DVD PLAYER
KV-DV50
For installation and connections, refer to the separate manual.
INSTRUCTIONS
GET0482-004A
[A]

Advertisement

Table of Contents
loading

Related Manuals for JVC KV-DV50

Summary of Contents for JVC KV-DV50

  • Page 1 DVD PLAYER KV-DV50 For installation and connections, refer to the separate manual. INSTRUCTIONS GET0482-004A...
  • Page 2 Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. IMPORTANT FOR LASER PRODUCTS 1. CLASS 1 LASER PRODUCT 2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to qualified service personnel.

  • Page 3: Table Of Contents

    WARNINGS: CONTENTS To prevent accidents and damage • TO REDUCE THE RISK OF FIRE OR ELECTRIC INTRODUCTIONS SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. Playable disc types ......4 • Avoid installing the unit in the following places.

  • Page 4: Introductions

    Playable disc types Disc type Recording format, file type, etc Playable DVD-Video (LPCM/Dolby Digital/Region Code numbers include “4”) * DVD-Video (DTS) DVD-Audio DVD-ROM/DVD-RAM DVD Recordable/Rewritable DVD-Video (LPCM/Dolby Digital) (DVD-R * /-RW, +R/+RW * DivX/MPEG-1/MPEG-2 Video • DVD-Video: UDF bridge MP3/WMA/WAV •...

  • Page 5: Operations

    Controls and features Front panel Loading slot (standby/on) button Insert disc and playback starts automatically. Turns on and off the power. Loading lamp Illumination lamp Lights : No disc in the loading slot Lights up when you turn on the power. Flashes : When loading/ejecting a disc Remote sensor Goes off : When a disc is loaded...
  • Page 6 • Also functions as / TITLE button when pressed with SHIFT button (see pages 8 and 9). MENU button * • DVD-Video/DivX6: Shows disc menu. MONITOR CONTROL • VCD: Starts PBC playback. Monitor control buttons • Used for a JVC monitor—KV-MR9010, KV-MH6510, KV-M706, or KV-M705.

  • Page 7: Basic Operations

    fi / ENTER buttons * To select a number from 0 – 9: • Makes selection/settings. • : DivX/MPEG Video: Return/advance the scenes by about 5 minutes. To select a number greater than 9: • DISC +/–: Not applicable for this unit. RETURN button * (language) / (subtitles) /...

  • Page 8: Advanced Operations (Using Rm-Rk230)

    Advanced operations (using RM-RK230) : Stop play : Pause (Frame-by-frame playback if pressed during pause.) : Start play (10-second review if pressed during play) : Reverse/forward chapter search * • Slow motion * during pause. : Press: Select chapter * Hold: Reverse/fast-forward chapter search * : Select title * : Select audio language...
  • Page 9 : Stop play : Pause (Frame-by-frame playback if Select track pressed during pause.) For VCD with PBC: : Start play : Select an item. : Reverse/forward track search * : Return to the previous menu. • Forward slow motion * during pause.
  • Page 10 Operations using the control screen (DivX/MPEG Video/MP3/WMA/WAV/CD) These operations are possible using the remote controller. Show the control screen. DivX/MPEG Video: Press during play. MP3/WMA/WAV/CD: Automatically appear during play. Ÿ Select “Folder” column or “Track” column (not applicable for CD). Select a folder or track.
  • Page 11 Operations using the list screen (DivX/MPEG Video/MP3/WMA/WAV) These operations are possible using the remote controller. Before playing, you can display the folder list/track list to confirm the contents and then start playing a track. Display the folder list while playback is stopped. Ÿ...
  • Page 12 Playback mode [On-screen bar display indication] (see pages 13 and 14) Disc type INTRO (Intro play) REPEAT (Repeat play) RANDOM (Random play) CHAPTER: Repeats the current chapter [C. RPT] TITLE: Repeats the current title [T. RPT] TRACK: Repeats the current track [T.
  • Page 13 Operations using the on-screen bar (DVD/DivX/MPEG Video/VCD) These operations are possible using the remote controller. Show the on-screen bar (see page 14). (twice) Ÿ Select an item. Make a selection. If a pop-up menu appears... • To cancel the pop-up menu, press •...
  • Page 14 On-screen bar Ex.: DVD-Video Information Operation Disc type Playback status Play • DVD-Video: Audio signal format type and Forward/reverse search channel Forward/reverse slow-motion • VCD: Playback mode * Pause DVD-Video: T. RPT: Title repeat Stop C. RPT: Chapter repeat Operation icons DivX/MPEG Video: T.

