H.

Field Replacement Parts

Field replacement parts have a limited life and are expected to end during
a customer's specific machine operations. They should be replaced as
needed by a Service Technician. Examples of field replacement parts
may include, but are not limited to the linear scale, carriage unit, etc. To
assist in the initial parts planning, the table below lists the estimated parts
life.
Note: All replacement parts shown in the tables below are for reference
purposes only and are subject to change without notice.
Table 9 - imagePROGRAF iPF8400S Field Replacement Parts List
Carriage Unit
Purge Unit
Ink Tank Supply Unit (L)
Ink Tank Supply Unit (R)
Operation Panel Unit
Power Supply Assembly
Scale, Linear
Main Board DIMM Ass'y
Printhead (PF-05)
Fan, Mist
I.

Recommended Spare Parts

In the event of a hardware failure, the following Spare Parts are recommended to
be kept in stock by the Dealer or Authorized Service Provider for replacement
purposes.
Note: All recommended spare parts shown in the table below are for reference
purposes only and are subject to change without notice.
Table 10 - imagePROGRAF iPF8400S Spare Parts List
Carriage Unit
Purge Unit
Ink Tank Supply Unit (L)
Ink Tank Supply Unit (R)
Operation Panel Unit
Power Supply Assembly
Scale, Linear
Main Board DIMM Ass'y
Printhead (PF-05)
1
Item Numbers and Part Numbers are subject to change due to engineering changes, etc.
2
A0 Paper Size 33.1" × 46.8" (841mm × 1189mm)
imagePROGRAF iPF8400S Service Guide
Parts Name
Parts Name
imagePROGRAF iPF8400S Service Guide
1
Part Number Quantity
QM4-8199-000
1
QM3-7018-000 1
QM3-9938-000 1
QM3-9937-000 1
QM3-9934-000 1
QK1-4084-000 1
QC3-1877-000 1
QM7-7200-000 1
3872B003AA 2
QK1-1387-000
1
1
Part Number
QM4-8199-000
QM3-7018-000
QM3-9938-000
QM3-9937-000
QM3-9934-000
QK1-4084-000
QC3-1877-000
QM7-7200-000
3872B003AA
Estimated
Life
2
(A0
Sheets)
25,000
25,000
25,000
25,000
N/A
25,000
25,000
25,000
N/A
25,000
Quantity
1
1
1
1
1
1
1
1
2
September 2013
Page 14
