AV7500 Dual DVD Headrest Replacement System
ROSEN ENTERTAINMENT SYSTEMS VIDEO PRODUCTS ARE NOT INTENDED FOR VIEWING BY
THE DRIVER, AND ARE TO BE INSTALLED ONLY TO BE VIEWED BY REAR-SEAT OCCUPANTS.
IMPROPER INSTALLATION COULD DISTRACT THE DRIVER OR INTERFERE WITH SAFE
OPERATION OF THE VEHICLE, WHICH COULD RESULT IN SERIOUS INJURY OR DEATH, AND
COULD ALSO VIOLATE STATE LAW. ROSEN ENTERTAINMENT SYSTEMS DISCLAIMS ANY
LIABILITY FOR ANY BODILY INJURY OR PROPERTY DAMAGE THAT MAY RESULT FROM ANY
IMPROPER OR UNINTENDED INSTALLATION AND/OR USE.
BEFORE YOU START THE INSTALLATION, READ THIS GUIDE!
Rosen "Headrest DVD" systems are the easiest-to-install DVD entertainment systems available today.
However, we strongly recommend reading this guide before starting the installation!
1 Make sure you have the tools you will need
These common items are needed to complete this installation:
· Digital multimeter (DMM)
· Appropriate tool for headrest removal · Allen wrench set
· Panel removing tools
· Security latch tool (included)
· Wire cutters, strippers, and a crimping tool
· 1/4" drive sockets are often needed for dashboard and trim disassembly
· Check if Torx or Allen-drive bolts are used on any panels you will be removing
· You will need a DVD in good condition when testing the system
Standard installation parts you will need include wire, wire ties, wire crimp connectors or solder, and
electrical insulating tape. Installation of aftermarket automotive electronics also often requires access to
special parts. It is a good idea to have a source for these common installation parts.
2 Inspect the vehicle and plan your work
CHECK THE BATTERY
Test the battery voltage to make sure it's fully charged and inspect battery terminals for tightness and any
corrosion. This only takes seconds and can save hours of troubleshooting later.
DECIDE ON A LOCATION FOR THE INTERFACE UNIT
Location of the interface unit varies by vehicle, but is typically secured underneath a driver or passenger
seat out of sight and unobstructed by moving parts and passengers.
Rosen Entertainment Systems
AV7500 Installation Guide

INSTALLATION GUIDE

NOTICE OF INTENDED INSTALLATION AND USE
For additional technical tips, please visit
www.Rosendealercentral.com
· #2 Phillips screwdriver
· Cable routing tool (included)
· Retractable knife
Copyright 2007 all rights reserved
AP1024 Rev A
Page 1
E
k

Advertisement

loading

Related Manuals for Rosen AV7500

Summary of Contents for Rosen AV7500

  • Page 1: Installation Guide

    IMPROPER OR UNINTENDED INSTALLATION AND/OR USE. BEFORE YOU START THE INSTALLATION, READ THIS GUIDE! Rosen “Headrest DVD” systems are the easiest-to-install DVD entertainment systems available today. However, we strongly recommend reading this guide before starting the installation! For additional technical tips, please visit www.Rosendealercentral.com...
  • Page 2 You will need to route the cables through the headrest posts. The following steps will guide you through this process. Step 1: Place the AV7500 electronics system above the headrest bucket as shown in figure 1. Step 2: Position the cables on each side of the headrest Fig.
  • Page 3 5 Mounting the AV7500 electronics into the headrest bucket You will need to mount the AV7500 electronics unit into the headrest bucket. The following steps will guide you through this process. CAUTION! Do NOT press directly on the surface of the LCD. This will cause permanent damage to the LCD which will not be covered by warranty.

  • Page 4: Wiring Diagram

    Step 2: If a locking device is present, press and hold the lock release, and pull firmly upward on the headrest. If no locking device is visibly present refer to the vehicle’s owners manual or the vehicle’s manufacturer for further instructions. Rosen Entertainment Systems Copyright 2007 all rights reserved AV7500 Installation Guide AP1024 Rev A Page 4...
  • Page 5 7 Installing the AV7500 headrests You will need to install the AV7500 headrests and route the cables through the seat backs. The following steps will guide you through this process. Step 1: Check the headrest down tubes in the seat backs for any obstructions.
  • Page 6 The Ground (-) should be located at a Factory Chassis ground point when possible. Step 2: Select a location to mount the junction box for the AV7500 unit. Normally the junction box is best located under either the driver or passenger seat. Be sure to locate it so that it will not obstruct any moving parts in the seat or damaged by the feet of passengers.

  • Page 7: Specifications

    : (1) 5” (12cm) DVD-VIDEO Disc (2) Compact Disc (CD-DA/CD-R/CD-RW/MP3) Operating Temperature : 0C to +60C Note: Specifications and designs are subject to modification without notice. Rosen Entertainment Systems Copyright 2007 all rights reserved AV7500 Installation Guide AP1024 Rev A Page 7...
  • Page 8 Solution: Use a cable pulling lubricant. The monitor does not fit into the headrest bucket The AV7500 unit has been designed to fit tightly into the headrest bucket. This was done to ensure a high quality fit with no gaps.
  • Page 9 Solution: Re-route the wire harnesses to avoid passing over other harnesses or near electrical motors. Solution: Try relocating the ground point to factory ground point or factory ground wire. Solution: In some cases, inline audio filters may be required. Contact Rosen for support on selection of a filter. Missing Channel B Audio System includes a monitor A and monitor B.
