney hood is designed to extract unpleasant odours from the kitchen, it will not extract steam. The appliance can be installed to recirculate or extract contaminated air. COOKER HOOD CONTROLS The chimney hood functions are controlled by four push buttons located centrally on the front of the canopy. -
Page 6: To Operate
OPERATING INSTRUCTIONS TO OPERATE Select the required fan speed and light if required. To obtain the best performance when cooking it is advisable to switch the chimney hood on for a few minutes before you start cooking and leave it running for about 15 minutes after finishing. -
Page 7: Metal Grease Filters
MAINTENANCE AND CLEANING Regular maintenance and cleaning will ensure good performance and reliability, while extending the working life of the hood. Special attention should be paid to the grease filter cassettes and the charcoal filter when the hood is used in the recirculation mode. Before carrying out any mainte- nance or cleaning isolate the cooker hood from the mains supply. -
Page 8: Lighting
MAINTENANCE AND CLEANING LIGHTING The canopy is fitted with three 20W halogen spotlamps. WARNING! The halogen light and cover lamp might hot. If one of the spotlamps fails to function check that the two pins are correctly inserted into the lamp holder. To replace a spotlamp remove the two screws, which secure the lens retaining ring and glass lens as illustrated. -
Page 9: Technical Information
INSTALLATION INSTRUCTIONS It is dangerous to alter the specifications or attempt to modify this chimney hood in any way. TECHNICAL INFORMATION DIMENSIONS ELECTRICAL SUPPLY PERFORMANCE *IEC 61591 method for cooker hoods in evacuation mode - ** IEC 61591 method with free delivery - ***IEC 60704-2-13 method Note: CE Marking certifies that this appliance complies with the requirements laid down in EEC directive 89:336 (Electromagnetic compatibility) and... -
Page 10: Elecrical Requirements
ELECTRICAL CONNECTION THIS APPLIANCE MUST BE EARTHED ELECTRICAL REQUIREMENTS Any permanent electrical installation must comply with the latest I.E.E. Regulations and local Electricity Board regulations. For your own safety this should be undertaken by a qualified electrician e.g. your local Electricity Board, or a contractor who is on the roll of the National Inspection Council for Electrical Installation Contracting (NICEIC). -
Page 11: Components
The installation work must be undertaken by a qualified and competent person. RANGEMASTER Consumer Products disclaims any responsibility for damage due to incorrect installation of the chimney hood or if the hood is not installed in compliance with relevant regulations controlling this type of installation. -
Page 12: Clearance Heights
685mm (27ins) when installed above a built- in gas hob. If fitting a Rangemaster splashback, fit the splash back after the cooker is installed but before the cooker hood. Measure 328 up from the top of the thick part of the splash (dimen- sion ‘B’) for the hood fixing holes. -
Page 13: Drilling The Holes 1
INSTALLING THE CHIMNEY HOOD Drill the holes for the fixing screws using an 8mm masonry drill bit. Insert the rawl plugs and fix the brackets (2) using the 4.2 x 44.4mm screws provided. DRILLING THE HOLES 1 Draw a horizontal line through the vertical 970mm up the wall from the top of the cooking appliance, ensuring it is level with a spirit level. -
Page 14: Ducting
INSTALLING THE CHIMNEY HOOD DUCTING The hood is more effective when used in the extraction mode (ducted to the outside). When used in the extraction mode ensure the ducting spigot has been correctly fitted as illustrated. The ducting used must be ∅ ∅ ∅ ∅ ∅ 125 (5ins) or ∅... -
Page 15: Fitting The Telescopic Chimney
INSTALLING THE CHIMNEY HOOD by pressing it downwards until the two pieces meet. Connect the two recirculation extension ducting pipes P1 on to the outlets on either side of the spigot R, which push fit into position, by pressing them horzontally until the two pieces meet. - Page 16 The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
