AV8900H Dual Multimedia Headrest Replacement System
AV8900H VIDEO PRODUCTS ARE NOT INTENDED FOR VIEWING BY THE DRIVER, AND ARE TO BE
INSTALLED FOR VIEWING BY REAR-SEAT OCCUPANTS ONLY.
IMPROPER INSTALLATION COULD DISTRACT THE DRIVER OR INTERFERE WITH SAFE
OPERATION OF THE VEHICLE, WHICH COULD RESULT IN SERIOUS INJURY OR DEATH, AND
COULD ALSO VIOLATE STATE LAW. ROSEN ELECTRONICS DISCLAIMS ANY LIABILITY FOR ANY
BODILY INJURY OR PROPERTY DAMAGE THAT MAY RESULT FROM ANY IMPROPER OR
BEFORE YOU START THE INSTALLATION, READ THIS GUIDE FIRST!
Rosen "Headrest Multimedia" systems are extremely easy to install. However, we strongly recommend
1) Make sure you have the tools you will need
These common items are needed to complete this installation:
· Digital multimeter (DMM)
· Appropriate tool for headrest removal · Allen wrench set
· Panel removing tools
· Security latch tool (included)
· Wire cutters, strippers, and a crimping tool
· 1/4" drive sockets are often needed for dashboard and trim disassembly
· Check if Torx or Allen-drive bolts are used on any panels you will be removing
· You will need a DVD disc in good condition when testing the system
Standard installation parts you will need include wire, wire ties, wire crimp connectors or solder, and
electrical insulating tape. Installation of aftermarket automotive electronics also often requires access to
special parts. It is a good idea to have a source for these common installation parts.
AV8900H Installation Guide

INSTALLATION GUIDE

NOTICE OF INTENDED INSTALLATION AND USE
UNINTENDED INSTALLATION AND/OR USE.
reading this guide before starting the installation process!
· #2 Phillips screwdriver
· Cable routing tool (included)
· Retractable knife
Copyright 2015 All Rights Reserved
IG1002 Rev A
E
Page 1

Advertisement

loading

Related Manuals for Rosen AV8900H

Summary of Contents for Rosen AV8900H

  • Page 1: Installation Guide

    AV8900H Dual Multimedia Headrest Replacement System NOTICE OF INTENDED INSTALLATION AND USE AV8900H VIDEO PRODUCTS ARE NOT INTENDED FOR VIEWING BY THE DRIVER, AND ARE TO BE INSTALLED FOR VIEWING BY REAR-SEAT OCCUPANTS ONLY. IMPROPER INSTALLATION COULD DISTRACT THE DRIVER OR INTERFERE WITH SAFE OPERATION OF THE VEHICLE, WHICH COULD RESULT IN SERIOUS INJURY OR DEATH, AND COULD ALSO VIOLATE STATE LAW.
  • Page 2 Post spacing indicators are located at bottom of headrest bucket IF YOU HAVE PURCHASED A PRE-ASSEMBLED HEADREST SYSTEM, SKIP TO STEP 4 Copyright 2015 All Rights Reserved AV8900H Installation Guide IG1002 Rev A Page 2...
  • Page 3 Step 3: Route the cables through the headrest posts, being careful not to cross the cables. Step 4: Position the AV8900H electronics unit in the headrest bucket while continuously pulling the cable through the headrest posts. This step is critical to prevent damage to the cables or AV8900H unit.
  • Page 4 6) Mounting the AV8900H electronics into the headrest bucket The following steps will guide you through this process. CAUTION! Do NOT press directly on the surface of the LCD screen. This will cause permanent damage to the LCD and will not be covered under warranty.

  • Page 5: Wiring Diagram

    7) Wiring diagram 8) Installing the AV8900H headrests You will need to install the AV8900H headrests and route the cables through the seat backs. The following steps will guide you through this process. Step 1: Check the headrest down tubes in the seat backs for any obstructions.
  • Page 6 The Ground (-) should be located at a Factory Chassis ground point when possible. Step 2: Select a location to mount the interface module for the AV8900H units. Normally the interface module is best located under either the driver or passenger seat. Be sure to locate it so that it will not obstruct any moving parts of the seat or can be damaged by the feet of passengers.
  • Page 7 Solution: Ensure there are no kinks or knots in the cables. The monitor does not fit into the headrest bucket The AV8900H unit has been designed to fit tightly into the headrest bucket. This was done to ensure a high quality fit with no gaps.
