imagePROGRAF iPF8400S Service Guide
Figure 5- imagePROGRAF iPF8400S Installation Space Diagram (Length)
Length
Length, Approximately 91"
Refer to the "Quick Start Guide" that is packaged with the printer and the
Service Manual for complete unpacking, installation, reinstallation, and
installation space requirements.
E.

Estimated Installation Times

Estimated installation times shown are the length of time needed to
unpack and install the main unit. The estimated unpacking and installation
times are based on two experienced technicians. Canon USA
recommends that service personnel perform the installation, with four (4)
or more persons to unpack and move the printer, and two (2) or more
persons to install it.
Included in the calculation of the estimated installation time are the
following:
• Power outlet preparation
• Installation space preparation
• Unpacking and positioning the printer (main unit) on a stand or table
• Installing the Printheads, ink tanks, and connecting the power cable
• Checking the printer operation and adjusting the printing position
• Connecting the printer to a computer and installing the printer driver
and software.
imagePROGRAF iPF8400S Service Guide September 2013
Page 11
