ROTARY SURFACE CLEANER
Professional Pressure Washer Accessories
Operation Instruction and Parts List Manual
Size 21 inch / 24 inch
This manual contains:
IMPORTANT WARNINGS and INSTRUCTIONS. READ AND RETAIN FOR REFERENCE
WARNING: To reduce the risk of injury, the user must read and understand the
operators manual before using this product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
VERSION: A+SC21-SC24
Advertisement
Table of Contents
Related Manuals for Kärcher A Plus SC21
Summary of Contents for Kärcher A Plus SC21
- Page 1 ROTARY SURFACE CLEANER Professional Pressure Washer Accessories Operation Instruction and Parts List Manual Size 21 inch / 24 inch This manual contains: IMPORTANT WARNINGS and INSTRUCTIONS. READ AND RETAIN FOR REFERENCE WARNING: To reduce the risk of injury, the user must read and understand the operators manual before using this product.
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS INSTALLATION & PREPARATION INTRODUCTION CLEAN UP WITH YOUR ROTARY IMPORTANT SURFACE CLEANER SAFETY WARNINGS OPERATION FEATURES PRODUCT EXPLODED AND SPECIFICATIONS PARTS LIST 9-11 TROUBLESHOOTING INTRODUCTION Congratulations on the purchase of your new Rotary Surface Cleaner! You can be assured this Cleaner was constructed and designed with quality and performance in mind. -
Page 3: Safety Warnings
SAFETY WARNINGS HAZARD RISK OF INJECTION OR SEVERE CUTTING INJURY POTENTIAL CONSEQUENCE Serious injury or death could occur from high pressure spray penetrating the skin. - Keep clear of nozzle and spray! Never put your hand, fingers or body directly over the spray nozzle. - Page 4 HAZARD RISK OF BODILY INJURY POTENTIAL CONSEQUENCE Serious injury or death may occur from detergents contacting or penetrating the skin. - SEEK EMERGENCY MEDICAL CARE if the spray appears to have penetrated the skin! DO NOT TREAT AS A SIMPLE CUT! Be prepared to tell a physician exactly what kind of cleaning agents you were using by reading the Material Safety Data Sheet provided with your detergent.
-
Page 5: Features
FEATURES Unpack the machine and make sure that it is complete and not damaged, In case it is not complete or damaged, do not use the machine and consult your dealer. For reasons of packaging or transport, some accessory components can be supplied loose. In this case they must be assembled according to the instructions in this manual. -
Page 6: Installation & Preparation
INSTALLATION & PREPARATION NOZZLE SELECTION & INSTALLATION: 1. Your Rotary Surface Cleaner will come installed with one set of Nozzle 25020 nozzles (25 degree and 2.0 orifice). a. The minimum orifice size to be used in your Rotary Surface Spray Pattern Cleaner is half that which is being used in your pressure washer. -
Page 7: Clean Up With Your Rotary Surface Cleaner
INSTALLATION & PREPARATION Risk of Injury or damage to machine!! COMPLETE SET UP NEVER OPERATE THE UNIT IF IT BEGINS TO VIBRATE! Shutdown the unit and tighten the rotating bar, bolts and fittings. PRE-START INSPECTION PROCEDURES: 1. Inspect Rotary Surface Cleaner before each use. Tighten rotating bar, bolts and fittings as needed. -
Page 8: Operation
OPERATION The Following Contains Operating And Maintenance Instructions. Do Not Attempt To Operate This Rotary Surface Cleaner Until You Have Read And Understood All Safety Warning And Instructions Listed In This Manual. Incorrect Operation Of This Unit Can Cause Serious Injury! SAFETY ON Do Not Alter Or Modify This Equipment In Any Manner! START-UP:... -
Page 9: Product Exploded And Parts List
PRODUCT EXPLODED AND PARTS LIST Handle Assembly AVAILABLE REPAIR PARTS AND KITS Hose, A+SC21-SC24 8.753-584.0 Coupler, ¼” Plug, Female 8.707-136.0 8.750-696.0 ¼” Quick Connect KIT, SPRAY GUN, A+SC21-SC24 8.921-834.0 Screw M6X30 ¼” Quick Connect Sleeve 6. Trigger Gun KIT, HANDLE ASSEMBLY, A+SC21-SC24 8.921-835.0 Grip Upper Handle... - Page 10 PRODUCT EXPLODED AND PARTS LIST Cover Assembly KIT, HANDLE MOUNTS, A+SC21 - SC24 8.921-841.0 10. Clevis Pin 11. Clevis Ring 14. Handle Support KIT, SWIVEL CLAMP, A+SC21 - SC24 8.921-842.0 12. Clamp Ring 13. Bolt KIT, CASTER ASSEMBLY, A+SC21 - SC24 8.921-843.0 17 18 19 17.
- Page 11 PRODUCT EXPLODED AND PARTS LIST Swivel Assembly 29. Grease Nipple 30. Swivel Housing 31. O-Ring* 32. Compression Spring 33. O-Ring 34. Bolt 35. Pin 36. O-Ring* 37. Back up Ring* 38. Stem 39. Bearing Retainer, Small 40. O-Ring* 41. Bearing Retainer 42.
-
Page 12: Troubleshooting
TROUBLESHOOTING PROBLEM PROBABLE CAUSE REMEDY Inadequate cleaning power. Not enough PSI from Ensure unit produces a minimum pressure washer. 2000 PSI. Most effective cleaning range is 2500-4000 PSI. Inadequate water supply. Turn water supply completely "ON" pressure washer. Ensure unit produces a minimum of 3.0 GPM. - Page 13 ACCESSORIES ND P ARTS RRANTY ACCESSORIES AND PARTS WARRANTY LIMITED MINIMUM 90 DAY WARRANTY We warrant to the original consumer that each new part and accessory sold by Kärcher North America (KNA) will be free from manufacturing defects in materials or workmanship in normal service for the duration specified by the original component manufacturer with a 90 day minimum from date of purchase, provided it is installed properly and the equipment is maintained in accordance with KNA’S instructions and manuals.
