6 F 2 S 0 7 5 5
INSTRUCTION MANUAL
OPTICAL INTERFACE UNIT
(CROSS-SITE FIBRE LINK UNIT)
G1IF1
© Toshiba Energy Systems & Solutions Corporation 2017
All Rights Reserved.
( Ver. 0.7 )

Advertisement

Table of Contents
loading

Related Manuals for Toshiba G1IF1

Summary of Contents for Toshiba G1IF1

  • Page 1 6 F 2 S 0 7 5 5 INSTRUCTION MANUAL OPTICAL INTERFACE UNIT (CROSS-SITE FIBRE LINK UNIT) G1IF1 © Toshiba Energy Systems & Solutions Corporation 2017 All Rights Reserved. ( Ver. 0.7 )

  • Page 2: Safety Precautions

    Before using this product, please read this chapter carefully. This chapter describes the safety precautions recommended when using the optical interface unit type G1IF1. Before installing and using the equipment, this chapter must be thoroughly read and understood. Explanation of symbols used Signal words such as DANGER, WARNING, and two kinds of CAUTION, will be followed by important safety information that must be carefully reviewed.
  • Page 3 6 F 2 S 0 7 5 5 WARNING  Exposed terminals Do not touch the terminals of this equipment while the power is on, as the high voltage generated is dangerous.  Residual voltage Hazardous voltage can be present in the DC circuit just after switching off the DC power supply. It takes approximately 30 seconds for the voltage to discharge.

  • Page 4: Table Of Contents

    6 F 2 S 0 7 5 5 Contents Safety Precautions Introduction Application Description 3.1 General Description 3.2 Electrical Connections 3.3 Indications 3.4 Response during Communication Fail Installation 4.1 Receipt of Relays 4.2 Mounting 4.3 Electrostatic Discharge 4.4 Handling Precautions 4.5 External Connections Commissioning and Maintenance 5.1 General...

  • Page 5: Introduction

    In most situations the telecommunications equipment is remote from the protection equipment in the substation. The G1IF1 unit is normally located close to the multiplexer and may be up to 2km away from the GRL100 relay. The fibre optic cable must be either 50/125m (for distances up to 1km) or 62.5/125m (for distances up to 2km) and should be terminated with standard ST type...

  • Page 6: Description

    Code conversion is performed for connection to the CCITT-G703 or X.21 interface. G703 or X.21 is a synchronous interface, and provides a 64kHz timing signal, which the G1IF1 uses for synchronisation. The connections to the G703 or X.21 interface use balanced drivers and receivers in accordance with the G703 or RS422A/V.11 standard.

  • Page 7: Electrical Connections

    However the G1IF1 can also be provided with dc 110/125V rating or dc 220/250V rating for 110/125V or 220/250V substation battery supplies. The connections to the G1IF1-01 are shown in Figure 3.2 (a), not including the test points. The figure also illustrates the functions of three removable links. The X.21 interface circuit is designed for 500V isolation against the rest of the system.
  • Page 8 6 F 2 S 0 7 5 5 Figure 3.2 (b) shows the connections for G1IF1-02 and -03. TB1- 6 Code Conversion TB1- 7 GRL100 Relay Fibre-optic cable TB1-8 Code TB1-9 Conversion Communication equipment TB1-10 G703 1.2.3(1.2.2) TB1-11 I/F only...
  • Page 9 Common Ground (a) Signal Definitions for G1IF1-01 (X.21) Interface G1IF1-02, 03 Telecommunications Multiplexer Shield Ground Transmit Receive Signal Timing (G703 1.2.3, 1.2.2 I/F only) (b) Signal Definitions for G1IF1-02 and -03 (G703) Interface Figure 3.3 Signal Definitions  8 ...
  • Page 10 6 F 2 S 0 7 5 5 Table 3.1 Electrical Connections (a) Electrical Connections to the G1IF1-01 and -04 (X.21) Circuit Signal Signal Terminal Numbers Name Type X.21 Transmit V.11/RS422 V.11/RS422 Timing V.11/RS422 V.11/RS422 Receive V.11/RS422 V.11/RS422 Power 48V dc...

  • Page 11: Indications

    (2) When the data transmission on fibre optic interface from the relay to G1IF1 is stopped: The LED “TX from RELAY” turns off and the send signal (the voltage between terminals TB1-6 and TB1-7) becomes “0V”.