  • Page 15: Settings

    Setup menu These operations are possible using the remote controller. Enter the setup menu before or after playback. Ÿ Select a menu. Select the item you want to set up. • To cancel the pop-up menu, press ⁄ Select an option. To return to the normal screen Menu Item...
  • Page 16 Menu Item Setting MONITOR TYPE Select the monitor type for watching a wide screen picture. OSD POSITION Select the on-screen bar position on the monitor. • 1 : Higher position • 2 : Lower position (Guidance below the setup menu will disappear.) FILE TYPE Select the file type to play.

  • Page 17: References

    More about this unit Playing Recordable/Rewritable discs • The file format should be MP@ML (Main Profile at Main Level)/SP@ML (Simple Profile at Main Level)/ • This unit can recognize a total of 3 500 files and 250 MP@LL (Main Profile at Low Level). folders (a maximum of 999 files per folder).
  • Page 18 • This unit can play back files recorded in VBR (variable On-screen guide icons bit rate). During playback, the following guide icons may Files recorded in VBR have a discrepancy in the appear for a while on the monitor. elapsed time indication. Playback •...
  • Page 19 Output signals through the DIGITAL OUT terminal Output signals are different depending on the “DIGITAL AUDIO OUTPUT” setting on the setup menu (see page 16). Output Signal Playback Disc STREAM/PCM DOLBY PCM ONLY DIGITAL/PCM DVD-Video 48 kHz, 16/20/24 bits 48 kHz, 16 bits stereo Linear PCM * Linear PCM 96 kHz, Linear PCM 48 kHz, 16 bits stereo Linear PCM...
  • Page 20 Language codes Code Language Code Language Code Language Code Language Code Language Afar Persian Greenlandic Occitan Sesotho Abkhazian Finnish KM Cambodian OM (Afan) Oromo SU Sundanese Afrikaans Fiji Kannada Oriya SW Swahili AM Ameharic Faroese Korean (KOR) Panjabi Tamil Arabic Frisian Kashmiri Polish...

  • Page 21: Maintenance

    Maintenance Moisture condensation To play new discs Moisture may condense on the lens inside the unit in New discs may have some rough spots the following cases: around the inner and outer edges. If • After starting the heater in the car. such a disc is used, this unit may reject •...

  • Page 22: Troubleshooting

    Troubleshooting What appears to be trouble is not always serious. Check the following points before calling a service center. Symptom Remedy/Cause • The unit does not work at all. Reset the unit (see page 3). • Disc can neither be ejected nor Force eject the disc.
  • Page 23 Symptom Remedy/Cause • The left and right edges of the picture Select “4:3 LETTERBOX” (see page 16). are missing on the monitor. • Tracks cannot be played back. • Record the tracks using a compliant application on the appropriate discs (see page 4). •...

  • Page 24: Specifications

    Specifications AUDIO SECTION Frequency Response: DVD, fs=48 kHz/96 kHz: 16 Hz to 22 000 Hz CD, fs=44.1 kHz: 16 Hz to 20 000 Hz Dynamic Range/Signal-to-Noise Ratio: 93 dB/95 dB Wow and Flutter: Less than measurable limit Video Output: VIDEO OUT: 1 Vp-p/75 Ω...
  • Page 25 GENERAL Power Requirement: Operating Voltage: DC 14.4 V (11 V to 16 V allowance) Grounding System: Negative ground Cigarette Lighter Adapter: Rated Voltage: 12 V Amperage Rating: 0.6 A Fuse: Allowable Operating Temperature: 0°C to +40°C Dimensions (W × H × D): Installation Size (approx.): 178 mm ×...
  • Page 26 Having TROUBLE with operation? Please reset your unit Refer to page of How to reset your unit © 2007 Victor Company of Japan, Limited 0507DTSMDTJEIN...
