Bosch GCM 10 S Professional Original Instructions Manual
  1. Manuals
  2. Brands
  3. Bosch Manuals
  4. Saw
  5. GCM 10 PROFESSIONAL
  6. Original instructions manual

Bosch GCM 10 S Professional Original Instructions Manual

Hide thumbs Also See for GCM 10 S Professional:

Advertisement

Quick Links

Download this manual See also: Original Instruction Manual
OBJ_BUCH-1126-004.book Page 1 Friday, November 28, 2014 9:10 AM
Robert Bosch GmbH
Power Tools Division
70764 Leinfelden-Echterdingen
GERMANY
www.bosch-pt.com
1 609 92A 0XJ (2014.11) T / 366 EURO
40
30
GCM 10 S Professional
de Originalbetriebsanleitung
pl Instrukcja oryginalna
en Original instructions
cs Původní návod k používání
fr
Notice originale
sk Pôvodný návod na použitie
es Manual original
hu Eredeti használati utasítás
pt Manual original
ru Оригинальное руководство по
it
Istruzioni originali
эксплуатации
nl Oorspronkelijke gebruiksaanwijzing
uk Оригінальна інструкція з
da Original brugsanvisning
експлуатації
sv Bruksanvisning i original
kk Пайдалану нұсқаулығының
no Original driftsinstruks
түпнұсқасы
fi
Alkuperäiset ohjeet
ro Instrucţiuni originale
el Πρωτότυπο οδηγιών χρήσης
bg Оригинална инструкция
tr
Orijinal işletme talimatı
mk Оригинално упатство за работа
10 0
90
80
70
60
50
sr Originalno uputstvo za rad
sl
Izvirna navodila
hr Originalne upute za rad
et Algupärane kasutusjuhend
lv
Instrukcijas oriģinālvalodā
lt
Originali instrukcija
ar
fa

Advertisement

loading

Related Manuals for Bosch GCM 10 S Professional

Summary of Contents for Bosch GCM 10 S Professional

  • Page 1 OBJ_BUCH-1126-004.book Page 1 Friday, November 28, 2014 9:10 AM 10 0 Robert Bosch GmbH Power Tools Division 70764 Leinfelden-Echterdingen GCM 10 S Professional GERMANY www.bosch-pt.com 1 609 92A 0XJ (2014.11) T / 366 EURO de Originalbetriebsanleitung pl Instrukcja oryginalna sr Originalno uputstvo za rad en Original instructions cs Původní...
  • Page 2 1 7 0 1 6 0 1 5 0 1 4 0 1 3 0 1 3 0 1 2 0 1 2 0 1 1 0 1 0 0 GCM 10 S Bosch Power Tools 1 609 92A 0XJ | (27.11.14)
  • Page 3 23 0 22 0 21 0 20 0 19 0 18 0 17 0 16 0 15 0 14 0 13 0 13 0 12 0 12 0 11 0 10 0 1 609 92A 0XJ | (27.11.14) Bosch Power Tools...
  • Page 4 OBJ_BUCH-1126-004.book Page 5 Thursday, November 27, 2014 6:23 PM 1,1 Pt 1,1 Pt 1,1 Pt Bosch Power Tools 1 609 92A 0XJ | (27.11.14)
  • Page 5 OBJ_BUCH-1126-004.book Page 6 Thursday, November 27, 2014 6:23 PM 1 609 92A 0XJ | (27.11.14) Bosch Power Tools...
  • Page 6 1 6 0 1 5 0 1 4 0 1 3 0 1 3 0 1 2 0 1 2 0 1 1 0 1 1 0 1 0 0 1 0 0 Bosch Power Tools 1 609 92A 0XJ | (27.11.14)
  • Page 7 OBJ_BUCH-1126-004.book Page 8 Thursday, November 27, 2014 6:23 PM 50 51 34 2 1 609 92A 0XJ | (27.11.14) Bosch Power Tools...
  • Page 8 OBJ_BUCH-1126-004.book Page 9 Thursday, November 27, 2014 6:23 PM Bosch Power Tools 1 609 92A 0XJ | (27.11.14)
  • Page 9 This will en-  Use personal protective equipment. Always wear eye sure that the safety of the power tool is maintained. protection. Protective equipment such as dust mask, 1 609 92A 0XJ | (27.11.14) Bosch Power Tools...
  • Page 10 The severed plug must be disposed of to avoid a possible paired only through an authorised customer service shock hazard and should never be inserted into a mains agent for Bosch power tools. Replace damaged exten- socket elsewhere. sion cables. This will ensure that the safety of the power Products sold in AUS and NZ only: Use a residual current tool is maintained.
  • Page 11 *Accessories shown or described are not part of the standard de- 6 Handle livery scope of the product. A complete overview of accessories 7 Saw blade can be found in our accessories program. 1 609 92A 0XJ | (27.11.14) Bosch Power Tools...
  • Page 12 (triax vector sum) and uncertainty K determined according to EN 61029: <2.5 m/s , K=1.5 m/s Robert Bosch GmbH, Power Tools Division 70764 Leinfelden-Echterdingen, GERMANY The vibration emission level given in this information sheet has Leinfelden, 10.07.2014 been measured in accordance with a standardised test given in EN 61029 and may be used to compare one tool with another.
  • Page 13 (see figures D1–D3) Mounting to a Bosch Saw Stand  Before any work on the machine itself, pull the mains With the height-adjustable legs, Bosch GTA saw stands pro- plug. vide firm support for the power tool on any surface. The work- ...
  • Page 14 – Loosen both hex socket screws 19 with the hex key 30 provided. – Pull out the saw table extension 21 to the stop and tighten the hex socket screws again. Bosch Power Tools 1 609 92A 0XJ | (27.11.14)
  • Page 15 – Saw through the workpiece applying uniform feed. – Switch off the machine and wait until the saw blade has come to a complete stop. – Guide the tool arm slowly upward. 1 609 92A 0XJ | (27.11.14) Bosch Power Tools...
  • Page 16 ... to the right ... to the left ... to the right ... to the right piece is located ... of the cut of the cut of the cut of the cut Bosch Power Tools 1 609 92A 0XJ | (27.11.14)
  • Page 17 – Turn the saw table 17 to the 0° detent 16. The lever 14 A Bosch after-sales service station will handle this mainte- must be felt to engage in the detent. nance task quickly and reliably.

  • Page 18: Maintenance And Service

    Fax: (01) 4666888 If the replacement of the supply cord is necessary, this has to be done by Bosch or an authorized Bosch service agent in or- der to avoid a safety hazard. Bosch Power Tools 1 609 92A 0XJ | (27.11.14)
  • Page 19 OBJ_BUCH-1126-004.book Page 32 Thursday, November 27, 2014 6:23 PM 32 | English Australia, New Zealand and Pacific Islands Disposal Robert Bosch Australia Pty. Ltd. The machine, accessories and packaging should be sorted for Power Tools environmental-friendly recycling. Locked Bag 66...