  • Page 12: Installation

    4.3 Electrostatic Discharge CAUTION The printed circuit board (PCB) within the G1IF1 is not intended to be a removable module. Do not remove the PCB from the unit case, since electronic components on the PCB are very sensitive to electrostatic discharge. If it is absolutely essential to take the PCB out of the case, do not touch the electronic components and terminals with your bare hands.

  • Page 13: External Connections

    6 F 2 S 0 7 5 5 4.5 External Connections External connections to the G1IF1 are shown in section 3.2. There are three types of connection to the unit. The fibre optic connections are made with standard ST type connectors. Transmitters are of the LED type.

  • Page 14: Commissioning And Maintenance

    6 F 2 S 0 7 5 5 5. Commissioning and Maintenance 5.1 General The G1IF1 should be commissioned in conjunction with the GRL100 relay with which it is specified. Test personnel must be familiar with general relay testing practices and safety precautions to avoid personal injuries or equipment damage.

  • Page 15: Commissioning Procedure

    Ensure that all necessary communication connections are made at each end of the protection scheme. Apply auxiliary power to both GRL100 relays and to both G1IF1 units. Any failure in communication will be indicated by the GRL100 relays. If communication is healthy then proceed with commissioning of the GRL100 relays.

  • Page 16: Appendix A Outline Of Optical Interface Unit

    6 F 2 S 0 7 5 5 Appendix A Outline of Optical Interface Unit  15 ...
  • Page 17 6 F 2 S 0 7 5 5 Dimensions and Connections 2- Φ5 ＴＢ１ ＴＯＳＨＩＢＡ Power TX from COM TX from RELAY CLK from COM 2-5×9 SPARE X.21 For G1IF1-01, and G1IF1-04 only  16 ...
  • Page 18 6 F 2 S 0 7 5 5 Outer Case Dimensions for G1IF1-01 4-Φ6 CROSS SITE FIBRE LINK UNIT  17 ...
  • Page 19 6 F 2 S 0 7 5 5 Outer Case Dimensions for G1RK7-0102 and -0103 (Option) 4-Φ6 OPTICAL INTERFACE UNIT For G1RK7-0103 only  18 ...

  • Page 20: Appendix B Technical Data

    6 F 2 S 0 7 5 5 Appendix B Technical Data  19 ...
  • Page 21 6 F 2 S 0 7 5 5 TECHNICAL DATA Ratings DC power supply: 48Vdc 110Vdc/125Vdc 220Vdc/250Vdc (Normal range: -20% to +10% of rated voltage, superimposed AC voltage  12%, break in supply duration  20ms) Burden: less than 8W Optical Interface Operative Range: <1km with 50/125m GI fibre (3dB/km)
  • Page 22 IEC60068-2-3 56 days at 40C and 93% relative humidity. Enclosure Protection IEC60529 IP50 (Dust Proof) for G1IF1 with outer case IP40 (excluding terminal parts) for G1IF1 without outer case Mechanical Environment Vibration IEC60255-21-1 Response - Class 1 Endurance - Class 1...
  • Page 23 6 F 2 S 0 7 5 5 Power Frequency IEC60255-22-7 300V 50Hz for 10s applied to PSU terminals in common mode. Disturbance Surge Immunity IEC61000-4-5, 1.2/50s surge applied to PSU terminals in common/differential modes: 2kV/1kV (peak) EN61000-4-5 Conducted and EN55022 Class A Conducted emissions: Radiated Emissions...
  • Page 24 6 F 2 S 0 7 5 5 Appendix C Ordering  23 ...
  • Page 25 For CCITT-G703-1.2.2 or 1.2.3 For X21 DC auxiliary power supply: DC 48V/54V/60V DC 110V/125V DC 220V/250V Outer Case (Option)  G1RK7 Type: Outer case for Optical interface unit G1RK7 Model: For G1IF1-02 and G1IF1-03 0102 For G1IF1-04 0103  24 ...
  • Page 26 Added the descriptions of “dc 125V” and “dc 250V” and modified Table 3.1. Sep. 22, 2004 Added the Section 3.4. Feb. 09, 2006 1 to 4 Modified the description and figures. (Added G1IF1-01.) Appendices Modified Appendix A and B, and added Appendix C. Jul. 6, 2006 Modified Table 1.
